| 320 |
I8-97202 328-A |
|
GASKET; PIPE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 184 |
I8-97035 883-1 |
|
GASKET; INL COVER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 53 |
I0-50151 035-0 |
|
BOLT; INL PIPE |
3 |
9312- |
|
4BE1 |
(B) M 10 X 35 (NKR58 ) |
| 138 |
I8-97180 566-2 |
|
PIPE; INL |
1 |
9811- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 525 |
I8-97033 689-0 |
|
STUD; CONT VALVE |
1 |
9312- |
|
4HF1 |
(B) ( NKR 66 ) |
| 10 |
I8-94477 782-0 |
|
GASKET; INLET PIPE |
1 |
9312- |
|
4BE1 |
(B) ID=66 ( NKR 58 ) |
| 7 |
I8-94116 988-0 |
|
GASKET; INL MANIF TO HD |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 27 |
I0-41010 825-0 |
|
STUD; INL MANIF |
2 |
9312- |
|
4JB1 |
M 8 X 25; L=29 ( NHR 55 ) |
| 50 |
I8-97178 735-5 |
|
PIPE; INL |
1 |
0702- |
|
4HG1-T |
(A) NKR71 EURO 2 |
| 572 |
I8-94107 762-0 |
|
CLIP; BOOST HOSE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 131 |
I8-97102 601-0 |
|
PIPE, PCV, INL |
1 |
9511- |
|
4HF1 |
NKR 66 |
| 115 |
I5-09709 034-0 |
|
CLIP; VAC HOSE, INT THROTLE |
1 |
9312- |
|
4JB1 |
(A) ID=8 & 23 ( NHR 55 ) |
| 95 |
I8-98133 350-0 |
|
CLIP; RUBBER HOSE |
1 |
0702- |
|
4JB1-TC |
(C) ID=68-85, NKR71 EURO 2 |
| 20 |
I0-91180 208-0 |
|
NUT; INL MANIF |
2 |
9312- |
|
4JB1 |
M 8 FLANGE NUT ( NHR 55 ) |
| 306 |
I0-28050 845-0 |
|
BOLT; VLV |
1 |
0702- |
|
4HG1-T |
(A) NKR71 EURO 2 |
| 138 |
I8-94479 568-1 |
|
PIPE; INL |
1 |
9312- |
|
4BE1 |
(B) AIR INTAKE REAR VERTICAL |
| 93 |
I5-09700 350-0 |
|
CLIP; HARNESS |
3 |
9312- |
|
4JB1 |
ID=12 ( NHR 55 ) |
| 138 |
I8-94311 856-0 |
|
PIPE; INL |
1 |
9312- |
|
4BE1 |
(A) AIR INTAKE REAR VERTICAL |
| 7 |
I8-97301 838-1 |
|
GASKET; INL MANIF TO HD |
1 |
0102- |
|
4JB1 |
NHR 55 |
| 144 |
I0-50541 040-0 |
|
BOLT; BRACKET FIX |
1 |
9312- |
|
4BE1 |
M 10 X 32 W/SP WASHER |
| 306 |
I8-97118 454-0 |
|
BOLT; VLV |
1 |
0702- |
|
4HG1-T |
(B) NKR71 EURO 2 |
| 436 |
I8-97029 837-1 |
|
BRACKET; FUEL CUT |
1 |
9312- |
|
4BE1 |
AIR INTAKE REAR VERTICAL |
| 571 |
I0-04740 300-0 |
|
HOSE; AIR BOOST |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 346 |
I5-09700 350-0 |
|
CLIP; ENG HARNESS |
5 |
9312- |
|
4HF1 |
(B) ID=66 ( NKR 66, NKR 71 ) |
| 283 |
I8-97105 689-A |
|
RUBBER; MTG, HD COVER, OUTER |
10 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 146 |
I1-09985 345-0 |
|
WASHER; LK, SUPPORT |
1 |
9312- |
|
4BE1 |
ID=10 ( NKR 58 ) |
| 306 |
I0-28050 812-A |
|
BOLT; VLV |
1 |
0702- |
|
4JB1-TC |
(C) NHR55,NKR55 EURO 2 |
| 229 |
I0-71040 408-0 |
|
SCREW; VENTILATION |
6 |
9312- |
|
4HF1 |
M 4 X 8 ( NKR 66 ) |
| 95 |
