| 58 |
I8-97307 060-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 74 |
I8-97359 819-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 31 |
I8-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4BE1 |
M10X30 L=49 ( NKR 58 ) |
| 49 |
I8-97304 377-2 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 31 |
I8-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4BE1 |
M10X30 L=49 ( NKR 58 ) |
| 154 |
I0-36410 616-0 |
|
SCREW; SLOTTED |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 58 |
I8-97109 869-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
9312- |
|
4BE1 |
NKR 58, NKR 66, NKR 71 |
| 58 |
I8-97307 060-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 9 |
I9-42332 605-5 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
LH |
4JB1-TC |
NKR55 TRUCK/BUS |
| 24 |
I0-50540 616-0 |
|
BOLT; LK WASHER |
4 |
9312- |
|
4HF1 |
NKR 66 |
| 9 |
I8-94383 437-2 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
|
4BE1 |
NKR 58, NKR 66-2 TRUK |
| 1 |
I8-97036 367-A |
|
DRUM; BRK, RR |
2 |
0702- |
|
4HG1-T |
NKR71 EURO2 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 10 |
I0-91110 520-0 |
|
NUT; WHEEL PIN, RR AXLE |
10 |
0702- |
|
4HG1-T |
NKR71-T/THD E2 GOLD |
| 49 |
I8-97304 377-2 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 67 |
I0-50561 050-0 |
|
BOLT; FINAL DRIVE SETTING |
4 |
0211- |
|
4HG1 |
NKR66,NKR71, NKR71 EURO 2 |
| 10 |
I0-91110 520-0 |
|
NUT; WHEEL PIN, RR AXLE |
10 |
9312- |
|
4BE1 |
NKR 58 |
| 10 |
I0-91110 520-0 |
|
NUT; WHEEL PIN, RR AXLE |
10 |
9312- |
|
4BE1 |
NKR 58 |
| 33 |
I8-97086 472-0 |
|
WASHER; AXLE SHAFT |
2 |
9811- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 44 |
I8-97029 433-0 |
|
CATCHER; OIL, REAR AXLE SHAFT |
2 |
9312-9406 |
|
4BE1 |
NKR 58 |
| 49 |
I8-97032 861-5 |
|
CASE; RR AXLE |
1 |
9811- |
|
4HF1-2 |
NKR 66-2 |
| 25 |
I6-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
0908-1201 |
|
4HG1-T |
(IADG) NKR71-T/HD EURO 2 |
| 13 |
I0-91510 512-0 |
|
WASHER; LK, BRG HOLDER TO CASE |
8 |
9312- |
|
4JB1 |
ID=12 ( NHR 55 ) |
| 49 |
I8-97357 375-2 |
|
CASE; RR AXLE |
1 |
0402- |
|
4JB1 |
NHR 55, NHR55 EURO 2 |
| 39 |
I9-42119 619-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.076 ( NHR 55 ) |
| 37 |
I9-00032 209-A |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4JB1 |
(IADG) NHR 55 |
| 39 |
I9-42119 617-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.500 ( NHR 55 ) |
| 37 |
I9-00093 624-0 |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4HF1 |
NKR 66 |
| 16 |
I8-98202 912-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4HF1 |
NKR66, NKR71 EURO 2 |
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 37 |
I9-00093 624-0 |
|
BEARING; HUB INNER, RR AXLE |
2 |
0211- |
|
4HG1 |
NKR 71 |
| 31 |
I6-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4HF1 |
(IADG) M 10 X 30 L=49 |
| 37 |
I9-00093 081-0 |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 37 |
I9-00032 209-0 |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 21 |
I9-09853 214-1 |
|
WASHER; LK, BRG NUT |
2 |
9312- |
|
4BE1 |
NKR58,NKR66-2,NKR55 EURO 2 |
| 49 |
I8-97304 377-2 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NKR55-T/B, NKR55-B (LWB) E2 |
| 9 |
I8-97126 489-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9312- |
LH |
4JB1 |
NHR 55 |
| 12 |
I8-94477 674-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
9312- |
|
4JB1 |
M12X72 ( NHR 55 ) |
| 49 |
I8-97070 484-5 |
|
CASE; RR AXLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 15 |
I9-00093 082-0 |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4JB1 |
NKR55-E2 |
| 16 |
I9-09724 022-1 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 9 |
I8-97126 489-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9312- |
LH |
4JB1 |
NHR 55 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 21 |
I9-09653 002-1 |
