| 2 |
I8-97957 675-A |
|
ELEMENT OIL FILTER |
1 |
0312- |
|
4JB1 |
NHR 55 |
| 102 |
I8-97385 200-A |
|
COOLER ASM OIL |
1 |
9709- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 329 |
I0-28050 860-0 |
|
BOLT OIL FILTER |
2 |
0702- |
|
4JB1-TC |
(B) M8X60, NKR55 EURO2 |
| 105 |
I8-97016 314-0 |
|
STUD OIL COOLER |
3 |
9312- |
|
4HF1 |
M8X52 L=63 |
| 103 |
I8-97329 626-0 |
|
BOLT OIL COOLER |
5 |
9312- |
|
4BE1 |
M 8 X 28 W/SP WASHER |
| 281 |
I8-94329 622-1 |
|
COVER OIL FILTER |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 469 |
I8-98045 447-A |
|
GASKET OIL COOLER TO C/BL |
1 |
0702- |
|
4HG1-T |
(C) OD=30.2 NKR71 EURO 2 |
| 272 |
I8-94370 670-0 |
|
GASKET OIL FILTER TO C/BL |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 471 |
I8-94221 519-0 |
|
CLIP WATER HOSE |
4 |
9811- |
|
4HF1-2 |
ID=15.5 ( NKR 66-2 ) |
| 2 |
I6-97247 514-0 |
|
ELEMENT OIL FILTER |
1 |
9312- |
|
4HF1 |
(IADG) NKR 66, NKR 66-2, NKR 71 |
| 164 |
I8-97146 684-A |
|
GASKET HTR PIPE |
1 |
9605- |
|
4HF1 |
(B) NKR 66, NKR 66-2, NKR 71 |
| 2 |
I8-94340 259-1 |
|
ELEMENT OIL FILTER |
1 |
9312- |
|
4BE1 |
(A) OD = 102 H = 80 ( NKR58 ) |
| 63 |
I8-94383 720-0 |
|
GASKET COOLER TO BRKT |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 273 |
I0-28751 030-0 |
|
BOLT OIL FILTER |
2 |
9607- |
|
4HF1-2 |
M 10 X 30 FLANGE |
| 469 |
I8-97233 302-2 |
|
GASKET OIL COOLER TO C/BL |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 379 |
I0-91180 208-0 |
|
NUT OIL COOLER |
1 |
0211- |
|
4HG1 |
M 8 FLANGE ( NKR 71 ) |
| 103 |
I0-28050 835-0 |
|
BOLT OIL COOLER |
7 |
0702- |
|
4HG1-T |
M8X35 NKR71 EURO2 |
| 469 |
I9-09566 226-0 |
|
GASKET OIL COOLER TO C/BL |
1 |
0301- |
|
4HF1 |
(C) ID=26.35 |
| 70 |
I9-09921 193-0 |
|
GASKET PULG, OIL FILTER |
1 |
0702- |
|
4JB1-TC |
(D) NHR55, NKR55 EURO 2 |
| 471 |
I8-94221 519-0 |
|
CLIP WATER HOSE |
2 |
0702- |
|
4HG1-T |
ID=15.5 NKR71 EURO2 |
| 394 |
I0-49241 025-0 |
|
STUD OIL FILTER |
2 |
9312-9612 |
|
4HF1 |
M 10 X 28.5 L=48.5 |
| 165 |
I0-91180 208-0 |
|
BOLT HANGER, FRT |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 70 |
I8-94167 886-0 |
|
GASKET PULG, OIL FILTER |
1 |
9312- |
|
4JB1 |
(C) ID=8.6 ( NHR 55 ) |
| 273 |
I8-94148 617-1 |
|
BOLT OIL FILTER |
1 |
9312- |
|
4BE1 |
M 10 X 109 ( NKR 58 ) |
| 69 |
I8-94167 883-0 |
|
PLUG BODY, OIL FILTER |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 519 |
I8-97160 961-1 |
|
HOSE RUBBER |
1 |
9811- |
|
4HF1-2 |
NKR 66-2 |
| 64 |
I8-97081 756-0 |
|
BODY OIL FILTER & OIL COOLER |
1 |
0211- |
|
4JB1 |
NHR55 (NON TURBO)
W/ OIL COOLER
|
| 164 |
I1-09623 395-0 |
|
GASKET HTR PIPE |
1 |
9312-9604 |
|
4HF1 |
(A) ID=23.3 ( NKR 66 ) |
| 265 |
I8-98328 486-0 |
|
BODY OIL FILTER |
1 |
9312-0208 |
|
4HF1 |
NKR 66 |
| 111 |
I8-94438 354-0 |
|
CORE OIL COOLER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 496 |
I8-97247 515-0 |
|
