1-45 | WATER SEDIMENTER FUEL
ELF
NHR NKR
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 56 | I5-13211 030-1 | CASE FUEL SEDIMENTER | 1 | 9312- | 4JB1 | NHR 55 | ||
| 1 | I6-97081 814-4 | FILTER ASM FUEL | 1 | 9312-0403 | 4JB1 | (IADG) NHR 55 ( 77PS ) | ||
| 7 | I8-94132 674-0 | PLUG DRAIN,SEDIMENTER | 1 | 9312- | 4BE1 | NKR 58 | ||
| 21 | I7-05110 010-A | NUT CUSHION RUB TO BRKT | 1 | 9312- | 4JB1 | NHR 55 | ||
| 9 | I8-94132 675-0 | GASKET DRAIN PLUG & CONNECTOR | 1 | 9312- | 4JB1 | NHR 55 | ||
| 9 | I8-94132 675-0 | GASKET DRAIN PLUG & CONNECTOR | 1 | 9312- | 4BE1 | NKR 58 | ||
| 37 | I8-94416 376-0 | PLUG SENSOR | 1 | 9312- | 4BE1 | NKR 58 | ||
| 21 | I0-91180 110-0 | NUT GUIDE TUBE | 1 | 0702- | 4JB1-TC | NHR55,NKR55 EURO 2 | ||
| 19 | I8-97226 277-0 | BRACKET FUEL SEDIMENTER | 1 | 9811- | 4HF1 | (C) NKR 66, NKR 66-2,NKR 71 | ||
| 14 | I8-94167 886-0 | GASKET PLUG, OIL FILTER | 1 | 0702- | 4HG1-T | NKR71T/THD | ||
| 37 | I8-94453 746-0 | PLUG SENSOR | 1 | 0702- | 4JB1-TC | NHR55,NKR55 EURO 2 | ||
| 1 | I8-97207 734-1 | FILTER ASM FUEL | 1 | 0404- | 4HF1-2 | NKR 66-2 ( 100PS ) | ||
| 7 | I8-94132 674-0 | PLUG DRAIN,SEDIMENTER | 1 | 0702- | 4JB1-TC | NHR55/NKR55 EURO 2 | ||
| 15 | I8-94153 430-0 | PLUG SENSOR FUEL FILTER | 1 | 9312- | 4BE1 | NKR 58 | ||
| 20 | I0-50740 820-0 | BOLT OIL PAN | 2 | 9312- | 4JB1 | M8X20 W/LK WASHER | ||
| 14 | I8-94167 886-0 | GASKET PLUG, OIL FILTER | 1 | 0702- | 4JB1-TC | NHR55/NKR55 | ||
| 20 | I0-28051 030-0 | BOLT BRACKET TO SEDIMENTER | 2 | 9312- | 4JB1 | M10X30 FLANGE ( NHR 55 ) | ||
| 1 | I6-97081 814-4 | FILTER ASM FUEL | 1 | 0404- | 4JB1 | (IADG) NHR 55 | ||
| 80 | I8-94328 912-0 | CLIP SEDIMENTER | 1 | 9312- | 4BE1 | NKR 58 | ||
| 21 | I7-05110 010-A | NUT CUSHION RUB TO BRKT | 1 | 9312- | 4HF1 | NKR 66, NKR 71 | ||
| 5 | I5-09623 075-0 | BOLT FUEL FILTER | 1 | 0702- | 4JB1-TC | (B) NHR55/NKR55 EURO 2 | ||
| 36 | I5-13234 010-0 | RING BODY TO CASE | 2 | 9312- | 4JB1 | NHR 55 | ||
| 21 | I7-05110 010-A | NUT CUSHION RUB TO BRKT | 1 | 9312- | 4BE1 | NKR 58 | ||
| 36 | I5-13234 010-0 | RING BODY TO CASE | 2 | 0702- | 4JB1-TC | NHR55,NKR55 EURO 2 | ||
| 5 | I5-09623 075-0 | BOLT FUEL FILTER | 1 | 9312- | 4BE1 | (B) NKR 58, NKR 66, NKR 71 | ||
| 87 | I8-97316 630-1 | CASE ASM SEDIMENTER | 1 | 0702- | 4HG1-T | NKR71 EURO 2 | ||
| 7 | I8-94132 674-0 | PLUG DRAIN,SEDIMENTER | 1 | 9312- | 4JB1 | NHR 55 | ||
| 5 | I5-09623 075-0 | BOLT FUEL FILTER | 1 | 0702- | 4HG1-T | (B) NKR71T/THD EURO 2 | ||
| 20 | I0-50740 820-0 | BOLT OIL PAN | 2 | 9312- | 4BE1 | M8X20 W/LK WASHER | ||