|
WASHER; LK, BRG NUT |
2 |
9312- |
|
4HF1 |
NKR 66, NKR71, NKLR71 E2 |
| 75 |
I0-91510 612-0 |
|
WASHER; L K, RR BRK ASM SETTING |
12 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 49 |
I8-97047 980-3 |
|
CASE; RR AXLE |
1 |
9312-0210 |
|
4JB1 |
NHR 55 |
| 58 |
I8-97307 060-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 9 |
I8-94383 436-2 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
RH |
4BE1 |
NKR 58, NKR 66-2 TRUK |
| 38 |
I6-94336 314-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
(IADG) TKK, KR58,NKR66-2,NKR55 E2 |
| 4 |
I8-97324 241-0 |
|
HOLDER; BRG, AXLE SHAFT |
2 |
0111- |
|
4JB1 |
NHR 55 |
| 9 |
I8-97081 585-4 |
|
PIN; WHEEL, RR AXLE |
6 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 38 |
I6-94367 958-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
(IADG) NOK, NKR66,NKR71,NKR71 E2 |
| 8 |
I8-97122 626-A |
|
HUB; RR AXLE |
2 |
9312-0701 |
|
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 9 |
I8-97126 488-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9811- |
RH |
4JB1 |
M14X42 TREAD,NHR 55T |
| 25 |
I8-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
1202- |
|
4HG1-T |
NKR71-T/HD E2, HARIMAU |
| 39 |
I9-42119 618-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.13 ( NHR 55 ), EURO 2 |
| 10 |
I0-91110 520-0 |
|
NUT; WHEEL PIN, RR AXLE |
10 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 39 |
I9-42119 620-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.050 ( NHR 55 ) |
| 8 |
I8-97026 139-A |
|
HUB; RR AXLE |
2 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 TRUK |
| 16 |
I6-09724 022-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4JB1 |
(IADG) NHR 55 |
| 34 |
I8-94178 278-0 |
|
NUT; AXLE SHAFT |
2 |
0305- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 8 |
I5-42311 009-A |
|
HUB; RR AXLE |
2 |
0702-1105 |
|
4JB1-TC |
NKR55 EURO 2 |
| 1 |
I8-97034 770-A |
|
DRUM; BRK, RR |
2 |
9312-0304 |
|
4BE1 |
NKR 58, NKR 66-2 TRUK |
| 12 |
I9-42119 603-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
9312- |
|
4JB1 |
M12X69 ( NHR 55 ) |
| 15 |
I9-00093 082-A |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4BE1 |
(IADG) NKR58 |
| 9 |
I5-89931 944-0 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
RH |
4JB1-TC |
NHR55 BUS ( FOR ALLOY ) |
| 46 |
I0-28050 610-0 |
|
BOLT; OIL PIPE |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 9 |
I8-97081 585-4 |
|
PIN; WHEEL, RR AXLE |
6 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 18 |
I9-09720 517-0 |
|
RETAINER; RR AXLE |
2 |
9312- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 20 |
I8-98327 903-0 |
|
NUT; BRG, RR HUB |
2 |
9312- |
|
4BE1 |
NKR58,NKR66-2,NKR55 EURO 2 |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 8 |
I8-97081 323-A |
|
HUB; RR AXLE |
2 |
1202- |
|
4HG1-T |
NKR71-T, NKR71-THD E2, HARIMAU
|
| 21 |
I9-09853 214-1 |
|
WASHER; LK, BRG NUT |
2 |
9312- |
|
4BE1 |
NKR58,NKR66-2,NKR55 EURO 2 |
| 16 |
I6-09724 022-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4JB1 |
(IADG) NHR 55 |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
4 |
9312- |
|
4HF1 |
NKR 66, NKR71 EURO 2 |
| 16 |
I6-94336 317-2 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4HF1 |
(IADG) NKR66, NKR71 EURO 2 |
| 9 |
I8-97017 043-2 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
RH |
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 49 |
I8-97122 348-4 |
|
CASE; RR AXLE |
1 |
9811- |
|
4HF1 |
NKR 66, NKR 71 |
| 37 |
I9-00093 624-0 |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4HF1 |
NKR 66 |
| 37 |
I9-00032 209-A |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4JB1 |
(IADG) NHR 55 |
| 49 |
I8-97357 375-2 |
|
CASE; RR AXLE |
1 |
0211-0401 |
|
4JB1 |
NHR 55 |
| 16 |
I8-98202 912-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4HF1 |
NKR66, NKR71 EURO 2 |
| 74 |
