| 140 |
I8-97116 039-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,54 ( NKR71 E2 ) |
| 62 |
I0-91180 208-0 |
|
NUT; NOZZEN HOLDER |
8 |
9312- |
|
4HF1 |
NKR 66 |
| 2 |
I1-09675 086-0 |
|
BOLT; INK PUMP |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 45 |
I8-97355 146-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,59( NHR55,NKR55 E2 ) |
| 110 |
I0-91180 106-0 |
|
NUT CLIP |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 140 |
I1-15349 048-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(B) T=0,60 ( NHR/NKR55 E2 ) |
| 44 |
I1-15343 003-0 |
|
SPRING; NOZZLE, NOZZLE HOLDER |
4 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 33 |
I8-97119 810-0 |
|
NOZZLE; INJ |
4 |
9511- |
|
4HF1 |
NKR 66 |
| 78 |
I0-50541 020-0 |
|
BOLT; BRKT TO C/BL |
2 |
9312- |
|
4BE1 |
M 10 X 20 W/SP WASHER |
| 140 |
I8-97163 132-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.400 ( NHR 55 ) |
| 45 |
I8-97355 164-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,77( NHR55,NKR55 E2 ) |
| 34 |
I1-09675 037-1 |
|
BOLT; EYE,NOZZLE HOLDER |
4 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 60 |
I0-91510 508-0 |
|
WASHER; LK, CLIP, HARNESS |
8 |
9312- |
|
4BE1 |
ID=8 ( NKR 58 ) |
| 33 |
I8-97119 809-0 |
|
NOZZLE; INJ |
4 |
0211- |
|
4HG1 |
NKR 71 |
| 58 |
I8-97065 713-0 |
|
FLANGE; INJ, NOZZLE HOLDER |
4 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 140 |
I8-97160 384-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.925 ( NHR 55 ) |
| 113 |
I5-15419 013-1 |
|
CLIP; INJ PIPE |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 140 |
I8-97116 039-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4HF1 |
T=0.54 ( NKR 66, NKR 71 ) |
| 43 |
I8-94312 723-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 18 |
I8-97209 495-1 |
|
PIPE; INJ NO.3 |
1 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 47 |
I8-94174 183-0 |
|
SPACER; NOZZLE SPRING, NOZZLE HOL |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97203 380-0 |
|
PUMP ASM; INJ |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 140 |
I8-97208 101-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.225 ( NKR 58 ) |
| 43 |
I8-97223 386-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,86 ( NHR55,NKR55 ) |
| 43 |
I8-97223 388-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,90 ( NHR55,NKR55 ) |
| 43 |
I8-97361 697-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(B) NHR55, NKR55 EURO 2 |
| 68 |
I8-97213 049-0 |
|
CLIP; INJ PIPE |
4 |
9811- |
|
4HF1-2 |
NKR 66-2 |
| 161 |
I8-97363 237-0 |
|
STUD; INL PUMP |
2 |
9906- |
|
4HF1 |
M 10 X 46.5; L=58.5 |
| 43 |
I8-97223 345-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,04 ( NHR55,NKR55 ) |
| 113 |
I8-98227 926-0 |
|
CLIP; INJ PIPE |
2 |
0702- |
|
4JB1-TC |
(A) NHR55, NKR55 EURO 2 |
| 113 |
I8-97213 050-0 |
|
CLIP; INJ PIPE |
4 |
0702- |
|
4HG1-T |
(D) NKR71 EURO 2 |
| 43 |
I8-97223 370-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,54 ( NHR55,NKR55 ) |
| 18 |
I8-97123 376-0 |
|
PIPE; INJ NO.3 |
1 |
9503- |
|
4HF1 |
NKR 66, NKR 71 |
| 45 |
I8-97355 165-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,78( NHR55,NKR55 E2 ) |
| 1 |
I8-97204 201-9 |
|
PUMP ASM; INJ |
1 |
1011- |
|
4JB1-TC |
100 ps, NHR55 T/B, NKR55 T/B, NKR55-B (LWB), NKR55L-T |
| 140 |
I8-97116 029-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,10 ( NHR/NKR55 E2 ) |
| 31 |
I8-97119 858-0 |
|
NOZZLE ASM; INJ |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 45 |
I8-97355 113-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,26( NHR55,NKR55 E2 ) |
| 72 |
I0-50551 020-0 |
|
BOLT; BRKT TO INJ PUMP |
2 |
9312- |
|
4JB1 |
M 10 X 20 ( NHR 55 ) |
| 47 |
I8-97223 340-0 |
|
SPACER; NOZZLE SPRING, NOZZLE HOL |
4 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 45 |
I8-97355 169-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,82( NHR55,NKR55 E2 ) |
| 146 |
I8-94344 439-0 |
|
SPACER; NOZZLE |
4 |
9312- |
|
4HF1 |
NKR 66, NKR71 |
| 140 |
I8-97116 037-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,52 ( NHR/NKR55 E2 ) |
| 80 |
I8-97368 671-0 |
|
BRACKET; PUMP |
1 |
0404- |
|
4JB1 |
(B) ( NHR 55 ) |
| 43 |
I8-97223 374-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,62 ( NHR55,NKR55 ) |
| 17 |
I8-94139 113-5 |
|
PIPE; INJ NO.2 |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 2 |
I1-09675 086-0 |
|
BOLT; INK PUMP |
1 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 43 |
I8-97223 365-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,42 ( NHR55,NKR55 ) |
| 140 |
I8-97181 984-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.425 ( NKR 58 ) |
| 30 |
I8-97364 773-0 |
|
HOSE; RUBBER, FUEL LEAK |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 19 |
I8-97071 715-3 |
|
PIPE; INJ NO.4 |
2 |
9312-9502 |
|
4HF1 |
NKR 66 |
| 140 |
I1-15349 139-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.000 ( NKR 58 ) |
| 68 |
I1-09701 091-0 |
|
CLIP; INJ PIPE |
4 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 113 |
I8-97213 481-0 |
|
CLIP; INJ PIPE |
1 |
0702- |
|
4HG1-T |
(B) NKR71 EURO 2 |
| 140 |
I1-15349 046-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(B) T=1,56 ( NKR71 E2 ) |
| 140 |
I8-97165 457-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.375 ( NHR 55 ) |
| 140 |
I1-15349 044-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(B) T=1,52 ( NHR/NKR55 E2 ) |
| 1 |
I8-97223 104-1 |
|
PUMP ASM; INJ |
1 |
9902- |
|
4HF1-2 |
NKR 66-2 |
| 35 |
I8-94174 184-0 |
|
