| 23 |
I8-97077 713-1 |
|
JOINT; BREATHER HOSE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 40 |
I8-94438 385-4 |
|
BELT; SUPPORT,FUEL TANK |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 11 |
I8-94152 613-A |
|
PLUG; DRAIN, FUEL TANK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 1 |
I7-22227 014-A |
|
TANK; FUEL |
1 |
0702- |
|
4HG1-T |
1000 X 340 X 327, 100L |
| 8 |
I9-09572 014-1 |
|
GASKET; DRAIN PLUG, FUEL TANK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 51 |
I0-28661 030-0 |
|
BOLT; BRACKET TO FRAME |
8 |
9610- |
|
4JB1 |
M10X30 FLANGE ( NHR 55 ) |
| 11 |
I8-94152 613-A |
|
PLUG; DRAIN, FUEL TANK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 51 |
I0-28061 025-0 |
|
BOLT; BRACKET TO FRAME |
8 |
9312-9609 |
|
4JB1 |
M10X25 ( NHR 55 ) |
| 43 |
I8-97035 517-A |
|
BRACKET; FUEL TANK |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 27 |
I8-94128 826-0 |
|
HOSE; BREATHER |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 10 |
I5-09709 013-0 |
|
CLIP; SPRING, FUEL TANK UNIT CABLE |
AR |
9312- |
|
4BE1 |
(A) NKR 58 |
| 25 |
I8-94258 609-1 |
|
CAP; FILLER,FUEL TANK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 43 |
I8-97035 517-A |
|
BRACKET; FUEL TANK |
2 |
0211- |
|
4HF1 |
NPN-CHS 7012 |
| 1 |
I8-87131 123-0 |
|
TANK; FUEL |
1 |
9511-9801 |
|
4BE1 |
NKR 58 , 100L |
| 1 |
I8-97350 987-1 |
|
TANK; FUEL |
1 |
9802- |
|
4JB1 |
NHR 55, 70L |
| 25 |
I8-94258 609-1 |
|
CAP; FILLER,FUEL TANK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 23 |
I8-97077 713-1 |
|
JOINT; BREATHER HOSE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 10 |
I5-09709 047-0 |
|
CLIP; SPRING, FUEL TANK UNIT CABLE |
AR |
9811- |
|
4JB1 |
(A) T=5.5 ( NHR 55 ) |
| 23 |
I8-97077 713-1 |
|
JOINT; BREATHER HOSE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 17 |
I8-94128 826-0 |
|
HOSE; BREATHER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 27 |
I8-94128 825-A |
|
HOSE; BREATHER |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 3 |
I8-94316 190-0 |
|
UNIT; FUEL TANK, SUB |
1 |
0702- |
|
4JB1-TC |
NHR55, NKR55 EURO 2 |
| 20 |
I8-94128 826-0 |
|
HOSE; BREATHER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 492 |
I5-09707 030-1 |
|
CLIP; HARNESS TO VAC HOSE |
1 |
9312- |
|
4HF1 |
L=250 ( NKR 66, NKR 71 ) |
| 6 |
I8-97024 319-0 |
|
SCREW; TANK UNIT TO SUB FUEL TANK |
5 |
9312- |
|
4HF1 |
M5X10 W/LK WASHER |
| 49 |
I7-05110 010-A |
|
NUT; BRKT |
8 |
9312- |
|
4BE1 |
M10 FLANGE ( NKR 58 ) |
| 25 |
I8-94258 609-1 |
|
CAP; FILLER,FUEL TANK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 230 |
I8-94128 319-A |
|
GROMMET; HARNESS, FUEL TANK UNIT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 1 |
I7-56200 200-A |
|
TANK; FUEL |
1 |
0012-0405 |
|
4JB1 |
NHR 55, 70L |
| 27 |
I8-94128 826-0 |
|
HOSE; BREATHER |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 1 |
