| 74 |
I8-94221 082-0 |
|
WASHER PL, CUSHION RUBBER |
1 |
9312- |
|
4BE1 |
ID=8.5 OD = 36 ( NKR 58 ) |
| 51 |
I8-97171 437-A |
|
PLUG DRAIN |
1 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 78 |
I0-91180 208-0 |
|
NUT CUSHION RUBBER |
1 |
9712- |
|
4HF1 |
M8 FLANGE |
| 81 |
I8-97088 810-A |
|
SCREW FAN GUIDE, RAD |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 23 |
I5-09440 006-0 |
|
NUT RAD MTG |
2 |
0211- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 62 |
I0-28050 812-A |
|
BOLT STAY |
2 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 2 |
I8-97203 091-A |
|
GUIDE FAN |
1 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 220 |
I0-91180 208-0 |
|
NUT CLIP |
1 |
9312- |
|
4BE1 |
M 8 FLANGE NUT |
| 131 |
I8-97245 216-0 |
|
CLIP ENGINE SIDE TOP |
1 |
0002- |
|
4HF1 |
ID=40 |
| 70 |
I8-97047 899-A |
|
STAY RAD |
1 |
1309- |
|
4HG1-T |
NKR71 EURO2 |
| 26 |
I8-94249 347-A |
|
BUFFER RAD, LOWER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 81 |
I8-97088 810-A |
|
SCREW FAN GUIDE, RAD |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 56 |
I8-97032 798-2 |
|
STAY RAD |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 74 |
I0-91610 710-0 |
|
WASHER PL, CUSHION RUBBER |
1 |
9312- |
|
4HF1 |
ID=8.5 OD=26 |
| 21 |
I8-97219 806-3 |
|
SEAL RAD |
2 |
0211- |
|
4JB1 |
(C) NHR 55 |
| 59 |
I8-94202 777-0 |
|
PIN SNAP, STAY |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 75 |
I8-94249 446-0 |
|
BOLT CUSHION RUBBER, RAD MTG |
1 |
9312- |
|
4BE1 |
M8X63 ( NKR 58 ) |
| 59 |
I8-94202 777-0 |
|
PIN SNAP, STAY |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 70 |
I8-97047 899-A |
|
STAY RAD |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 51 |
I8-97171 437-A |
|
PLUG DRAIN |
1 |
1309- |
|
4HG1-T |
NKR71 EURO2 |
| 52 |
I9-09720 557-0 |
|
GASKET DRAIN PLUG, RAD |
1 |
0211- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71) |
| 27 |
I8-94249 346-A |
|
BUFFER RAD, UPPER |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 51 |
I8-94321 236-0 |
|
PLUG DRAIN |
1 |
0211- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71) |
| 1 |
I8-97162 142-A |
|
RADIATOR ASM |
1 |
0702- |
|
4HG1-T |
NKR 71 EURO2 |
| 81 |
I8-97088 810-A |
|
SCREW FAN GUIDE, RAD |
4 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 23 |
I5-09440 009-0 |
|
NUT RAD MTG |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 52 |
I9-09561 110-0 |
|
GASKET DRAIN PLUG, RAD |
1 |
9312- |
|
4JB1 |
O-RING ( NHR 55 ) |
| 16 |
I8-94228 748-A |
|
CAP RAD |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 74 |
I0-91610 710-0 |
|
WASHER PL, CUSHION RUBBER |
1 |
9312- |
|
4BE1 |
ID=8.5 OD = 26 ( NKR 58 ) |
| 74 |
I8-94221 082-0 |
|
WASHER PL, CUSHION RUBBER |
1 |
9312- |
|
4JB1 |
ID=8.5 OD = 36 ( NHR 55 ) |
| 62 |
I0-28050 812-A |
|
BOLT STAY |
2 |
9312- |
|
4BE1 |
(A) M 8 X 12 ( NKR 55 ) |
| 22 |