NUT; NOZZLE RET, NOZZLE HOLDER |
4 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 140 |
I8-97204 021-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.650 ( NKR 58 ) |
| 16 |
I8-97027 349-1 |
|
PIPE; INJ NO,1 |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 45 |
I8-97355 112-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,25( NHR55,NKR55 E2 ) |
| 140 |
I8-97160 382-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.800 ( NHR 55 ) |
| 43 |
I8-97223 376-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,66 ( NHR55,NKR55 ) |
| 140 |
I8-97160 388-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.125 ( NKR 58 ) |
| 45 |
I8-97355 171-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,84( NHR55,NKR55 E2 ) |
| 43 |
I8-97223 373-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,60 ( NHR55,NKR55 ) |
| 140 |
I8-97116 036-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,60 ( NKR71 E2 ) |
| 84 |
I0-91110 510-0 |
|
NUT; BRKT TO BRKT |
1 |
9312- |
|
4BE1 |
M 10; H = 8 ( NKR 58 ) |
| 58 |
I8-97065 713-0 |
|
FLANGE; INJ, NOZZLE HOLDER |
4 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 66 |
I8-94326 439-0 |
|
GASKET; INJ NOZZLE |
4 |
9312- |
|
4HF1 |
(B) (NKR 66, NKR 66-2, NKR 71) |
| 59 |
I8-97259 884-0 |
|
CLAMP; NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 45 |
I8-97355 125-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,38( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 138-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,51( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 040-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.550 ( NHR 55 ) |
| 140 |
I8-97187 148-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.050 ( NKR 58 ) |
| 29 |
I8-97173 219-0 |
|
CLIP; HOSE |
2 |
0306- |
|
4JB1 |
( NHR 55, NKR 71 ) |
| 45 |
I8-97355 133-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,46( NHR55,NKR55 E2 ) |
| 31 |
I8-94334 713-1 |
|
NOZZLE ASM; INJ |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97091 742-0 |
|
PUMP ASM; INJ |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 43 |
I8-97223 383-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,80 ( NHR55,NKR55 ) |
| 63 |
I8-97118 895-0 |
|
PIPE; FUEL, NOZZLE LEAK OFF |
1 |
9511- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 140 |
I8-97116 040-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.550 ( NKR 58 ) |
| 34 |
I1-09675 037-1 |
|
BOLT; EYE,NOZZLE HOLDER |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 113 |
I8-94388 824-3 |
|
CLIP; INJ PIPE |
4 |
9312-9403 |
|
4HF1 |
NKR 66 |
| 140 |
I8-97179 861-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.700 ( NKR 58 ) |
| 18 |
I8-97134 168-0 |
|
PIPE; INJ NO.3 |
1 |
9811- |
|
4HF1-2 |
NKR66-2 |
| 17 |
I8-97223 924-1 |
|
PIPE; INJ NO.2 |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 140 |
I8-97160 384-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.925 ( NKR 58 ) |
| 80 |
I5-19751 071-0 |
|
BRACKET; PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 140 |
I8-97160 383-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.825 ( NHR 55 ) |
| 138 |
I8-94174 141-0 |
|
SPRING; NOZZLE LWR, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 19 |
I8-97223 926-1 |
|
PIPE; INJ NO.4 |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 140 |
I8-97116 033-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,30 ( NKR71 E2 ) |
| 140 |
I8-97179 861-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.700 ( NHR 55 ) |
| 32 |
I8-94311 966-2 |
|
HOLDER ASM; NOZZEL |
4 |
9312- |
|
4HF1 |
NKR66, NKR66-2, NKR 71 |
| 16 |
I8-97120 154-2 |
|
PIPE; INJ NO,1 |
1 |
9811- |
|
4JB1 |
EXC. TURBOCHARGER, NHR 55 |
| 140 |
I8-97165 457-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.375 ( NKR 58 ) |
| 80 |
I8-94311 184-1 |
|
BRACKET; PUMP |
1 |
9312-9510 |
|
4HF1 |
NKR 66 |
| 140 |
I8-97169 909-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.600 ( NKR 58 ) |
| 18 |
I8-97120 156-2 |
|
PIPE; INJ NO.3 |
1 |
9811- |
|
4JB1 |
EXC. TURBOCHARGER, NHR 55 |
| 1 |
I8-97212 102-0 |
|
PUMP ASM; INJ |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 63 |
I8-94479 575-0 |
|
PIPE; FUEL, NOZZLE LEAK OFF |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 219 |
I1-09630 085-0 |
|
GASKET |
2 |
9812- |
|
4HF1 |
ID=14.2 OD = 19.2 |
| 50 |
I8-94326 439-0 |
|
GASKET; NOZZLE HOLDER |
4 |
9312- |
|
4JB1 |
NHR 55, NKR 71 |
| 140 |
I8-97116 042-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,57 ( NHR/NKR55 E2 ) |
| 78 |
I0-28650 820-0 |
|
BOLT; BRKT TO C/BL |
2 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 19 |
I8-97120 157-3 |
|
PIPE; INJ NO.4 |
2 |
9811- |
|
4JB1 |
EXC. TURBOCHARGER, NHR 55 |
| 16 |
I8-94374 902-0 |
|
PIPE; INJ NO,1 |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 140 |
I8-97160 380-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.725 ( NHR 55 ) |
| 43 |
I8-97223 346-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,06 ( NHR55,NKR55 ) |
| 140 |
I8-97116 041-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,56 ( NHR/NKR55 E2 ) |
| 43 |
I8-97223 363-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,38 ( NHR55,NKR55 ) |
| 1 |
I8-97114 005-0 |
|
PUMP ASM; INJ |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 31 |
I8-97122 939-0 |
|
NOZZLE ASM; INJ |
4 |
9811- |
|
4JB1 |
EXC. TURBOCHARGER, NHR 55 |
| 30 |
I8-94152 989-2 |
|
HOSE; RUBBER, FUEL LEAK |
1 |
9312- |
|
4JB1 |
L=240 ( NHR 55 ) |
| 32 |
I8-94442 225-0 |
|
