| 2 |
I8-97020 591-0 |
|
GASKET EXH MANIF TO HD |
1 |
9312-9409 |
|
4JB1 |
NHR 55 |
| 14 |
I8-97257 914-0 |
|
WASHER PL, EXH MANIF |
2 |
0007- |
|
4HF1 |
OD = 15 T=4 ( NKR 66 -2) |
| 2 |
I8-97146 499-A |
|
GASKET EXH MANIF TO HD |
1 |
0702- |
|
4HG1-T |
(IADG) NKR71 EURO 2 |
| 18 |
I0-51110 510-0 |
|
NUT EXH MANIF |
2 |
0702- |
|
4HG1-T |
M10 NKR71 EURO 2 |
| 34 |
I8-97250 073-1 |
|
COLLAR DIST, EXH MANIF |
8 |
0702- |
|
4HG1-T |
L=28 NKR71 EURO 2 |
| 15 |
I8-97061 543-0 |
|
BOLT EXH MANIF |
4 |
0702- |
|
4HG1-T |
M10X60 ( NKR71 EURO 2 ) |
| 2 |
I8-97350 317-2 |
|
GASKET EXH MANIF TO HD |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 2 |
I8-97350 317-2 |
|
GASKET EXH MANIF TO HD |
1 |
9410- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97124 873-0 |
|
MANIFOLD EXHAUST |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 18 |
I0-91110 510-0 |
|
NUT EXH MANIF |
3 |
0211- |
|
4HG1 |
NKR 71 |
| 1 |
I8-97163 079-1 |
|
MANIFOLD EXHAUST |
1 |
9612- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 34 |
I8-94396 410-0 |
|
COLLAR DIST, EXH MANIF |
8 |
9312-9406 |
|
4HF1 |
L=24.0 ( NKR 66 ) |
| 18 |
I7-05110 010-A |
|
NUT EXH MANIF |
3 |
9312- |
|
4HF1 |
M 10 FLANGE NUT (NKR66) |
| 21 |
I0-28050 812-A |
|
BOLT HEAT PROTECTOR |
2 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 15 |
I8-97020 490-0 |
|
BOLT EXH MANIF |
1 |
9312- |
|
4BE1 |
M8X53 ( NKR58 ) |
| 13 |
I1-09556 015-0 |
|
WASHER LK, EXH MANIF |
2 |
0702- |
|
4HG1-T |
T=2.2 ( NKR71 EURO 2) |
| 16 |
I5-09603 008-0 |
|
STUD EXH PIPE TO MANIF |
4 |
9312- |
|
4JB1 |
M10X45L=45 PLATING NHR55 |
| 21 |
I8-94279 201-0 |
|
BOLT HEAT PROTECTOR |
4 |
9312- |
|
4BE1 |
M 6 X 12 W/SP WASHER |
| 15 |
I8-97131 597-1 |
|
BOLT EXH MANIF |
6 |
9312- |
|
4JB1 |
M8X35 FULL-THREAD NHR55 |
| 3 |
I8-97214 580-0 |
|
PROTECTOR HEAT, EXH MANIF |
1 |
0702- |
|
4JB1-TC |
(A) NHR55,NKR55 EURO 2 |
| 3 |
I8-97095 360-1 |
|
PROTECTOR HEAT, EXH MANIF |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 15 |
I8-94318 555-0 |
|
BOLT EXH MANIF |
3 |
9312- |
|
4BE1 |
M8X75 NKR58 |
| 15 |
I8-97061 543-0 |
|
BOLT EXH MANIF |
4 |
9312- |
|
4HF1 |
M10X60 ( NKR66, 66-2, 71 ) |
| 1 |
I8-97028 475-1 |
|
MANIFOLD EXHAUST |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 2 |
I8-97146 499-2 |
|
GASKET EXH MANIF TO HD |
1 |
9610- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 1 |
I8-97217 908-0 |
|
MANIFOLD EXHAUST |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 21 |
I0-28050 610-0 |
|
BOLT HEAT PROTECTOR |
8 |