FILTER ASM OIL |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 265 |
I8-98328 486-0 |
|
BODY OIL FILTER |
1 |
0711- |
|
4HG1-T |
NKR71 EURO 2 |
| 164 |
I8-97146 684-A |
|
GASKET HTR PIPE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 544 |
I8-97147 028-0 |
|
COVER HEATER |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 1 |
I8-97224 298-2 |
|
FILTER & COOLER ASM OIL |
1 |
0711- |
|
4JB1-TC |
NHR/NKR55 EURO 2
TURBOCHRAGER
W/ OIL COOLER |
| 105 |
I8-97016 314-0 |
|
STUD OIL COOLER |
3 |
0702- |
|
4HG1-T |
M8X52 L=63 NKR71 EURO 2 |
| 469 |
I8-94399 339-0 |
|
GASKET OIL COOLER TO C/BL |
1 |
0301- |
|
4HF1 |
(B) NKR 66, NKR 66-2, NKR 71 |
| 89 |
I0-28050 816-0 |
|
BOLT ELEMENT TO CASE |
2 |
0702- |
|
4HG1-T |
M8X16 NKR71 EURO 2 |
| 273 |
I0-50141 032-0 |
|
BOLT OIL FILTER |
2 |
9312- |
|
4BE1 |
M 10 X 32 W/SP WASHER |
| 329 |
I0-50540 830-0 |
|
BOLT OIL FILTER |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 112 |
I8-97028 587-0 |
|
PLUG OIL COOLER CASE |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 65 |
I8-94167 882-0 |
|
VALVE OIL COOLER |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 208 |
I8-97146 519-0 |
|
PIPE WATER,HTR |
1 |
9605- |
|
4HF1 |
NKR 66, NKR 71 |
| 62 |
I8-94401 680-0 |
|
COOLER ASM OIL |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 265 |
I8-97129 937-1 |
|
BODY OIL FILTER |
1 |
0502- |
|
4JB1 |
NHR55 (NON TURBO) W/O OIL COOLER |
| 555 |
I8-97212 335-1 |
|
HOUSING COOLER |
1 |
1108- |
|
4HF1 |
NKR66 |
| 496 |
I8-94462 137-2 |
|
FILTER ASM OIL |
1 |
0502- |
|
4JB1 |
NHR55 (NON TURBO) W/O OIL COOLER |
| 65 |
I8-94450 772-0 |
|
VALVE OIL COOLER |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 273 |
I0-28151 030-0 |
|
BOLT OIL FILTER |
2 |
9312-9606 |
|
4HF1 |
M 10 X 30 FLANGE NUT |
| 103 |
I0-28050 835-0 |
|
BOLT OIL COOLER |
14 |
9312- |
|
4HF1 |
M 8 X 35 FLANGE NUT |
| 2 |
I8-97329 911-A |
|
ELEMENT OIL FILTER |
1 |
0702- |
|
4JB1-TC |
NHR/NKR55 EURO 2 |
| 2 |
I2-97247 514-0 |
|
ELEMENT OIL FILTER |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 2 |
I6-97329 911-0 |
|
ELEMENT OIL FILTER |
1 |
0702- |
|
4JB1-TC |
(IADG) NHR/NKR55 EURO 2 |
| 444 |
I8-97384 130-0 |
|
GASKET ELEMET TO BODY |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 62 |
I8-97226 391-0 |
|
COOLER ASM OIL |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 469 |
I8-94399 339-0 |
|
GASKET OIL COOLER TO C/BL |
1 |
0702- |
|
4HG1-T |
(B) ID=9.8 NKR71 EURO 2 |
| 394 |
I0-49241 025-0 |
|
STUD OIL FILTER |
2 |
0702- |
|
4HG1-T |
M10X25 L=48,5 NKR71 E2 |
| 2 |
I6-94430 983-1 |
|
ELEMENT OIL FILTER |
1 |
9312-0311 |
|
4JB1 |
(IADG) NHR 55 |
| 444 |
I8-97384 130-0 |
|
GASKET ELEMET TO BODY |
2 |
0702- |
|
4HG1-T |
M8 NKR71 EURO 2 |
| 102 |
I8-97027 982-2 |
|
COOLER ASM OIL |
1 |
9312-9708 |
|
4HF1 |
NKR 66 |
| 469 |
I8-94338 878-A |
|
GASKET OIL COOLER TO C/BL |
1 |
0702- |
|
4HG1-T |
(A) NKR71 EURO 2 |
| 90 |