I8-97359 819-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 38 |
I6-94367 958-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
(IADG) NOK, NKR66,NKR71,NKR71 E2 |
| 4 |
I8-97324 241-0 |
|
HOLDER; BRG, AXLE SHAFT |
2 |
0702- |
|
4JB1-TC |
NHR55 EURO 2 |
| 31 |
I6-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4BE1 |
(IADG) M10X30 L=49 ( NKR 58 ) |
| 9 |
I8-97081 585-4 |
|
PIN; WHEEL, RR AXLE |
6 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 39 |
I9-42119 619-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.076 ( NHR 55 ), EURO 2 |
| 12 |
I8-94477 674-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
0702- |
|
4JB1-TC |
M12X72 ( NHR 55 EURO 2) |
| 74 |
I8-97359 819-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 39 |
I9-42119 620-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.050 ( NHR 55 ), EURO 2 |
| 60 |
I8-97383 656-0 |
|
BREATHER; RR AXLE CASE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 21 |
I9-09653 002-1 |
|
WASHER; LK, BRG NUT |
2 |
9312- |
|
4HF1 |
NKR 66, NKR71, NKLR71 E2 |
| 4 |
I8-97324 241-0 |
|
HOLDER; BRG, AXLE SHAFT |
2 |
0702- |
|
4JB1-TC |
NHR55 EURO 2 |
| 38 |
I6-94367 959-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
(IADG) NOK,NKR58,NKR66-2,NKR55 E2 |
| 20 |
I8-98327 903-0 |
|
NUT; BRG, RR HUB |
2 |
9312- |
|
4BE1 |
NKR58,NKR66-2,NKR55 EURO 2 |
| 12 |
I8-94477 674-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
0702- |
|
4JB1-TC |
M12X72 ( NHR 55 EURO 2) |
| 1 |
I8-94455 285-A |
|
DRUM; BRK, RR |
2 |
0702- |
|
4JB1-TC |
NKR55 ( CKD ) |
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
0211- |
|
4JB1 |
NKR 71 |
| 63 |
I9-09662 005-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 39 |
I9-42119 618-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.13 ( NHR 55 ), EURO 2 |
| 10 |
I0-91110 520-0 |
|
NUT; WHEEL PIN, RR AXLE |
10 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 9 |
I8-97126 488-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9312- |
RH |
4JB1 |
NHR 55 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97034 770-A |
|
DRUM; BRK, RR |
2 |
1011- |
|
4HF1-2 |
NKR55L-T (6T) E2 GOLD, PARIN |
| 39 |
I9-42119 618-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.13 ( NHR 55 ) |
| 9 |
I9-42331 605-5 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
RH |
4JB1-TC |
NKR55 TRUCK/BUS |
| 9 |
I8-94383 436-2 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
RH |
4BE1 |
NKR 58, NKR 66-2 TRUK |
| 1 |
I8-97081 219-A |
|
DRUM; BRK, RR |
2 |
1202- |
|
4HG1-T |
NKR71-T, NKR71-THD E2, 8970812192 ( BAKRI ) HARIMAU |
| 58 |
I8-97109 869-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 37 |
I9-00093 624-A |
|
BEARING; HUB INNER, RR AXLE |
2 |
0211- |
|
4HG1 |
(IADG) NKR 71 |
| 9 |
I8-97126 488-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9312- |
RH |
4JB1 |
NHR 55 |
| 15 |
I9-00093 082-A |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4JB1 |
(IADG) NKR55-E2 |
| 60 |
I8-97383 656-0 |
|
BREATHER; RR AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 25 |
I8-97032 496-0 |
|
SHAFT; AXLE, RR |
2 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 8 |
I8-97026 139-A |
|
HUB; RR AXLE |
2 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 TRUK |
| 154 |
I0-36410 616-0 |
|
SCREW; SLOTTED |
2 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 9 |
I5-89931 944-0 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
RH |
4JB1-TC |
NHR55 BUS ( FOR ALLOY ) |
| 25 |
I8-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
0908-1201 |
|
4HG1-T |
NKR71-T/HD EURO 2 |
| 60 |
I8-97383 656-0 |
|
BREATHER; RR AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 37 |
I9-00032 209-0 |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 37 |
I9-00093 624-A |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4HF1 |
(IADG) NKR 66 |
| 8 |
I8-97122 626-A |
