| 4 |
I1-15729 795-0 |
|
PLATE START SPRING, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 71 |
I8-97026 929-0 |
|
SPRING CONT LEVER, GOV |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 271 |
I1-15729 810-2 |
|
ROD TORQUE CAM, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 55 |
I8-94239 373-0 |
|
GASKET MAG VLV, INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 90 |
I1-15729 843-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4HF1 |
(B) M6X32 ( NKR 66, NKR 71 ) |
| 51 |
I8-94363 187-0 |
|
SHAFT LOAD CONT LEVER, GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 237 |
I1-15729 967-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4HF1 |
T=0.50 ( NKR 66, NKR 71 ) |
| 48 |
I8-94171 146-1 |
|
SHAFT GOV, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 20 |
I8-94408 526-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=3.30 ( NHR 55 ) |
| 90 |
I8-94313 253-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9902- |
|
4HF1-2 |
(C) 01.531 ( NKR 66-2 ) |
| 53 |
I8-94227 585-0 |
|
GASKET CONT SHAFT. GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 336 |
I5-15729 181-0 |
|
COLLAR LEVER |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 52 |
I8-94227 590-0 |
|
WASHER CONT SHAFT, GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 50 |
I8-94171 147-0 |
|
NUT GOV SHAFT, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 79 |
I1-15729 896-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.60 ( NKR 66 ) |
| 237 |
I1-15729 968-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4HF1 |
T=0.80 ( NKR 66, NKR 71 ) |
| 46 |
I8-94336 938-0 |
|
SPRING GOV, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 37 |
I8-94339 965-0 |
|
LEVER ASM TENSION, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 79 |
I1-15729 826-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4BE1 |
(B) T=0.35 ( NKR 58 ) |
| 163 |
I1-15629 859-0 |
|
GASKET CONT SHAFT, GOV |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 12 |
I5-15722 017-0 |
|
FLYWEIGHT ASM GOV |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 7 |
I8-97142 961-0 |
|
COVER GOV HSG, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 64 |
I8-97086 120-0 |
|
LEVER LOAD CONT, GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 13 |
I8-94221 411-0 |
|
KEY FLYWEIGHT, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 150 |
I9-81315 065-0 |
|
ADAPTER GOV HSG, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 130 |
I1-15725 527-0 |
|
LEVER CONT, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 121 |
I9-01910 612-0 |
|
BOLT ENG STOP LEVER, GOV |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 15 |
I8-94227 614-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 128 |
I9-81325 556-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4HF1 |
T=0.50 ( NKR 66, NKR 71 ) |
| 13 |
I8-94221 411-0 |
|
KEY FLYWEIGHT, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 128 |
I9-81325 558-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4BE1 |
T=0.40 ( NKR 58 ) |
| 295 |
I9-81325 445-0 |
|
RING SNAP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 50 |
I8-94171 147-0 |
|
NUT GOV SHAFT, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 16 |
I9-81325 086-0 |
|
NUT FLYWEIGHT FIX, GOV |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 49 |
I8-94227 606-0 |
|
GASKET GOV SHAFT, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 305 |
I1-15729 700-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4BE1 |
T=0.20 ( NKR 58 ) |
| 108 |
I8-94368 298-1 |
|
COLLAR SWIVEL LEVER, GOVERNOR |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 56 |
I8-94343 355-0 |
|
WIRE LEAD, MAG VLV, INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 177 |
I9-81325 445-0 |
|
RING SNAP, GOV LEVER, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 270 |
I5-15729 051-0 |
|
NUT TORQUE ROD LK,GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 2 |
I8-97024 866-0 |
|
HOUSING GOV, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 411 |
I1-15719 005-0 |
|
BOLT BRKT |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 90 |
I1-15729 803-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 336 |
I5-15729 181-0 |
|
COLLAR LEVER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 235 |
I8-97121 626-0 |
|
SPRING OUTER, GOV, INJ PUMP |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 28 |
I1-15725 485-0 |
|
LEVER SUPPORTING, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 93 |
I8-97026 924-0 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9312- |
|
4HF1 |
(C) (F) NKR 66, NKR 71 |
| 79 |
I1-15729 082-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.50 ( NKR 71 ) |
| 8 |
I5-15729 033-0 |
|
BOLT GOV COVER, INJ PUMP |
7 |
9312- |
|
4HF1 |
NKR 66 |
| 18 |
I5-15729 372-0 |
|
SLEEVE GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 163 |
I1-15629 859-0 |
|
GASKET CONT SHAFT, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 237 |
I8-94472 268-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4BE1 |
T=0.10 ( NKR 58 ) |
| 23 |
I1-15725 928-0 |
|
LINK LEVER TO CONT RACK, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 34 |
I8-94171 140-1 |
|
SPRING SPD CONT LEVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 79 |
I1-15729 079-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.30 ( NKR 71 ) |
| 130 |
I1-15725 527-0 |
|
LEVER CONT, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 169 |
I5-15723 032-0 |
|
SPRING LEVER SET, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 71 |
I1-15723 295-0 |
|
SPRING CONT LEVER, GOV |
1 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 117 |
I8-94336 925-0 |
|
SPRING STOP LEVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 79 |
I1-15729 827-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4BE1 |
(B) T=0.25 ( NKR 58 ) |
| 305 |
I1-15729 701-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4BE1 |
T=0.40 ( NKR 58 ) |
| 197 |
I5-15725 008-0 |
|
SHAFT LEVER, GOV COVER |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 15 |
I5-15729 034-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 96 |
I8-94171 145-0 |
|
PLUG LEVER SHAFT, GOV |
1 |
9312- |
|
4HF1 |
(B) NKR 66, NKR 71 |
| 12 |
I8-94228 403-0 |
|
FLYWEIGHT ASM GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 79 |
I1-15729 081-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.40 ( NKR 66 ) |
| 3 |
I5-15729 071-0 |
|
BOLT GOV HSG, INJ PUMP |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 96 |
I8-94171 145-0 |
|
PLUG LEVER SHAFT, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 128 |
I1-15729 898-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4HF1 |
T=0.80 ( NKR 66, NKR 71 ) |
| 464 |
I8-97214 519-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 79 |
I1-15729 517-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(C) ( NKR 66 ) |
| 79 |
I1-15729 618-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.90 ( NKR 66 ) |
| 79 |
I1-15729 517-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(C) ( NKR 66 ) |
| 38 |
I1-15729 370-0 |
|
PIN TENSION LVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 17 |
I8-94227 611-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4JB1 |
T=1.85 ( NHR 55 ) |
| 423 |
I1-15729 820-0 |
|
SHAFT CONT, GOV HSG, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 237 |
I8-94472 270-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4BE1 |
T=0.25 ( NKR 58 ) |
| 167 |
