| 27 |
I8-98103 434-0 |
|
BRACKET; AXLE CASE |
1 |
1704- |
|
B |
(B) |
| 9 |
I8-94407 724-A |
|
BEARING; AXLE SHAFT,INNER |
2 |
1704- |
|
B |
(IADG) (B) |
| 95 |
I8-97103 392-A |
|
BEARING; AXLE SHAFT,FRT |
1 |
1704- |
|
B |
(IADG) |
| 7 |
I8-98036 560-0 |
|
SEAL; DUST,DRIVE SHAFT |
2 |
1704- |
|
B |
|
| 43 |
I0-04740 300-0 |
|
HOSE; RUBBER,AIR BREATHER |
1 |
1704- |
|
B |
08.962 (A) L=250 SERVICED BY L=3000 |
| 9 |
I8-97101 878-0 |
|
BEARING; AXLE SHAFT,INNER |
1 |
1704- |
|
B |
(A) |
| 222 |
I8-94462 734-0 |
|
GASKET; FILLER PLUG |
1 |
1704- |
|
B |
05.400 ID=20 OD=30 |
| 19 |
I0-28650 616-0 |
|
BOLT; FRT AXLE |
2 |
1704- |
|
B |
02 .343 (G) M6X16 FLANGE |
| 19 |
I8-97947 581-0 |
|
BOLT; FRT AXLE |
2 |
1704- |
|
B |
(F) M8X95 W/SP WASHER |
| 36 |
I8-97364 319-0 |
|
BUSHING; RUBBER,FRT AXLE MTG |
1 |
1704- |
|
B |
|
| 69 |
I8-97188 174-1 |
|
SHAFT; AXLE,FRT INNER |
1 |
1704- |
|
B |
|
| 37 |
I8-98166 418-4 |
|
BREATHER; FRT AXLE CASE |
1 |
1704- |
|
B |
(B) |
| 48 |
I8-98009 333-0 |
|
PLUG; DRAIN,AXLE CASE |
1 |
1704- |
|
B |
(B) M2 0X10.5 |
| 186 |
I8-94107 652-0 |
|
CLIP; HOSE,BREATHER |
1 |
1704- |
|
B |
02.587 (A) L=172 |
| 184 |
I8-98177 663-0 |
|
HOSE; BREATHER |
1 |
1704- |
|
B |
(B) |
| 28 |
I8-98270 578-0 |
|
BOLT; BRKT TO AXLE CASE |
8 |
1704- |
|
B |
M12X22 FLANGE |
| 50 |
I8-97084 507-0 |
|
SEAL; OIL,SHAFT,FRT AXLE |
1 |
1704- |
|
B |
|
| 62 |
I9-09180 040-0 |
|
RING; SNAP,AXLE SHAFT |
1 |
1704- |
|
B |
08 . 934 (A) ID=37.0 |
| 10 |
I8-97373 555-0 |
|
SEAL; OIL,AXLE SHAFT,INNER |
2 |
1704- |
|
B |
|
| 11 |
I8-98147 681-1 |
|
JOINT ASM; OUTSIDE,FRT DRIVE SHA |
2 |
1704- |
|
B |
|
| 79 |
I0-28061 230-0 |
|
BOLT; BRKT |
1 |
1704- |
|
B |
07.425 (A) M12X3 0 FLANGE |
| 19 |
I8-97947 579-0 |
|
BOLT; FRT AXLE |
3 |
1704- |
|
B |
(D) M8X28.5 W/SP WASHER |
| 183 |
I8-98125 294-1 |
|
PIPE; BREATHER |
1 |
1704- |
|
B |
(A) |
| 36 |
I8-97364 323-0 |
|
BUSHING; RUBBER,FRT AXLE MTG |
1 |
1704- |
|
B |
|
| 19 |
I0-28051 230-0 |
|
BOLT; FRT AXLE |
4 |
1704- |
|
B |
09 . 003 (C) M12X3 0 FLANGE |
| 62 |
I9-09180 162-0 |
|
RING; SNAP,AXLE SHAFT |
1 |
1704- |
|
B |
01 . 105 (B) ID=57.9 |
| 34 |
I8-97259 306-0 |
|
BOLT; FRT AXLE MTG |
2 |
1704- |
|
B |
M14X8 5 FLANGE |
| 30 |
I0-91180 214-0 |
|
NUT; FRT AXLE MTG |
1 |
1704- |
|
B |
00.429 M14 FLANGE |
| 233 |
I8-94226 943-0 |
|
BREATHER; AIR,OIL TANK |
1 |
1704- |
|
B |
|
| 79 |
I0-28061 240-0 |
|
BOLT; BRKT |
1 |
1704- |
|
B |
(B) M12X4 0 FLANGE |
| 223 |
I8-98103 437-0 |
|
BRACKET; HSG |
1 |
1704- |
|
B |
|
| 224 |
I8-94107 652-0 |
|
CLIP; HARNESS |
1 |
1704- |
|
B |
02.587 (B) L=172 |
| 18 |
I8-98084 280-8 |
|
CASE; FRT AXLE |
1 |
1704- |
|
B |
(A) |
| 13 |
I8-98147 678-1 |
|
BOOT KIT; OUTSIDE,FRT DRIVE SHAF |
2 |
1704- |
|
B |
|
| 2 |
I8-98147 676-0 |
|
BAND; "A",FRT DRIVE SHAFT |
2 |
1704- |
|
B |
|
| 19 |
I8-97947 580-0 |
|
BOLT; FRT AXLE |
5 |
1704- |
|
B |
(E) M8X40 W/SP WASHER |
| 137 |
I8-98140 853-1 |
|
ACTUATOR; AXLE |
1 |
1704- |
|
B |
|
| 35 |
I8-98008 020-0 |
