| 26 |
I9-09851 986-0 |
|
PLATE; SHOE GUIDE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 34 |
I8-94132 159-0 |
|
PIN; BRK SHOE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 17 |
I8-97020 250-2 |
|
SHOE; PARKING BRK |
2 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 30 |
I8-94311 779-0 |
|
STRUT; PARKING BRK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 38 |
I0-91510 808-0 |
|
WASHER; LK, SUPPORT PLATE |
2 |
9312- |
|
4JB1 |
ID =12 ( NHR 55 ) |
| 24 |
I8-94132 155-1 |
|
SPRING; BRK SHOE |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 24 |
I8-94132 155-1 |
|
SPRING; BRK SHOE |
2 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 36 |
I5-47169 002-0 |
|
GROMMET; ADJ HOLE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2 |
| 114 |
I8-97289 002-0 |
|
STUD; SUPPORT PLATE |
4 |
0010- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 25 |
I8-94132 156-0 |
|
SPRING; SHOE ALIGNMENT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 32 |
I8-94311 780-1 |
|
PLATE; SUPPORT, PARKING BRK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 47 |
I8-97213 401-0 |
|
BOLT; SUPPORT PLATE |
4 |
9312- |
|
4HF1 |
NKR 66, NKR66-2 |
| 172 |
I8-94378 404-0 |
|
CUP; SHOE HOLD |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 32 |
I8-94311 780-1 |
|
PLATE; SUPPORT, PARKING BRK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2 |
| 22 |
I9-09942 340-1 |
|
SPRING; ADJ SCREW, PARKING |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 17 |
I8-97042 933-1 |
|
SHOE; PARKING BRK |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 22 |
I8-94107 618-0 |
|
SPRING; ADJ SCREW, PARKING |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 37 |
I8-97033 122-0 |
|
NUT; SUPPORT PLATE |
1 |
9312- |
|
4JB1 |
M 12 ( NHR 55 ) |
| 112 |
I0-50540 616-0 |
|
BOLT; COVER TO BRK DRUM |
1 |
9312- |
|
4HF1 |
M 6 X 16 W / SP WASHER |
| 1 |
I8-97100 212-3 |
|
BRAKE ASM; CENTER, PARKING |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 29 |
I8-94128 765-0 |
|
LEVER; PARKING BRK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-98029 922-0 |
|
BRAKE ASM; CENTER, PARKING |
1 |
0211- |
|
4HG1 |
NKR 66, NKR66-2, NKR 71 |
| 38 |
I1-09985 189-0 |
|
WASHER; LK, SUPPORT PLATE |
4 |
9312- |
|
4BE1 |
ID=8 ( NKR 58 ) |
| 47 |
I8-97213 401-0 |
|
BOLT; SUPPORT PLATE |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 29 |
I8-98043 949-0 |
|
LEVER; PARKING BRK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 25 |
I8-94132 156-0 |
|
SPRING; SHOE ALIGNMENT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 48 |
I9-46349 005-1 |
|
RETAINER; PIN, PARKING BRK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 31 |
I9-09942 521-1 |
|
SPRING; SHOE TO STRUT |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 32 |
I9-46213 601-2 |
|
PLATE; SUPPORT, PARKING BRK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 22 |
I8-94107 618-0 |
|
SPRING; ADJ SCREW, PARKING |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 36 |
I5-47169 002-0 |
|
GROMMET; ADJ HOLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 31 |
I8-94132 158-0 |
|
SPRING; SHOE TO STRUT |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 2 |
I5-46210 005-A |
|
DRUM; PARKING BRK |
1 |
1011- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 GOLD |
| 2 |
I5-46210 005-A |
|
DRUM; PARKING BRK |
1 |
9312-0701 |
|
4JB1 |
NHR 55 |
| 2 |
I7-85105 299-A |
|
DRUM; PARKING BRK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 21 |
I9-09942 552-1 |
|
SPRING; RETURN, PARKING BRK SHOE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 17 |