I8-94247 717-0 |
|
BOLT PLATE |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 252 |
I1-15779 003-1 |
|
SCREW GUIDE |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 302 |
I8-97176 489-0 |
|
PLATE CAM, GOV |
1 |
0211- |
|
4HF1 |
NKR 66 |
| 117 |
I8-94171 167-0 |
|
SPRING STOP LEVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 269 |
I5-15723 290-0 |
|
SPRING ROD OUTER, TORQUE CAM, GOV |
1 |
9312- |
|
4HF1 |
(B) NKR 66 |
| 116 |
I8-97121 632-0 |
|
LEVER ENG STOP, GOV |
1 |
0211- |
|
4HG1 |
(B) NKR 66, NKR 71 |
| 169 |
I5-15723 032-0 |
|
SPRING LEVER SET, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 175 |
I1-15729 459-1 |
|
LEVER GOV, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 51 |
I8-94363 187-0 |
|
SHAFT LOAD CONT LEVER, GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 82 |
I1-15729 236-0 |
|
NUT CONT LEVER FIX, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 96 |
I5-15729 076-0 |
|
PLUG LEVER SHAFT, GOV |
1 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 234 |
I1-15723 355-0 |
|
SPRING INNER, GOV INJ PUMP |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 4 |
I1-15779 591-0 |
|
PLATE START SPRING, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 224 |
I8-94171 142-0 |
|
SHIFTER TENSION LEVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 50 |
I8-94473 129-0 |
|
NUT GOV SHAFT, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 8 |
I8-94227 636-0 |
|
BOLT GOV COVER, INJ PUMP |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 48 |
I8-94248 002-0 |
|
SHAFT GOV, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 237 |
I8-94472 271-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4HF1 |
T=1.00 ( NKR 66, NKR 71 ) |
| 302 |
I8-97104 951-0 |
|
PLATE CAM, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 20 |
I8-94408 531-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=4.30 ( NHR 55 ) |
| 7 |
I8-94320 283-0 |
|
COVER GOV HSG, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 237 |
I8-94472 271-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4BE1 |
T=1.00 ( NKR 58 ) |
| 126 |
I1-15729 853-0 |
|
GASKET STOP LEVER, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 270 |
I5-15729 051-0 |
|
NUT TORQUE ROD LK,GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 12 |
I5-15722 017-0 |
|
FLYWEIGHT ASM GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 305 |
I9-81325 553-0 |
|
SHIM STOP LEVER GOV |
1 |
9312- |
|
4HF1 |
T=1.00 ( NKR 66, NKR 71 ) |
| 199 |
I5-15729 076-0 |
|
PLUG LEVER SHAFT, GOV COVER |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 20 |
I8-94408 527-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=3.50 ( NHR 55 ) |
| 20 |
I8-94372 500-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9902- |
|
4HF1-2 |
L=5.30 ( NKR 66-2 ) |
| 90 |
I1-15729 799-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 7 |
I8-94413 725-0 |
|
COVER GOV HSG, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 267 |
I1-15729 858-0 |
|
BOLT CONN, CONT RACK, GOVERNOR |
1 |
0211- |
|
4HF1 |
NKR 66, NKR 71 |
| 15 |
I5-15729 034-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 128 |
I9-81325 556-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4BE1 |
T=0.50 ( NKR 58 ) |
| 64 |
I8-94123 992-0 |
|
LEVER LOAD CONT, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 17 |
I8-94231 123-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9902- |
|
4HF1-2 |
T=1.15 ( NKR66-2 ) |
| 464 |
I8-97168 229-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 20 |
I8-94428 878-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=4.20 ( NHR 55 ) |
| 464 |
I8-97214 517-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 151 |
I0-50540 818-0 |
|
BOLT ADAPTER, GOV HSG, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 3 |
I5-15729 027-0 |
|
BOLT GOV HSG, INJ PUMP |
5 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 4 |
I1-15779 591-0 |
|
PLATE START SPRING, GOV |
1 |
0106- |
|
4HF1 |
( FOR ASSY 8-97212 102-0 ) |
| 46 |
I8-97115 984-0 |
|
SPRING GOV, INJ PUMP |
1 |
0106- |
|
4HF1 |
(A) NKR 66, NKR 71 |
| 12 |
I5-15722 017-0 |
|
FLYWEIGHT ASM GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 269 |
I5-15723 070-1 |
|
SPRING ROD OUTER, TORQUE CAM, GOV |
1 |
0106- |
|
4HF1 |
(B) NKR 66 |
| 168 |
I1-15729 796-0 |
|
PLUG CONT SHAFT, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 235 |
I1-15723 094-0 |
|
SPRING OUTER, GOV, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 93 |
I1-15729 643-0 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 46 |
I8-94473 128-0 |
|
SPRING GOV, INJ PUMP |
2 |
0702- |
|
4JB1-TC |
(C) NHR55,NKR55 EURO 2 |
| 253 |
I8-94167 792-0 |
|
LIMITTER GOV CONT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 282 |
I8-97148 143-0 |
|
SCREW POTENTIO METER |
2 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 126 |
I1-15729 853-0 |
|
GASKET STOP LEVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 140 |
I8-94313 203-0 |
|
BOLT BRKT, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
(C) NHR55,NKR55 EURO 2 |
| 128 |
I9-81325 557-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4BE1 |
T=0.30 ( NKR 58 ) |
| 271 |
I1-15729 810-2 |
|
ROD TORQUE CAM, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 104 |
I8-94316 264-0 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9902- |
|
4HF1-2 |
(B) L=21.0 NKR66-2 |
| 79 |
I1-15729 080-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.35 ( NKR 66 ) |
| 82 |
I1-15729 236-0 |
|
NUT CONT LEVER FIX, GOV |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 224 |
I8-94171 142-0 |
|
SHIFTER TENSION LEVER, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 82 |
I1-15729 236-0 |
|
NUT CONT LEVER FIX, GOV |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 272 |
I8-94171 138-0 |
|
SCREW ADJ, TORQUE CAM ROD, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 272 |
I8-94171 138-0 |
|
SCREW ADJ, TORQUE CAM ROD, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 101 |
I8-94227 598-0 |
|
GASKET ADJ SPRING CAPSULE, GOVE |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 17 |
I8-94227 609-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9902- |
|
4HF1-2 |
T=1.45 ( NKR66-2 ) |
| 57 |
I8-94473 135-0 |
|
NUT VLV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 53 |
I8-94227 585-0 |
|
GASKET CONT SHAFT. GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 24 |
I8-94344 426-0 |
|
SPRING START, GOV, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 7 |
I8-97142 963-0 |
|
COVER GOV HSG, INJ PUMP |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 64 |
I8-97086 121-0 |
|
LEVER LOAD CONT, GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 125 |
I8-94171 168-0 |
|
CAP STOP LEVER SPRING, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 128 |
I9-81325 558-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4HF1 |
T=0.40 ( NKR 66, NKR 71 ) |
| 179 |
I8-94171 132-0 |
|
LEVER SPD ADJ, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 90 |
I1-15729 801-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 16 |
I9-81325 086-0 |
|
NUT FLYWEIGHT FIX, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 11 |
I1-15779 107-0 |
|
GASKET COVER TO HSG, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 64 |
I8-97121 634-0 |
|
LEVER LOAD CONT, GOV |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 79 |
I1-15729 517-0 |
|
SHIM LEVER SETTING, GOV |
1 |
9312- |
|
4BE1 |
(C) ( NKR 58 ) |
