| 406 |
I5-09605 005-0 |
|
PLUG; CRANKCASE |
2 |
0211- |
|
4HG1 |
PT 3/8 ( NKR 71 ) |
| 8 |
I8-97941 068-0 |
|
BOLT; BRG CAP |
10 |
0702- |
|
4JB1-TC |
NHR55 EURO 2 |
| 128 |
I9-08150 816-0 |
|
PIN; STRAIGHT, OIL SEAL RET |
2 |
9312- |
|
4BE1 |
OD = 8; L=16 ( NKR 58 ) |
| 136 |
I8-94105 115-1 |
|
BUSHING; DRIVE SHAFT, OIL PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 60 |
I9-09661 005-0 |
|
BOLT; OIL JET |
1 |
9312- |
|
4JB1 |
M 16 X 8 PLUG ( NHR 55 ) |
| 89 |
I9-11129 128-0 |
|
CUP; SEALING, OIL GALLERY |
3 |
0211- |
|
4HG1 |
NKR 71, OD=20, EURO 2 |
| 120 |
I8-94140 427-1 |
|
BUSHING; MTG RUBBER, CYL HD COVER |
4 |
9312- |
|
4HF1 |
NKR 66 |
| 1 |
I8-98204 534-0 |
|
BLOCK ASM; CYL |
1 |
0702- |
|
4HG1-T |
NKR71 EURO2 |
| 2 |
I5-87813 194-3 |
|
LINER SET; ENG CYL |
4 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 132 |
I8-97329 618-0 |
|
VALVE; CHECK, OIL |
4 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2 |
| 17 |
I8-97176 230-0 |
|
SWITCH; OIL PRESSURE |
1 |
9712- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 54 |
I8-94133 974-2 |
|
STUD; OIL PAN TO BLOCK |
10 |
0702- |
|
4JB1-TC |
M 10 X 52 ( NHR/NKR55 E2 ) |
| 119 |
I0-50640 825-0 |
|
BOLT; COVER |
4 |
0702- |
|
4JB1-TC |
(B) M 8 X 22 ( NKR 55 E2 ) |
| 34 |
I8-94393 077-1 |
|
VALVE; OIL RELIEF |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 351 |
I1-09630 083-0 |
|
GASKET; COCK, WATERDRAIN |
1 |
0702- |
|
4HG1-T |
ID=10.2 ( NKR71 EURO 2 ) |
| 23 |
I1-09600 012-2 |
|
CUP; SEALING, C/BL FRT & RR |
2 |
9312- |
|
4JB1 |
(D) OD = 32 ( NHR 55 ) |
| 23 |
I5-11219 008-0 |
|
CUP; SEALING, C/BL FRT & RR |
3 |
9312- |
|
4JB1 |
(A) OD = 18 ( NHR 55 ) |
| 24 |
I8-94107 560-0 |
|
NIPPLE; OIL FEED, VAC PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 56 |
I8-98370 780-0 |
|
JET; OIL, PISTON COOLING |
4 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2 |
| 117 |
I8-97204 191-1 |
|
COVER ASM; C/BL |
1 |
0702- |
|
4JB1-TC |
RH, NHR/NKR55 EURO 2 |
| 25 |
I9-11693 035-1 |
|
METAL; CM/SHF |
2 |
9312- |
|
4BE1 |
CENTER & REAR ( NKR 58 ) |
| 25 |
I8-97378 147-0 |
|
METAL; CM/SHF |
2 |
9312-9506 |
|
4JB1 |
CENTER & REAR ( NHR 55 ) |
| 21 |
I5-11219 018-0 |
|
CUP; SEALING, RR |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 14 |
I9-11229 058-1 |
|
DOWEL; TIMING GEAR CASE TO C/BL |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 211 |
I8-94399 553-2 |
|
BOLT; CRANKCASE |
17 |
9312- |
|
4HF1 |
(B) M 1 0 X82 ( NKR 66 ) |