|
WASHER; FRT AXLE MTG |
2 |
1704- |
|
B |
ID=14.2 OD=50 |
| 23 |
I0-91110 508-0 |
|
NUT; FRT AXLE |
2 |
1704- |
|
B |
02 .334 M8 |
| 3 |
I8-97349 959-1 |
|
BAND; "B",FRT DRIVE SHAFT |
2 |
1704- |
|
B |
|
| 1 |
I8-98147 245-2 |
|
SHAFT ASM; FRT DRIVE |
2 |
1704- |
|
B |
|
| 12 |
I8-98147 680-2 |
|
JOINT ASM |
2 |
1704- |
|
B |
|
| 26 |
I0-91510 808-0 |
|
WASHER; LK,CASE,FRT AXLE |
2 |
1704- |
|
B |
02 . 559 ID=8.2 |
| 45 |
I5-09709 108-0 |
|
CLIP |
1 |
1704- |
|
B |
02.726 OD=14 HOLE ID=6 |
| 231 |
I8-98165 859-2 |
|
BRACKET; CATCH TANK,OIL |
1 |
1704- |
|
B |
|
| 183 |
I8-98177 662-1 |
|
PIPE; BREATHER |
1 |
1704- |
|
B |
(B) |
| 4 |
I8-97222 152-1 |
|
BAND; "C",FRT DRIVE SHAFT |
4 |
1704- |
|
B |
|
| 184 |
I0-04750 300-0 |
|
HOSE; BREATHER |
1 |
1704- |
|
B |
08.962 (C) L=190 SERVICED BY L=3000 |
| 9 |
I8-94407 724-A |
|
BEARING; AXLE SHAFT,INNER |
2 |
1704- |
|
B |
(IADG) (B) |
| 95 |
I8-97103 392-A |
|
BEARING; AXLE SHAFT,FRT |
1 |
1704- |
|
B |
(IADG) |
| 44 |
I8-94368 493-0 |
|
CLIP; AIR BREATHER HOSE |
1 |
1704- |
|
B |
16.716 L=12 9 . 5 |
| 24 |
I0-40210 825-0 |
|
STUD; CASE,FRT AXLE |
2 |
1704- |
|
B |
03 .275 M8X25 L=41 |
| 138 |
I8-97134 857-1 |
|
GEAR; CLUTCH |
1 |
1704- |
|
B |
Z=17 |
| 234 |
I8-94270 377-1 |
|
FINISHER; BRKT |
2 |
1704- |
|
B |
03.885 L=22 SERVICED BY L=50 |
| 224 |
I8-97811 150-1 |
|
CLIP; HARNESS |
2 |
1704- |
|
B |
02 . 559 (A) L=150 |
| 166 |
I8-98125 310-3 |
|
BRACKET; CLIP |
1 |
1704- |
|
B |
|
| 27 |
I8-98103 425-0 |
|
BRACKET; AXLE CASE |
1 |
1704- |
|
B |
(A) |
| 99 |
I8-94107 652-0 |
|
CLIP; RUBBER HOSE |
1 |
1704- |
|
B |
02.587 L=172 |
| 48 |
I8-97307 060-0 |
|
PLUG; DRAIN,AXLE CASE |
1 |
1704- |
|
B |
05 . 508 (A) M16X12.5 |
| 5 |
I8-97131 402-0 |
|
RING; RET,FRT DRIVE SHAFT |
2 |
1704- |
|
B |
|
| 14 |
I8-98147 677-1 |
|
BOOT KIT; IN SIDE,FRT DRIVE SHAF |
2 |
1704- |
|
B |
|
| 168 |
I8-97130 567-1 |
|
SLEEVE; FRT AXLE |
1 |
1704- |
|
B |
6008 |
| 186 |
I8-97173 307-0 |
|
CLIP; HOSE,BREATHER |
1 |
1704- |
|
B |
02 . 559 (B) L=155 |
| 43 |
I0-04950 300-0 |
|
HOSE; RUBBER,AIR BREATHER |
1 |
1704- |
|
B |
(B) L=12 0 SERVICED BY L=3000 |
| 232 |
I0-28650 616-0 |
|
BOLT; TANK TO BRKT |
2 |
1704- |
|
B |
02 .343 M6X16 FLANGE |
| 221 |
I8-98009 333-0 |
|
PLUG; FILLER |
1 |
1704- |
|
B |
05.400 M2 0X10.5 |
| 19 |
I0-28650 825-0 |
|
BOLT; FRT AXLE |
1 |
1704- |
|
B |
06 .216 (B) M8X2 5 FLANGE |
| 17 |
I9-09180 030-0 |
|
RING; SNAP,DRIVE SHAFT TO TRANS |
4 |
1704- |
|
B |
04 .416 ID=2 7.9 |
| 184 |
I8-98234 652-1 |
|
HOSE; BREATHER |
1 |
1704- |
|
B |
(A) |
| 84 |
I8-94462 734-0 |
|
GASKET; PLUG,OIL FILLER |
1 |
1704- |
|
B |
05.400 ID=20 OD=30 |
| 49 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
1704- |
|
B |
01.252 ID=16.2 OD=24 |
| 37 |
I8-94226 943-0 |
|
BREATHER; FRT AXLE CASE |
2 |
1704- |
|
B |
(A) |
| 18 |
I8-98084 292-3 |
|
CASE; FRT AXLE |
1 |
1704- |
|
B |
(B) |
| 19 |
I0-28650 840-0 |
|
BOLT; FRT AXLE |
3 |
1704- |
|
B |
00.685 (A) M8X4 0 FLANGE |