| 79 |
I8-94344 427-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4BE1 |
(B) T=0.60 ( NKR 58 ) |
| 179 |
I8-94171 132-0 |
|
LEVER SPD ADJ, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 102 |
I8-94227 593-0 |
|
WASHER FULL LOAD ADJ SCREW, GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 15 |
I8-94227 614-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
9902- |
|
4HF1-2 |
(B) NKR66-2 |
| 65 |
I8-97026 928-0 |
|
BRACKET RETURN SPRING, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 11 |
I8-97136 413-0 |
|
GASKET COVER TO HSG, GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 53 |
I8-94227 585-0 |
|
GASKET CONT SHAFT. GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 276 |
I1-15725 534-0 |
|
LEVER ASM LOAD CONT, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 184 |
I8-94325 502-0 |
|
BOLT GOV CENTER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 121 |
I9-01900 616-0 |
|
BOLT ENG STOP LEVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 79 |
I1-15729 619-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.80 ( NKR 66 ) |
| 133 |
I8-94313 264-0 |
|
BOLT BRKT FIX, GOV |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 116 |
I1-15725 479-0 |
|
LEVER ENG STOP, GOV |
1 |
9312- |
|
4HF1 |
(A) NKR 66 |
| 126 |
I9-81391 906-0 |
|
GASKET STOP LEVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 17 |
I8-94231 126-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9902- |
|
4HF1-2 |
T=1.75 ( NKR66-2 ) |
| 51 |
I8-94325 501-0 |
|
SHAFT LOAD CONT LEVER, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 17 |
I1-15729 891-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4HF1 |
T=2.00 ( NKR 66, NKR 71 ) |
| 1 |
I8-97225 683-0 |
|
GOVERNOR ASM INJ PUMP |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 463 |
I8-97147 144-0 |
|
BOOT POTENTIO MOTER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 150 |
I9-81315 065-0 |
|
ADAPTER GOV HSG, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 14 |
I8-94227 613-0 |
|
HOLDER GOV FLYWEIGHT, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 18 |
I5-15729 372-0 |
|
SLEEVE GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 28 |
I8-94171 152-0 |
|
LEVER SUPPORTING, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 12 |
I5-15722 017-0 |
|
FLYWEIGHT ASM GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 96 |
I5-15729 076-0 |
|
PLUG LEVER SHAFT, GOV |
1 |
9312- |
|
4HF1 |
(A) NKR 66, NKR 71 |
| 104 |
I8-97085 021-0 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9312- |
|
4HF1 |
(A) (C) , NKR 66, NKR 71 |
| 64 |
I8-97026 934-1 |
|
LEVER LOAD CONT, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 37 |
I8-94339 965-0 |
|
LEVER ASM TENSION, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 79 |
I1-15729 618-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.90 ( NKR 66 ) |
| 90 |
I8-94316 276-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9902- |
|
4HF1-2 |
(B) L=57.0 ( NKR 66-2 ) |
| 71 |
I8-94132 785-0 |
|
SPRING CONT LEVER, GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 464 |
I8-97168 231-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 17 |
I8-94227 608-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4JB1 |
T=1.25 ( NHR 55 ) |
| 197 |
I5-15725 008-0 |
|
SHAFT LEVER, GOV COVER |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 98 |
I8-94433 808-0 |
|
GASKET PIVOT BOLT, GOV LEVER |
2 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 135 |
I8-97231 937-0 |
|
BRACKET, POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 8 |
I5-15729 033-0 |
|
BOLT GOV COVER, INJ PUMP |
5 |
0702- |
|
4HG1-T |
(A) NKR71 EURO 2 |
| 67 |
I1-15729 005-0 |
|
BOLT SPRING BRKT, GOV |
2 |
9312- |
|
4HF1 |
(A) NKR 66 |
| 17 |
I9-81325 553-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4BE1 |
T=1.00 ( NKR 58 ) |
| 267 |
I1-15729 797-0 |
|
BOLT CONN, CONT RACK, GOVERNOR |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 464 |
I8-97214 518-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 170 |
I5-15723 033-0 |
|
SPRING LEVER TO LEVER, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 79 |
I1-15729 081-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.40 ( NKR 66 ) |
| 90 |
I1-15729 802-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 237 |
I1-15729 966-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4BE1 |
T=0.30 ( NKR 58 ) |
| 170 |
I5-15723 033-0 |
|
SPRING LEVER TO LEVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 20 |
I8-94372 501-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9902- |
|
4HF1-2 |
L=5.40 ( NKR 66-2 ) |
| 74 |
I9-09160 506-0 |
|
WASHER LEVER SPR |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 79 |
I1-15729 619-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.80 ( NKR 66 ) |
| 79 |
I1-15729 702-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4BE1 |
(B) T=0.20 ( NKR 58 ) |
| 116 |
I8-97026 920-1 |
|
LEVER ENG STOP, GOV |
1 |
9312- |
|
4HF1 |
(B) NKR 66 |
| 79 |
I1-15729 077-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.20 ( NKR 71 ) |
| 7 |
I8-97142 962-0 |
|
COVER GOV HSG, INJ PUMP |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 93 |
I1-15729 807-0 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 46 |
I8-97115 982-0 |
|
SPRING GOV, INJ PUMP |
1 |
9312- |
|
4HF1 |
(B) NKR 66 |
| 79 |
I1-15729 080-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.35 ( NKR 71 ) |
| 79 |
I1-15729 617-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.70 ( NKR 66 ) |
| 177 |
I9-81325 445-0 |
|
RING SNAP, GOV LEVER, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 18 |
I5-97214 475-0 |
|
SLEEVE GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 96 |
I8-94171 148-0 |
|
PLUG LEVER SHAFT, GOV |
1 |
9312- |
|
4HF1 |
(C) NKR 66, NKR 71 |
| 97 |
I8-94227 601-0 |
|
BOLT PIVOT, GOV LEVER |
2 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 175 |
I8-97176 488-0 |
|
LEVER GOV, INJ PUMP |
1 |
0211- |
|
4HF1 |
NKR 66, NKR 71 |
| 20 |
I8-94428 876-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=3.80 ( NHR 55 ) |
| 52 |
I8-94227 590-0 |
|
WASHER CONT SHAFT, GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 55 |
I8-94239 373-0 |
|
GASKET MAG VLV, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 17 |
I5-15729 286-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4BE1 |
T=0.50 ( NKR 58 ) |
| 184 |
I8-94325 502-0 |
|
BOLT GOV CENTER |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 93 |
I8-94316 277-0 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9902- |
|
4HF1-2 |
(B) NKR66-2 |
| 163 |
I1-15629 859-0 |
|
GASKET CONT SHAFT, GOV |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 128 |
I9-88410 421-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4HF1 |
T=0.20 ( NKR 66, NKR 71 ) |
| 18 |
I5-15729 372-0 |
|
SLEEVE GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 12 |
I8-94228 403-0 |
|
FLYWEIGHT ASM GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 82 |
I1-15729 006-0 |
|
NUT CONT LEVER FIX, GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 8 |
I1-15729 535-0 |
|
BOLT GOV COVER, INJ PUMP |
2 |
0702- |
|
4HG1-T |
(B) NKR71 EURO 2 |
| 90 |
I1-15729 761-0 |
|
SCREW FULL LOAD ADJ, GOV |
2 |
9312- |
|
4HF1 |
(A) M8X65 ( NKR 66, NKR 71 ) |
| 138 |
I8-97214 513-0 |
|
POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 48 |
I8-94171 146-1 |
|
SHAFT GOV, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 116 |