HOLDER ASM; NOZZEL |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 33 |
I8-94476 376-0 |
|
NOZZLE; INJ |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 43 |
I8-97223 387-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,88 ( NHR55,NKR55 ) |
| 140 |
I8-97160 389-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.175 ( NHR 55 ) |
| 45 |
I8-97355 162-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,75( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 032-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,20 ( NHR/NKR55 E2 ) |
| 45 |
I8-97355 127-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,40( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 153-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,66( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 129-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,42( NHR55,NKR55 E2 ) |
| 140 |
I8-97179 860-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.350 ( NKR 58 ) |
| 29 |
I8-98150 358-0 |
|
CLIP; HOSE |
7 |
0306- |
|
4JB1 |
( NHR 55, NKR 71 ) |
| 140 |
I8-97116 040-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,55 ( NKR71 E2 ) |
| 73 |
I8-94226 554-0 |
|
WASHER; LK, BRKT TO INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 45 |
I8-97355 124-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,37( NHR55,NKR55 E2 ) |
| 140 |
I8-97181 983-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.300 ( NKR 58 ) |
| 63 |
I8-97288 702-0 |
|
PIPE; FUEL, NOZZLE LEAK OFF |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 50 |
I8-97287 402-2 |
|
GASKET; NOZZLE HOLDER |
4 |
0104- |
|
4JB1 |
NHR 55 |
| 140 |
I8-97116 041-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,56 ( NKR71 E2 ) |
| 114 |
I5-15419 013-1 |
|
CLIP; INJ PUMP |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 140 |
I8-97116 037-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,52 ( NKR71 E2 ) |
| 66 |
I8-94326 439-0 |
|
GASKET; INJ NOZZLE |
4 |
0702- |
|
4HG1-T |
(B) (NKR71 EURO 2 |
| 17 |
I8-97123 375-0 |
|
PIPE; INJ NO.2 |
1 |
9503- |
|
4HF1 |
NKR 66, NKR 71 |
| 140 |
I1-15349 138-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.950 ( NHR 55 ) |
| 1 |
I8-97178 485-5 |
|
PUMP ASM; INJ |
1 |
0702- |
|
4HG1-T |
NKR71T/THD |
| 140 |
I8-97208 102-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.275 ( NHR 55 ) |
| 66 |
I8-94326 439-0 |
|
GASKET; INJ NOZZLE |
4 |
9312- |
|
4BE1 |
(B) ( NKR 58 ) |
| 140 |
I8-97160 385-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.975 ( NHR 55 ) |
| 31 |
I8-97174 112-0 |
|
NOZZLE ASM; INJ |
4 |
9811- |
|
4HF1-2 |
NKR66-2 |
| 43 |
I8-97223 355-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,22 ( NHR55,NKR55 ) |
| 140 |
I1-15349 004-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(B) T=1,20 ( NHR/NKR55 E2 ) |
| 45 |
I8-97355 170-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,83( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 039-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,54 ( NHR/NKR55 E2 ) |
| 140 |
I1-15349 043-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(B) T=0,50 ( NKR71 E2 ) |
| 45 |
I8-97355 150-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,63( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 043-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4HF1 |
T=0.58 ( NKR 66, NKR 71 ) |
| 226 |
I8-97203 567-0 |
|
PIPE; FUEL |
1 |
9812- |
|
4HF1 |
NKR 66, NKR 71 |
| 17 |
I8-97120 155-2 |
|
PIPE; INJ NO.2 |
1 |
9811- |
|
4JB1 |
EXC. TURBOCHARGER, NHR 55 |
| 43 |
I8-97223 356-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,24 ( NHR55,NKR55 ) |
| 2 |
I0-28151 070-0 |
|
BOLT; INK PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 43 |
I8-97223 380-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,74 ( NHR55,NKR55 ) |
| 99 |
I0-28650 625-0 |
|
BOLT; CLIP, INJ, PIPE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 140 |
I8-97179 863-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.850 ( NKR 58 ) |
| 272 |
I8-97329 208-0 |
|
NOZZLE KIT; INJ |
4 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 140 |
I8-97169 909-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.600 ( NHR 55 ) |
| 43 |
I8-97223 353-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,20 ( NHR55,NKR55 ) |
| 18 |
I8-97223 925-1 |
|
PIPE; INJ NO.3 |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 140 |
I8-97160 381-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.775 ( NHR 55 ) |
| 43 |
I8-94329 555-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 45 |
I8-97355 179-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,92( NHR55,NKR55 E2 ) |
| 140 |
I1-15349 049-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(B) T=0,70 ( NHR/NKR55 E2 ) |
| 140 |
I8-97116 038-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,53 ( NHR/NKR55 E2 ) |
| 140 |
I8-97116 043-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,58 ( NKR71 E2 ) |
| 45 |
I8-97355 158-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,71( NHR55,NKR55 E2 ) |
| 43 |
I8-97223 352-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,18 ( NHR55,NKR55 ) |
| 45 |
I8-97355 145-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,58( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 152-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,65( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 042-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,57 ( NKR71 E2 ) |
| 78 |
I0-28751 020-0 |
|
BOLT; BRKT TO C/BL |
