| 391 |
I8-97172 882-0 |
|
BRACKET ENG CONT |
1 |
9811- |
|
4HF1 |
(A) NKR 66, NKR66-2, NKR 71 |
| 316 |
I5-09707 027-0 |
|
CLIP LAMP BRACKET |
1 |
9504- |
|
4JB1 |
ID=9.0 OD = 20.0 T=2.0 |
| 60 |
I0-28650 820-0 |
|
BOLT |
2 |
0211- |
|
4HF1 |
M 8 X 20 FLANGE |
| 110 |
I0-28050 816-0 |
|
BOLT COVER |
3 |
0211- |
|
4HG1 |
M 8 X 14 FLANGE ( NKR 66 ) |
| 326 |
I0-50540 616-0 |
|
BOLT PCV BRACKET |
1 |
9312- |
|
4BE1 |
M 16 X 16 W / SP WASHER |
| 230 |
I8-97853 064-0 |
|
PIN JOINT, ACCEL PEDAL TO BRKT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 101 |
I9-09851 411-0 |
|
WASHER ENG CONT |
3 |
9312- |
|
4BE1 |
OD = 18 T=0.4 ( NKR 58 ) |
| 389 |
I0-91180 106-0 |
|
BOLT CABLE FIX |
1 |
9312- |
|
4HF1 |
M6 FLANGE ( NKR 66, NKR 71 ) |
| 158 |
I8-94279 060-0 |
|
NUT BRKT |
2 |
9312- |
|
4HF1 |
(B) M 8 FLANGE NUT |
| 67 |
I7-11127 063-A |
|
CABLE ASM IDLE CONT |
1 |
9801- |
|
4HF1 |
( NPN-OTH-7063 ) |
| 82 |
I5-23319 012-0 |
|
BUSHING ENG CONT LVR |
4 |
9312- |
|
4BE1 |
ID=10 OD = 17.5 ( NKR 58 ) |
| 67 |
I7-11127 063-A |
|
CABLE ASM IDLE CONT |
1 |
9312- |
|
4JB1 |
L=375 ( NHR 55 ) |
| 320 |
I8-94178 110-0 |
|
CLIP FRAME |
1 |
9312- |
|
4HF1 |
(B) NKR 66, NKR 66-2, NKR 71 |
| 99 |
I8-97099 831-1 |
|
BRACKET ASM ENG CONT, INLET MANIFOLD |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 80 |
I8-97853 061-A |
|
LINK ASM ENG CONT |
1 |
9312- |
|
4HF1 |
(B) NKR 66, NKR66-2, NKR 71 |
| 316 |
I1-09987 201-0 |
|
CLIP LAMP BRACKET |
1 |
9312-9503 |
|
4JB1 |
ID=12 ( NHR 55 ) |
| 110 |
I0-50741 025-0 |
|
BOLT OIL PUMP |
2 |
9312- |
|
4BE1 |
M 10 X 25 W / SP WASHER |
| 60 |
I0-50640 825-0 |
|
BOLT BRKT, ENG CONTROL CABLE |
1 |
9312- |
|
4BE1 |
M 8 X 25 W/SP & PL WASHER |
| 99 |
I8-97118 729-0 |
|
BRACKET ASM ENG CONT, INLET MANIFOLD |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 158 |
I8-94279 060-0 |
|
NUT BRKT |
2 |
9312- |
|
4BE1 |
(B) M 8 FLANGE NUT |
| 54 |
I8-97071 711-4 |
|
CABLE ENG CONT |
1 |
0702- |
|
4HG1-T |
(A) NKR71 EURO 2 |
| 87 |
I8-97853 204-1 |
|
LINK ENG CONT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 403 |
I8-94279 976-0 |
|
BOLT BRT, ACCEL PEDAL |
2 |
9312- |
|
4HF1 |
NKR 58, NKR 66 |
| 158 |
I8-94279 050-0 |
|
NUT BRKT |
2 |
9312- |
|
4JB1 |
(A) M 8 W / SP WASHER |
| 392 |
I8-94360 745-0 |
|
CLIP ACCEL CONT CABLE |
1 |
9312- |
|
4BE1 |
ID=10 & 16.5 ( NKR 58 ) |
| 323 |
I0-50540 616-0 |
|
BOLT CLIP FIX |
1 |
9312- |
|
4BE1 |
M 6 X 16 W / SP WASHER |
| 392 |
I1-09707 001-1 |
|
CLIP ACCEL CONT CABLE |
1 |
9312- |
|
4JB1 |
L=330 ( NHR 55 ) |
| 65 |
I8-94310 730-0 |
|
BOLT |
2 |
9604- |
|
4HF1 |
M 8 X 16 W/LK & PL WASHER |
| 298 |
I8-94424 178-0 |
|
NUT BALL JOINT, LINK ROD |