|
HUB; RR AXLE |
2 |
9312-0701 |
|
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 15 |
I9-00093 082-A |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4JB1 |
(IADG) NKR55-E2 |
| 31 |
I8-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4BE1 |
M10X30 L=49 ( NKR 58 ) |
| 31 |
I8-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4HF1 |
M 10 X 30 L=49 |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 38 |
I6-94336 314-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
(IADG) TKK, KR58,NKR66-2,NKR55 E2 |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 1 |
I8-97034 770-A |
|
DRUM; BRK, RR |
2 |
9312-0304 |
|
4BE1 |
NKR 58, NKR 66-2 TRUK |
| 12 |
I9-42119 603-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
0702- |
|
4JB1-TC |
M12X69 ( NHR 55 EURO 2 ) |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
9 |
9312- |
|
4HF1 |
NKR66, NKR55 EURO 2 |
| 44 |
I8-97029 433-0 |
|
CATCHER; OIL, REAR AXLE SHAFT |
2 |
9312-9406 |
|
4HF1 |
NKR 66 |
| 154 |
I0-36410 616-0 |
|
SCREW; SLOTTED |
2 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 25 |
I6-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
1202- |
|
4HG1-T |
(IADG) NKR71-T/HD E2, HARIMAU |
| 9 |
I8-98007 976-0 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
LH |
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 15 |
I9-00093 082-0 |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4JB1 |
NKR55-E2 |
| 38 |
I6-09625 092-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4JB1 |
(IADG) NHR55 EURO 2 |
| 25 |
I6-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
0908-1201 |
|
4HG1-T |
(IADG) NKR71-T/HD EURO 2 |
| 31 |
I6-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4BE1 |
(IADG) M10X30 L=49 ( NKR 58 ) |
| 49 |
I8-97032 861-5 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NKR55L-T (6T) EURO 2 |
| 76 |
I0-91110 512-0 |
|
NUT; RR BRK ASM SETTING |
12 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 49 |
I8-97047 980-3 |
|
CASE; RR AXLE |
1 |
9312-0210 |
|
4JB1 |
NHR 55 |
| 8 |
I5-42311 009-A |
|
HUB; RR AXLE |
2 |
1106- |
|
4JB1-TC |
NKR55 EURO 2 |
| 38 |
I8-94336 316-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
TKK, NKR66, NKR71, NKR71 E2 |
| 9 |
I8-94383 437-2 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
|
4BE1 |
NKR 58, NKR 66-2 TRUK |
| 154 |
I0-36410 616-0 |
|
SCREW; SLOTTED |
2 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 74 |
I8-97359 819-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 9 |
I8-97126 489-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9811- |
LH |
4JB1 |
M14X42 TREAD,NHR 55T |
| 38 |
I6-94336 316-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
(IADG) TKK, NKR66, NKR71, NKR71 E2 |
| 31 |
I6-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4HF1 |
(IADG) M 10 X 30 L=49 |
| 12 |
I8-94477 674-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
0702- |
|
4JB1-TC |
M12X72 ( NHR 55 EURO 2) |
| 39 |
I9-42119 616-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 1.000 ( NHR 55 ) |
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
0211- |
|
4JB1 |
NKR71 EURO 2 |
| 49 |
I8-97357 375-2 |
|
CASE; RR AXLE |
1 |
0211-0401 |
|
4JB1 |
NHR 55 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
4 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 4 |
I8-94120 081-0 |
|
HOLDER; BRG, AXLE SHAFT |
1 |
9312- |
|
4JB1 |
LH ( NHR 55 ) |
| 12 |
I9-42119 603-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
0702- |
|
4JB1-TC |
M12X69 ( NHR 55 EURO 2 ) |
| 1 |
I8-97034 799-A |
|
DRUM; BRK, RR |
2 |
9312-0304 |
|
4JB1 |
NHR 55 |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
8 |
9312- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 4 |
I8-97324 241-0 |
|
HOLDER; BRG, AXLE SHAFT |
2 |
0111- |
|
4JB1 |
NHR 55 |
| 25 |
I8-94366 192-0 |
|
SHAFT; AXLE, RR |
2 |
0702- |
|