2 |
9607- |
|
4HF1 |
M 10 X 20 FLANGE |
| 80 |
I8-97368 670-0 |
|
BRACKET; PUMP |
1 |
0702- |
|
4JB1-TC |
(A) NHR55,NKR55 EURO 2 |
| 78 |
I0-28151 020-0 |
|
BOLT; BRKT TO C/BL |
2 |
9312-9606 |
|
4HF1 |
M 10 X 20 ( NKR 66 ) |
| 16 |
I8-97209 493-1 |
|
PIPE; INJ NO,1 |
1 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 1 |
I8-97122 090-1 |
|
PUMP ASM; INJ |
1 |
9811- |
|
4JB1 |
NHR 55 |
| 16 |
I8-97071 712-3 |
|
PIPE; INJ NO,1 |
1 |
9312-9502 |
|
4HF1 |
NKR 66 |
| 45 |
I8-97355 115-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,28( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 130-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,43( NHR55,NKR55 E2 ) |
| 43 |
I8-97223 344-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,02 ( NHR55,NKR55 ) |
| 42 |
I5-15339 003-0 |
|
GASKET; INL CONNECTOR, NOZZLE HOLDER |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 43 |
I8-97223 371-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,56 ( NHR55,NKR55 ) |
| 62 |
I0-91180 208-0 |
|
NUT; NOZZEN HOLDER |
8 |
0702- |
|
4HG1-T |
M8 FLANGE, NKR71 EURO 2 |
| 140 |
I8-97116 044-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,59 ( NKR71 E2 ) |
| 140 |
I8-97163 131-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.200 ( NKR 58 ) |
| 59 |
I8-94433 427-0 |
|
CLAMP; NOZZLE HOLDER |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 80 |
I8-97136 677-A |
|
BRACKET; PUMP |
1 |
9511- |
|
4HF1 |
NKR 66, NKR 71 |
| 140 |
I8-97116 041-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4HF1 |
T=0.56 ( NKR 66, NKR 71 ) |
| 140 |
I8-97116 036-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,60 ( NHR/NKR55 E2 ) |
| 44 |
I8-94174 141-0 |
|
SPRING; NOZZLE, NOZZLE HOLDER |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 45 |
I8-97355 123-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,36( NHR55,NKR55 E2 ) |
| 43 |
I8-97223 366-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,44 ( NHR55,NKR55 ) |
| 140 |
I8-97179 862-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.150 ( NHR 55 ) |
| 17 |
I8-97027 350-1 |
|
PIPE; INJ NO.2 |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 161 |
I0-49241 025-0 |
|
STUD; INL PUMP |
2 |
9312- |
|
4HF1 |
M 10 X 28.5; L=48.5 |
| 45 |
I8-97355 136-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,49( NHR55,NKR55 E2 ) |
| 43 |
I8-94329 555-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 36 |
I8-98065 992-0 |
|
GASKET; RETRUN PIPE, NOZZEL HOLDER |
4 |
9503- |
|
4HF1-2 |
(B) ID=8.6 |
| 50 |
I8-97287 402-2 |
|
GASKET; NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 43 |
I8-97223 349-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,12 ( NHR55,NKR55 ) |
| 140 |
I1-15349 044-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(B) T=1,52 ( NKR71 E2 ) |
| 77 |
I8-97029 109-3 |
|
RUBBER; SPACE, INJ PUMP |
1 |
9312-9406 |
|
4HF1 |
NKR 66 |
| 272 |
I8-97352 267-0 |
|
NOZZLE KIT; INJ |
4 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 28 |
I8-94152 353-0 |
|
HOSE; FUEL, NOZZLE TO NOZZLE |
3 |
9312- |
|
4JB1 |
NHR 55 |
| 140 |
I8-97175 866-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.750 ( NHR 55 ) |
| 17 |
I8-97071 713-3 |
|
PIPE; INJ NO.2 |
1 |
9312-9502 |
|
4HF1 |
NKR 66 |
| 140 |
I8-97160 390-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.325 ( NHR 55 ) |
| 140 |
I8-97116 040-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,55 ( NHR/NKR55 E2 ) |
| 140 |
I8-97185 578-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.450 ( NKR 58 ) |
| 140 |
I8-97116 042-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.575 ( NHR 55 ) |
| 32 |
I8-97203 471-1 |
|
HOLDER ASM; NOZZEL |
4 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 45 |
I8-97355 132-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,45( NHR55,NKR55 E2 ) |
| 35 |
I8-94174 184-0 |
|
NUT; NOZZLE RET, NOZZLE HOLDER |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 32 |
I8-97352 048-0 |
|
HOLDER ASM; NOZZEL |
4 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 43 |
I8-97223 361-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,34 ( NHR55,NKR55 ) |
| 140 |
I8-97160 385-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.975 ( NKR 58 ) |
| 140 |
I8-97116 032-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,20 ( NKR71 E2 ) |
| 80 |
I8-97136 677-A |
|
BRACKET; PUMP |
1 |
0702- |
|
4HG1-T |
(D) NKR71 EURO 2 |
| 43 |
I8-97223 375-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,64 ( NHR55,NKR55 ) |
| 140 |
I8-97116 037-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.525 ( NKR 58 ) |
| 45 |
I1-15341 008-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 167 |
I8-97065 515-2 |
|
SPACER; GUID TUBE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 140 |
I8-97160 378-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.625 ( NKR 58 ) |
| 45 |
I8-97355 117-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,30( NHR55,NKR55 E2 ) |
| 140 |
I8-97160 386-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.025 ( NKR 58 ) |
| 43 |
I8-97223 367-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,46 ( NHR55,NKR55 ) |
| 140 |
I8-97175 865-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.875 ( NKR 58 ) |
| 31 |
I8-97382 945-0 |
|
NOZZLE ASM; INJ |
4 |
0702- |
|
4JB1-TC |
(C) NHR55/NKR55 |
| 43 |
I8-97223 393-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=3,00 ( NHR55,NKR55 ) |
| 43 |
I8-97223 378-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,70 ( NHR55,NKR55 ) |