2 |
9312- |
|
4BE1 |
M 5 W / SP WASHER |
| 404 |
I8-94472 577-0 |
|
CLIP CABLE |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 447 |
I0-91180 208-0 |
|
NUT BRKT, CONT WIRE |
1 |
9312- |
|
4BE1 |
M 8 FLANGE NUT ( NKR 58 ) |
| 403 |
I8-94279 976-0 |
|
BOLT BRT, ACCEL PEDAL |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 83 |
I8-97853 201-4 |
|
BRACKET CONT LINK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 90 |
I8-97174 068-3 |
|
LEVER RELAY, ENG CONT |
1 |
0211- |
|
4JB1 |
NHR 55 |
| 232 |
I8-97378 461-0 |
|
BOLT STOPPER, ACCEL PEDAL |
1 |
0407- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71 ) |
| 90 |
I8-97853 202-6 |
|
LEVER RELAY, ENG CONT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 100 |
I8-97118 737-0 |
|
SHAFT ASM ENG CONT |
1 |
0211- |
|
4HF1 |
NKR 66, NKR 71 |
| 108 |
I5-15549 001-1 |
|
BUSHING ENG CONT |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 395 |
I5-09707 031-1 |
|
CLIP ENGINE STOP CABLE |
1 |
9312- |
|
4JB1 |
L=140 ( NHR 55 ) |
| 54 |
I7-59100 201-A |
|
CABLE ENG CONT |
1 |
0108- |
|
4HG1 |
NKR 71, ( P591002010 ) |
| 443 |
I8-94360 745-0 |
|
CLIP ACCEL CONTROL FIX |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 124 |
I8-97022 566-0 |
|
NUT LEVER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 80 |
I8-97853 061-A |
|
LINK ASM ENG CONT |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 391 |
I8-97357 141-0 |
|
BRACKET ENG CONT |
1 |
0702- |
|
4HG1-T |
(C) NKR 71 EURO 2 |
| 54 |
I7-59100 201-A |
|
CABLE ENG CONT |
1 |
9312- |
|
4HF1 |
(A) NKR 66 |
| 232 |
I0-20800 865-0 |
|
BOLT STOPPER, ACCEL PEDAL |
1 |
9407-0406 |
|
4HF1 |
M 8 X 65 |
| 67 |
I8-97853 058-1 |
|
CABLE ASM IDLE CONT |
1 |
0702- |
|
4JB1-TC |
L=439 NHR55, NKKR55 EURO 2 |
| 124 |
I8-94279 042-0 |
|
NUT LEVER |
2 |
0211- |
|
4HG1 |
NKR 66, NKR 71 |
| 89 |
I8-97968 042-0 |
|
LEVER RELAY |
1 |
0211- |
|
4HF1 |
NKR 66, NKR 71 |
| 54 |
I7-11117 040-A |
|
CABLE ENG CONT |
1 |
9312-0108 |
|
4HG1 |
NKR 71 |
| 54 |
I8-97046 362-A |
|
CABLE ENG CONT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 68 |
I8-97853 765-1 |
|
KNOB IDLE CONT |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 108 |
I8-97120 004-0 |
|
BUSHING ENG CONT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 54 |
I7-11117 040-A |
|
CABLE ENG CONT |
1 |
9312- |
|
4HF1 |
(B) NKR 66 |
| 99 |
I8-97118 729-0 |
|
BRACKET ASM ENG CONT, INLET MANIFOLD |
1 |
9411- |
|
4HF1 |
NKR 66, NKR 71 |
| 100 |
I8-97118 737-0 |
|
SHAFT ASM ENG CONT |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 389 |
I0-91180 106-0 |
|
BOLT CABLE FIX |
1 |
9312- |
|
4BE1 |
M 6 FLANGE ( NKR 58 ) |
| 115 |