| 117 |
I8-97118 347-0 |
|
COVER ASM; C/BL |
1 |
9409- |
|
4HF1 |
NKR 66 |
| 115 |
I8-97204 193-0 |
|
RUBBER; SPACE RH |
1 |
0702- |
RH |
4JB1-TC |
NHR/NKR55 EURO 2 |
| 51 |
I8-94336 292-0 |
|
GASKET: OIL PRESS WARNING SW. C/B |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 138 |
I5-09744 015-2 |
|
NIPPLE; OIL RETURN, VAC PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 335 |
I8-97018 606-0 |
|
PLUG; C/BL, SIDE |
3 |
0702- |
|
4HG1-T |
M14X16.5 ( NKR71 EURO 2 ) |
| 89 |
I9-11129 128-0 |
|
CUP; SEALING, OIL GALLERY |
3 |
9312-9907 |
|
4HF1 |
NKR 66, OD=20 |
| 40 |
I8-94344 462-0 |
|
CUP; SEALING, C/BL RR |
1 |
9312- |
|
4BE1 |
OD = 67 ( NKR 58 ) |
| 97 |
I8-97209 609-0 |
|
CUP; SEALING |
7 |
0303- |
|
4JB1 |
NHR 55 |
| 8 |
I8-97941 068-0 |
|
BOLT; BRG CAP |
10 |
9312- |
|
4JB1 |
M 14 X 89 ( NHR 55 ) |
| 13 |
I8-94399 688-1 |
|
DOWEL; C/BL TO HD |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2 |
| 149 |
I0-91510 508-0 |
|
WASHER; LK, |
1 |
9312- |
|
4BE1 |
ID=8 ( NKR 58, NKR 71 ) |
| 7 |
I8-97352 537-0 |
|
PLUG; WATER DRAIN |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 40 |
I8-94250 514-1 |
|
CUP; SEALING, C/BL RR |
1 |
9312- |
|
4JB1 |
OD = 56 ( NHR55 ) |
| 119 |
I0-50541 020-0 |
|
BOLT; COVER |
4 |
0702- |
|
4JB1-TC |
(D) M 8 X 20 ( NKR 55 E2 ) |
| 406 |
I5-09605 005-0 |
|
PLUG; CRANKCASE |
2 |
0702- |
|
4HG1-T |
PT 3/8 ( NKR 71 ) EURO2 |
| 23 |
I1-09600 016-1 |
|
CUP; SEALING, C/BL FRT & RR |
1 |
0702- |
|
4HG1-T |
(A) OD= 25 ( NKR71 EURO 2) |
| 155 |
I8-97249 325-0 |
|
PLUG; OIL GALLERY END |
1 |
0001- |
|
4HF1 |
NKR 66, NKR 66-2 |
| 4 |
I8-97176 685-0 |
|
LINER; C/BL |
4 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 13 |
I8-94453 344-0 |
|
DOWEL; C/BL TO HD |
2 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 13 |
I8-94399 688-1 |
|
DOWEL; C/BL TO HD |
2 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 120 |
I8-94140 427-1 |
|
BUSHING; MTG RUBBER, CYL HD COVER |
4 |
0702- |
|
4JB1-TC |
NHR/NKR55 E2 |
| 2 |
I5-87813 161-1 |
|
LINER SET; ENG CYL |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 212 |
I8-94483 674-0 |
|
PIN; CRANKCASE |
2 |
9312-9604 |
|
4HF1 |
L=22 (NKR 66, NKR 66-2 ) |
| 51 |
I8-94336 292-0 |
|
GASKET: OIL PRESS WARNING SW. C/B |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 21 |
I5-11219 017-0 |
|
CUP; SEALING, RR |
1 |
0702- |
|
4JB1-TC |
(A) NHR55/NKR55 EURO 2 |
| 2 |
I5-87816 321-0 |
|
LINER SET; ENG CYL |
4 |
0211-0504 |
|
4HG1 |