4JB1-TC |
NKR55-T/B,NKR55-B (LWB) E2 |
| 37 |
I9-00093 624-0 |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4HF1 |
NKR 66 |
| 38 |
I8-94367 959-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
NOK,NKR58,NKR66-2,NKR55 E2 |
| 38 |
I8-94367 959-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
NOK,NKR58,NKR66-2,NKR55 E2 |
| 154 |
I0-36410 616-0 |
|
SCREW; SLOTTED |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 154 |
I0-36410 616-0 |
|
SCREW; SLOTTED |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 20 |
I8-98327 903-0 |
|
NUT; BRG, RR HUB |
2 |
9312- |
|
4BE1 |
NKR58,NKR66-2,NKR55 EURO 2 |
| 38 |
I6-94367 959-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
(IADG) NOK,NKR58,NKR66-2,NKR55 E2 |
| 8 |
I8-97122 626-A |
|
HUB; RR AXLE |
2 |
9312-0701 |
|
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 34 |
I7-05110 010-A |
|
NUT; AXLE SHAFT |
16 |
9312- |
|
4HF1 |
NKR 58, NKR 66, NKR 71 |
| 47 |
I0-91510 606-0 |
|
WASHER; LK OIL CATCHER |
10 |
9312- |
|
4HF1 |
NKR 66 |
| 12 |
I8-94477 674-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
9312- |
|
4JB1 |
M12X72 ( NHR 55 ) |
| 24 |
I0-50540 616-0 |
|
BOLT; LK WASHER |
4 |
9312-9507 |
|
4BE1 |
NKR 58 |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
4 |
9312- |
|
4BE1 |
NKR58, NKR66-2, NKR55 E2 |
| 63 |
I9-09662 005-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 12 |
I9-42119 603-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
9312- |
|
4JB1 |
M12X69 ( NHR 55 ) |
| 39 |
I9-42119 618-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.13 ( NHR 55 ) |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
9811- |
|
4HF1-2 |
NKR 66-2 |
| 37 |
I9-00032 209-0 |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4JB1 |
NHR 55 |
| 38 |
I8-94367 958-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
NOK, NKR66,NKR71,NKR71 E2 |
| 63 |
I9-09662 005-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 49 |
I8-98151 843-0 |
|
CASE; RR AXLE |
1 |
0702- |
|
4HG1-T |
NKR71-T/THD EURO 2 |
| 63 |
I9-09662 005-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 58 |
I8-97109 869-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 1 |
I8-94455 285-A |
|
DRUM; BRK, RR |
2 |
0702- |
|
4JB1-TC |
NKR55 ( CKD ) |
| 25 |
I8-94366 192-0 |
|
SHAFT; AXLE, RR |
2 |
0702- |
|
4JB1-TC |
NKR55-T/B,NKR55-B (LWB) E2 |
| 18 |
I9-09720 517-0 |
|
RETAINER; RR AXLE |
2 |
9312- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 25 |
I8-97083 094-2 |
|
SHAFT; AXLE, RR |
2 |
0702- |
|
4JB1-TC |
NHR55-T/B EURO 2 |
| 15 |
I9-00093 082-0 |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4BE1 |
NKR58 |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 24 |
I0-50540 616-0 |
|
BOLT; LK WASHER |
4 |
9312-9507 |
|
4BE1 |
NKR 58 |
| 37 |
I9-00093 624-A |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4HF1 |
(IADG) NKR 66 |
| 8 |
I8-97081 323-A |
|
HUB; RR AXLE |
2 |
1202- |
|
4HG1-T |
NKR71-T, NKR71-THD E2, HARIMAU
|
| 34 |
I8-94178 278-0 |
|
NUT; AXLE SHAFT |
2 |
0305- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 39 |
I9-42119 616-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 1.000 ( NHR 55 ) |
| 38 |
I6-09625 092-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4JB1 |
(IADG) NHR55 EURO 2 |
| 37 |
I9-00093 624-0 |
|
BEARING; HUB INNER, RR AXLE |
2 |
0211- |
|
4HG1 |
NKR 71 |
| 8 |
I5-42311 009-A |
|
HUB; RR AXLE |
2 |
1106- |
|
4JB1-TC |
NKR55 EURO 2 |
| 4 |
I8-97324 241-0 |
|
HOLDER; BRG, AXLE SHAFT |
1 |
9312- |
|
4JB1 |
RH ( NHR 55 ) |
| 46 |
I0-28050 610-0 |
|
BOLT; OIL PIPE |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 74 |
I8-97359 819-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 154 |
I0-36410 616-0 |
|
SCREW; SLOTTED |
2 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 1 |
I8-97036 367-A |
|
DRUM; BRK, RR |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 20 |