I7-53192 063-A |
|
BRACKET RAD MTG |
1 |
0702- |
|
4HG1-T |
RH, NKR71 EURO2 |
| 1 |
I8-97032 737-2 |
|
RADIATOR ASM |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 51 |
I8-97036 939-0 |
|
PLUG DRAIN |
1 |
9312- |
|
4HF1 |
W / O-RING ( NKR 66 ) |
| 51 |
I8-94321 236-0 |
|
PLUG DRAIN |
1 |
0702- |
|
4HG1-T |
NKR71 EURO2 |
| 21 |
I8-97085 690-0 |
|
SEAL RAD |
2 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 24 |
I0-28050 825-0 |
|
BOLTM8x1,25, L=25 |
2 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 1 |
I8-97210 644-A |
|
RADIATOR ASM |
1 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 21 |
I8-97085 689-0 |
|
SEAL RAD |
1 |
9312- |
|
4JB1 |
(A) NHR 55 |
| 1 |
I8-97210 644-A |
|
RADIATOR ASM |
1 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 62 |
I0-28050 812-A |
|
BOLT STAY |
2 |
9312- |
|
4HF1 |
(A) M8X45 ( NKR 66, NKR 71 ) |
| 16 |
I7-63401 240-A |
|
CAP RAD |
1 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 1 |
I8-97178 662-A |
|
RADIATOR ASM |
1 |
0702- |
|
4JB1-TC |
NHR, NKR55 EURO2 |
| 2 |
I8-97203 091-A |
|
GUIDE FAN |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2 |
| 58 |
I8-97011 676-0 |
|
WASHER CURVE, STAY |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 51 |
I8-97171 437-A |
|
PLUG DRAIN |
1 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 27 |
I8-94249 346-A |
|
BUFFER RAD, UPPER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 52 |
I9-09720 557-0 |
|
GASKET DRAIN PLUG, RAD |
1 |
0702- |
|
4HG1-T |
NKR71 EURO2 |
| 131 |
I1-09704 057-0 |
|
CLIP ENGINE SIDE TOP |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 56 |
I8-97094 807-2 |
|
STAY RAD |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 52 |
I9-09720 557-0 |
|
GASKET DRAIN PLUG, RAD |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 2 |
I8-97066 011-A |
|
GUIDE FAN |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 22 |
I7-53192 063-A |
|
BRACKET RAD MTG |
1 |
9312- |
|
4BE1 |
(B) NKR 58 |
| 74 |
I0-91610 710-0 |
|
WASHER PL, CUSHION RUBBER |
1 |
9312- |
|
4JB1 |
ID=8.5 OD = 26 ( NHR 55 ) |
| 51 |
I8-94321 236-0 |
|
PLUG DRAIN |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 62 |
I0-28050 812-A |
|
BOLT STAY |
2 |
1309- |
|
4HG1-T |
NKR71 EURO2 |
| 16 |
I8-94228 748-A |
|
CAP RAD |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 25 |
I0-28051 025-0 |
|
BOLT BRKT |
2 |
9312- |
|
4JB1 |
M10X25 FLANGE ( NHR 55 ) |
| 240 |
I8-94178 701-0 |
|
NUT STAY |
1 |
9312- |
|
4JB1 |
M8 ( NHR 55 ) |
| 21 |
I8-97062 615-0 |
|
SEAL RAD |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 24 |
I0-28050 825-0 |
|
BOLTM8x1,25, L=25 |
2 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 21 |
I8-97164 332-0 |
|
SEAL RAD |
1 |
0211- |
|
4HF1 |
(D) NKR 66, NKR 71 |
| 1 |
I8-97032 733-0 |
|
RADIATOR ASM |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 70 |
