| 226 |
I8-94170 378-0 |
|
PIN; SHIFT CABLE |
1 |
9312- |
|
4JB1 |
(B) L=23 ( NHR 55 ) |
| 203 |
I0-91180 208-0 |
|
NUT; CAM BRKT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 249 |
I9-09851 889-0 |
|
WASHER; RUBBER, CONT ROD TO LEVER |
1 |
9312- |
|
4JB1 |
ID=8.5 T = 1.5 ( NHR 55 ) |
| 274 |
I8-97093 491-1 |
|
CLIP; CONT CABLE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I6-71800 201-0 |
|
CABLE; SHIFT, TRANS CONT |
1 |
9801- |
|
4JB1 |
(IADG) NHR 55 (P718002010) |
| 29 |
I5-09509 001-0 |
|
WASHER; LK, RELAY LVR |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 201 |
I0-28050 816-0 |
|
BOLT; BRKT |
1 |
9312- |
|
4JB1 |
M8X16 FLANGE ( NHR 55 ) |
| 52 |
I0-91180 208-0 |
|
NUT; COVER, HD |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 199 |
I0-91610 508-0 |
|
WASHER; PL, SELECT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 51 |
I8-97029 286-0 |
|
BRACKET; GEAR CONT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 52 |
I0-91180 208-0 |
|
NUT; COVER, HD |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 3 |
I6-71800 203-0 |
|
CABLE; SELECT, TRANS CONT |
1 |
9312-0311 |
|
4JB1 |
(IADG) NHR 55 |
| 6 |
I8-97211 011-0 |
|
CLIP; CABLE |
2 |
9312- |
|
4BE1 |
(F) NKR 58, NKR 66 |
| 228 |
I8-97182 975-0 |
|
WASHER; PL, SHIFT CABLE |
2 |
9312-9707 |
|
4JB1 |
(A) ID=8 T = 2.3 ( NHR 55 ) |
| 3 |
I8-97351 821-A |
|
CABLE; SELECT, TRANS CONT |
1 |
9801- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 219 |
I8-94363 045-0 |
|
NUT; FLANGE, SHAFT CABLE |
1 |
9312- |
|
4BE1 |
M8 T = 8.0 ( NKR 58 ) |
| 226 |
I8-94157 841-0 |
|
PIN; SHIFT CABLE |
1 |
9312- |
|
4JB1 |
(A) L=27.7 ( NHR 55 ) |
| 486 |
I8-97359 618-0 |
|
NUT; WEIGHT |
1 |
9312- |
|
4BE1 |
M12 FLANGE ( NKR 58 ) |
| 201 |
I0-28050 820-0 |
|
BOLT; BRKT |
1 |
9312-9411 |
|
4JB1 |
M8X20 FLANGE ( NHR 55 ) |
| 6 |
I8-97036 333-1 |
|
CLIP; CABLE |
AR |
9312- |
|
4BE1 |
(A) NKR 58 |
| 1 |
I7-71800 201-A |
|
CABLE; SHIFT, TRANS CONT |
1 |
9801- |
|
4JB1 |
NHR 55 (P718002010) |
| 228 |
I8-97182 975-0 |
|
WASHER; PL, SHIFT CABLE |
2 |
9312-9707 |
|
4BE1 |
(A) NKR 58 |
| 6 |
I8-97147 985-0 |
|
CLIP; CABLE |
1 |
9312-9510 |
|
4BE1 |
(E) NKR 58, NKR 66 |
| 6 |
I8-97036 333-1 |
|
CLIP; CABLE |
AR |
9312- |
|
4JB1 |
(A) NHR 55 |
| 228 |
I8-97182 975-0 |
|
WASHER; PL, SHIFT CABLE |
2 |
9708- |
|
4HF1 |
(A) NKR 66, NKR 66-2, NKR 71 |
| 376 |
I8-94170 378-0 |
|
PIN; SHIFT CABLE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 113 |
I8-97089 693-0 |
|
WASHER; RELAY LEVER |
1 |
9312-9704 |
|
4JB1 |
(B) NHR 55 |
| 3 |
I8-97176 480-1 |
|
CABLE; SELECT, TRANS CONT |
1 |
9608- |
|
4BE1 |
NKR 58 |
| 114 |
I7-05110 010-A |
|
NUT; RELAY LEVER |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 357 |
I8-97089 692-0 |
|
BRACKET; RELAY LEVER |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 228 |
I8-97182 975-0 |
|
WASHER; PL, SHIFT CABLE |
2 |
9312-9707 |
|
4HF1 |
(A) NKR 66 |
| 376 |
I8-94170 378-0 |
|
PIN; SHIFT CABLE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 1 |