I1-15725 479-0 |
|
LEVER ENG STOP, GOV |
1 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 8 |
I5-15729 033-0 |
|
BOLT GOV COVER, INJ PUMP |
7 |
9312- |
|
4BE1 |
NKR 58 |
| 169 |
I5-15723 032-0 |
|
SPRING LEVER SET, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 268 |
I5-15723 070-1 |
|
SPRING ROD INNER, TORQUE CAM, GOV |
1 |
9312- |
|
4HF1 |
(B) NKR 66 |
| 90 |
I8-94426 049-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9902- |
|
4HF1-2 |
(A) 01.531 ( NKR 66-2 ) |
| 237 |
I8-94472 270-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4HF1 |
T=0.25 ( NKR 66, NKR 71 ) |
| 11 |
I1-15779 107-0 |
|
GASKET COVER TO HSG, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 104 |
I8-94316 264-0 |
|
CAP LOCK NUT. ADJ SCREW |
AR |
9312- |
|
4JB1 |
L=21.0 ( NHR 55 ) |
| 237 |
I8-94472 269-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4HF1 |
T=0.20 ( NKR 66, NKR 71 ) |
| 104 |
I8-94316 263-0 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9902- |
|
4HF1-2 |
(B) L=18.0 NKR66-2 |
| 305 |
I8-97089 310-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4HF1 |
T=0.40 ( NKR 66, NKR 71 ) |
| 17 |
I8-94227 610-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9902- |
|
4HF1-2 |
T=1.65 ( NKR66-2 ) |
| 64 |
I8-97175 326-0 |
|
LEVER LOAD CONT, GOV |
1 |
9902- |
|
4HF1-2 |
STAMP 194, NKR66-2 |
| 295 |
I9-81325 445-0 |
|
RING SNAP |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 175 |
I1-15729 459-1 |
|
LEVER GOV, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 71 |
I8-97101 205-0 |
|
SPRING CONT LEVER, GOV |
2 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 304 |
I0-91805 504-0 |
|
RING SNAP, LINK TO CAM PLATE, GOVE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 287 |
I1-15725 542-0 |
|
LEVER GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 119 |
I1-15729 236-0 |
|
NUT ENG STOP LEVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 48 |
I8-94171 146-1 |
|
SHAFT GOV, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 4 |
I1-15779 591-0 |
|
PLATE START SPRING, GOV |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 98 |
I8-94433 808-0 |
|
GASKET PIVOT BOLT, GOV LEVER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 90 |
I1-15729 843-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 79 |
I1-15729 896-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.60 ( NKR 71 ) |
| 5 |
I1-15779 093-0 |
|
GASKET GOV TO INJ PUMP HSG |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 20 |
I8-94428 877-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=4.00 ( NHR 55 ) |
| 11 |
I8-97136 413-0 |
|
GASKET COVER TO HSG, GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 291 |
I9-81325 445-0 |
|
RING SNAP, CON SHAFT, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 92 |
I8-94313 253-0 |
|
BOLT FULL LOAD STOPPER, GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 128 |
I1-15729 898-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4BE1 |
T=0.80 ( NKR 58 ) |
| 139 |
I8-97211 766-0 |
|
BRACKET INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 456 |
I8-94413 728-0 |
|
SPRING LEVER, GOV |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 79 |
I1-15729 565-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4BE1 |
(B) T=0.30 ( NKR 58 ) |
| 291 |
I9-81325 445-0 |
|
RING SNAP, CON SHAFT, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 276 |
I8-94325 500-0 |
|
LEVER ASM LOAD CONT, GOV |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 141 |
I8-94174 822-0 |
|
PLATE ASM PIPE BRKT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 37 |
I8-94339 976-0 |
|
LEVER ASM TENSION, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 13 |
I8-94221 411-0 |
|
KEY FLYWEIGHT, GOV |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 75 |
I1-15729 963-0 |
|
TUBE RETRUN SPRING, STOPPER LEVE |
2 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 17 |
I8-94231 124-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9902- |
|
4HF1-2 |
T=1.35 ( NKR66-2 ) |
| 45 |
I8-97168 214-0 |
|
LEVER ASM GOV, INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 133 |
I8-94331 551-0 |
|
BOLT BRKT FIX, GOV |
3 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 79 |
I1-15729 081-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.40 ( NKR 71 ) |
| 464 |
I8-97214 516-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 8 |
I5-15729 033-0 |
|
BOLT GOV COVER, INJ PUMP |
7 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 15 |
I8-94227 612-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
0702- |
|
4JB1-TC |
(A) NHR55,NKR55 EURO 2 |
| 79 |
I1-15729 617-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.70 ( NKR 66 ) |
| 3 |
I5-15729 027-0 |
|
BOLT GOV HSG, INJ PUMP |
5 |
9312- |
|
4HF1 |
(A) M6X15 ( NKR 66, NKR 71 ) |
| 57 |
I8-97138 042-1 |
|
NUT VLV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 121 |
I9-01900 616-0 |
|
BOLT ENG STOP LEVER, GOV |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 64 |
I8-97332 321-0 |
|
LEVER LOAD CONT, GOV |
1 |
9902- |
|
4HF1-2 |
STAMP 194, NKR66-2 |
| 128 |
I9-81325 560-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4BE1 |
T=0.35 ( NKR 58 ) |
| 17 |
I5-15729 287-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4BE1 |
T=1.50 ( NKR 58 ) |
| 20 |
I8-94428 875-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=3.60 ( NHR 55 ) |
| 20 |
I8-94372 499-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9902- |
|
4HF1-2 |
L=5.20 ( NKR 66-2 ) |
| 51 |
I1-15729 876-0 |
|
SHAFT LOAD CONT LEVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 79 |
I1-15729 619-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.80 ( NKR 71 ) |
| 128 |
I9-88410 421-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4BE1 |
T=0.20 ( NKR 58 ) |
| 133 |
I8-94343 302-0 |
|
BOLT BRKT FIX, GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 253 |
I8-94167 792-0 |
|
LIMITTER GOV CONT |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 39 |
I9-88410 201-0 |
|
RING SNAP, LEVER PIN, GOV |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 448 |
I8-97182 233-0 |
|
PLATE BRKT |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 268 |
I5-15723 070-1 |
|
SPRING ROD INNER, TORQUE CAM, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 15 |
I5-15729 034-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 128 |
I9-81325 560-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4HF1 |
T=0.35 ( NKR 66, NKR 71 ) |
| 41 |
I8-97109 745-0 |
|
SPRING CAPSULE IDLE CONT, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 234 |
I8-94368 299-1 |
|
SPRING INNER, GOV INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 90 |
I1-15729 802-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4HF1 |
(B) M6X36 ( NKR 66, NKR 71 ) |
| 79 |
I8-97066 844-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(A) ( NKR 66 ) |
| 39 |
I9-88410 201-0 |
|
RING SNAP, LEVER PIN, GOV |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 18 |
I5-15729 372-0 |
|
SLEEVE GOV |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 92 |
I8-94426 049-0 |
|
BOLT FULL LOAD STOPPER, GOV |
1 |
9902- |
|
4HF1-2 |
01.531 ( NKR 66-2 ) |
| 133 |
I8-94247 717-0 |
|
BOLT BRKT FIX, GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 38 |
I1-15729 370-0 |
|
PIN TENSION LVER, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 181 |
I8-97214 506-0 |
|
SPACER BRKT |
2 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 20 |