I8-98133 357-0 |
|
CLIP; RUBBER HOSE |
1 |
0702- |
|
4JB1-TC |
(A) ID=77-95, NKR71 EURO 2 |
| 53 |
I0-28650 830-0 |
|
BOLT; INL PIPE |
2 |
9607- |
|
4HF1 |
M 8X30 ( NKR66, 66-2,71 ) |
| 13 |
I8-97118 455-0 |
|
BOLT; INL MANIF |
1 |
0702- |
|
4HG1-T |
M8X30, L=68, NKR71 E2 |
| 53 |
I0-50551 025-0 |
|
BOLT; INL PIPE |
2 |
9312- |
|
4BE1 |
(A) M 10 X 25 ( NKR 58 ) |
| 1 |
I8-97107 744-1 |
|
MANIFOLD; INL |
1 |
9312- |
|
4JB1 |
NHR55 |
| 23 |
I8-94155 884-1 |
|
WASHER; PL, INL MANIF |
1 |
9312- |
|
4BE1 |
OD = 28.6 ( NKR 58 ) |
| 306 |
I0-36230 510-0 |
|
BOLT; VLV |
2 |
0702- |
|
4JB1-TC |
(D) NHR55,NKR55 EURO 2 |
| 229 |
I0-71040 408-0 |
|
SCREW; VENTILATION |
6 |
9312- |
|
4HF1 |
M 4 X 8 ( NKR 66 ) |
| 336 |
I8-97010 548-0 |
|
VALVE ASM; VENTILATION |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 53 |
I0-28650 820-0 |
|
BOLT; INL PIPE |
2 |
0702- |
|
4HG1-T |
M8X20 NKR71 EURO 2 |
| 138 |
I8-97180 566-2 |
|
PIPE; INL |
1 |
0702- |
|
4HG1-T |
(A) NKR71 EURO 2 |
| 26 |
I9-09164 512-0 |
|
WASHER; PL, SPRING SEAT |
8 |
9312- |
|
4BE1 |
ID=12 ( NKR 58 ) |
| 25 |
I5-14129 008-0 |
|
SEAT; SPRING, INLET MANIF |
2 |
9312- |
|
4BE1 |
AIR INTAKE REAR VERTICAL |
| 480 |
I8-94144 597-1 |
|
VALVE ASM; VAC SW |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 116 |
I0-50551 025-0 |
|
BOLT; INL PIPE |
2 |
9312- |
|
4JB1 |
M 1 0 X 25 ( NHR 55 ) |
| 228 |
I8-97016 313-0 |
|
STUD; INL COVER |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 10 |
I8-97035 883-1 |
|
GASKET; INLET PIPE TO MANIFOLD |
1 |
9312-0209 |
|
4JB1 |
NHR 55 |
| 53 |
I0-28650 830-0 |
|
BOLT; INL PIPE |
2 |
0702- |
|
4HG1-T |
M8X30 NKR71 EURO 2 |
| 13 |
I0-50540 840-0 |
|
BOLT; INL MANIF |
1 |
9312- |
|
4BE1 |
M 8 X 40 W/SP WASHER |
| 222 |
I8-97084 938-2 |
|
GASKET; INL COVER |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 333 |
I6-97369 717-0 |
|
HOSE; RUBBER, INL PIPE |
1 |
0702- |
|
4HG1-T |
(IADG) (B) NKR71 EURO 2 |
| 20 |
I0-91110 508-0 |
|
NUT; INL MANIF |
2 |
9312- |
|
4BE1 |
M 8 ( NKR 58 ) |
| 306 |
I0-28050 845-0 |
|
BOLT; VLV |
5 |
9511- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71 ) |
| 53 |
I0-28151 025-0 |
|
BOLT; INL PIPE |
2 |
0702- |
|
4JB1-TC |
M10X35; L=29 (NHR/NKR55 E2) |
| 7 |
I8-97301 838-1 |
|
GASKET; INL MANIF TO HD |
1 |
9312-0101 |
|
4JB1 |
NHR 55 |
| 333 |
I8-97201 103-2 |
|
HOSE; RUBBER, INL PIPE |
1 |
0702- |
|
4HG1-T |
(A) NKR71 EURO 2 |
| 20 |
I0-91180 108-0 |
|
NUT; INL MANIF |
2 |
0702- |
|
4HG1-T |
M 8 ( NKR71 EURO 2 ) |
| 525 |
I8-97021 431-0 |
|
STUD; OIL PAN TO BLOCK |
2 |
9312- |
|
4HF1 |
(A) ( NKR 66 ) |
| 603 |