I6-71800 201-0 |
|
CABLE; SHIFT, TRANS CONT |
1 |
9312- |
|
4JB1 |
(IADG) NHR 55 |
| 3 |
I8-97176 475-0 |
|
CABLE; SELECT, TRANS CONT |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 226 |
I8-94157 841-0 |
|
PIN; SHIFT CABLE |
1 |
9312- |
|
4HF1 |
(A) L=27.7 (NKR 66, NKR 66-2, NKR 71) |
| 52 |
I0-91180 208-0 |
|
NUT; COVER, HD |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 303 |
I0-91180 208-0 |
|
NUT; CAM BRKT |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 300 |
I0-28050 820-0 |
|
BOLT; CLIP |
AR |
9312-9411 |
|
4BE1 |
M8X20 FLANGE ( NKR 58 ) |
| 201 |
I0-28050 820-0 |
|
BOLT; BRKT |
1 |
9312-9411 |
|
4HF1 |
M8X20 FLANGE ( NKR 66 ) |
| 6 |
I8-97211 011-0 |
|
CLIP; CABLE |
2 |
9312- |
|
4JB1 |
(F) NHR 55 |
| 278 |
I0-91541 208-0 |
|
WASHER; LK, SHIFT WIRE |
1 |
9312- |
|
4JB1 |
M8 ( NHR 55 ) |
| 226 |
I8-94170 378-0 |
|
PIN; SHIFT CABLE |
1 |
9312- |
|
4BE1 |
(B) L=23 ( NKR 58 ) |
| 226 |
I8-94157 841-0 |
|
PIN; SHIFT CABLE |
1 |
9312- |
|
4BE1 |
(A) L=27.7 ( NKR 58 ) |
| 226 |
I8-94170 378-0 |
|
PIN; SHIFT CABLE |
1 |
9312- |
|
4HF1 |
(A) L=23 (NKR 66, NKR 66-2, NKR 71) |
| 300 |
I0-28050 816-0 |
|
BOLT; CLIP |
1 |
9312- |
|
4JB1 |
M8X16 FLANGE ( NHR 55 ) |
| 112 |
I8-97085 157-0 |
|
BUSHING; RELAY LEVER |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 201 |
I0-28650 825-0 |
|
BOLT; BRKT |
1 |
9412- |
|
4BE1 |
M8X25 ( NKR 58 ) |
| 282 |
I8-97013 217-3 |
|
BRACKET; TRANS SIDE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 22 |
I8-97085 158-0 |
|
ROD; CONT, SHIFT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 6 |
I8-97036 332-1 |
|
CLIP; CABLE |
1 |
9312- |
|
4BE1 |
(C) NKR 58, NKR66 |
| 201 |
I0-28650 825-0 |
|
BOLT; BRKT |
1 |
9412- |
|
4BE1 |
M8X25 ( NKR 66, NKR 71 ) |
| 303 |
I0-91180 208-0 |
|
NUT; CAM BRKT |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 201 |
I0-28650 825-0 |
|
BOLT; BRKT |
1 |
9412- |
|
4JB1 |
M8X25 ( NHR 55 ) |
| 6 |
I8-97147 985-0 |
|
CLIP; CABLE |
1 |
9609- |
|
4JB1 |
(E) NHR 55 |
| 203 |
I0-91180 208-0 |
|
NUT; CAM BRKT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 6 |
I8-97011 448-0 |
|
CLIP; CABLE |
2 |
9312- |
|
4JB1 |
(G) NHR 55 |
| 247 |
I9-09876 059-1 |
|
PIN; CONT ROD TO LEVER |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 376 |
I8-94170 378-0 |
|
PIN; SHIFT CABLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 283 |
I0-28051 040-0 |
|
BOLT; RELAY LEVER |
1 |
9312-9703 |
|
4JB1 |
(B) NHR 55 |
| 279 |
I8-97103 234-0 |
|
BRACKET; CABLE TO FRAME |
1 |
9312- |
|
4JB1 |
(C) NHR 55 |
| 279 |
I8-97047 898-0 |
|
BRACKET; CABLE TO FRAME |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
| 303 |
I0-91180 208-0 |
|
NUT; CAM BRKT |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 300 |
I0-28050 820-0 |
|
BOLT; CLIP |
AR |
9312-9411 |
|
4JB1 |
M8X20 FLANGE ( NHR 55 ) |
| 219 |
I8-94363 045-0 |
|
NUT; FLANGE, SHAFT CABLE |
1 |
9312- |
|
4JB1 |
M8 T = 8.0 ( NHR 55 ) |
| 294 |
I0-91180 208-0 |
|