I1-21729 043-0 |
|
GASKET BOLT, OIL COOLER |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 2 |
I2-97247 514-0 |
|
ELEMENT OIL FILTER |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 272 |
I8-94399 399-0 |
|
GASKET OIL FILTER TO C/BL |
2 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 272 |
I8-94399 399-0 |
|
GASKET OIL FILTER TO C/BL |
2 |
0301- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 64 |
I8-94423 698-2 |
|
BODY OIL FILTER & OIL COOLER |
1 |
9312- |
|
4JB1 |
NHR55 (NON TURBO)
|
| 281 |
I8-94114 583-1 |
|
COVER OIL FILTER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 137 |
I0-28650 820-0 |
|
BOLT |
1 |
9711- |
|
4HF1 |
M8X20 FLANGE |
| 112 |
I8-94416 170-0 |
|
PLUG OIL COOLER CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 64 |
I8-97166 497-2 |
|
BODY OIL FILTER & OIL COOLER |
1 |
0711- |
|
4JB1-TC |
NHR/NKR55 EURO 2 TURBOCHRAGER W/ OIL COOLER |
| 2 |
I8-97329 911-0 |
|
ELEMENT OIL FILTER |
1 |
0702- |
|
4JB1-TC |
NHR/NKR55 EURO 2 |
| 103 |
I0-28050 820-0 |
|
BOLT OIL COOLER |
7 |
0702- |
|
4HG1-T |
NKR71 EURO2 |
| 159 |
I5-09700 350-0 |
|
CLIP HARNESS |
3 |
9312- |
|
4BE1 |
ID=12 ( NKR 58 ) |
| 379 |
I0-91180 108-0 |
|
NUT OIL COOLER |
3 |
0702- |
|
4HG1-T |
M8 NKR71 EURO 2 |
| 90 |
I1-21729 043-0 |
|
GASKET BOLT, OIL COOLER |
4 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 70 |
I8-94167 884-0 |
|
GASKET PULG, OIL FILTER |
1 |
9312- |
|
4JB1 |
(A) ID=13.6 ( NHR 55 ) |
| 544 |
I8-97147 028-0 |
|
COVER HEATER |
1 |
9811- |
|
4HF1 |
NKR 66, NKR 71 |
| 379 |
I0-91180 208-0 |
|
NUT OIL COOLER |
1 |
9312- |
|
4HF1 |
M 8 FLANGE NUT ( NKR 66 ) |
| 362 |
I0-91180 110-0 |
|
NUT OIL FILTER |
2 |
0702- |
|
4HG1-T |
M10 NKR71 EURO 2 |
| 274 |
I9-09572 010-0 |
|
GASKET OIL FILTER TO CYLINDER BLOCK |
2 |
9312- |
|
4BE1 |
ID=10.2 OD = 19 |
| 444 |
I5-11282 011-0 |
|
GASKET ELEMET TO BODY |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 102 |
I8-94438 371-1 |
|
COOLER ASM OIL |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 89 |
I0-28050 816-0 |
|
BOLT ELEMENT TO CASE |
2 |
9312- |
|
4HF1 |
M 8 X 16 FLANGE |
| 469 |
I8-94399 339-0 |
|
GASKET OIL COOLER TO C/BL |
1 |
9312- |
|
4HF1 |
(B) ID=9.8 |
| 137 |
I0-28650 820-0 |
|
BOLT |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 2 |
I8-94463 713-1 |
|
ELEMENT OIL FILTER |
1 |
9312- |
|
4BE1 |
(B) OD = 80 H = 100 ( NKR58 ) |
| 90 |
I1-21729 043-0 |
|
GASKET BOLT, OIL COOLER |
4 |
0702- |
|
4HG1-T |
NKR 71 EURO 2 |
| 1 |
I8-94327 272-1 |
|
FILTER & COOLER ASM OIL |
1 |
9312- |
|
4JB1 |
NHR55 (NON TURBO)
W/ OIL COOLER
|
| 113 |
I9-09571 418-0 |
|
GASKET PLUG, OIL COOLER CASE |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 101 |
I0-49140 822-0 |
|
STUD OIL COOLER TO PIPE |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 273 |
I8-94148 616-1 |
|
BOLT OIL FILTER |
1 |
9312- |
|
4BE1 |
M 10 X 140 ( NKR 58 ) |
| 12 |