I8-97137 093-0 |
|
NUT; BRG, RR HUB |
2 |
9312-9606 |
|
4HF1 |
NKR 66 |
| 49 |
I8-97304 377-2 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NKR55-T/B, NKR55-B (LWB) E2 |
| 1 |
I8-97034 770-A |
|
DRUM; BRK, RR |
2 |
9312-0304 |
|
4BE1 |
NKR 58, NKR 66-2 TRUK |
| 25 |
I8-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
0908-1201 |
|
4HG1-T |
NKR71-T/HD EURO 2 |
| 9 |
I5-89931 945-0 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
LH |
4JB1-TC |
NHR55 BUS ( FOR ALLOY ) |
| 44 |
I8-97029 433-0 |
|
CATCHER; OIL, REAR AXLE SHAFT |
2 |
9312-9406 |
|
4BE1 |
NKR 58 |
| 20 |
I8-97137 093-0 |
|
NUT; BRG, RR HUB |
2 |
9312-9606 |
|
4HF1 |
NKR 66 |
| 39 |
I9-42119 617-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.500 ( NHR 55 ), EURO 2 |
| 39 |
I9-42119 620-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.050 ( NHR 55 ), EURO 2 |
| 75 |
I0-91510 612-0 |
|
WASHER; L K, RR BRK ASM SETTING |
12 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
2 |
9312- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 25 |
I6-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
0908-1201 |
|
4HG1-T |
(IADG) NKR71-T/HD EURO 2 |
| 37 |
I9-00093 624-A |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4HF1 |
(IADG) NKR 66 |
| 60 |
I8-97383 656-0 |
|
BREATHER; RR AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 24 |
I0-50540 616-0 |
|
BOLT; LK WASHER |
4 |
9312- |
|
4HF1 |
NKR 66 |
| 38 |
I8-94336 314-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
TKK, KR58,NKR66-2,NKR55 E2 |
| 37 |
I9-00093 624-A |
|
BEARING; HUB INNER, RR AXLE |
2 |
0211- |
|
4HG1 |
(IADG) NKR 71 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 63 |
I9-09662 005-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
9 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 39 |
I9-42119 618-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.13 ( NHR 55 ), EURO 2 |
| 9 |
I8-97017 043-2 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
RH |
4HG1-T |
NKR71-T/THD E2 GOLD |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
8 |
9312- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 58 |
I8-97109 869-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 37 |
I9-00093 081-A |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4BE1 |
(IADG) NKR 58, NKR66-2 |
| 1 |
I8-97034 799-A |
|
DRUM; BRK, RR |
2 |
9312-0304 |
|
4JB1 |
NHR 55 |
| 37 |
I9-00093 081-A |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4BE1 |
(IADG) NKR 58, NKR66-2 |
| 12 |
I8-94477 674-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
9312- |
|
4JB1 |
M12X72 ( NHR 55 ) |
| 25 |
I8-97083 094-2 |
|
SHAFT; AXLE, RR |
2 |
0702- |
|
4JB1-TC |
NHR55-T/B EURO 2 |
| 10 |
I0-91110 520-0 |
|
NUT; WHEEL PIN, RR AXLE |
10 |
9312- |
|
4BE1 |
NKR 58 |
| 9 |
I8-97017 043-2 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
RH |
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 39 |
I9-42119 616-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 1.000 ( NHR 55 ), EURO 2 |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 46 |
I0-28050 610-0 |
|
BOLT; OIL PIPE |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 75 |
I0-91510 612-0 |
|
WASHER; L K, RR BRK ASM SETTING |
12 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 34 |
I8-94178 278-0 |
|
NUT; AXLE SHAFT |
2 |
0305- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 37 |
I9-00093 081-0 |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 16 |
I8-98202 911-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4BE1 |
NKR58,NR66-2, NKR55 EURO 2 |
| 4 |
I8-97324 241-0 |
|
HOLDER; BRG, AXLE SHAFT |
2 |
0111- |
|
4JB1 |
NHR 55 |
| 34 |
I6-94178 278-0 |
|
NUT; AXLE SHAFT |
2 |
0305- |
|
4JB1 |
(IADG) NHR55, NHR55 EURO 2 |
| 39 |
I9-42119 620-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.050 ( NHR 55 ) |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