| 45 |
I8-97355 177-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,90( NHR55,NKR55 E2 ) |
| 140 |
I8-97160 389-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.175 ( NKR 58 ) |
| 140 |
I8-97116 035-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,50 ( NHR/NKR55 E2 ) |
| 140 |
I8-97160 383-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.825 ( NKR 58 ) |
| 45 |
I8-97355 155-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,68( NHR55,NKR55 E2 ) |
| 19 |
I8-97027 352-1 |
|
PIPE; INJ NO.4 |
3 |
9312- |
|
4BE1 |
NKR 58 |
| 35 |
I8-94174 184-0 |
|
NUT; NOZZLE RET, NOZZLE HOLDER |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 138 |
I1-15343 004-0 |
|
SPRING; NOZZLE LWR, NOZZLE HOLDER |
4 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 140 |
I8-97179 862-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.150 ( NKR 58 ) |
| 31 |
I8-97119 811-0 |
|
NOZZLE ASM; INJ |
4 |
0211- |
|
4HG1 |
NKR 71 |
| 78 |
I0-50140 822-0 |
|
BOLT; BRKT TO C/BL |
2 |
9312- |
|
4JB1 |
M 8 X 22 W/SP & PL WASHER |
| 44 |
I8-94174 141-0 |
|
SPRING; NOZZLE, NOZZLE HOLDER |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 2 |
I0-28151 270-0 |
|
BOLT; INK PUMP |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66, NKR 71 |
| 140 |
I8-97160 381-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.775 ( NKR 58 ) |
| 19 |
I8-97123 377-1 |
|
PIPE; INJ NO.4 |
1 |
9503- |
|
4HF1 |
NKR 66, NKR 71 |
| 45 |
I8-97355 175-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,88( NHR55,NKR55 E2 ) |
| 16 |
I8-97223 923-1 |
|
PIPE; INJ NO,1 |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 140 |
I1-15349 042-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(B) T=0,40 ( NKR71 E2 ) |
| 43 |
I8-97223 347-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,08 ( NHR55,NKR55 ) |
| 19 |
I8-97134 169-0 |
|
PIPE; INJ NO.4 |
1 |
9811- |
|
4HF1-2 |
NKR66-2 |
| 226 |
I8-97203 567-0 |
|
PIPE; FUEL |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 76 |
I0-50540 825-0 |
|
BOLT; BRKT TO BRKT |
2 |
0702- |
|
4JB1-TC |
M 8 X 25 ( NHR55,NKR55 E2 ) |
| 140 |
I8-97181 982-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.100 ( NKR 58 ) |
| 140 |
I1-15349 046-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(B) T=1,56 ( NHR/NKR55 E2 ) |
| 78 |
I0-28751 020-0 |
|
BOLT; BRKT TO C/BL |
2 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 140 |
I8-97208 102-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.275 ( NKR 58 ) |
| 33 |
I8-97094 803-0 |
|
NOZZLE; INJ |
4 |
9312-9510 |
|
4HF1 |
NKR 66 |
| 76 |
I0-50540 825-0 |
|
BOLT; BRKT TO BRKT |
2 |
9312- |
|
4JB1 |
M 8 X 25 ( NHR55 ) |
| 45 |
I8-97355 142-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,55( NHR55,NKR55 E2 ) |
| 31 |
I8-97200 570-3 |
|
NOZZLE ASM; INJ |
4 |
0702- |
|
4HG1-T |
(D) NKR 71 EURO2 |
| 140 |
I8-97160 380-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.725 ( NKR 58 ) |
| 44 |
I8-94174 141-0 |
|
SPRING; NOZZLE, NOZZLE HOLDER |
4 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 17 |
I8-97209 494-1 |
|
PIPE; INJ NO.2 |
1 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 29 |
I8-97364 774-1 |
|
CLIP; HOSE |
9 |
0303- |
|
4JB1 |
NHR 55 |
| 140 |
I8-97116 034-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,40 ( NKR71 E2 ) |
| 2 |
I0-28151 290-0 |
|
BOLT; INK PUMP |
1 |
9811- |
|
4HF1 |
M12X90 ( NKR66, 662, 71) |
| 43 |
I8-97223 392-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,98 ( NHR55,NKR55 ) |
| 46 |
I8-94174 139-0 |
|
PIN; NOZZLE SET, NOZZLE HOLDER |
8 |
9312- |
|
4BE1 |
NKR 58, NKR 66, NKR66-2, NKR 71 |
| 140 |
I8-97179 863-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.850 ( NHR 55 ) |
| 113 |
I8-97213 050-0 |
|
CLIP; INJ PIPE |
2 |
9404- |
|
4HF1 |
NKR 66 |
| 43 |
I8-97223 354-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,20 ( NHR55,NKR55 ) |
| 43 |
I8-97223 382-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,78 ( NHR55,NKR55 ) |
| 140 |
I8-97160 382-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.800 ( NKR 58 ) |
| 140 |
I1-15349 139-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.000 ( NHR 55 ) |
| 43 |
I8-97223 368-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,50 ( NHR55,NKR55 ) |
| 140 |
I8-97181 981-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.900 ( NHR 55 ) |
| 140 |
I8-97181 981-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.900 ( NKR 58 ) |
| 140 |
I1-15349 045-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(B) T=1,54 ( NKR71 E2 ) |
| 140 |
I8-97181 984-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.425 ( NHR 55 ) |
| 43 |
I8-97223 351-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,16 ( NHR55,NKR55 ) |
| 45 |
I8-97355 135-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,48( NHR55,NKR55 E2 ) |
| 43 |
I8-97223 369-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,52 ( NHR55,NKR55 ) |
| 140 |
I8-97160 386-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.025 ( NHR 55 ) |
| 45 |
I8-97355 156-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,69( NHR55,NKR55 E2 ) |
| 2 |
I8-94150 045-1 |
|
BOLT; INK PUMP |
6 |
9312- |
|
4BE1 |
NKR 58 |
| 140 |
I8-97160 379-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.675 ( NHR 55 ) |
| 33 |
I8-97174 114-0 |
|
NOZZLE; INJ |
4 |
9811- |
|
4HF1 |
NKR66-2 |
| 1 |
I8-97263 086-3 |
|
PUMP ASM; INJ |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 84 |
I7-05110 010-A |
|
NUT; BRKT TO BRKT |