GRADE = 1X ( NKR 71 ) |
| 2 |
I5-87816 322-0 |
|
LINER SET; ENG CYL |
4 |
0211- |
|
4HG1 |
GRADE = 3X ( NKR 71 ) |
| 4 |
I6-98014 048-0 |
|
LINER; C/BL |
4 |
0211- |
|
4HG1 |
(IADG) GRADE = 1X ( NKR 71 ) |
| 351 |
I1-09630 083-0 |
|
GASKET; COCK, WATERDRAIN |
1 |
0211- |
|
4HG1 |
ID=10.2 ( NKR66,66-2,71 ) |
| 17 |
I8-97072 947-0 |
|
SWITCH; OIL PRESSURE |
1 |
9312- |
|
4BE1 |
NKR58 |
| 4 |
I8-98014 049-1 |
|
LINER; C/BL |
4 |
0211- |
|
4HG1 |
GRADE = 3X ( NKR 71 ) |
| 53 |
I9-09806 020-0 |
|
BOLT; REAMER |
1 |
0702- |
|
4JB1-TC |
M 10 X 52 ( NHR/NKR55 E2 ) |
| 70 |
I8-97096 824-0 |
|
CUP; SEALING, FRT & RR |
4 |
0702- |
|
4HG1-T |
OD=40 |
| 50 |
I9-08161 032-0 |
|
PIN; STRAIGHT, RR PLATE |
1 |
0702- |
|
4JB1-TC |
OD = 10 ( NHR/NKR55 E2 ) |
| 4 |
I8-98014 048-1 |
|
LINER; C/BL |
4 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 131 |
I5-09605 005-0 |
|
PLUG; TAPER, C/BL |
1 |
0702- |
|
4HG1-T |
PT 3/8 |
| 4 |
I6-98014 048-0 |
|
LINER; C/BL |
4 |
0702- |
|
4HG1-T |
(IADG) NKR71 EURO 2 |
| 4 |
I8-97176 728-1 |
|
LINER; C/BL |
4 |
9312- |
|
4HF1 |
NKR 66 |
| 24 |
I8-94443 670-1 |
|
NIPPLE; OIL FEED, VAC PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 119 |
I0-28050 810-0 |
|
BOLT; COVER |
4 |
0702- |
|
4JB1-TC |
(C) M 8 X 10 ( NKR 55 E2 ) |
| 4 |
I8-98014 048-1 |
|
LINER; C/BL |
4 |
0211- |
|
4HG1 |
GRADE = 1X ( NKR 71 ) |
| 131 |
I5-09605 005-0 |
|
PLUG; TAPER, C/BL |
1 |
9312- |
|
4BE1 |
PT 3/8 ( NKR 58 ) |
| 1 |
I8-97163 853-7 |
|
BLOCK ASM; CYL |
1 |
0107- |
|
4HF1-2 |
NKR 66-2 |
| 7 |
I9-09861 010-0 |
|
PLUG; WATER DRAIN |
1 |
9312-0207 |
|
4HF1 |
NKR 66 |
| 212 |
I8-97135 423-0 |
|
PIN; CRANKCASE |
2 |
0211- |
|
4HG1 |
L=20 ( NKR 71 ) |
| 52 |
I8-94167 750-2 |
|
NIPPLE; OIL PRESS WARNING SW, C/B |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 61 |
I8-94483 674-0 |
|
PIN; STRAIGHT |
4 |
0211- |
|
4HG1 |
L=22 |
| 25 |
I8-97378 147-0 |
|
METAL; CM/SHF |
6 |
0702- |
|
4JB1-TC |
CENTER & REAR ( NHR/NKR55 ) |
| 61 |
I8-94483 674-0 |
|
PIN; STRAIGHT |
4 |
0702- |
|
4HG1-T |
L=22 |
| 25 |
I8-97378 147-0 |
|
METAL; CM/SHF |
2 |
9312-9506 |
|
4JB1 |
CENTER & REAR ( NHR 55 ) |
| 15 |
I8-97369 552-1 |
|
PLUG; OIL GALLERY |
2 |
0702- |
|
4JB1-TC |
(A) PT 1/8 L=8 ( NHR55 E2 ) |
| 117 |
I8-97118 347-0 |
|
COVER ASM; C/BL |
1 |
9312-9408 |
|
4HF1 |
NKR 66 |
| 4 |
I8-98014 049-1 |
|
LINER; C/BL |
4 |
0211- |
|
4HG1 |
GRADE = 3X ( NKR 71 ) |
| 15 |
I8-97369 552-1 |
|
PLUG; OIL GALLERY |
2 |
9312- |
|