I0-50540 840-0 |
|
BOLT BED PLATE TO C/BL |
1 |
9312- |
|
4BE1 |
M 8 X 40 W / SP WASHER |
| 89 |
I8-97853 203-4 |
|
LEVER RELAY |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 86 |
I9-09160 605-0 |
|
WASHER PL, ENGINE CONT LEVER |
1 |
9312- |
|
4BE1 |
ID=5 ( NKR 58 ) |
| 316 |
I1-09987 201-0 |
|
CLIP LAMP BRACKET |
1 |
9312-9503 |
|
4BE1 |
ID=12 ( NKR 58 ) |
| 104 |
I0-91180 208-0 |
|
NUT ENG CONT |
1 |
9312- |
|
4HF1 |
M8 FLANGE ( NKR 66, NKR 71 ) |
| 348 |
I8-94327 073-0 |
|
NUT LAMP BRACKET |
1 |
9312- |
|
4HF1 |
M 8 FLANGE NUT |
| 81 |
I8-97853 205-1 |
|
SPRING RETURN, ENG CONT LEVER |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 80 |
I8-97853 057-9 |
|
LINK ASM ENG CONT |
1 |
9312- |
|
4BE1 |
(A) NKR 58 |
| 83 |
I8-97853 201-4 |
|
BRACKET CONT LINK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 80 |
I8-97853 061-A |
|
LINK ASM ENG CONT |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 70 |
I8-97853 233-0 |
|
NUT CONTROL CABLE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 54 |
I7-59100 200-A |
|
CABLE ENG CONT |
1 |
0108- |
|
4HG1 |
NKR 66, NKR 66-2 (P59100200) |
| 105 |
I0-91510 508-0 |
|
WASHER LK, CLIP, HARNESS |
1 |
9312- |
|
4BE1 |
ID=8 ( NKR 58 ) |
| 107 |
I8-94148 078-0 |
|
WASHER ENGINE CONTROL |
1 |
9312- |
|
4BE1 |
OD = 18 T=1 ( NKR 58 ) |
| 89 |
I8-97853 203-4 |
|
LEVER RELAY |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 35 |
I8-97302 305-0 |
|
STOPPER ACCEL PEDAL |
2 |
9312- |
|
4HF1 |
NKR 58, NKR 66 |
| 46 |
I0-91805 504-0 |
|
RING SNAP, ACCEL CONT PEDAL |
1 |
9312- |
|
4BE1 |
ID=4 ( NKR 58 ) |
| 391 |
I8-97357 141-0 |
|
BRACKET ENG CONT |
1 |
9811- |
|
4HF1 |
(C) NKR 66, NKR66-2, NKR 71 |
| 87 |
I8-97853 204-1 |
|
LINK ENG CONT |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 158 |
I8-94279 050-0 |
|
NUT BRKT |
2 |
9312- |
|
4BE1 |
(A) M 8 W / SP WASHER |
| 39 |
I0-91110 508-0 |
|
NUT ACCEL PEDAL STOPPER |
1 |
9312- |
|
4HF1 |
M8 ( NKR 58, NKR 66, NKR 71 ) |
| 67 |
I7-11127 063-A |
|
CABLE ASM IDLE CONT |
1 |
9312- |
|
4HF1 |
L=375 (NKR66, NKR66-2, NKR71) |
| 6 |
I0-91805 504-0 |
|
RING SNAP, LINK TO CAM PLATE, GOV |
2 |
9312- |
|
4HF1 |
NKR 58, NKR 66 |
| 70 |
I8-97853 233-0 |
|
NUT CONTROL CABLE |
1 |
9312- |
|
4BE1 |
M18 ( NKR 58 ) |
| 70 |
I8-97853 233-0 |
|
NUT CONTROL CABLE |
1 |
9312- |
|
4JB1 |
M18 ( NHR 55 ) |
| 447 |
I8-94462 219-0 |
|
NUT BRKT, CONT WIRE |
1 |
0211- |
|
4HF1 |
ID=10 H = 40, NKR 66 |
| 316 |
I5-09707 027-0 |
|
CLIP LAMP BRACKET |
1 |
9504- |
|
4HF1 |
ID=9.0 OD = 20.0 T=2.0 |
| 100 |
I8-94416 112-1 |
|
SHAFT ASM ENG CONT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 14 |
I8-97853 062-2 |
|