1 |
9312- |
|
4HF1 |
M 10 FLANGE NUT |
| 18 |
I8-97071 714-3 |
|
PIPE; INJ NO.3 |
1 |
9312-9502 |
|
4HF1 |
NKR 66 |
| 45 |
I8-97355 149-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,62( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 161-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,74( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 042-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.575 ( NKR 58 ) |
| 140 |
I8-97116 032-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4HF1 |
T=0.20 ( NKR 66, NKR 71 ) |
| 45 |
I8-97355 167-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,80( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 131-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,44( NHR55,NKR55 E2 ) |
| 140 |
I1-15349 138-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.950 ( NKR 58 ) |
| 140 |
I8-97163 131-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.200 ( NHR 55 ) |
| 2 |
I8-97412 794-1 |
|
BOLT; INK PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 140 |
I1-15349 049-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(B) T=0,70 ( NKR71 E2 ) |
| 140 |
I8-97175 865-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.875 ( NHR 55 ) |
| 43 |
I8-97361 697-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4HG1-T |
(A) NKR71 EURO 2 |
| 43 |
I8-97223 377-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,68 ( NHR55,NKR55 ) |
| 45 |
I8-97355 173-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,86( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 033-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4HF1 |
T=0.30 ( NKR 66 ), NKR 71 |
| 43 |
I8-97223 391-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,96 ( NHR55,NKR55 ) |
| 110 |
I0-91180 106-0 |
|
NUT CLIP |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 140 |
I8-97163 132-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.400 ( NKR 58 ) |
| 1 |
I8-97085 067-2 |
|
PUMP ASM; INJ |
1 |
9312-9410 |
|
4BE1 |
NKR 58 |
| 140 |
I8-97116 038-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,53 ( NKR71 E2 ) |
| 45 |
I8-97355 141-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,54( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 166-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,79( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 029-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,10 ( NKR71 E2 ) |
| 36 |
I1-09630 082-0 |
|
GASKET; RETRUN PIPE, NOZZEL HOLDER |
8 |
9312- |
|
4HF1 |
(A) NKR66, NKR66-2 |
| 35 |
I1-15349 041-0 |
|
NUT; NOZZLE RET, NOZZLE HOLDER |
4 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 140 |
I8-97202 697-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.500 ( NHR 55 ) |
| 140 |
I1-15349 048-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(B) T=0,60 ( NKR71 E2 ) |
| 45 |
I8-97355 122-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,35( NHR55,NKR55 E2 ) |
| 84 |
I7-05110 010-A |
|
NUT; BRKT TO BRKT |
1 |
0702- |
|
4HG1-T |
M 10 FLANGE NUT |
| 31 |
I8-97094 799-0 |
|
NOZZLE ASM; INJ |
4 |
9312-9407 |
|
4HF1 |
NKR 66 |
| 136 |
I8-94473 967-0 |
|
CAP; NOZZLE, FUEL END |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 140 |
I8-97116 035-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(A) T=0,50 ( NKR71 E2 ) |
| 45 |
I8-97355 159-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,72( NHR55,NKR55 E2 ) |
| 16 |
I8-97123 374-0 |
|
PIPE; INJ NO,1 |
1 |
9503- |
|
4HF1 |
NKR 66, NKR 71 |
| 19 |
I8-94133 751-5 |
|
PIPE; INJ NO.4 |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 45 |
I8-97355 119-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,32( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 176-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,89( NHR55,NKR55 E2 ) |
| 33 |
I8-94334 714-1 |
|
NOZZLE; INJ |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 35 |
I1-15349 041-0 |
|
NUT; NOZZLE RET, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 43 |
I8-97223 390-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,94 ( NHR55,NKR55 ) |
| 45 |
I8-97355 163-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,76( NHR55,NKR55 E2 ) |
| 140 |
I8-97206 454-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.475 ( NHR 55 ) |
| 45 |
I8-97355 114-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,27( NHR55,NKR55 E2 ) |
| 194 |
I8-97176 071-0 |
|
STUD; INJ PUMP |
2 |
9811- |
|
4HF1-2 |
( NKR 66-2 ) |
| 45 |
I8-97355 137-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,50( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 128-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,41( NHR55,NKR55 E2 ) |
| 120 |
I8-98015 024-1 |
|
BRACKET; INJ PIPE |
1 |
0702- |
|
4JB1-TC |
(A) NHR55, NKR55 EURO 2 |
| 66 |
I8-97171 333-0 |
|
GASKET; INJ NOZZLE |
4 |
9312- |
|
4HF1 |
(A) ( NKR 66 ) |
| 80 |
I8-97119 363-1 |
|
BRACKET; PUMP |
1 |
9811- |
|
4HF1-2 |
NKR 66-2 |
| 32 |
I8-94476 337-1 |
|
HOLDER ASM; NOZZEL |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 5 |
I8-97089 165-0 |
|
BRACKET; INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 219 |
I1-09630 085-0 |
|
GASKET |
2 |
9812- |
|
4HF1-T |
ID=14.2 OD = 19.2 |
| 140 |
I8-97208 101-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.225 ( NHR 55 ) |
| 140 |
I8-97204 021-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.650 ( NHR 55 ) |
| 140 |
I8-97116 037-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4HF1 |
T=0.52 ( NKR 66, NKR 71 ) |
| 43 |