4JB1 |
(A) PT 1/8 L=8 ( NHR 55 ) |
| 23 |
I1-09600 016-1 |
|
CUP; SEALING, C/BL FRT & RR |
1 |
0211- |
|
4HG1 |
(A) OD = 25 ( NKR 71) |
| 53 |
I8-94200 831-2 |
|
BOLT; REAMER |
1 |
9312-9403 |
|
4JB1 |
M 10 X 60 ( NHR 55 ) |
| 1 |
I8-97017 152-1 |
|
BLOCK ASM; CYL |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 4 |
I6-97176 728-0 |
|
LINER; C/BL |
4 |
9312- |
|
4HF1 |
(IADG) NKR 66 |
| 8 |
I1-09000 469-2 |
|
BOLT; BRG CAP |
10 |
9312- |
|
4BE1 |
M 16 X 119 ( NKR 58 ) |
| 211 |
I8-97077 638-0 |
|
BOLT; CRANKCASE |
10 |
0211- |
|
4HG1 |
(A) M 14 X 115 ( NKR 71 ) |
| 151 |
I0-91110 508-0 |
|
NUT; HD COVER, OUTER |
1 |
9312- |
|
4BE1 |
M 8 ( NKR 58, NKR 71 ) |
| 40 |
I8-94250 514-1 |
|
CUP; SEALING, C/BL RR |
1 |
0702- |
|
4JB1-TC |
OD = 56 ( NHR/NKR55 E2 ) |
| 151 |
I0-91110 508-0 |
|
NUT; HD COVER, OUTER |
1 |
9312- |
|
4BE1 |
M 8 ( NKR 58, NKR 71 ) |
| 97 |
I8-97209 609-0 |
|
CUP; SEALING |
3 |
0211- |
|
4HG1 |
(B) NKR 71, OD = 22, E2 |
| 155 |
I8-97249 325-0 |
|
PLUG; OIL GALLERY END |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 70 |
I8-97096 824-0 |
|
CUP; SEALING, FRT & RR |
4 |
0211- |
|
4HG1 |
OD=40 |
| 351 |
I9-09571 410-0 |
|
GASKET; COCK, WATERDRAIN |
1 |
0702- |
|
4JB1-TC |
ID=10.2;OD=16.0, ( NKR55 E2 ) |
| 80 |
I1-09600 012-2 |
|
CUP; SEALING, CYL HEAD |
2 |
9312- |
|
4BE1 |
OD = 32 ( NKR 58 ) |
| 17 |
I8-97072 947-0 |
|
SWITCH; OIL PRESSURE |
1 |
9312- |
|
4JB1 |
NHR55 |
| 135 |
I8-94254 920-0 |
|
COVER; OIL PUMP HOLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 7 |
I9-09664 001-0 |
|
PLUG; WATER DRAIN |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97352 707-2 |
|
BLOCK ASM; CYL |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO2 |
| 61 |
I8-97135 423-0 |
|
PIN; STRAIGHT |
1 |
0211- |
|
4JB1-TC |
OD=10 L=20 |
| 63 |
I8-94419 436-2 |
|
DUCT; WATER C/BL |
1 |
0211- |
|
4JB1-TC |
|
| 24 |
I8-94443 670-1 |
|
NIPPLE; OIL FEED, VAC PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 15 |
I8-94152 613-A |
|
PLUG; OIL GALLERY |
1 |
9312- |
|
4JB1 |
(B) M 14 X 14 ( NHR 55 ) |
| 21 |
I5-11219 017-0 |
|
CUP; SEALING, RR |
1 |
9312- |
|
4JB1 |
(A) NHR 55 |
| 70 |
I8-97096 824-0 |
|
CUP; SEALING, FRT & RR |
4 |
9312- |
|
4HF1 |
OD=40 |
| 15 |
I8-94152 613-A |
|
PLUG; OIL GALLERY |
1 |
9312- |
|
4JB1 |
(B) M 14 X 14 ( NHR 55 ) |
| 7 |
I9-09664 001-0 |
|
PLUG; WATER DRAIN |
1 |
0702- |
|
4JB1-TC |
NHR55 EURO 2 |
| 139 |
I9-09571 614-0 |
|
GASKET; NIPPLE, VAC PUMP OIL RETURN |