PAD PEDAL, ACCEL |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 80 |
I8-97853 057-9 |
|
LINK ASM ENG CONT |
1 |
0702- |
|
4JB1-TC |
(A) NNH55, NKR55 EURO 2 |
| 35 |
I8-97302 305-0 |
|
STOPPER ACCEL PEDAL |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 6 |
I0-91805 504-0 |
|
RING SNAP, LINK TO CAM PLATE, GOV |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 106 |
I8-97094 292-0 |
|
LEVER B , ENGINE CONT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 82 |
I5-23319 012-0 |
|
BUSHING ENG CONT LVR |
4 |
9312- |
|
4HF1 |
ID=10 OD = 17.5 ( NKR 66 ) |
| 70 |
I8-97853 233-0 |
|
NUT CONTROL CABLE |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 232 |
I8-97378 461-0 |
|
BOLT STOPPER, ACCEL PEDAL |
1 |
0407- |
|
4JB1 |
( NHR 55 ) |
| 68 |
I8-97853 765-1 |
|
KNOB IDLE CONT |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 39 |
I0-91110 508-0 |
|
NUT ACCEL PEDAL STOPPER |
1 |
9312- |
|
4JB1 |
M8 ( NHR 55 ) |
| 158 |
I8-94279 050-0 |
|
NUT BRKT |
2 |
9312- |
|
4HF1 |
(A) M 8 W / SP WASHER |
| 89 |
I8-97853 203-4 |
|
LEVER RELAY |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 114 |
I8-94472 578-0 |
|
CLIP HARNESS CONNECTOR |
1 |
9312- |
|
4HF1 |
ID=10 & 14 ( NKR 66, NKR 71 ) |
| 86 |
I9-09160 605-0 |
|
WASHER PL, ENGINE CONT LEVER |
1 |
9312- |
|
4HF1 |
ID=5 ( NKR 66 ) |
| 82 |
I5-23319 012-0 |
|
BUSHING ENG CONT LVR |
4 |
9312- |
|
4JB1 |
ID=10 OD = 17.5 ( NHR 55 ) |
| 391 |
I8-97068 801-1 |
|
BRACKET ENG CONT |
1 |
9811- |
|
4JB1 |
(B) NHR 55 |
| 14 |
I8-97853 062-2 |
|
PAD PEDAL, ACCEL |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 90 |
I8-97868 039-0 |
|
LEVER RELAY, ENG CONT |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 68 |
I8-97853 765-1 |
|
KNOB IDLE CONT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 314 |
I8-97031 742-0 |
|
BRACKET ACCEL CABLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 158 |
I8-94279 060-0 |
|
NUT BRKT |
2 |
9312- |
|
4JB1 |
(B) M 8 FLANGE NUT |
| 87 |
I8-97853 204-1 |
|
LINK ENG CONT |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 102 |
I8-94255 643-1 |
|
RUBBER MTG, INL MANIF TO BRKT |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 89 |
I8-97968 042-0 |
|
LEVER RELAY |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 65 |
I8-94279 207-0 |
|
BOLT |
2 |
9312-9603 |
|
4BE1 |
M 8 X 16 ( NKR 58 ) |
| 325 |
I8-94144 775-0 |
|
CLIP PCV BRACKET |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 81 |
I8-97853 205-1 |
|
SPRING RETURN, ENG CONT LEVER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 83 |
I8-97853 201-4 |
|
BRACKET CONT LINK |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 68 |