I8-94408 528-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=3.70 ( NHR 55 ) |
| 268 |
I5-15723 056-0 |
|
SPRING ROD INNER, TORQUE CAM, GOV |
1 |
9312- |
|
4HF1 |
(A) NKR 66 |
| 79 |
I1-15729 896-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.60 ( NKR 66 ) |
| 140 |
I8-94313 267-0 |
|
BOLT BRKT, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
(B) NHR55,NKR55 EURO 2 |
| 71 |
I8-97121 629-0 |
|
SPRING CONT LEVER, GOV |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 93 |
I9-84410 027-0 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9312- |
|
4BE1 |
(C) NKR 58 |
| 5 |
I1-15779 093-0 |
|
GASKET GOV TO INJ PUMP HSG |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 19 |
I8-94408 519-0 |
|
CAP GOV SLEEVE, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 130 |
I1-15725 527-0 |
|
LEVER CONT, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 4 |
I1-15729 795-0 |
|
PLATE START SPRING, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 1 |
I8-97109 734-0 |
|
GOVERNOR ASM INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 17 |
I9-81325 552-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4HF1 |
T=0.40 ( NKR 66, NKR 71 ) |
| 456 |
I8-94413 728-0 |
|
SPRING LEVER, GOV |
1 |
0106- |
|
4HF1 |
(B) NKR 66 |
| 71 |
I8-94413 728-0 |
|
SPRING CONT LEVER, GOV |
1 |
9312- |
|
4BE1 |
(C) NKR 58 |
| 8 |
I8-94227 636-0 |
|
BOLT GOV COVER, INJ PUMP |
4 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 197 |
I5-15725 008-0 |
|
SHAFT LEVER, GOV COVER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 17 |
I9-81325 553-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4HF1 |
T=1.00 ( NKR 66, NKR 71 ) |
| 79 |
I1-15729 082-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.50 ( NKR 66 ) |
| 56 |
I8-94470 582-0 |
|
WIRE LEAD, MAG VLV, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 21 |
I8-94339 977-0 |
|
LEVER ASM GUID, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 464 |
I8-97168 232-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 52 |
I8-94227 590-0 |
|
WASHER CONT SHAFT, GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 132 |
I8-97211 763-0 |
|
BRACKET ADJ SCREW |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 90 |
I1-15729 803-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4HF1 |
(B) M6X37 ( NKR 66, NKR 71 ) |
| 464 |
I8-97214 515-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 28 |
I1-15725 472-0 |
|
LEVER SUPPORTING, GOV |
1 |
9312- |
|
4HF1 |
(A) NKR 66 |
| 163 |
I8-94171 129-0 |
|
GASKET CONT SHAFT, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 48 |
I8-94248 002-0 |
|
SHAFT GOV, INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 46 |
I8-94473 128-0 |
|
SPRING GOV, INJ PUMP |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 151 |
I0-50540 818-0 |
|
BOLT ADAPTER, GOV HSG, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 15 |
I8-94227 612-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
9312- |
|
4JB1 |
(A) NHR 55 |
| 79 |
I1-15729 079-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.30 ( NKR 66 ) |
| 267 |
I1-15729 797-0 |
|
BOLT CONN, CONT RACK, GOVERNOR |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 64 |
I8-97026 934-1 |
|
LEVER LOAD CONT, GOV |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 96 |
I8-94171 148-0 |
|
PLUG LEVER SHAFT, GOV |
1 |
9312- |
|
4BE1 |
(C) NKR 58 |
| 170 |
I5-15723 033-0 |
|
SPRING LEVER TO LEVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 93 |
I1-15729 643-0 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9312- |
|
4HF1 |
(A) (D) NKR 66, NKR 71 |
| 46 |
I8-97115 984-0 |
|
SPRING GOV, INJ PUMP |
1 |
9312- |
|
4HF1 |
(A) NKR 66 |
| 17 |
I1-15729 892-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4BE1 |
T=3.00 ( NKR 58 ) |
| 92 |
I8-94426 049-0 |
|
BOLT FULL LOAD STOPPER, GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 79 |
I1-15729 082-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.50 ( NKR 66 ) |
| 51 |
I8-97211 764-0 |
|
SHAFT LOAD CONT LEVER, GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 17 |
I8-94227 607-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4JB1 |
T=1.05 ( NHR 55 ) |
| 82 |
I0-91110 506-0 |
|
NUT CONT LEVER FIX, GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 20 |
I8-94408 530-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=4.10 ( NHR 55 ) |
| 79 |
I1-15729 703-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4BE1 |
(B) T=0.40 NKR 58 ) |
| 97 |
I8-94227 601-0 |
|
BOLT PIVOT, GOV LEVER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 93 |
I8-94316 277-0 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 54 |
I8-94433 811-0 |
|
VALVE MAG, ENG STOP, INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 90 |
I1-15729 801-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4HF1 |
(B) M6X35 ( NKR 66, NKR 71 ) |
| 119 |
I1-15729 236-0 |
|
NUT ENG STOP LEVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 46 |
I8-97115 982-0 |
|
SPRING GOV, INJ PUMP |
1 |
0106- |
|
4HF1 |
(B) NKR 66, NKR 71 |
| 128 |
I1-15729 897-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4BE1 |
T=0.60 ( NKR 58 ) |
| 55 |
I8-94239 373-0 |
|
GASKET MAG VLV, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 304 |
I0-91805 504-0 |
|
RING SNAP, LINK TO CAM PLATE, GOVE |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 93 |
I8-94426 047-1 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9902- |
|
4HF1-2 |
(C) NKR 66-2 |
| 116 |
I8-97024 867-0 |
|
LEVER ENG STOP, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 276 |
I1-15725 534-0 |
|
LEVER ASM LOAD CONT, GOV |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 57 |
I8-94473 135-0 |
|
NUT VLV |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 64 |
I8-97175 325-0 |
|
LEVER LOAD CONT, GOV |
1 |
9902- |
|
4HF1-2 |
STAMP 193, NKR66-2 |
| 79 |
I8-97066 844-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(A) ( NKR 71 ) |
| 104 |
I8-94316 265-0 |
|
CAP LOCK NUT. ADJ SCREW |
AR |
9312- |
|
4JB1 |
L=24.0 ( NHR 55 ) |
| 24 |
I5-15723 035-0 |
|
SPRING START, GOV, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 46 |
I8-94473 128-0 |
|
SPRING GOV, INJ PUMP |
2 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 39 |
I9-88410 201-0 |
|
RING SNAP, LEVER PIN, GOV |
2 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 235 |
I5-15723 150-0 |
|
SPRING OUTER, GOV, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 104 |
I8-94316 266-1 |
|
CAP LOCK NUT. ADJ SCREW |
AR |
9312- |
|
4JB1 |
L=27.0 ( NHR 55 ) |
| 21 |
I8-94339 977-0 |
|
LEVER ASM GUID, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 80 |
I1-09985 179-0 |
|
WASHER LK, CONT LEVER, GOV |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 20 |
I8-94428 880-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=4.60 ( NHR 55 ) |
| 64 |
I8-97332 322-0 |
|
LEVER LOAD CONT, GOV |
1 |
9902- |
|
4HF1-2 |
STAMP 194, NKR66-2 |
| 18 |
I8-97214 475-0 |
|
SLEEVE GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 119 |
I1-15729 236-0 |
|
NUT ENG STOP LEVER, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 41 |
I8-97026 922-0 |
|
SPRING CAPSULE IDLE CONT, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 266 |
I0-91110 505-0 |
|
NUT PIN TO LINK, CONT RACK, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 93 |
I1-15729 807-0 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9312- |
|
4HF1 |
(B) (E) NKR 66, NKR 71 |