1 |
9312- |
|
4BE1 |
ID=14.2; OD = 20.0 |
| 17 |
I8-97072 947-0 |
|
SWITCH; OIL PRESSURE |
1 |
9312- |
|
4HF1 |
NKR66 |
| 2 |
I5-87813 333-2 |
|
LINER SET; ENG CYL |
4 |
9312-9510 |
|
4HF1 |
NKR 66 |
| 130 |
I5-11257 001-1 |
|
DOWEL; BRG CAP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 23 |
I5-11219 018-0 |
|
CUP; SEALING, C/BL FRT & RR |
3 |
9312- |
|
4JB1 |
(C) OD = 36 ( NHR 55 ) |
| 2 |
I5-87813 178-4 |
|
LINER SET; ENG CYL |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 119 |
I8-94329 952-1 |
|
BOLT; COVER |
4 |
0702- |
|
4JB1-TC |
(A) M 8 X 28 ( NKR 55 E2 ) |
| 1 |
I8-98005 433-2 |
|
BLOCK ASM; CYL |
1 |
0211- |
|
4HF1 |
NKR 66, NKR 71 |
| 25 |
I8-97378 148-0 |
|
METAL; CM/SHF |
6 |
0702- |
|
4JB1-TC |
FRONT ( NHR/NKR55 E2 ) |
| 23 |
I8-97036 550-1 |
|
CUP; SEALING, C/BL FRT & RR |
3 |
0702- |
|
4JB1-TC |
(B) OD=45 ( NHR/NKR55 E2 ) |
| 97 |
I5-11129 006-0 |
|
CUP; SEALING |
1 |
0211- |
|
4HG1 |
(A) NKR 71, OD = 16, E2 |
| 211 |
I8-97077 638-0 |
|
BOLT; CRANKCASE |
10 |
9312- |
|
4HF1 |
(A) M 14 X 115 ( NKR 66 ) |
| 119 |
I0-50640 825-0 |
|
BOLT; COVER |
4 |
9312- |
|
4HF1 |
M 8 X 22 ( NKR 66 ) |
| 130 |
I5-11257 001-1 |
|
DOWEL; BRG CAP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 56 |
I8-98370 781-0 |
|
JET; OIL, PISTON COOLING |
4 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 335 |
I8-97018 606-0 |
|
PLUG; C/BL, SIDE |
3 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2 |
| 2 |
I5-87816 317-0 |
|
LINER SET; ENG CYL |
4 |
0702- |
|
4HG1-T |
GRADE = 1X (NKR71 EURO 2) |
| 2 |
I5-87816 321-0 |
|
LINER SET; ENG CYL |
4 |
0505- |
|
4HG1 |
GRADE = 1X ( NKR 71 ) |
| 22 |
I8-97036 335-1 |
|
CUP; SEALING, DUCT HOLE |
1 |
9312- |
|
4JB1 |
OD = 123 ( NHR 55 ) |
| 179 |
I9-09572 008-0 |
|
GASKET; COVER TO BOLT |
4 |
9312- |
|
4BE1 |
ID=82; OD = 17 ( NKR 58 ) |
| 37 |
I8-97025 440-0 |
|
PLUG; OIL GALLERY |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 132 |
I8-97329 618-0 |
|
VALVE; CHECK, OIL |
4 |
0211- |
|
4HG1-T |
M10X18.5 ( NKR71 EURO 2 ) |
| 23 |
I1-09600 012-2 |
|
CUP; SEALING, C/BL FRT & RR |
2 |
0702- |
|
4JB1-TC |
(D) OD=32 ( NHR/NKR55 E2 ) |
| 13 |
I8-94148 079-0 |
|
DOWEL; C/BL TO HD |
2 |
9312- |
|
4BE1 |
OD = 16 ( NKR 58 ) |
| 212 |
I8-97135 423-0 |
|
PIN; CRANKCASE |
2 |
9605- |
|
4HF1 |
L=20 ( NKR 66 ) |
| 222 |
I8-97209 129-0 |
|
BRACKET; COVER, C/BL |
1 |
0702- |
|
4JB1-TC |
NHR/NKR55 EURO 2 |
| 2 |
I5-87813 182-4 |
|
LINER SET; ENG CYL |
4 |
9811- |
|