I8-97047 899-A |
|
STAY RAD |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97162 142-A |
|
RADIATOR ASM |
1 |
9712- |
|
4HF1 |
NKR 66-2, NKR 66, NKR 71 |
| 16 |
I8-94228 748-A |
|
CAP RAD |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2 |
| 78 |
I0-91180 208-0 |
|
NUT CUSHION RUBBER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 23 |
I5-09440 009-0 |
|
NUT RAD MTG |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 23 |
I5-09440 009-0 |
|
NUT RAD MTG |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 131 |
I1-09704 057-0 |
|
CLIP ENGINE SIDE TOP |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 62 |
I8-94401 350-0 |
|
BOLT STAY |
1 |
9312- |
|
4JB1 |
(B) M 8 X 45 ( NHR 55 ) |
| 25 |
I0-28051 025-0 |
|
BOLT BRKT |
2 |
9312- |
|
4BE1 |
M10X25 FLANGE ( NKR 58 ) |
| 75 |
I8-94249 446-0 |
|
BOLT CUSHION RUBBER, RAD MTG |
1 |
9312- |
|
4HF1 |
M8X63 (NKR 66, NKR 66-2, NKR 71) |
| 70 |
I8-97047 899-A |
|
STAY RAD |
1 |
1309- |
|
4HG1-T |
NKR71 EURO2 |
| 51 |
I8-97036 939-0 |
|
PLUG DRAIN |
1 |
9312- |
|
4JB1 |
W / O-RING ( NHR 55 ) |
| 1 |
I8-97162 143-A |
|
RADIATOR ASM |
1 |
1309- |
|
4HG1-T |
NKR71 EURO2 (ALUMINIUM) |
| 16 |
I8-94228 748-A |
|
CAP RAD |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 62 |
I8-94401 350-0 |
|
BOLT STAY |
1 |
9312- |
|
4BE1 |
(B) M 8 X 45 ( NKR 58 ) |
| 16 |
I8-94228 748-A |
|
CAP RAD |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 62 |
I8-94401 350-0 |
|
BOLT STAY |
1 |
9312- |
|
4HF1 |
(B) M8X45 |
| 81 |
I8-97088 810-A |
|
SCREW FAN GUIDE, RAD |
4 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 22 |
I7-53192 063-A |
|
BRACKET RAD MTG |
1 |
9312- |
|
4HF1 |
(B) NKR 66 |
| 75 |
I8-94249 446-0 |
|
BOLT CUSHION RUBBER, RAD MTG |
1 |
9312- |
|
4JB1 |
M8X63 ( NHR 55 ) |
| 58 |
I8-97011 676-0 |
|
WASHER CURVE, STAY |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 16 |
I8-94228 748-A |
|
CAP RAD |
1 |
9803- |
|
4HF1 |
NKR 66-2, NKR 66, NKR 71 |
| 57 |
I0-91610 510-0 |
|
WASHER PL, STAY |
1 |
9312- |
|
4JB1 |
ID=10 ( NHR 55 ) |
| 58 |
I8-97011 676-0 |
|
WASHER CURVE, STAY |
1 |
9312- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71) |
| 240 |
I8-94178 701-0 |
|
NUT STAY |
1 |
9312- |
|
4BE1 |
M8 ( NKR 58 ) |
| 52 |
I9-09561 110-0 |
|
GASKET DRAIN PLUG, RAD |
1 |
9312- |
|
4BE1 |
O-RING ( NKR 58 ) |
| 70 |
I8-97047 899-A |
|
STAY RAD |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 2 |
I8-97066 013-1 |
|
GUIDE FAN |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 74 |
I8-94221 082-0 |
|
WASHER PL, CUSHION RUBBER |
1 |
9312- |
|
4HF1 |
ID=8.5 OD=36 |
| 240 |
I8-94178 701-0 |
|
NUT STAY |
1 |
9312- |
|
4HF1 |
M8 (NKR 66, NKR 66-2, NKR71) |
| 22 |
I8-97205 216-0 |
|
BRACKET RAD MTG |
1 |
0702- |
|
4JB1-TC |
LH, NHR55, NKR55 EURO2 |
| 25 |
I0-28051 025-0 |
|
BOLT BRKT |
2 |
9312- |
|
4HF1 |
M10X25 FLANGE ( NKR 66) |