| 237 |
I1-15729 968-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4BE1 |
T=0.80 ( NKR 58 ) |
| 128 |
I1-15729 897-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4HF1 |
T=0.60 ( NKR 66, NKR 71 ) |
| 116 |
I8-97121 631-0 |
|
LEVER ENG STOP, GOV |
1 |
0211- |
|
4HG1 |
(A) NKR 66, NKR 71 |
| 102 |
I8-94227 593-0 |
|
WASHER FULL LOAD ADJ SCREW, GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 17 |
I8-94227 610-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4JB1 |
T=1.65 ( NHR 55 ) |
| 17 |
I9-81325 088-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4BE1 |
T=0.20 ( NKR 58 ) |
| 239 |
I8-94171 144-0 |
|
SCREW GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 79 |
I1-15729 828-0 |
|
SHIM LEVER SETTING, GOV |
1 |
9312- |
|
4BE1 |
(A) ( NKR 58 ) |
| 5 |
I1-15779 106-0 |
|
GASKET GOV TO INJ PUMP HSG |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 17 |
I9-81325 552-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4BE1 |
T=0.40 ( NKR 58 ) |
| 93 |
I1-15729 006-0 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
1 |
9902- |
|
4HF1-2 |
(A) NKR66-2 |
| 18 |
I8-94339 971-2 |
|
SLEEVE GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 128 |
I1-15729 899-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4BE1 |
T=0.90 ( NKR 58 ) |
| 133 |
I8-94343 302-0 |
|
BOLT BRKT FIX, GOV |
2 |
0211- |
|
4HG1 |
NKR 71 |
| 23 |
I1-15725 483-0 |
|
LINK LEVER TO CONT RACK, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 269 |
I5-15723 290-0 |
|
SPRING ROD OUTER, TORQUE CAM, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 64 |
I8-94443 056-1 |
|
LEVER LOAD CONT, GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 167 |
I8-94174 987-0 |
|
BOLT PLATE |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 82 |
I1-15729 236-0 |
|
NUT CONT LEVER FIX, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 90 |
I8-94316 275-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9902- |
|
4HF1-2 |
(B) L=55.0 ( NKR 66-2 ) |
| 184 |
I8-94325 502-0 |
|
BOLT GOV CENTER |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 411 |
I5-15729 304-0 |
|
BOLT BRKT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 12 |
I8-94228 403-0 |
|
FLYWEIGHT ASM GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 287 |
I1-15725 542-0 |
|
LEVER GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 17 |
I5-15729 286-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4HF1 |
T=0.50 ( NKR 66, NKR 71 ) |
| 80 |
I1-09985 179-0 |
|
WASHER LK, CONT LEVER, GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 , ID=6 |
| 90 |
I1-15729 799-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4HF1 |
(B) M6X33 ( NKR 66, NKR 71 ) |
| 65 |
I8-94339 966-0 |
|
BRACKET RETURN SPRING, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 11 |
I1-15779 107-0 |
|
GASKET COVER TO HSG, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 179 |
I8-94171 132-0 |
|
LEVER SPD ADJ, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 104 |
I8-94316 266-1 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9902- |
|
4HF1-2 |
(B) L=27.0 NKR66-2 |
| 198 |
I8-97085 014-0 |
|
BRACKET COVER |
2 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 16 |
I9-81325 086-0 |
|
NUT FLYWEIGHT FIX, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 17 |
I1-15729 892-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4HF1 |
T=3.00 ( NKR 66, NKR 71 ) |
| 410 |
I8-97231 936-0 |
|
BRACKET GOV |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 303 |
I5-15729 023-0 |
|
RING SNAP, CAM PLATE, GOVE |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 15 |
I8-94227 614-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
0702- |
|
4JB1-TC |
(B) NHR55,NKR55 EURO 2 |
| 239 |
I8-94171 144-0 |
|
SCREW GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 21 |
I8-94339 977-0 |
|
LEVER ASM GUID, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 102 |
I8-94227 593-0 |
|
WASHER FULL LOAD ADJ SCREW, GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 234 |
I8-94368 299-1 |
|
SPRING INNER, GOV INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 67 |
I1-15729 521-0 |
|
BOLT SPRING BRKT, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 79 |
I1-15729 076-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.95 ( NKR 66 ) |
| 23 |
I1-15725 483-0 |
|
LINK LEVER TO CONT RACK, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 79 |
I1-15729 077-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.20 ( NKR 66 ) |
| 456 |
I8-94413 728-0 |
|
SPRING LEVER, GOV |
1 |
9312- |
|
4HF1 |
(B) NKR 66 |
| 90 |
I1-15729 842-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 464 |
I8-97214 514-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 24 |
I8-94344 426-0 |
|
SPRING START, GOV, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 79 |
I1-15729 080-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.35 ( NKR 66 ) |
| 255 |
I8-94171 173-0 |
|
SEAT GOV SPRING, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 305 |
I8-97089 308-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4HF1 |
T=0.20 ( NKR 66, NKR 71 ) |
| 456 |
I1-15723 295-0 |
|
SPRING LEVER, GOV |
1 |
9312- |
|
4HF1 |
(A) NKR 66 |
| 199 |
I5-15729 076-0 |
|
PLUG LEVER SHAFT, GOV COVER |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 20 |
I8-94372 502-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9902- |
|
4HF1-2 |
L=5.50 ( NKR 66-2 ) |
| 464 |
I8-97168 233-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 167 |
I1-15729 796-0 |
|
BOLT PLATE |
1 |
0106- |
|
4HF1 |
( FOR ASSY 8-97114 005-0 ) |
| 237 |
I8-94472 269-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4BE1 |
T=0.20 ( NKR 58 ) |
| 423 |
I1-15729 820-0 |
|
SHAFT CONT, GOV HSG, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 448 |
I8-97211 767-0 |
|
PLATE BRKT |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 90 |
I1-15729 842-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4HF1 |
(B) M6X31 ( NKR 66, NKR 71 ) |
| 271 |
I5-15725 009-1 |
|
ROD TORQUE CAM, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 125 |
I8-94336 926-0 |
|
CAP STOP LEVER SPRING, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 48 |
I8-94248 002-0 |
|
SHAFT GOV, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 20 |
I8-94408 532-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=4.50 ( NHR 55 ) |
| 150 |
I9-81315 065-0 |
|
ADAPTER GOV HSG, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 464 |
I8-97214 520-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 237 |
I1-15729 967-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4BE1 |
T=0.50 ( NKR 58 ) |
| 71 |
I8-97214 511-0 |
|
SPRING CONT LEVER, GOV |
2 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 79 |
I8-97066 844-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(A) ( NKR 66 ) |
| 305 |
I8-94344 423-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4BE1 |
T=0.60 ( NKR 58 ) |
| 270 |
I5-15729 051-0 |
|
NUT TORQUE ROD LK,GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 64 |
I8-94443 055-1 |
|
LEVER LOAD CONT, GOV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 14 |
I8-94227 403-0 |
|
HOLDER GOV FLYWEIGHT, INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 303 |
I5-15729 023-0 |
|
RING SNAP, CAM PLATE, GOVE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 79 |
I1-15729 076-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.95 ( NKR 66 ) |
| 90 |