I8-97853 765-1 |
|
KNOB IDLE CONT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 42 |
I0-50640 825-0 |
|
BOLT BRKT, ENG CONTROL CABLE |
1 |
9312- |
|
4BE1 |
M 8 X 25 W/SP & PL WASHER |
| 320 |
I8-94167 969-2 |
|
CLIP FRAME |
1 |
9312- |
|
4JB1 |
(A) NHR 55 |
| 54 |
I8-97387 019-A |
|
CABLE ENG CONT |
1 |
0702- |
|
4JB1-TC |
(C) NHR55, NKR55 EURO 2 |
| 100 |
I8-97118 737-0 |
|
SHAFT ASM ENG CONT |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 318 |
I8-94327 073-0 |
|
NUT LAMP BRACKET |
1 |
9312- |
|
4JB1 |
M 8 FLANGE NUT |
| 232 |
I0-20800 845-0 |
|
BOLT STOPPER, ACCEL PEDAL |
1 |
9312-9406 |
|
4HF1 |
M 8 X 45 |
| 14 |
I8-97853 062-2 |
|
PAD PEDAL, ACCEL |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 65 |
I8-94279 207-0 |
|
BOLT |
2 |
9312-9603 |
|
4HF1 |
M 8 X 16 ( NKR 66 ) |
| 90 |
I8-97868 039-0 |
|
LEVER RELAY, ENG CONT |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 87 |
I8-97853 204-1 |
|
LINK ENG CONT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 83 |
I8-97853 201-4 |
|
BRACKET CONT LINK |
1 |
0702- |
|
4JB1-TC |
NNH55, NKR55 EURO 2 |
| 81 |
I8-97853 205-1 |
|
SPRING RETURN, ENG CONT LEVER |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 230 |
I8-97853 064-0 |
|
PIN JOINT, ACCEL PEDAL TO BRKT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 60 |
I0-50640 825-0 |
|
BOLT BRKT, ENG CONTROL CABLE |
2 |
9312- |
|
4HF1 |
M 8 X 25 W/SP & PL WASHER |
| 232 |
I0-20800 865-0 |
|
BOLT STOPPER, ACCEL PEDAL |
1 |
9407-0406 |
|
4JB1 |
M 8 X 65 ( NHR 55 ) |
| 316 |
I1-09987 201-0 |
|
CLIP LAMP BRACKET |
1 |
9312-9503 |
|
4HF1 |
ID=12 ( NKR 66 ) |
| 86 |
I9-09160 605-0 |
|
WASHER PL, ENGINE CONT LEVER |
1 |
9312- |
|
4JB1 |
ID=5 ( NHR 55 ) |
| 81 |
I8-97853 205-1 |
|
SPRING RETURN, ENG CONT LEVER |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 67 |
I7-11127 063-A |
|
CABLE ASM IDLE CONT |
1 |
9312- |
|
4BE1 |
L=375 ( NKR 58 ) |
| 109 |
I8-94155 884-1 |
|
WASHER PL, INLET MANIF |
1 |
9312- |
|
4BE1 |
OD = 28.6 ( NKR 58 ) |
| 218 |
I0-91180 208-0 |
|
NUT COVER, HD |
1 |
9307- |
|
4HF1 |
M 8 FLANGE ( NKR 66, NKR 71 ) |
| 70 |
I8-97853 233-0 |
|
NUT CONTROL CABLE |
1 |
9312- |
|
4HF1 |
M18 ( NKR 66, NKR 71 ) |
| 87 |
I8-97853 204-1 |
|
LINK ENG CONT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 83 |
I8-97853 201-4 |
|
BRACKET CONT LINK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 54 |
I8-97090 655-1 |
|
CABLE ENG CONT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 89 |
I8-97853 203-4 |
|
LEVER RELAY |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 80 |
I8-97853 057-9 |
|
LINK ASM ENG CONT |
1 |
9312- |
|
4JB1 |
(A) NHR 55 |