I8-97204 780-0 |
|
CHAMBER; THROTTLE |
1 |
9511- |
|
4HF1 |
NKR66-2 |
| 7 |
I8-97301 838-1 |
|
GASKET; INL MANIF TO HD |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 13 |
I0-28050 830-0 |
|
BOLT; INL MANIF |
1 |
0702- |
|
4JB1-TC |
M8X30, NHR55/NKR55 E2 |
| 27 |
I9-09630 034-1 |
|
STUD; INL MANIF |
1 |
0702- |
|
4JB1-TC |
M8X35; L=29 (NHR/NKR55 E2) |
| 1 |
I8-97064 280-1 |
|
MANIFOLD; INL |
1 |
9312- |
|
4BE1 |
NKR58 |
| 2 |
I8-97146 866-2 |
|
COVER; INL |
1 |
9609- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 24 |
I5-09580 105-1 |
|
SPRING; INLET MANIF |
8 |
9312- |
|
4BE1 |
NKR 58 |
| 115 |
I8-94481 468-0 |
|
CLIP; VAC HOSE, INT THROTLE |
1 |
9312- |
|
4JB1 |
(B) ID=37 ( NHR 55 ) |
| 94 |
I0-28050 830-0 |
|
BOLT |
1 |
0702- |
|
4HG1-T |
M8X30 NKR71 EURO 2 |
| 260 |
I8-94206 392-0 |
|
CAP; RUBBER |
1 |
9811- |
|
4HF1 |
ID=4 |
| 1 |
I8-97192 327-1 |
|
MANIFOLD; INL |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 346 |
I5-09700 350-0 |
|
CLIP; ENG HARNESS |
3 |
0702- |
|
4HG1-T |
ID =126 ( NKR71 EURO 2 ) |
| 10 |
I8-97035 883-1 |
|
GASKET; INLET PIPE TO MANIFOLD |
1 |
0702- |
|
4JB1-TC |
NKR55 EURO2 |
| 222 |
I8-97084 938-2 |
|
GASKET; INL COVER |
1 |
9511- |
|
4HF1 |
NKR 66 |
| 407 |
I8-94152 318-0 |
|
PIPE; INL, REAR |
1 |
9312- |
|
4JB1 |
AIR INTAKE REAR VERTICAL |
| 333 |
I8-97369 717-3 |
|
HOSE; RUBBER, INL PIPE |
1 |
0702- |
|
4HG1-T |
(B) NKR71 EURO 2 |
| 229 |
I0-71040 408-0 |
|
SCREW; VENTILATION |
6 |
0702- |
|
4HG1-T |
M 4 X 8 ( NKR71 EURO 2 ) |
| 143 |
I8-94129 880-0 |
|
BRACKET; INL MANIF FRT |
1 |
9312- |
|
4BE1 |
AIR INTAKE REAR VERTICAL |
| 10 |
I8-94478 120-0 |
|
GASKET; INLET PIPE TO MANIFOLD |
1 |
9312- |
|
4BE1 |
(A) ID=64 X 89 ( NKR 58 ) |
| 28 |
I0-28050 612-0 |
|
BOLT; CHAMBER |
2 |
0702- |
|
4HG1-T |
M6X12 ( NKR71 EURO 2 ) |
| 115 |
I8-94463 708-0 |
|
CLIP; VAC HOSE, INT THROTLE |
1 |
9707- |
|
4JB1 |
(C) ID=6 & 6 ( NHR 55 ) |
| 148 |
I8-94255 642-1 |
|
BUSHING; SPACER, INL MANIF TO BRK |
1 |
9312- |
|
4BE1 |
OD = 12 ( NKR 58 ) |
| 324 |
I8-97180 546-1 |
|
GASKET; INL PIPE TO INL CVR |
1 |
9811- |
|
4HF1 |
AIR INTAKE REAR VERTICAL |
| 336 |
I8-97119 887-0 |
|
VALVE ASM; VENTILATION |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 20 |
I0-91180 208-0 |
|
NUT; INL MANIF |
2 |
9312- |
|
4HF1 |
M 8 FLANGE NUT ( NKR 66 ) |
| 113 |
I0-50041 080-0 |
|
BOLT; STAY |
1 |
9312- |
|
4BE1 |
M 10 X 80 W/SP WASHER |
| 95 |
I8-94316 991-0 |
|
CLIP; RUBBER HOSE |
2 |
0702- |
|
4JB1-TC |
(B) ID=50-65, NKR71 EURO 2 |
| 20 |
I5-14129 011-0 |
|
NUT; INL MANIF |
8 |
9312- |
|
4BE1 |