I8-94316 274-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9902- |
|
4HF1-2 |
(B) L=53.0 ( NKR 66-2 ) |
| 104 |
I8-97085 022-0 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9312- |
|
4HF1 |
(B) , (D) NKR 66, NKR 71 |
| 11 |
I1-15779 107-0 |
|
GASKET COVER TO HSG, GOV |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 79 |
I1-15729 617-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.70 ( NKR 71 ) |
| 2 |
I1-15721 265-0 |
|
HOUSING GOV, INJ PUMP |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 90 |
I8-94426 049-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 104 |
I8-94316 263-0 |
|
CAP LOCK NUT. ADJ SCREW |
AR |
9312- |
|
4JB1 |
L=18.0 ( NHR 55 ) |
| 1 |
I8-97223 285-0 |
|
GOVERNOR ASM INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 90 |
I1-15729 800-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 224 |
I8-94171 142-0 |
|
SHIFTER TENSION LEVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 17 |
I8-94227 609-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4JB1 |
T=1.45 ( NHR 55 ) |
| 188 |
I1-15729 790-0 |
|
STUD COVER |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 235 |
I1-15723 094-0 |
|
SPRING OUTER, GOV, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 90 |
I8-94316 274-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4JB1 |
(A) L=53.0 ( NHR 55 ) |
| 17 |
I8-94227 607-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9902- |
|
4HF1-2 |
T=1.05 ( NKR66-2 ) |
| 97 |
I8-94227 601-0 |
|
BOLT PIVOT, GOV LEVER |
2 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 7 |
I8-94328 617-0 |
|
COVER GOV HSG, INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 38 |
I1-15729 370-0 |
|
PIN TENSION LVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 5 |
I1-15779 093-0 |
|
GASKET GOV TO INJ PUMP HSG |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 75 |
I1-15729 963-0 |
|
TUBE RETRUN SPRING, STOPPER LEVE |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 77 |
I9-88410 201-0 |
|
RING SNAP CONT LEVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 188 |
I1-15729 790-0 |
|
STUD COVER |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 20 |
I8-94428 879-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=4.40 ( NHR 55 ) |
| 276 |
I1-15725 534-0 |
|
LEVER ASM LOAD CONT, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 16 |
I9-81325 086-0 |
|
NUT FLYWEIGHT FIX, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 128 |
I1-15729 899-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4HF1 |
T=0.90 ( NKR 66, NKR 71 ) |
| 149 |
I8-94316 278-0 |
|
WIRE VLV |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 104 |
I8-97085 022-0 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 67 |
I5-15729 304-0 |
|
BOLT SPRING BRKT, GOV |
1 |
9312- |
|
4HF1 |
(B) NKR 66 |
| 17 |
I1-15729 891-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4BE1 |
T=2.00 ( NKR 58 ) |
| 17 |
I5-15729 287-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4HF1 |
T=1.50 ( NKR 66, NKR 71 ) |
| 28 |
I1-15725 485-0 |
|
LEVER SUPPORTING, GOV |
1 |
9312- |
|
4HF1 |
(B) NKR 66 |
| 22 |
I8-94368 298-1 |
|
COLLAR LEVER., GOV |
1 |
0211- |
|
4HG1 |
NKR 66, NKR 71 |
| 71 |
I8-97026 929-0 |
|
SPRING CONT LEVER, GOV |
2 |
0106- |
|
4HF1 |
NKR 66 |
| 77 |
I9-88410 201-0 |
|
RING SNAP CONT LEVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 28 |
I1-15725 472-0 |
|
LEVER SUPPORTING, GOV |
1 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 305 |
I8-94362 696-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4BE1 |
T=0.90 ( NKR 58 ) |
| 50 |
I8-94171 147-0 |
|
NUT GOV SHAFT, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 41 |
I8-97026 922-0 |
|
SPRING CAPSULE IDLE CONT, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 17 |
I8-94227 608-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9902- |
|
4HF1-2 |
T=1.25 ( NKR66-2 ) |
| 303 |
I5-15729 023-0 |
|
RING SNAP, CAM PLATE, GOVE |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 175 |
I1-15729 459-1 |
|
LEVER GOV, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 56 |
I8-94470 582-0 |
|
WIRE LEAD, MAG VLV, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 305 |
I1-15729 564-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4BE1 |
T=0.30 ( NKR 58 ) |
| 79 |
I1-15729 618-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.90 ( NKR 71 ) |
| 252 |
I1-15779 003-1 |
|
SCREW GUIDE |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 79 |
I1-15729 077-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.20 ( NKR 66 ) |
| 1 |
I8-97214 531-3 |
|
GOVERNOR ASM INJ PUMP |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 71 |
I8-94132 785-0 |
|
SPRING CONT LEVER, GOV |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 268 |
I5-15723 056-0 |
|
SPRING ROD INNER, TORQUE CAM, GOV |
1 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 54 |
I8-94239 372-0 |
|
VALVE MAG, ENG STOP, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 79 |
I1-15729 078-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.25 ( NKR 71 ) |
| 423 |
I1-15729 820-0 |
|
SHAFT CONT, GOV HSG, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 34 |
I8-94171 140-1 |
|
SPRING SPD CONT LEVER, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 134 |
I8-97168 218-0 |
|
BRACKET CONT CABLE GOVERNOR |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 167 |
I8-94343 302-0 |
|
BOLT PLATE |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 17 |
I1-15729 893-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4HF1 |
T=4.00 ( NKR 66, NKR 71 ) |
| 128 |
I9-81325 559-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4HF1 |
T=0.25 ( NKR 66, NKR 71 ) |
| 51 |
I1-15729 876-0 |
|
SHAFT LOAD CONT LEVER, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 75 |
I8-94433 757-0 |
|
TUBE RETRUN SPRING, STOPPER LEVE |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 20 |
I8-94408 529-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=3.90 ( NHR 55 ) |
| 20 |
I8-94408 533-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=4.70 ( NHR 55 ) |
| 90 |
I1-15729 800-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4HF1 |
(B) M6X34 ( NKR 66, NKR 71 ) |
| 20 |
I8-94408 525-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L= 3.10 ( NHR 55 ) |
| 295 |
I9-81325 445-0 |
|
RING SNAP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 302 |
I8-97104 951-0 |
|
PLATE CAM, GOV |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 104 |
I8-94316 262-0 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9902- |
|
4HF1-2 |
(A) L=16.5 NKR66-2 |
| 79 |
I1-15729 078-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0106- |
|
4HF1 |
(B) T=0.25 ( NKR 66 ) |
| 54 |
I8-94239 372-0 |
|
VALVE MAG, ENG STOP, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 125 |
I8-94171 168-0 |
|
CAP STOP LEVER SPRING, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 291 |
I9-81325 445-0 |
|
RING SNAP, CON SHAFT, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 47 |
I8-94363 519-0 |
|
PIN RET |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 121 |
I9-01900 616-0 |
|
BOLT ENG STOP LEVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 7 |
I1-15729 854-0 |
|
COVER GOV HSG, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 90 |
I8-94316 276-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4JB1 |
(A) L=57.0 ( NHR 55 ) |
| 140 |
I8-97218 971-0 |
|
BOLT BRKT, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