I8-97223 360-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,32 ( NHR55,NKR55 ) |
| 45 |
I8-97355 140-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,53( NHR55,NKR55 E2 ) |
| 107 |
I8-94178 699-0 |
|
NUT; INJ PIPE CLIP |
2 |
9811- |
|
4HF1 |
M5 FLANGE ( NKR 60-2 ) |
| 43 |
I8-97223 379-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,72 ( NHR55,NKR55 ) |
| 17 |
I8-97134 167-1 |
|
PIPE; INJ NO.2 |
1 |
9811- |
|
4HF1-2 |
NKR66-2 |
| 81 |
I0-91614 708-0 |
|
WASHER; PL, BRKT TO PUMP |
2 |
9312- |
|
4JB1 |
ID=8; OD = 22 ( NHR 55 ) |
| 61 |
I8-94468 020-2 |
|
BOLT; CLAMP NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 158 |
I8-98039 986-0 |
|
NUT; INJ PUMP |
2 |
9312- |
|
4JB1 |
M 8 ( NHR 55 ) |
| 140 |
I8-97160 387-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.075 ( NKR 58 ) |
| 140 |
I8-97181 983-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.300 ( NHR 55 ) |
| 140 |
I8-97165 456-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.250 ( NHR 55 ) |
| 18 |
I8-97027 351-1 |
|
PIPE; INJ NO.3 |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 45 |
I8-97355 157-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,70( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 172-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,85( NHR55,NKR55 E2 ) |
| 140 |
I8-97202 697-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.500 ( NKR 58 ) |
| 45 |
I8-97355 126-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,39( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 029-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4HF1 |
T=0.10 ( NKR 66, NKR 71) |
| 45 |
I8-97355 160-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,73( NHR55,NKR55 E2 ) |
| 140 |
I8-97160 378-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.625 ( NHR 55 ) |
| 140 |
I8-97160 390-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.325 ( NKR 58 ) |
| 161 |
I8-97363 237-0 |
|
STUD; INL PUMP |
2 |
0702- |
|
4HG1-T |
M 10 X 46.5; L=58.5 |
| 45 |
I8-97355 147-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,60( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 174-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,87( NHR55,NKR55 E2 ) |
| 77 |
I8-97114 301-0 |
|
RUBBER; SPACE, INJ PUMP |
1 |
9407-9510 |
|
4HF1 |
NKR 66 |
| 140 |
I1-15349 047-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4HG1-T |
(B) T=1,58 ( NKR71 E2 ) |
| 36 |
I9-09571 408-0 |
|
GASKET; RETRUN PIPE, NOZZEL HOLDER |
8 |
9312- |
|
4BE1 |
ID=8.2;OD=14.0;T=1.0 (NKR58) |
| 18 |
I8-97108 558-2 |
|
PIPE; INJ NO.3 |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 45 |
I8-97355 134-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,47( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 118-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,31( NHR55,NKR55 E2 ) |
| 43 |
I8-97223 372-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,58 ( NHR55,NKR55 ) |
| 140 |
I8-94174 142-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.500 ( NKR 58 ) |
| 16 |
I8-97134 166-1 |
|
PIPE; INJ NO,1 |
1 |
9811- |
|
4HF1-2 |
NKR66-2 |
| 62 |
I0-91180 208-0 |
|
NUT; NOZZEN HOLDER |
8 |
0211- |
|
4HG1 |
M8 FLANGE ( NKR 71 ) |
| 140 |
I8-97116 034-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,40 ( NHR/NKR55 E2 ) |
| 43 |
I8-97223 348-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,10 ( NHR55,NKR55 ) |
| 43 |
I8-97223 389-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,92 ( NHR55,NKR55 ) |
| 140 |
I8-97116 035-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4HF1 |
T=0.50 ( NKR 66, NKR 71 ) |
| 45 |
I8-97355 116-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,29( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 043-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,58 ( NHR/NKR55 E2 ) |
| 86 |
I1-09985 345-0 |
|
WASHER; LK, SUPPORT RUBBER TO BRK |
1 |
9312- |
|
4BE1 |
ID=10 ( NKR 58 ) |
| 45 |
I8-97355 139-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,52( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 151-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,64( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 044-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,59 ( NHR/NKR55 E2 ) |
| 158 |
I7-05110 010-A |
|
NUT; INJ PUMP |
2 |
9312- |
|
4HF1 |
M 10 ( NKR 66 ) |
| 158 |
I0-91180 110-0 |
|
NUT; INJ PUMP |
2 |
0702- |
|
4HG1-T |
M10 NKR71 EURO 2 |
| 45 |
I8-97355 168-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,81( NHR55,NKR55 E2 ) |
| 140 |
I8-97185 578-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.450 ( NHR 55 ) |
| 140 |
I8-97116 037-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.525 ( NHR 55 ) |
| 66 |
I8-97171 331-0 |
|
GASKET; INJ NOZZLE |
4 |
0702- |
|
4JB1-TC |
(A) ID=7.2; OD=15.0;T=6.6 |
| 43 |
I8-97223 343-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,00 ( NHR55,NKR55 ) |
| 62 |
I0-91110 508-0 |
|
NUT; NOZZEN HOLDER |
8 |
9312- |
|
4BE1 |
NKR 58 |
| 81 |
I0-91614 708-0 |
|
WASHER; PL, BRKT TO PUMP |
2 |
9702- |
|
4JB1-TC |
ID=8; OD=22 ( NHR,NKR55 E2 ) |
| 2 |
I1-15759 029-0 |
|
BOLT; INK PUMP |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 140 |
I8-97116 033-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(A) T=0,30 ( NHR/NKR55 E2 ) |
| 72 |
I0-50551 020-0 |
|
BOLT; BRKT TO INJ PUMP |
2 |
0702- |
|
4JB1-TC |
M 10 X 20 ( NHR55,NKR55 E2 ) |
| 34 |
I8-94320 307-0 |
|
BOLT; EYE,NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 46 |
I8-94174 139-0 |
|