NUT; COVER, HD |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 6 |
I8-97036 332-1 |
|
CLIP; CABLE |
1 |
9312- |
|
4JB1 |
(C) NHR 55 |
| 279 |
I8-97028 496-1 |
|
BRACKET; CABLE TO FRAME |
1 |
9312- |
|
4HF1 |
(A) NKR 66, NKR 66-2, NKR 71 |
| 113 |
I8-97061 437-0 |
|
WASHER; RELAY LEVER |
2 |
9312- |
|
4JB1 |
(A) NHR 55 |
| 300 |
I0-28050 816-0 |
|
BOLT; CLIP |
1 |
9312- |
|
4HF1 |
M8X16 FLANGE ( NKR 66, NKR 71 ) |
| 201 |
I0-28050 820-0 |
|
BOLT; BRKT |
1 |
9312-9411 |
|
4BE1 |
M8X20 FLANGE ( NKR 58 ) |
| 6 |
I8-97147 985-0 |
|
CLIP; CABLE |
1 |
9609- |
|
4HF1 |
(E) NKR 66, NKR 66-2, NKR 71 |
| 77 |
I8-94363 045-0 |
|
NUT; LK. BALL JOINT, CONT ROD |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 3 |
I6-71800 203-0 |
|
CABLE; SELECT, TRANS CONT |
1 |
0312- |
|
4JB1 |
(IADG) NHR 55, (P718002030) |
| 300 |
I0-28050 816-0 |
|
BOLT; CLIP |
1 |
9312- |
|
4BE1 |
M8X16 FLANGE ( NKR 58 ) |
| 6 |
I8-97011 448-0 |
|
CLIP; CABLE |
2 |
9312- |
|
4HF1 |
(G) NKR58, NKR66, NKR66-2, NKR71 |
| 112 |
I8-94252 671-0 |
|
BUSHING; RELAY LEVER |
2 |
9312- |
|
4JB1 |
(A) NHR 55 |
| 282 |
I8-97035 759-0 |
|
BRACKET; TRANS SIDE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 117 |
I8-97061 438-0 |
|
SEAL; DUST, RELAY LEVER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 6 |
I8-97211 011-0 |
|
CLIP; CABLE |
2 |
9811- |
|
4HF1 |
(G) NKR 66, NKR 66-2, NKR 71 |
| 282 |
I8-97182 260-0 |
|
BRACKET; TRANS SIDE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 300 |
I0-28050 820-0 |
|
BOLT; CLIP |
AR |
9312-9411 |
|
4HF1 |
M8X20 FLANGE ( NKR 66 ) |
| 228 |
I9-09164 508-0 |
|
WASHER; PL, SHIFT CABLE |
1 |
9312- |
|
4JB1 |
(B) ID=8 ( NHR 55 ) |
| 283 |
I8-94184 573-1 |
|
BOLT; RELAY LEVER |
1 |
9312-9703 |
|
4JB1 |
(A) NHR 55 |
| 113 |
I0-91610 610-0 |
|
WASHER; RELAY LEVER |
1 |
9705- |
|
4JB1 |
(B) NHR 55 |
| 6 |
I8-97036 331-1 |
|
CLIP; CABLE |
1 |
9312- |
|
4HF1 |
(D) NKR 66, NKR 66-2, NKR 71 |
| 228 |
I9-09164 508-0 |
|
WASHER; PL, SHIFT CABLE |
1 |
9312- |
|
4HF1 |
(B) ID=8 (NKR 66, NKR 66-2, NKR 71) |
| 284 |
I8-94242 854-0 |
|
WASHER; WAVED, SELECT CABLE, CAB |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 482 |
I8-97017 290-1 |
|
WEIGHT; SHIFT CABLE |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 279 |
I8-97047 898-0 |
|
BRACKET; CABLE TO FRAME |
1 |
9312- |
|
4BE1 |
(B) NKR 58, NKR 66-2, NKR 66, NKR 71 |
| 284 |
I8-94242 854-0 |
|
WASHER; WAVED, SELECT CABLE, CAB |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 407 |
I8-97174 055-2 |
|
LEVER; RELAY, SHIFT |
1 |
0211- |
|
4JB1 |
NHR 55 |
| 203 |
I0-91180 208-0 |
|
NUT; CAM BRKT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 300 |
I0-28650 825-0 |
|
BOLT; CLIP |
1 |
9412- |
|
4HF1 |
M8X25 FLANGE |
| 222 |
I8-97061 403-A |
|
GROMMET; CABLE |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 300 |
I0-28650 825-0 |
|
BOLT; CLIP |
1 |
9412- |
|
4JB1 |
M8X25 FLANGE ( NHR 55 ) |
| 357 |
I8-97089 691-0 |
|
BRACKET; RELAY LEVER |
1 |
9312- |
|
4JB1 |
(A) NHR 55 |
| 219 |
I8-94363 045-0 |
|