M 8 ( NKR 58 ) |
| 115 |
I8-94481 468-0 |
|
CLIP; VAC HOSE, INT THROTLE |
1 |
0702- |
|
4JB1-TC |
(B) ID=37 ( NKR55 EURO2 ) |
| 50 |
I8-97202 327-2 |
|
PIPE; INL |
1 |
0702- |
|
4HG1-T |
(B) NKR71 EURO 2 |
| 27 |
I0-41010 620-0 |
|
STUD; INL MANIF |
1 |
9312- |
|
4BE1 |
M 6 X 20; L=29 ( NKR 58 ) |
| 142 |
I8-94255 643-1 |
|
RUBBER; MTG, INL MANIF TO BRKT |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 131 |
I8-97102 601-0 |
|
PIPE, PCV, INL |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 27 |
I0-41010 825-0 |
|
STUD; INL MANIF |
1 |
0702- |
|
4JB1-TC |
M8X25; L=29 (NHR/NKR55 E2) |
| 114 |
I8-97228 401-0 |
|
HOSE; VAC, INT THROTTLE |
1 |
0702- |
|
4JB1-TC |
(A) L=403, NHR/NKR55 E2 |
| 20 |
I0-91180 208-0 |
|
NUT; INL MANIF |
2 |
0702- |
|
4JB1-TC |
M 8 ( NHR55/NKR55 EURO 2 ) |
| 138 |
I8-97178 748-3 |
|
PIPE; INL |
1 |
0702- |
|
4HG1-T |
(B) NKR71 EURO 2 |
| 138 |
I8-97044 648-0 |
|
PIPE; INL |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 53 |
I0-28050 830-0 |
|
BOLT; INL PIPE |
2 |
9312-9606 |
|
4HF1 |
M 8 X 30 ( NKR 66 ) |
| 23 |
I0-91614 708-0 |
|
WASHER; PL, INL MANIF |
1 |
0702- |
|
4HG1-T |
M 8 ( NKR71 EURO 2 ) |
| 320 |
I8-97180 546-1 |
|
GASKET; PIPE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 13 |
I0-28050 830-0 |
|
BOLT; INL MANIF |
7 |
9312- |
|
4HF1 |
M 8 X 30 |
| 13 |
I0-50540 825-0 |
|
BOLT; INL MANIF |
6 |
9312- |
|
4JB1 |
M8X25, NHR55 |
| 147 |
I0-91110 510-0 |
|
NUT; CUSHION RUB TO BRKT |
1 |
9312- |
|
4BE1 |
M 10; H = 8 ( NKR 58 ) |
| 13 |
I0-50540 825-0 |
|
BOLT; INL MANIF |
5 |
0702- |
|
4JB1-TC |
M8X25, NHR55/NKR55 E2 |
| 2 |
I8-97033 719-1 |
|
COVER; INL |
1 |
9312-9510 |
|
4HF1 |
NKR 66 |
| 10 |
I8-97035 883-1 |
|
GASKET; INLET PIPE TO MANIFOLD |
1 |
0210- |
|
4JB1 |
NHR 55 |
| 115 |
I8-94428 437-0 |
|
CLIP; VAC HOSE, |
3 |
9312- |
|
4JB1 |
(A) ID=8 & 16 ( NHR 55 ) |
| 2 |
I8-97109 049-4 |
|
COVER; INL |
1 |
9511-9608 |
|
4HF1 |
NKR 66, NKR 66-2 |
| 603 |
I8-97204 780-0 |
|
CHAMBER; THROTTLE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 283 |
I8-97105 689-A |
|
RUBBER; MTG, HD COVER, OUTER |
10 |
9511- |
|
4HF1 |
NKR 66 |
| 53 |
I0-28651 025-0 |
|
BOLT; INL PIPE |
2 |
0702- |
|
4HG1-T |
M10X25 NKR71 EURO 2 |
| 28 |
I0-28050 612-0 |
|
BOLT; CHAMBER |
2 |
9803- |
|
4HF1 |
NKR66-2 , M6X12 FLANGE |
| 50 |
I8-97078 858-0 |
|
PIPE; INL |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 23 |
I0-91614 708-0 |
|
WASHER; PL, INL MANIF |
1 |
9312- |
|
4JB1 |
ID-8; OD = 22 ( NHR 55, NKR 71 ) |
| 94 |
I0-28050 812-A |
|
BOLT |
3 |
9312- |
|
4JB1 |
M 8 X 12 ( NHR 55 ) |
.png)
.png)