I8-97075 754-0 |
|
VALVE ASM BYPASS |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 555 |
I8-97212 335-1 |
|
HOUSING COOLER |
1 |
1108- |
|
4HG1-T |
NKR71 EURO 2 |
| 208 |
I8-97139 585-1 |
|
PIPE WATER,HTR |
1 |
9811- |
|
4HF1-2 |
NKR 66-2 |
| 272 |
I8-94399 399-0 |
|
GASKET OIL FILTER TO C/BL |
2 |
9312- |
|
4HF1 |
ID=22.1 ( NKR 66, NKR 71 ) |
| 2 |
I6-97247 514-0 |
|
ELEMENT OIL FILTER |
1 |
0702- |
|
4HG1-T |
(IADG) NKR71 EURO 2 |
| 394 |
I0-49241 025-0 |
|
STUD OIL FILTER |
2 |
9701- |
|
4HF1 |
M 10 X 25 L=40 |
| 103 |
I0-28650 835-0 |
|
BOLT OIL COOLER |
6 |
9312- |
|
4BE1 |
M 8 X 32 W/SP WASHER |
| 469 |
I8-94338 878-A |
|
GASKET OIL COOLER TO C/BL |
1 |
9312- |
|
4HF1 |
(A) NKR 66, NKR 66-2, NKR 71 |
| 102 |
I8-97385 200-A |
|
COOLER ASM OIL |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 67 |
I9-09920 975-0 |
|
GASKET VLV |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 362 |
I0-91180 208-0 |
|
NUT OIL FILTER |
3 |
9312- |
|
4HF1 |
M 10 ( NKR 66 ) |
| 362 |
I7-05110 010-A |
|
NUT OIL FILTER |
2 |
9312- |
|
4HF1 |
M 10 FLANGE |
| 111 |
I8-97334 101-1 |
|
CORE OIL COOLER |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 273 |
I0-28751 030-0 |
|
BOLT OIL FILTER |
2 |
0702- |
|
4HG1-T |
M10X30 NKR71 EURO 2 |
| 469 |
I9-09566 226-0 |
|
GASKET OIL COOLER TO C/BL |
1 |
9702- |
|
4HF1 |
(C) ID=26.35 |
| 555 |
I8-94438 372-0 |
|
HOUSING COOLER |
1 |
1108- |
|
4BE1 |
NKR58 |
| 89 |
I0-28050 816-0 |
|
BOLT ELEMENT TO CASE |
4 |
9312- |
|
4BE1 |
M 8 X 16 ( NKR 58 ) |
| 103 |
I0-50540 825-0 |
|
BOLT OIL COOLER |
2 |
9312- |
|
4BE1 |
M 8 X 25 W/SP WASHER |
| 113 |
I9-09571 420-0 |
|
GASKET PLUG, OIL COOLER CASE |
1 |
9312- |
|
4BE1 |
ID=20.5 OD =28.0 |
| 265 |
I8-98328 486-0 |
|
BODY OIL FILTER |
1 |
0211-0701 |
|
4HG1 |
NKR 71 |
| 329 |
I0-28050 835-0 |
|
BOLT OIL FILTER |
2 |
0702- |
|
4JB1-TC |
(A) M8X32, NKR55 EURO2 |
| 111 |
I8-97334 101-1 |
|
CORE OIL COOLER |
1 |
9909- |
|
4HF1 |
NKR 66, NKR 71 |
| 272 |
I8-98087 965-0 |
|
GASKET OIL FILTER TO C/BL |
1 |
0702- |
|
4JB1-TC |
NKR55 EURO2 |
| 469 |
I8-94399 716-1 |
|
GASKET OIL COOLER TO C/BL |
1 |
9312-9701 |
|
4HF1 |
(C) NKR 66 |
| 111 |
I8-97028 739-0 |
|
CORE OIL COOLER |
1 |
9312-9908 |
|
4HF1 |
NKR 66 |
| 70 |
I8-94167 885-0 |
|
GASKET PULG, OIL FILTER |
1 |
9312- |
|
4JB1 |
(B) ID=8.8 ( NHR 55 ) |
| 2 |
I8-94430 983-1 |
|
ELEMENT OIL FILTER |
1 |
9312-0311 |
|
4JB1 |
NHR 55 |
| 103 |
I0-50540 835-0 |
|
BOLT OIL COOLER |
9 |
9312- |
|
4BE1 |
M 8X35 W/SP WASHER (NKR 58 ) |
| 272 |
I8-98087 965-0 |
|
GASKET OIL FILTER TO C/BL |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 265 |
I8-98328 486-0 |
|
BODY OIL FILTER |
1 |
0702-1010 |
|
4HG1-T |
NKR71 EURO 2 |
| 1 |
I8-97224 298-2 |
|
FILTER & COOLER ASM OIL |
1 |
0702-1010 |
|
4JB1-TC |
NHR/NKR55 EURO 2
|
| 555 |
I8-97212 335-1 |
|
HOUSING COOLER |
1 |
1108- |
|
4HG1 |
NKR71 |
.png)
.png)