PIN; NOZZLE SET, NOZZLE HOLDER |
8 |
9312- |
|
4JB1 |
NHR 55 |
| 2 |
I5-09000 222-1 |
|
BOLT; INK PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 19 |
I8-97209 496-1 |
|
PIPE; INJ NO.4 |
1 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 140 |
I8-97160 387-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.075 ( NHR 55 ) |
| 45 |
I8-97355 144-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,57( NHR55,NKR55 E2 ) |
| 43 |
I8-97223 358-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,28 ( NHR55,NKR55 ) |
| 61 |
I8-94433 717-1 |
|
BOLT; CLAMP NOZZLE HOLDER |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 29 |
I8-98150 358-0 |
|
CLIP; HOSE |
9 |
9312-0305 |
|
4JB1 |
L=240 ( NHR 55, NKR 71 ) |
| 113 |
I8-98380 442-0 |
|
CLIP; INJ PIPE |
2 |
0702- |
|
4JB1-TC |
(B) NHR55, NKR55 EURO 2 |
| 43 |
I8-97223 362-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,36 ( NHR55,NKR55 ) |
| 140 |
I8-97165 456-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.250 ( NKR 58 ) |
| 194 |
I8-97363 237-0 |
|
STUD; INJ PUMP |
2 |
0302- |
|
4HF1-2 |
NKR 66, NKR 66-2, NKR 71 |
| 80 |
I8-94133 762-2 |
|
BRACKET; PUMP |
1 |
9312-0403 |
|
4JB1 |
(B) ( NHR 55 ) |
| 140 |
I8-97181 982-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.100 ( NHR 55 ) |
| 43 |
I8-97223 364-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,40 ( NHR55,NKR55 ) |
| 66 |
I8-97171 331-0 |
|
GASKET; INJ NOZZLE |
4 |
9312- |
|
4BE1 |
(A) ID=7.2; OD = 15.0; T=6.6 |
| 45 |
I8-97355 180-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,93( NHR55,NKR55 E2 ) |
| 43 |
I8-97223 350-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,14 ( NHR55,NKR55 ) |
| 158 |
I7-05110 010-A |
|
NUT; INJ PUMP |
2 |
9312- |
|
4HF1 |
M 10 FLANGE |
| 140 |
I8-97160 388-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.125 ( NHR 55 ) |
| 47 |
I8-97223 340-0 |
|
SPACER; NOZZLE SPRING, NOZZLE HOL |
4 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 43 |
I8-97223 359-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,30 ( NHR55,NKR55 ) |
| 140 |
I8-94174 142-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=0.500 ( NHR 55 ) |
| 66 |
I8-97171 331-0 |
|
GASKET; INJ NOZZLE |
4 |
9312- |
|
4JB1 |
(A) ID=7.2; OD = 15.0; T=6.6 |
| 41 |
I8-94328 764-0 |
|
CONNECTOR; FUEL INL, NOZZLE HOLDER |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 43 |
I8-97223 381-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,76 ( NHR55,NKR55 ) |
| 45 |
I8-97355 148-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,61( NHR55,NKR55 E2 ) |
| 140 |
I8-97116 034-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4HF1 |
T=0.40 ( NKR 66, NKR 71 ) |
| 45 |
I8-97355 120-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,33( NHR55,NKR55 E2 ) |
| 140 |
I8-97175 866-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=0.750 ( NKR 58 ) |
| 43 |
I8-97349 452-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4HG1-T |
(B) NKR71 EURO 2 |
| 31 |
I8-97114 017-0 |
|
NOZZLE ASM; INJ |
4 |
9408-9510 |
|
4HF1 |
NKR 66 |
| 31 |
I8-97119 812-0 |
|
NOZZLE ASM; INJ |
4 |
9511- |
|
4HF1 |
NKR 66 |
| 47 |
I8-94174 183-0 |
|
SPACER; NOZZLE SPRING, NOZZLE HOL |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 29 |
I8-97173 219-0 |
|
CLIP; HOSE |
2 |
0702- |
|
4JB1-TC |
NHR55/NKR55 |
| 63 |
I8-97027 985-1 |
|
PIPE; FUEL, NOZZLE LEAK OFF |
1 |
9312-9510 |
|
4HF1 |
NKR 66 |
| 45 |
I8-97355 143-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,56( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 121-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,34( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 154-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,67( NHR55,NKR55 E2 ) |
| 45 |
I8-97355 178-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,91( NHR55,NKR55 E2 ) |
| 63 |
I8-97239 891-A |
|
PIPE; FUEL, NOZZLE LEAK OFF |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 43 |
I8-97223 384-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,82 ( NHR55,NKR55 ) |
| 140 |
I8-97206 454-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4BE1 |
T=1.475 ( NKR 58 ) |
| 1 |
I8-97117 560-1 |
|
PUMP ASM; INJ |
1 |
9411- |
|
4BE1 |
NKR 58 |
| 45 |
I8-97355 182-0 |
|
ROD; PUSH, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
L=38,94( NHR55,NKR55 E2 ) |
| 140 |
I8-97187 148-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.050 ( NHR 55 ) |
| 43 |
I8-97223 357-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,26 ( NHR55,NKR55 ) |
| 44 |
I1-15343 003-0 |
|
SPRING; NOZZLE, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 140 |
I1-15349 045-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(B) T=1,54 ( NHR/NKR55 E2 ) |
| 58 |
I8-94319 320-0 |
|
FLANGE; INJ, NOZZLE HOLDER |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 140 |
I8-97179 860-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
9312- |
|
4JB1 |
T=1.350 ( NHR 55 ) |
| 140 |
I1-15349 047-0 |
|
SHIM; NOZZLE SPRING, NOZZLE HOLDER |
AR |
0702- |
|
4JB1-TC |
(B) T=1,58 ( NHR/NKR55 E2 ) |
| 88 |
I0-91614 610-0 |
|
WASHER; PL, GUIDE TUBE |
1 |
9312- |
|
4BE1 |
ID=10; OD = 22 ( NKR 58 ) |
| 80 |
I8-97942 900-0 |
|
BRACKET; PUMP |
1 |
9312- |
|
4JB1 |
(A) ( NHR 55 ) |
| 36 |
I8-98065 992-0 |
|
GASKET; RETRUN PIPE, NOZZEL HOLDER |
4 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 43 |
I8-97223 385-0 |
|
SEAT; NOZZLE SPRING, NOZZLE HOLDER |
4 |
0702- |
|
4JB1-TC |
(A) T=2,84 ( NHR55,NKR55 ) |
.png)
.png)
.png)
.png)