NUT; FLANGE, SHAFT CABLE |
1 |
9312- |
|
4HF1 |
M8 T = 8.0 ( NKR 66, NKR 71 ) |
| 486 |
I8-97359 618-0 |
|
NUT; WEIGHT |
1 |
9312- |
|
4HF1 |
M12 FLANGE ( NKR 66 ) |
| 25 |
I8-94210 407-0 |
|
PIN; SNAP, CONTROL ROD RELAY LEVER |
1 |
9312- |
|
4JB1 |
L=27.7 ( NHR 55 ) |
| 274 |
I8-97093 491-1 |
|
CLIP; CONT CABLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 228 |
I8-97182 975-0 |
|
WASHER; PL, SHIFT CABLE |
2 |
9708- |
|
4JB1 |
(A) NHR 55 |
| 485 |
I0-28061 260-0 |
|
BOLT; WEIGHT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 283 |
I0-28651 025-0 |
|
BOLT; RELAY LEVER |
1 |
9704- |
|
4JB1 |
(A) NHR 55 |
| 1 |
I8-97351 820-A |
|
CABLE; SHIFT, TRANS CONT |
1 |
9801- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 222 |
I8-97061 403-A |
|
GROMMET; CABLE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 485 |
I0-28061 260-0 |
|
BOLT; WEIGHT |
1 |
9312- |
|
4HF1 |
NKR 66 |
| 6 |
I8-97036 333-1 |
|
CLIP; CABLE |
AR |
9312- |
|
4HF1 |
(A) NKR 66, NKR 66-2, NKR 71 |
| 228 |
I9-09164 508-0 |
|
WASHER; PL, SHIFT CABLE |
1 |
9312- |
|
4BE1 |
(B) ID=8 ( NKR 58 ) |
| 278 |
I0-91541 208-0 |
|
WASHER; LK, SHIFT WIRE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 1 |
I8-97176 467-0 |
|
CABLE; SHIFT, TRANS CONT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 3 |
I7-71800 203-A |
|
CABLE; SELECT, TRANS CONT |
1 |
9312-0311 |
|
4JB1 |
NHR 55 |
| 1 |
I7-71800 201-A |
|
CABLE; SHIFT, TRANS CONT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 199 |
I0-91610 508-0 |
|
WASHER; PL, SELECT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 257 |
I8-94369 173-0 |
|
PIECE; DIST, RELAY LVR |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97176 472-0 |
|
CABLE; SHIFT, TRANS CONT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 274 |
I8-97093 491-1 |
|
CLIP; CONT CABLE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 222 |
I8-97061 403-A |
|
GROMMET; CABLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 278 |
I0-91541 208-0 |
|
WASHER; LK, SHIFT WIRE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 283 |
I0-28651 035-0 |
|
BOLT; RELAY LEVER |
1 |
9704- |
|
4JB1 |
(B) NHR 55 |
| 282 |
I8-97311 441-1 |
|
BRACKET; TRANS SIDE |
1 |
0108- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 3 |
I8-97176 480-1 |
|
CABLE; SELECT, TRANS CONT |
1 |
9312-9607 |
|
4BE1 |
NKR 58 |
| 6 |
I8-97147 985-0 |
|
CLIP; CABLE |
1 |
9312-9510 |
|
4JB1 |
(E) NHR 55 |
| 199 |
I0-91610 508-0 |
|
WASHER; PL, SELECT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 482 |
I8-97017 290-1 |
|
WEIGHT; SHIFT CABLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 284 |
I8-94242 854-0 |
|
WASHER; WAVED, SELECT CABLE, CAB |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 3 |
I7-71800 203-A |
|
CABLE; SELECT, TRANS CONT |
1 |
0312- |
|
4JB1 |
NHR 55, (P718002030) |
| 6 |
I8-97039 295-0 |
|
CLIP; CABLE |
1 |
9312- |
|
4HF1 |
(B) NKR 66, NKR 66-2, NKR 71 |
| 113 |
I0-91610 708-0 |
|
WASHER; RELAY LEVER |
1 |
9312- |
|
4JB1 |
(B) NHR 55 |