| 54 |
I7-59100 200-A |
|
CABLE ENG CONT |
1 |
9811- |
|
4HF1-2 |
(A) NKR 66-2 |
| 60 |
I0-50640 825-0 |
|
BOLT BRKT, ENG CONTROL CABLE |
2 |
9312- |
|
4JB1 |
M 8 X 25 W/SP & PL WASHER |
| 80 |
I8-97853 057-9 |
|
LINK ASM ENG CONT |
1 |
0702- |
|
4HG1-T |
(A) NKR71 EURO 2 |
| 101 |
I0-91610 708-0 |
|
WASHER ENG CONT |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 65 |
I8-94310 730-0 |
|
BOLT |
2 |
9604- |
|
4JB1 |
M 8 X 16 W/LK & PL WASHER |
| 40 |
I8-94446 927-2 |
|
BRACKET ENGINE CTRL CBL |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 67 |
I7-11127 063-A |
|
CABLE ASM IDLE CONT |
1 |
9801- |
|
4JB1 |
NHR 55, ( NPN-OTH-7063 ) |
| 232 |
I0-20800 845-0 |
|
BOLT STOPPER, ACCEL PEDAL |
1 |
9312-9406 |
|
4JB1 |
M 8 X 45 ( NHR 55 ) |
| 158 |
I8-94279 050-0 |
|
NUT BRKT |
2 |
0702- |
|
4JB1-TC |
(A) M 8 W / SP WASHER |
| 110 |
I0-28080 814-0 |
|
BOLT COVER |
3 |
9312- |
|
4HF1 |
M 8 X 14 FLANGE ( NKR 66 ) |
| 80 |
I8-97853 057-9 |
|
LINK ASM ENG CONT |
1 |
9312- |
|
4HF1 |
(A) NKR 66, NKR66-2, NKR 71 |
| 67 |
I8-97853 058-1 |
|
CABLE ASM IDLE CONT |
1 |
0702- |
|
4HG1-T |
L=439 NKR71 EURO 2 |
| 99 |
I8-97118 729-0 |
|
BRACKET ASM ENG CONT, INLET MANIFOLD |
1 |
9312-9410 |
|
4HF1 |
NKR 66 |
| 230 |
I8-97853 064-0 |
|
PIN JOINT, ACCEL PEDAL TO BRKT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 46 |
I0-91805 504-0 |
|
RING SNAP, ACCEL CONT PEDAL |
1 |
9312- |
|
4HF1 |
ID=4 ( NKR 66, NKR 71 ) |
| 65 |
I8-94279 207-0 |
|
BOLT |
2 |
9312-9603 |
|
4JB1 |
M 8 X 16 ( NHR 55 ) |
| 447 |
I8-97118 760-0 |
|
NUT BRKT, CONT WIRE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 124 |
I8-97022 566-0 |
|
NUT LEVER |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 90 |
I8-97853 202-6 |
|
LEVER RELAY, ENG CONT |
1 |
9312- |
|
4BE1 |
NKR 58, NKR 66 |
| 35 |
I8-97302 305-0 |
|
STOPPER ACCEL PEDAL |
1 |
0211- |
|
4HF1 |
NHR 55, NKR 66, NKR 71 |
| 46 |
I0-91805 504-0 |
|
RING SNAP, ACCEL CONT PEDAL |
1 |
9312- |
|
4JB1 |
ID=4 ( NHR 55 ) |
| 81 |
I8-97853 205-1 |
|
SPRING RETURN, ENG CONT LEVER |
1 |
0702- |
|
4JB1-TC |
NNH55, NKR55 EURO 2 |
| 104 |
I9-09111 508-A |
|
NUT ENG CONT |
1 |
9312- |
|
4BE1 |
M 8 ( NKR 58 ) |
| 68 |
I8-97853 765-1 |
|
KNOB IDLE CONT |
1 |
9312- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71 ) |
| 54 |
I7-11117 040-A |
|
CABLE ENG CONT |
1 |
0702- |
|
4HG1-T |
(B) NKR71 EURO 2 |
| 90 |
I8-97868 039-0 |
|
LEVER RELAY, ENG CONT |
1 |
0211- |
|
4HF1 |
NKR 66, NKR 71 |
| 61 |
I0-28050 612-0 |
|
BOLT CHECK HOLE COVER |
1 |
9312- |
|
4JB1 |
M 6 X 12 ( NHR 55 ) |
| 103 |
I8-94255 642-1 |
|
BUSHING SPACER, INL MANIF TO BRK |
1 |
9312- |
|
4BE1 |
OD = 12 ( NKR 58 ) |