9312-9402 |
|
4HF1 |
M 6 X 10 ( NKR 66 ) |
| 18 |
I0-91110 508-0 |
|
NUT EXH MANIF |
2 |
9312- |
|
4JB1 |
M 8 ( NHR 55 ) |
| 13 |
I1-09556 015-0 |
|
WASHER LK, EXH MANIF |
4 |
9312- |
|
4HF1 |
T=2.2 ( NKR66, 66-2, 71) |
| 19 |
I8-97378 065-0 |
|
STUD MANIF TO CYL HD |
2 |
0702- |
|
4JB1-TC |
M8X35 NHR55,NKR55 EURO 2 |
| 3 |
I8-97096 424-1 |
|
PROTECTOR HEAT, EXH MANIF |
1 |
9510- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 15 |
I8-97131 597-1 |
|
BOLT EXH MANIF |
6 |
9803- |
|
4JB1 |
M8X35 NHR55 |
| 14 |
I8-97257 914-0 |
|
WASHER PL, EXH MANIF |
2 |
0702- |
|
4JB1-TC |
OD=15T=4 ( NHR55,NKR55 E2 ) |
| 18 |
I0-91180 208-0 |
|
NUT EXH MANIF |
2 |
0702- |
|
4JB1-TC |
M8 NHR55,NKR55 EURO 2 |
| 16 |
I8-97032 977-1 |
|
STUD EXH PIPE TO MANIF |
2 |
0702- |
|
4JB1-TC |
M10X45L=60 PLATING NHR55 E2 |
| 2 |
I8-97350 317-2 |
|
GASKET EXH MANIF TO HD |
1 |
0211- |
|
4JB1 |
NHR 55 |
| 2 |
I8-97146 499-A |
|
GASKET EXH MANIF TO HD |
1 |
9610- |
|
4HF1 |
(IADG) NKR 66, NKR 66-2, NKR 71 |
| 1 |
I8-97163 079-1 |
|
MANIFOLD EXHAUST |
1 |
9312-9611 |
|
4HF1 |
NKR 66 |
| 14 |
I0-91614 608-0 |
|
WASHER PL, EXH MANIF |
4 |
9312- |
|
4BE1 |
ID=8 T=2 ( NKR 58 ) |
| 16 |
I8-97032 977-1 |
|
STUD EXH PIPE TO MANIF |
3 |
9312- |
|
4BE1 |
M 10 X 45 L=60 STAINLESSS |
| 2 |
I8-97061 542-0 |
|
GASKET EXH MANIF TO HD |
2 |
9312-9405 |
|
4HF1 |
NKR 66 |
| 18 |
I0-91110 508-0 |
|
NUT EXH MANIF |
3 |
9312- |
|
4BE1 |
M 8 ( NKR 58 ) |
| 14 |
I1-14149 042-0 |
|
WASHER PL, EXH MANIF |
8 |
9312-9406 |
|
4HF1 |
OD = 18.5 T=5.5 ( NKR 66 ) |
| 15 |
I8-97131 597-1 |
|
BOLT EXH MANIF |
6 |
0702- |
|
4JB1-TC |
M8X35 NHR55/NKR55 E2 |
| 16 |
I8-97077 549-0 |
|
STUD EXH PIPE TO MANIF |
3 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 34 |
I8-97250 073-1 |
|
COLLAR DIST, EXH MANIF |
8 |
9312- |
|
4HF1 |
L=2 8 (NKR 66, NKR 66-2, NKR 71) |
| 19 |
I8-97378 065-0 |
|
STUD MANIF TO CYL HD |
2 |
9312- |
|
4JB1 |
M8X35L=46 ( NHR 55 ) |
| 13 |
I0-91510 508-0 |
|
WASHER LK, EXH MANIF |
2 |
9312- |
|
4JB1 |
ID=8 ( NHR 55 ) |
| 21 |
I8-97108 669-0 |
|
BOLT HEAT PROTECTOR |
4 |
0702- |
|
4HG1-T |
M6X10 NKR71 EURO2 |
| 2 |
I8-94404 610-0 |
|
GASKET EXH MANIF TO HD |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 64 |
I0-91180 208-0 |
|
NUT HEAT PROTECTOR |
4 |
9312- |
|
4BE1 |
M 8 FLANGE NUT |
| 16 |
I8-97032 977-1 |
|
STUD EXH PIPE TO MANIF |
4 |
9012- |
|
4JB1 |
M10X45L=60 PLATING NHR55 |
| 21 |
I8-97108 669-0 |
|
BOLT HEAT PROTECTOR |
8 |
9403- |
|
4HF1 |
M6X10 (NKR 66, NKR 66 -2, NKR 71) |