4 |
9312- |
|
4BE1 |
NKR58, NKR66-2, NKR55 E2 |
| 38 |
I8-94367 958-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
NOK, NKR66,NKR71,NKR71 E2 |
| 24 |
I0-50540 616-0 |
|
BOLT; LK WASHER |
4 |
9312-9507 |
|
4BE1 |
NKR 58 |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
7 |
0211- |
|
4HG1 |
NKR66-2,NKR71,NKR71 EURO 2 |
| 24 |
I0-50540 612-0 |
|
BOLT; LK WASHER |
4 |
9508- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 9 |
I8-97126 488-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9312- |
RH |
4JB1 |
NHR 55 |
| 58 |
I8-97109 869-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 49 |
I8-98192 225-0 |
|
CASE; RR AXLE |
1 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 10 |
I0-91110 522-0 |
|
NUT; WHEEL PIN, RR AXLE |
12 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 76 |
I0-91110 512-0 |
|
NUT; RR BRK ASM SETTING |
12 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 76 |
I0-91110 512-0 |
|
NUT; RR BRK ASM SETTING |
12 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 44 |
I8-97029 433-0 |
|
CATCHER; OIL, REAR AXLE SHAFT |
2 |
9312-9406 |
|
4BE1 |
NKR 58 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 1 |
I8-97034 770-A |
|
DRUM; BRK, RR |
2 |
0305-1010 |
|
4HF1-2 |
NKR 66-2 ( TRUK ) |
| 33 |
I8-97086 472-0 |
|
WASHER; AXLE SHAFT |
2 |
9811- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 39 |
I9-42119 616-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 1.000 ( NHR 55 ), EURO 2 |
| 20 |
I8-97137 094-0 |
|
NUT; BRG, RR HUB |
2 |
9607- |
|
4HF1 |
NKR66, NKR71, NKR71 EURO 2 |
| 36 |
I8-97360 004-0 |
|
WASHER; SPECIAL, AXLE SHAFT |
16 |
9312- |
|
4HF1 |
NKR 58, NKR 66, NKR 66-2, NKR 71 |
| 15 |
I9-00093 082-A |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4JB1 |
(IADG) NHR55 |
| 38 |
I6-94367 959-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
(IADG) NOK,NKR58,NKR66-2,NKR55 E2 |
| 74 |
I8-97359 819-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 16 |
I9-09724 022-1 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 47 |
I0-91510 606-0 |
|
WASHER; LK OIL CATCHER |
10 |
9312- |
|
4HF1 |
NKR 66 |
| 14 |
I0-91110 512-0 |
|
NUT; BRG HOLDER TO CASE |
8 |
9312- |
|
4JB1 |
M12 ( NHR 55 ) |
| 25 |
I8-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
0908-1201 |
|
4HG1-T |
NKR71-T/HD EURO 2 |
| 25 |
I8-97032 496-0 |
|
SHAFT; AXLE, RR |
2 |
1011- |
|
4JB1-TC |
NKR55L-T (6T) EURO 2 |
| 15 |
I9-00093 082-0 |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4BE1 |
NKR58 |
| 25 |
I8-97032 496-0 |
|
SHAFT; AXLE, RR |
2 |
1011- |
|
4JB1-TC |
NKR55L-T (6T) EURO 2 |
| 34 |
I6-94178 278-0 |
|
NUT; AXLE SHAFT |
2 |
0305- |
|
4JB1 |
(IADG) NHR55, NHR55 EURO 2 |
| 38 |
I8-94336 316-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
TKK, NKR66, NKR71, NKR71 E2 |
| 37 |
I9-00093 624-0 |
|
BEARING; HUB INNER, RR AXLE |
2 |
0211- |
|
4HG1 |
NKR 71 |
| 60 |
I8-97383 656-0 |
|
BREATHER; RR AXLE CASE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 37 |
I9-00093 081-A |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4BE1 |
(IADG) NKR 58, NKR66-2 |
| 8 |
I5-42311 009-A |
|
HUB; RR AXLE |
2 |
0702-1105 |
|
4JB1-TC |
NKR55 EURO 2 |
| 60 |
I8-97383 656-0 |
|
BREATHER; RR AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 49 |
I8-97032 861-5 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NKR55L-T (6T) EURO 2 |
| 4 |
I8-94120 081-0 |
|
HOLDER; BRG, AXLE SHAFT |
1 |
9312- |
|
4JB1 |
LH ( NHR 55 ) |
| 20 |
I8-97137 094-0 |
|
NUT; BRG, RR HUB |
2 |
9607- |
|
4HF1 |
NKR66, NKR71, NKR71 EURO 2 |
| 25 |
I8-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
1202- |
|
4HG1-T |
NKR71-T/HD E2, HARIMAU |
| 9 |
I8-94383 437-2 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
|
4BE1 |
NKR 58, NKR 66-2 TRUK |
| 9 |