| 9 | I8-94132 675-0 | GASKET DRAIN PLUG & CONNECTOR | 1 | 0702- | 4HG1-T | NKR71T/THD EURO 2 | ||
| 9 | I9-09571 406-0 | GASKET DRAIN PLUG & CONNECTOR | 1 | 0211- | 4HG1 | NKR 71 | ||
| 19 | I8-94162 580-0 | BRACKET FUEL SEDIMENTER | 1 | 9312- | 4JB1 | (A) NHR 55 | ||
| 20 | I0-28051 030-0 | BOLT BRACKET TO SEDIMENTER | 2 | 9312- | 4BE1 | M10X30 FLANGE ( NKR 58 ) | ||
| 19 | I8-97226 277-0 | BRACKET FUEL SEDIMENTER | 1 | 9811- | 4JB1 | (C) NHR 55 | ||
| 87 | I8-97316 630-1 | CASE ASM SEDIMENTER | 1 | 0702- | 4JB1-TC | NHR55,NKR55 EURO 2 | ||
| 56 | I5-13211 030-1 | CASE FUEL SEDIMENTER | 1 | 9312- | 4BE1 | NKR 58 | ||
| 26 | I5-15411 223-A | PIPE FUEL, IN & OUT | 2 | 9312- | 4BE1 | NKR 58 | ||
| 21 | I0-91180 110-0 | NUT GUIDE TUBE | 1 | 0702- | 4HG1-T | NKR71 EURO 2 | ||
| 87 | I8-97316 630-1 | CASE ASM SEDIMENTER | 1 | 0211- | 4HG1 | NKR 71 | ||
| 1 | I8-97207 734-1 | FILTER ASM FUEL | 1 | 9811-0403 | 4HF1-2 | NKR 66-2 ( 100PS ) | ||
| 43 | I9-09572 014-1 | GASKET EYE BOLT | 4 | 9312- | 4BE1 | NKR 58 | ||
| 9 | I8-94132 675-0 | GASKET DRAIN PLUG & CONNECTOR | 1 | 9312- | 4HF1 | NKR 66 | ||
| 41 | I9-09563 334-0 | GASKET SENSOR TO CASE | 1 | 9312- | 4HF1 | NKR 66 | ||
| 7 | I8-94132 674-0 | PLUG DRAIN,SEDIMENTER | 1 | 9312- | 4HF1 | NKR 66, NKR 71 | ||
| 7 | I8-94132 674-0 | PLUG DRAIN,SEDIMENTER | 1 | 0702- | 4HG1-T | NKR71T/THD EURO 2 | ||
| 43 | I9-09572 014-1 | GASKET EYE BOLT | 4 | 9312- | 4HF1 | ID=14.2 OD = 23.0 | ||
| 19 | I8-97090 294-3 | BRACKET FUEL SEDIMENTER | 1 | 9811- | 4HF1-2 | (A) NKR 66-2 | ||
| 27 | I8-98037 827-0 | BOLT WATER PIPE | 2 | 9312- | 4HF1 | NKR 66, NKR 71 | ||
| 39 | I8-94242 117-0 | HOSE SEDIMENTER | 1 | 9312- | 4BE1 | NKR 58 | ||
| 15 | I8-97316 630-1 | PLUG SENSOR FUEL FILTER | 1 | 9312- | 4JB1 | NHR 55 | ||
| 1 | I8-94144 933-4 | FILTER ASM FUEL | 1 | 9312- | 4HF1 | NKR 66 (135PS ), NKR 71 | ||
| 1 | I8-97081 814-3 | FILTER ASM FUEL | 1 | 9312-0403 | 4JB1 | NHR 55 ( 77PS ) | ||
| 26 | I5-15411 223-A | PIPE FUEL, IN & OUT | 2 | 9312- | 4HF1 | NKR 66, NKR 71 | ||
| 15 | I8-97079 821-0 | PLUG SENSOR FUEL FILTER | 1 | 9811- | 4HF1-2 | NKR 66 -2 ( 100PS ) | ||
| 5 | I9-19563 334-0 | BOLT FUEL FILTER | 1 | 9312- | 4JB1 | (A) NHR 55 | ||
| 20 | I0-28051 030-0 | BOLT BRACKET TO SEDIMENTER | 2 | 0702- | 4JB1-TC | NHR55,NKR55 EURO 2 | ||
| 56 | I5-13211 030-1 | CASE FUEL SEDIMENTER | 1 | 9312- | 4HF1 | NKR 66, NKR 71 | ||
| 19 | I8-98017 562-0 | BRACKET FUEL SEDIMENTER | 1 | 0702- | 4HG1-T | (A) NKR71T/THD EURO 2 | ||