I8-97350 991-1 |
|
TANK; FUEL |
1 |
9802- |
|
4HF1 |
NKR 66 , NKR66-2 , 100L |
| 33 |
I8-94358 688-0 |
|
SCREW; JOINT TO FUEL TANK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 14 |
I9-09914 701-0 |
|
HOSE; BREATHER, OUTLATE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 40 |
I8-94438 385-4 |
|
BELT; SUPPORT,FUEL TANK |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 230 |
I8-94128 319-A |
|
GROMMET; HARNESS, FUEL TANK UNIT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 51 |
I0-28061 025-0 |
|
BOLT; BRACKET TO FRAME |
8 |
9312-9609 |
|
4HF1 |
M10X25 ( NKR 66 ) |
| 33 |
I8-94358 688-0 |
|
SCREW; JOINT TO FUEL TANK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 27 |
I8-94128 826-0 |
|
HOSE; BREATHER |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 43 |
I8-97035 517-A |
|
BRACKET; FUEL TANK |
2 |
9312- |
|
4BE1 |
NKR 58, NKR 66 |
| 1 |
I8-97350 987-1 |
|
TANK; FUEL |
1 |
9312-9510 |
|
4JB1 |
NHR 55, 70L |
| 51 |
I0-28061 025-0 |
|
BOLT; BRACKET TO FRAME |
8 |
9312-9609 |
|
4BE1 |
M10X25 ( NKR 58 ) |
| 42 |
I9-09130 408-0 |
|
NUT; SUPPORT BELT |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 49 |
I7-05110 010-A |
|
NUT; BRKT |
8 |
9312- |
|
4JB1 |
M10 FLANGE ( NHR 55 ) |
| 8 |
I9-09572 014-1 |
|
GASKET; DRAIN PLUG, FUEL TANK |
1 |
9312- |
|
4HF1 |
NKR 58, NKR 66, NKR 71 |
| 17 |
I8-94128 826-0 |
|
HOSE; BREATHER |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 230 |
I8-94128 319-A |
|
GROMMET; HARNESS, FUEL TANK UNIT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 10 |
I5-09709 013-0 |
|
CLIP; SPRING, FUEL TANK UNIT CABLE |
AR |
9312- |
|
4JB1 |
(A) NHR 55 |
| 1 |
I8-97350 991-1 |
|
TANK; FUEL |
1 |
9312-9510 |
|
4BE1 |
NKR 58 , 100L |
| 49 |
I7-05110 010-A |
|
NUT; BRKT |
8 |
9312- |
|
4HF1 |
M10 FLANGE |
| 492 |
I5-09707 030-1 |
|
CLIP; HARNESS TO VAC HOSE |
1 |
9312- |
|
4BE1 |
L=250 ( NKR 58 ) |
| 10 |
I5-09709 023-0 |
|
CLIP; SPRING, FUEL TANK UNIT CABLE |
AR |
9312- |
|
4BE1 |
(B) T=4.5 & 9 ( NKR 58 ) |
| 10 |
I5-09709 013-0 |
|
CLIP; SPRING, FUEL TANK UNIT CABLE |
AR |
9312- |
|
4HF1 |
(A) T=9.2 (NKR 66,NKR 66-2, NKR 71) |
| 501 |
I8-97096 990-0 |
|
GROMMET; BRACKET |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97350 991-1 |
|
TANK; FUEL |
1 |
9802- |
|
4BE1 |
NKR 58 , 100L |
| 10 |
I8-97041 091-0 |
|
CLIP; SPRING, FUEL TANK |
AR |
9811- |
|
4HF1 |
(B) T=9.2 & 9 |
| 6 |
I8-97024 319-0 |
|
SCREW; TANK UNIT TO SUB FUEL TANK |
5 |
9312- |
|
4BE1 |
NKR 58 |
| 10 |
I5-09709 023-0 |
|
CLIP; SPRING, FUEL TANK UNIT CABLE |
AR |
9312- |
|
4HF1 |
(B) T=4.5 & 9 |
| 3 |
I8-94316 190-0 |
|
UNIT; FUEL TANK, SUB |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 452 |
I8-97062 954-1 |
|
BREATHER; FUEL TANK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 20 |
I8-94128 825-A |
|
HOSE; BREATHER |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 10 |
I5-09709 047-0 |