I8-97020 250-2 |
|
SHOE; PARKING BRK |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 21 |
I8-94132 157-0 |
|
SPRING; RETURN, PARKING BRK SHOE |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 30 |
I8-94311 779-0 |
|
STRUT; PARKING BRK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 38 |
I1-09985 189-0 |
|
WASHER; LK, SUPPORT PLATE |
4 |
9312- |
|
4HF1 |
ID=8 ( NKR 66 ) |
| 34 |
I9-47162 034-0 |
|
PIN; BRK SHOE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 23 |
I5-47165 025-0 |
|
SCREW; ADJ, PARKING BRK SH |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 4 |
I5-46219 001-0 |
|
COVER; ADJ HOLE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 24 |
I9-09941 062-1 |
|
SPRING; BRK SHOE |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 172 |
I9-47162 033-A |
|
CUP; SHOE HOLD |
4 |
9312- |
|
4BE1 |
NKR 58 |
| 4 |
I5-46219 001-0 |
|
COVER; ADJ HOLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 37 |
I8-98029 927-0 |
|
NUT; SUPPORT PLATE |
4 |
0010- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 30 |
I5-46251 007-0 |
|
STRUT; PARKING BRK |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97034 553-2 |
|
BRAKE ASM; CENTER, PARKING |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 20 |
I9-09942 553-1 |
|
SPRING; RETURN, SECONDARY, PARKING |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 4 |
I5-42319 003-0 |
|
COVER; ADJ HOLE |
1 |
1011- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 GOLD |
| 112 |
I0-50540 616-0 |
|
BOLT; COVER TO BRK DRUM |
1 |
9312- |
|
4JB1 |
M 6 X 16 W / SP WASHER |
| 4 |
I5-42319 003-0 |
|
COVER; ADJ HOLE |
1 |
0702-1010 |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 48 |
I9-46349 005-1 |
|
RETAINER; PIN, PARKING BRK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 48 |
I9-46349 005-1 |
|
RETAINER; PIN, PARKING BRK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 112 |
I0-50540 616-0 |
|
BOLT; COVER TO BRK DRUM |
1 |
9312- |
|
4BE1 |
M 6 X 16 W / SP WASHER |
| 32 |
I8-97308 176-0 |
|
PLATE; SUPPORT, PARKING BRK |
1 |
0211- |
|
4HG1 |
NKR 71 |
| 23 |
I5-47165 025-0 |
|
SCREW; ADJ, PARKING BRK SH |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 47 |
I9-02060 814-0 |
|
BOLT; SUPPORT PLATE |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97034 553-2 |
|
BRAKE ASM; CENTER, PARKING |
1 |
0702-1010 |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 26 |
I9-09851 986-0 |
|
PLATE; SHOE GUIDE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 172 |
I9-47162 033-A |
|
CUP; SHOE HOLD |
4 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 31 |
I8-94132 158-0 |
|
SPRING; SHOE TO STRUT |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 34 |
I8-94132 159-0 |
|
PIN; BRK SHOE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 23 |
I5-47165 025-0 |
|
SCREW; ADJ, PARKING BRK SH |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 2 |
I7-85105 299-A |
|
DRUM; PARKING BRK |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 4 |
I5-42319 003-0 |
|
COVER; ADJ HOLE |
1 |
9312-0701 |
|
4JB1 |
NHR 55 |
| 1 |
I8-97034 553-2 |
|
BRAKE ASM; CENTER, PARKING |
1 |
1011- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 GOLD |
| 114 |
I8-98029 929-0 |
|
STUD; SUPPORT PLATE |
4 |
0211- |
|
4HG1 |
NKR 71 |
| 21 |
I8-94132 157-0 |
|
SPRING; RETURN, PARKING BRK SHOE |
2 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
| 2 |
I5-46210 005-A |
|
DRUM; PARKING BRK |
1 |
0702-1010 |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 29 |
I8-98043 949-0 |
|
LEVER; PARKING BRK |
1 |
9312- |
|
4HF1 |
NKR 66, NKR66-2, NKR 71 |