| 80 | I8-94328 912-0 | CLIP SEDIMENTER | 1 | 9312- | 4HF1 | NKR 66 | ||
| 19 | I8-97090 296-3 | BRACKET FUEL SEDIMENTER | 1 | 9312- | 4BE1 | (C) NKR 58 | ||
| 36 | I5-13234 010-0 | RING BODY TO CASE | 2 | 9312- | 4HF1 | NKR 66, NKR 71 | ||
| 1 | I6-97081 814-4 | FILTER ASM FUEL | 1 | 0702- | 4HG1-T | (IADG) NKR71T/THD | ||
| 27 | I8-98037 827-0 | BOLT WATER PIPE | 2 | 9312- | 4BE1 | NKR 58 | ||
| 1 | I8-94144 933-4 | FILTER ASM FUEL | 1 | 9312- | 4BE1 | NKR 58 ( 100PS ) | ||
| 9 | I8-94132 675-0 | GASKET DRAIN PLUG & CONNECTOR | 1 | 0702- | 4JB1-TC | NHR55/NKR55 EURO 2 | ||
| 14 | I8-94167 886-0 | GASKET PLUG, OIL FILTER | 1 | 9312- | 4HF1 | NKR 66, NKR 71 | ||
| 20 | I0-28051 030-0 | BOLT BRACKET TO SEDIMENTER | 2 | 0702- | 4HG1-T | NKR71 EURO 2 | ||
| 1 | I8-97081 814-3 | FILTER ASM FUEL | 1 | 0702- | 4HG1-T | NKR71T/THD | ||
| 1 | I8-97081 814-3 | FILTER ASM FUEL | 1 | 0404- | 4JB1 | NHR 55 | ||
| 37 | I8-94453 746-0 | PLUG SENSOR | 1 | 0211- | 4HG1 | NKR 71 | ||
| 36 | I5-13234 010-0 | RING BODY TO CASE | 2 | 9312- | 4BE1 | NKR 58 | ||
| 14 | I8-94167 886-0 | GASKET PLUG, OIL FILTER | 1 | 9312- | 4JB1 | NHR 55 | ||
| 36 | I5-13234 010-0 | RING BODY TO CASE | 2 | 0702- | 4HG1-T | NKR71 EURO 2 | ||
| 20 | I0-28051 030-0 | BOLT BRACKET TO SEDIMENTER | 2 | 9312- | 4HF1 | M10X30 FLANGE ( NKR 66 ) | ||
| 1 | I6-97081 814-4 | FILTER ASM FUEL | 1 | 0702- | 4JB1-TC | (IADG) NHR55/NKR55 | ||
| 1 | I8-97081 814-3 | FILTER ASM FUEL | 1 | 0702- | 4JB1-TC | NHR55/NKR55 | ||
| 38 | I5-13258 001-0 | FLOAT SEDIMENTER | 1 | 9312- | 4BE1 | NKR 58 | ||
| 20 | I0-50740 820-0 | BOLT OIL PAN | 2 | 9312- | 4HF1 | M8X20 W/LK WASHER | ||
| 15 | I8-94153 430-0 | PLUG SENSOR FUEL FILTER | 1 | 9312- | 4HF1 | NKR 66 ( 135PS ) | ||
| 41 | I9-09563 334-0 | GASKET SENSOR TO CASE | 1 | 9312- | 4BE1 | NKR 58 | ||
| 37 | I8-94416 376-0 | PLUG SENSOR | 1 | 9312- | 4HF1 | NKR 66 | ||
| 19 | I8-98017 562-0 | BRACKET FUEL SEDIMENTER | 1 | 0702- | 4JB1-TC | (A) NHR55/NKR55 EURO 2 | ||
| 19 | I8-97090 296-3 | BRACKET FUEL SEDIMENTER | 1 | 9312- | 4HF1 | (C) NKR 66 | ||
| 39 | I8-94242 117-0 | HOSE SEDIMENTER | 1 | 9312- | 4HF1 | NKR 66 | ||
| 37 | I8-94450 148-0 | PLUG SENSOR | 1 | 9312- | 4JB1 | NHR 55 | ||
| 14 | I8-94167 886-0 | GASKET PLUG, OIL FILTER | 1 | 9312- | 4JB1 | NHR 55 | ||
| 19 | I8-97090 294-3 | BRACKET FUEL SEDIMENTER | 1 | 9811- | 4JB1 | (A) NHR 55 | ||
| 38 | I5-13258 001-0 | FLOAT SEDIMENTER | 1 | 9312- | 4HF1 | NKR 66 | ||
| 37 | I8-94453 746-0 | PLUG SENSOR | 1 | 0702- | 4HG1-T | NKR71 EURO 2 |