4HF1 |
NKR 66 |
| 23 |
I5-11219 018-0 |
|
CUP; SEALING, C/BL FRT & RR |
3 |
0702- |
|
4JB1-TC |
(C) OD=36 ( NHR/NKR55 E2) |
| 117 |
I8-97020 126-0 |
|
COVER ASM; C/BL |
1 |
0702- |
|
4JB1-TC |
LH, NHR/NKR55 EURO 2 |
| 133 |
I9-04100 840-0 |
|
STUD; BED PLATE |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 52 |
I8-94167 749-2 |
|
NIPPLE; OIL PRESS WARNING SW, C/B |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 136 |
I8-98091 566-0 |
|
BUSHING; DRIVE SHAFT, OIL PUMP |
1 |
9312- |
|
4HG1-T |
NKR71 EURO 2 |
| 13 |
I8-94399 688-1 |
|
DOWEL; C/BL TO HD |
2 |
0211- |
|
4HG1 |
NKR 71 |
| 60 |
I9-99202 316-0 |
|
BOLT; OIL JET |
1 |
9612- |
|
4JB1 |
M 16 X 12 ( NHR 55 ) |
| 23 |
I5-11219 014-0 |
|
CUP; SEALING, C/BL FRT & RR |
1 |
9312- |
|
4BE1 |
OD = 28 ( NKR 58 ) |
| 23 |
I1-09600 016-1 |
|
CUP; SEALING, C/BL FRT & RR |
1 |
9312- |
|
4HF1 |
(A) OD = 25 ( NKR 66 ) |
| 13 |
I8-94453 344-0 |
|
DOWEL; C/BL TO HD |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 121 |
I8-97325 051-0 |
|
RUBBER; MTG, COVER |
4 |
9312- |
|
4HF1 |
NKR 66, EURO 2 |
| 211 |
I8-94399 553-2 |
|
BOLT; CRANKCASE |
17 |
0211- |
|
4HG1 |
(B) M 1 0 X82 ( NKR 71 ) |
| 15 |
I8-97369 552-1 |
|
PLUG; OIL GALLERY |
2 |
0702- |
|
4JB1-TC |
(A) PT 1/8 L=8 ( NKR55 E2 ) |
| 131 |
I5-09605 005-0 |
|
PLUG; TAPER, C/BL |
1 |
9312- |
|
4BE1 |
PT 3/8 |
| 61 |
I8-94483 674-0 |
|
PIN; STRAIGHT |
4 |
9312- |
|
4HF1 |
L=22 |
| 83 |
I9-08151 018-0 |
|
PIN; FLYWHEEL HSG |
2 |
9312- |
|
4BE1 |
OD = 10; L=18 ( NKR 58 ) |
| 17 |
I8-97176 230-0 |
|
SWITCH; OIL PRESSURE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 194 |
I8-97137 781-0 |
|
PIPE; OIL DRAIN, C/BL |
1 |
0702- |
|
4JB1-TC |
NHR/NKR55 EURO 2 |
| 34 |
I8-97328 859-0 |
|
VALVE; OIL RELIEF |
2 |
0702- |
|
4HG1-T |
NKR 71 EURO 2 |
| 35 |
I5-09623 035-0 |
|
GASKET; RELIEF VLV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 23 |
I8-97036 550-1 |
|
CUP; SEALING, C/BL FRT & RR |
3 |
9312- |
|
4JB1 |
(B) OD = 45 ( NHR 55 ) |
| 21 |
I5-11219 018-0 |
|
CUP; SEALING, RR |
1 |
9312- |
|
4JB1-TC |
(B) NHR55/NKR55 EURO 2 |
| 1 |
I8-97352 707-2 |
|
BLOCK ASM; CYL |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 132 |
I8-97329 618-0 |
|
VALVE; CHECK, OIL |
4 |
0211- |
|
4HG1 |
M10X18.5 ( NKR 71 ) |
| 38 |
I1-09740 078-0 |
|
PIN; TIMING GEAR CASE |
1 |
9312- |
|
4BE1 |
OD = 10 L=50 ( NKR 58 ) |
| 7 |
I8-97352 537-0 |
|
PLUG; WATER DRAIN |
1 |
0208- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 23 |