(A) NHR55,NKR55 EURO 2 |
| 79 |
I1-15729 076-0 |
|
SHIM LEVER SETTING, GOV |
AR |
0211- |
|
4HG1 |
(B) T=0.95 ( NKR 71 ) |
| 20 |
I8-94428 874-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=3.40 ( NHR 55 ) |
| 237 |
I8-94472 268-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4HF1 |
T=0.10 ( NKR 66, NKR 71 ) |
| 117 |
I8-94336 925-0 |
|
SPRING STOP LEVER, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 128 |
I9-81325 557-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4HF1 |
T=0.30 ( NKR 66, NKR 71 ) |
| 15 |
I8-94227 612-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
9902- |
|
4HF1-2 |
(A) NKR66-2 |
| 17 |
I8-94231 125-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9902- |
|
4HF1-2 |
T=1.55 ( NKR66-2 ) |
| 464 |
I8-97168 230-0 |
|
JOINT POTENTIO METER |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 20 |
I8-94428 873-0 |
|
PLUG CLOSING, GOV SLEEVE |
1 |
9312- |
|
4JB1 |
L=3.20 ( NHR 55 ) |
| 3 |
I5-15729 071-0 |
|
BOLT GOV HSG, INJ PUMP |
1 |
9312- |
|
4HF1 |
(B) M6X16 ( NKR 66, NKR 71 ) |
| 17 |
I9-81325 551-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4BE1 |
T=0.30 ( NKR 58 ) |
| 79 |
I1-15729 078-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.25 ( NKR 66 ) |
| 19 |
I8-94227 616-0 |
|
CAP GOV SLEEVE, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 234 |
I8-94368 299-1 |
|
SPRING INNER, GOV INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 90 |
I1-15729 761-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 80 |
I1-09985 179-0 |
|
WASHER LK, CONT LEVER, GOV |
2 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 49 |
I8-94227 606-0 |
|
GASKET GOV SHAFT, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 14 |
I8-94227 613-0 |
|
HOLDER GOV FLYWEIGHT, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 128 |
I9-81325 559-0 |
|
SHIM CONT SHAFT, GOV |
AR |
9312- |
|
4BE1 |
T=0.25 ( NKR 58 ) |
| 199 |
I5-15729 076-0 |
|
PLUG LEVER SHAFT, GOV COVER |
2 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 255 |
I8-94171 173-0 |
|
SEAT GOV SPRING, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 267 |
I1-15729 797-0 |
|
BOLT CONN, CONT RACK, GOVERNOR |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 34 |
I8-94171 140-1 |
|
SPRING SPD CONT LEVER, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 98 |
I8-94433 808-0 |
|
GASKET PIVOT BOLT, GOV LEVER |
2 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 302 |
I8-97109 749-0 |
|
PLATE CAM, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 74 |
I9-09160 506-0 |
|
WASHER LEVER SPR |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 305 |
I8-97089 309-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4HF1 |
T=0.30 ( NKR 66, NKR 71 ) |
| 104 |
I8-94316 262-0 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9312- |
|
4JB1 |
L=16.5 ( NHR 55 ) |
| 237 |
I1-15729 966-0 |
|
SHIM SPR CAPSULE, TIMER, INJ PUMP |
AR |
9312- |
|
4HF1 |
T=0.30 ( NKR 66, NKR 71 ) |
| 239 |
I8-94171 144-0 |
|
SCREW GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 132 |
I8-94174 810-0 |
|
BRACKET ADJ SCREW, GOVERNOR |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 272 |
I8-94171 138-0 |
|
SCREW ADJ, TORQUE CAM ROD, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 90 |
I8-94316 275-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4JB1 |
(A) L=55.0 ( NHR 55 ) |
| 266 |
I0-91110 505-0 |
|
NUT PIN TO LINK, CONT RACK, GOV |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 17 |
I8-94227 611-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9902- |
|
4HF1-2 |
T=1.85 ( NKR66-2 ) |
| 180 |
I8-97121 643-0 |
|
PLATE GOV COVER |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 305 |
I8-97089 311-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4HF1 |
T=0.60 ( NKR 66, NKR 71 ) |
| 287 |
I1-15725 542-0 |
|
LEVER GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 151 |
I0-50540 818-0 |
|
BOLT ADAPTER, GOV HSG, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 17 |
I9-81325 088-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4HF1 |
T=0.20 ( NKR 66, NKR 71 ) |
| 17 |
I9-81325 551-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4HF1 |
T=0.30 ( NKR 66, NKR 71 ) |
| 104 |
I8-94316 265-0 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9902- |
|
4HF1-2 |
(B) L=24.0 NKR66-2 |
| 45 |
I8-97302 244-0 |
|
LEVER ASM GOV, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 304 |
I0-91805 504-0 |
|
RING SNAP, LINK TO CAM PLATE, GOVE |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 302 |
I8-97185 013-0 |
|
PLATE CAM, GOV |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 101 |
I8-94227 598-0 |
|
GASKET ADJ SPRING CAPSULE, GOVE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 268 |
I5-15723 070-1 |
|
SPRING ROD INNER, TORQUE CAM, GOV |
1 |
0106- |
|
4HF1 |
(A) NKR 66 |
| 90 |
I5-15729 123-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4BE1 |
(C) NKR 58 |
| 17 |
I1-15729 893-0 |
|
SHIM FLYWEIGHT SLEEVE, GOV |
AR |
9312- |
|
4BE1 |
T=4.00 ( NKR 58 ) |
| 79 |
I1-15729 079-0 |
|
SHIM LEVER SETTING, GOV |
AR |
9312- |
|
4HF1 |
(B) T=0.30 ( NKR 66 ) |
| 253 |
I8-94167 792-0 |
|
LIMITTER GOV CONT |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 50 |
I8-94473 129-0 |
|
NUT GOV SHAFT, INJ PUMP |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 2 |
I1-15721 209-0 |
|
HOUSING GOV, INJ PUMP |
1 |
0106- |
|
4HF1 |
NKR 66 |
| 2 |
I1-15721 265-0 |
|
HOUSING GOV, INJ PUMP |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 101 |
I8-94227 598-0 |
|
GASKET ADJ SPRING CAPSULE, GOVE |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 15 |
I5-15729 034-0 |
|
WASHER LK, FLYWEIGHT FIX, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 255 |
I8-94171 173-0 |
|
SEAT GOV SPRING, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 1 |
I8-97102 281-1 |
|
GOVERNOR ASM INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 45 |
I8-94344 440-0 |
|
LEVER ASM GOV, INJ PUMP |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 305 |
I8-97089 312-0 |
|
SHIM STOP LEVER GOV |
AR |
9312- |
|
4HF1 |
T=0.80 ( NKR 66, NKR 71 ) |
| 104 |
I8-97085 021-0 |
|
CAP LOCK NUT. ADJ SCREW |
1 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 252 |
I1-15779 003-1 |
|
SCREW GUIDE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 93 |
I8-94426 047-1 |
|
NUT ADJ SCREW LK, INJ PUMP GOV |
2 |
9312- |
|
4JB1 |
(A) NHR 55 |
| 177 |
I9-81325 445-0 |
|
RING SNAP, GOV LEVER, INJ PUMP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 82 |
I1-15729 006-0 |
|
NUT CONT LEVER FIX, GOV |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 169 |
I5-15723 033-0 |
|
SPRING LEVER SET, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 50 |
I8-94473 129-0 |
|
NUT GOV SHAFT, INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 2 |
I1-15721 203-0 |
|
HOUSING GOV, INJ PUMP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 13 |
I8-94221 411-0 |
|
KEY FLYWEIGHT, GOV |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 49 |
I8-94227 606-0 |
|
GASKET GOV SHAFT, INJ PUMP |
1 |
9902- |
|
4HF1-2 |
NKR66-2 |
| 90 |
I1-15729 642-0 |
|
SCREW FULL LOAD ADJ, GOV |
1 |
9312- |
|
4HF1 |
(A) M 8 X 62 ( NKR 66 ) |
| 266 |
I0-91110 505-0 |
|
NUT PIN TO LINK, CONT RACK, GOV |
1 |
0106- |
|
4HF1 |
NKR 66, NKR 71 |
| 5 |
I1-15779 106-0 |
|
GASKET GOV TO INJ PUMP HSG |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
.png)
.png)
.png)