| 62 |
I0-28050 812-A |
|
BOLT STAY |
2 |
9312- |
|
4JB1 |
(A) M 8 X 12 ( NHR 55 ) |
| 70 |
I8-97061 314-A |
|
STAY RAD |
1 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 |
| 26 |
I8-94249 347-A |
|
BUFFER RAD, LOWER |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 21 |
I8-97164 333-0 |
|
SEAL RAD |
1 |
0211- |
|
4HF1 |
(E) NKR 66, NKR 71 |
| 27 |
I8-94249 346-A |
|
BUFFER RAD, UPPER |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 78 |
I0-91180 208-0 |
|
NUT CUSHION RUBBER |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97162 144-A |
|
RADIATOR ASM |
1 |
0005- |
|
4JB1 |
NHR 55 |
| 16 |
I7-63401 240-A |
|
CAP RAD |
1 |
1309- |
|
4HG1-T |
NKR71 EURO2 |
| 81 |
I8-97088 810-A |
|
SCREW FAN GUIDE, RAD |
4 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 22 |
I7-53192 063-A |
|
BRACKET RAD MTG |
1 |
9312- |
|
4HF1 |
(RH) NKR 66, NKR 66-2, NKR 71 |
| 22 |
I7-53192 022-A |
|
BRACKET RAD MTG |
1 |
9312- |
|
4HF1 |
(LH) NKR 66, NKR 66-2, NKR 71 |
| 2 |
I8-97066 011-A |
|
GUIDE FAN |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 52 |
I9-09561 110-0 |
|
GASKET DRAIN PLUG, RAD |
1 |
9312- |
|
4HF1 |
O-RING ( NKR 66 ) |
| 81 |
I8-97088 810-A |
|
SCREW FAN GUIDE, RAD |
4 |
1309- |
|
4HG1-T |
NKR71 EURO2 |
| 1 |
I8-97032 727-1 |
|
RADIATOR ASM |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 26 |
I8-94249 347-A |
|
BUFFER RAD, LOWER |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 21 |
I8-97062 615-0 |
|
SEAL RAD |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 57 |
I0-91610 510-0 |
|
WASHER PL, STAY |
1 |
9312- |
|
4HF1 |
ID=10 |
| 22 |
I7-53192 063-A |
|
BRACKET RAD MTG |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 2 |
I8-97203 091-A |
|
GUIDE FAN |
1 |
9803- |
|
4HF1 |
NKR 66-2, NKR 66, NKR 71 |
| 62 |
I0-28050 812-A |
|
BOLT STAY |
2 |
1309- |
|
4HG1-T |
NKR71 EURO2 |
| 56 |
I8-97032 801-2 |
|
STAY RAD |
1 |
9712- |
|
4HF1 |
NKR 66, NKR 66-2 |
| 131 |
I1-09704 077-0 |
|
CLIP ENGINE SIDE TOP |
1 |
9312- |
|
4JB1 |
ID=42 ( NHR 55 ) |
| 56 |
I8-97350 322-0 |
|
STAY RAD |
1 |
0108- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71) |
| 22 |
I7-53192 063-A |
|
BRACKET RAD MTG |
1 |
0702- |
|
4JB1-TC |
RH, NHR55, NKR55 EURO2 |
| 59 |
I8-94202 777-0 |
|
PIN SNAP, STAY |
1 |
9312- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71) |
| 57 |
I0-91610 510-0 |
|
WASHER PL, STAY |
1 |
9312- |
|
4BE1 |
ID=10 ( NKR 58 ) |
| 78 |
I0-91180 208-0 |
|
NUT CUSHION RUBBER |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 1 |
I8-97178 663-A |
|
RADIATOR ASM |
1 |
1309- |
|
4JB1-TC |
NHR55/NKR55 EURO2 (ALUMINIUM) |
| 51 |
I8-97036 939-0 |
|
PLUG DRAIN |
1 |
9312- |
|
4BE1 |
W / O-RING ( NKR 58 ) |
| 25 |
I0-28651 030-0 |
|
BOLT BRKT |
2 |
9703- |
|
4HF1 |
M10X30 FLANGE |
| 22 |
I8-97205 216-0 |
|
BRACKET RAD MTG |
1 |
0702- |
|
4HG1-T |
LH, NKR71 EURO2 |