I5-11219 008-0 |
|
CUP; SEALING, C/BL FRT & RR |
3 |
0702- |
|
4JB1-TC |
(A) OD=18 ( NHR/NKR55 E2 ) |
| 17 |
I8-97072 947-0 |
|
SWITCH; OIL PRESSURE |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 50 |
I9-08161 032-0 |
|
PIN; STRAIGHT, RR PLATE |
1 |
9312- |
|
4JB1 |
OD = 10 L=32 ( NHR 55 ) |
| 406 |
I5-09605 005-0 |
|
PLUG; CRANKCASE |
2 |
9312- |
|
4HF1 |
PT 3/8 ( NKR 66 ) |
| 25 |
I8-97378 148-0 |
|
METAL; CM/SHF |
1 |
9507- |
|
4JB1 |
FRONT ( NHR 55 ) |
| 70 |
I5-11129 006-0 |
|
CUP; SEALING, FRT & RR |
2 |
0211- |
|
4JB1-TC |
OD=16 |
| 4 |
I8-97176 717-0 |
|
LINER; C/BL |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 53 |
I9-09806 020-0 |
|
BOLT; REAMER |
1 |
9404- |
|
4JB1 |
M 10 X 52 ( NHR 55 ) |
| 54 |
I8-97021 431-0 |
|
STUD; OIL PAN TO BLOCK |
3 |
9312- |
|
4HF1 |
NKR 66 |
| 137 |
I1-09680 025-0 |
|
COCK; DRAIN WATER |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 89 |
I9-11129 128-0 |
|
CUP; SEALING, OIL GALLERY |
3 |
9908- |
|
4HF1 |
NKR 66, NKR 66-2, OD=20 |
| 351 |
I9-09571 410-0 |
|
GASKET; COCK, WATERDRAIN |
1 |
9312- |
|
4HF1 |
ID=10.2; OD = 16.0,( NKR66 ) |
| 69 |
I9-09571 414-0 |
|
GASKET; PLUG, OIL GALLERY,C/BL |
1 |
0211- |
|
4JB1-TC |
|
| 115 |
I8-97204 194-0 |
|
RUBBER; SPACE LH |
1 |
0702- |
LH |
4JB1-TC |
NHR/NKR55 EURO 2 |
| 54 |
I8-94133 974-2 |
|
STUD; OIL PAN TO BLOCK |
10 |
9312- |
|
4JB1 |
NHR 55 |
| 137 |
I1-09680 025-0 |
|
COCK; DRAIN WATER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 34 |
I8-97328 859-0 |
|
VALVE; OIL RELIEF |
2 |
0211- |
|
4HG1 |
NKR 71 |
| 60 |
I9-09661 005-0 |
|
BOLT; OIL JET |
1 |
0702- |
|
4HG1-T |
M 16 X 12 ( NKR 71 ) |
| 56 |
I8-98370 780-0 |
|
JET; OIL, PISTON COOLING |
4 |
0211- |
|
4HG1 |
NKR 71 |
| 134 |
I8-94105 114-2 |
|
PLUG; OIL PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 335 |
I8-97018 606-0 |
|
PLUG; C/BL, SIDE |
3 |
0211- |
|
4HG1 |
M14X16.5 ( NKR 71 ) |
| 34 |
I8-97328 859-0 |
|
VALVE; OIL RELIEF |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 4 |
I8-97176 685-0 |
|
LINER; C/BL |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97163 853-7 |
|
BLOCK ASM; CYL |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 22 |
I5-09600 013-0 |
|
CUP; SEALING, DUCT HOLE |
1 |
0702- |
|
4JB1-TC |
OD = 123 ( NHR55/NKR55 E2 ) |
| 25 |
I9-11691 048-1 |
|
METAL; CM/SHF |
1 |
9312- |
|
4BE1 |
FRONT ( NKR 58 ) |
| 25 |
I8-97378 148-0 |
|
METAL; CM/SHF |
1 |
9507- |
|
4JB1 |
FRONT ( NHR 55 ) |