|
CLIP; SPRING, FUEL TANK UNIT CABLE |
AR |
9811- |
|
4HF1-2 |
(A) T=5.5 |
| 1 |
I8-87131 123-0 |
|
TANK; FUEL |
1 |
9511-9801 |
|
4HF1 |
NKR 66 , NKR66-2 , 100L |
| 1 |
I8-97350 991-1 |
|
TANK; FUEL |
1 |
0211- |
|
4HG1 |
1000 X 340 X 327, 100L |
| 3 |
I8-94316 190-0 |
|
UNIT; FUEL TANK, SUB |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 452 |
I8-97062 954-1 |
|
BREATHER; FUEL TANK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 1 |
I8-97350 991-1 |
|
TANK; FUEL |
1 |
9312-9510 |
|
4HF1 |
NKR 66 , NKR66-2 , 100L |
| 452 |
I8-97062 954-1 |
|
BREATHER; FUEL TANK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 20 |
I8-94128 826-0 |
|
HOSE; BREATHER |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 1 |
I7-22227 014-A |
|
TANK; FUEL |
1 |
0211- |
|
4HG1 |
1000 X 340 X 327, 100L |
| 14 |
I9-09914 701-0 |
|
HOSE; BREATHER, OUTLATE |
1 |
0211- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71 ) |
| 42 |
I9-09130 408-0 |
|
NUT; SUPPORT BELT |
2 |
9312- |
|
4HF1 |
NKR 58, NKR 66, NKR 71 |
| 17 |
I8-94128 826-0 |
|
HOSE; BREATHER |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 3 |
I8-94316 190-0 |
|
UNIT; FUEL TANK, SUB |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 17 |
I8-94128 825-A |
|
HOSE; BREATHER |
1 |
0211- |
|
4HF1 |
( NKR 66, NKR 66-2, NKR 71 ) |
| 10 |
I5-09709 023-0 |
|
CLIP; SPRING, FUEL TANK UNIT CABLE |
AR |
9312- |
|
4JB1 |
(B) T=4.5 & 9 ( NHR 55 ) |
| 33 |
I8-94358 688-0 |
|
SCREW; JOINT TO FUEL TANK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 492 |
I5-09707 030-1 |
|
CLIP; HARNESS TO VAC HOSE |
1 |
9312- |
|
4JB1 |
L=250 ( NHR 55 ) |
| 43 |
I8-97035 516-A |
|
BRACKET; FUEL TANK |
2 |
0211- |
|
4JB1 |
NHR 55, (NPN-CHS-7011) |
| 40 |
I7-56402 275-A |
|
BELT; SUPPORT,FUEL TANK |
2 |
9801- |
|
4JB1 |
NHR 55, (NPN-CHS-7013) |
| 14 |
I9-09914 701-0 |
|
HOSE; BREATHER, OUTLATE |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 1 |
I7-56200 200-A |
|
TANK; FUEL |
1 |
0702- |
|
4JB1-TC |
NHR55,NKR55 EURO 2, 70L |
| 11 |
I8-94152 613-A |
|
PLUG; DRAIN, FUEL TANK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 51 |
I0-28661 030-0 |
|
BOLT; BRACKET TO FRAME |
8 |
9610- |
|
4HF1 |
M10X30 FLANGE |
| 501 |
I8-97096 990-0 |
|
GROMMET; BRACKET |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 1 |
I8-97131 121-0 |
|
TANK; FUEL |
1 |
9511-9801 |
|
4JB1 |
NHR 55, 70L |
| 14 |
I9-09914 701-0 |
|
HOSE; BREATHER, OUTLATE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 20 |
I8-94128 826-0 |
|
HOSE; BREATHER |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 501 |
I8-97096 990-0 |
|
GROMMET; BRACKET |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 3 |
I8-94316 190-0 |
|
UNIT; FUEL TANK, SUB |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 6 |
I8-97024 319-0 |
|
SCREW; TANK UNIT TO SUB FUEL TANK |
5 |
9312- |
|
4JB1 |
M5X10 W/LK WASHER |