I9-42331 605-5 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
RH |
4JB1-TC |
NKR55 TRUCK/BUS |
| 75 |
I0-91510 612-0 |
|
WASHER; L K, RR BRK ASM SETTING |
12 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 9 |
I8-98007 976-0 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
LH |
4HG1-T |
NKR71-T/THD E2 GOLD |
| 49 |
I8-97357 375-2 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NHR55-T, NHR55-B EURO 2 |
| 8 |
I8-97081 323-A |
|
HUB; RR AXLE |
2 |
1202- |
|
4HG1-T |
NKR71-T, NKR71-THD E2, HARIMAU
|
| 25 |
I8-97032 496-0 |
|
SHAFT; AXLE, RR |
2 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 39 |
I9-42119 619-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.076 ( NHR 55 ) |
| 38 |
I6-94367 958-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
(IADG) NOK, NKR66,NKR71,NKR71 E2 |
| 25 |
I8-97083 094-2 |
|
SHAFT; AXLE, RR |
2 |
9312-0701 |
|
4JB1 |
NHR55-T/B |
| 1 |
I8-97034 770-A |
|
DRUM; BRK, RR |
2 |
1011- |
|
4HF1-2 |
NKR55L-T (6T) E2 GOLD, PARIN |
| 8 |
I8-97026 139-A |
|
HUB; RR AXLE |
2 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 TRUK |
| 13 |
I0-91510 512-0 |
|
WASHER; LK, BRG HOLDER TO CASE |
8 |
9312- |
|
4JB1 |
ID=12 ( NHR 55 ) |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
9 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 47 |
I0-91510 606-0 |
|
WASHER; LK OIL CATCHER |
10 |
9312- |
|
4BE1 |
NKR 58 |
| 9 |
I8-98007 976-0 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
LH |
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 24 |
I0-50540 612-0 |
|
BOLT; LK WASHER |
4 |
9508- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 16 |
I9-09724 022-1 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 8 |
I8-97122 626-A |
|
HUB; RR AXLE |
2 |
0702-1201 |
|
4HG1-T |
NKR71 EURO 2 |
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
0211- |
|
4JB1 |
NKR 71 |
| 39 |
I9-42119 619-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.076 ( NHR 55 ), EURO 2 |
| 63 |
I9-09662 005-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 15 |
I9-00093 082-0 |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4BE1 |
NKR58 |
| 15 |
I9-00093 082-A |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4JB1 |
(IADG) NHR55 |
| 10 |
I0-91110 520-0 |
|
NUT; WHEEL PIN, RR AXLE |
10 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 49 |
I8-97304 377-2 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NKR55-T/B, NKR55-B (LWB) E2 |
| 49 |
I8-97032 861-5 |
|
CASE; RR AXLE |
1 |
9811- |
|
4HF1-2 |
NKR 66-2 |
| 9 |
I9-42331 605-5 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
RH |
4JB1-TC |
NKR55 TRUCK/BUS |
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
0211- |
|
4JB1 |
NKR71 EURO 2 |
| 25 |
I8-97083 094-2 |
|
SHAFT; AXLE, RR |
2 |
9312-0701 |
|
4JB1 |
NHR55-T/B |
| 9 |
I9-42332 605-5 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
LH |
4JB1-TC |
NKR55 TRUCK/BUS |
| 1 |
I8-97036 367-A |
|
DRUM; BRK, RR |
2 |
0702- |
|
4HG1-T |
NKR71 EURO2 |
| 38 |
I8-94367 959-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
NOK,NKR58,NKR66-2,NKR55 E2 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
4 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 44 |
I8-97029 433-0 |
|
CATCHER; OIL, REAR AXLE SHAFT |
2 |
9312-9406 |
|
4HF1 |
NKR 66 |
| 4 |
I8-97324 241-0 |
|
HOLDER; BRG, AXLE SHAFT |
1 |
9312- |
|
4JB1 |
RH ( NHR 55 ) |
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 49 |
I8-98151 843-0 |
|
CASE; RR AXLE |
1 |
0702- |
|
4HG1-T |
NKR71-T/THD EURO 2 |
| 39 |
I9-42119 617-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.500 ( NHR 55 ), EURO 2 |
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
0211- |
|
4JB1 |
NKR 71 |
| 76 |
I0-91110 512-0 |
|
NUT; RR BRK ASM SETTING |
12 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 1 |
I8-97034 799-A |
|
DRUM; BRK, RR |
2 |
0702- |
|
4JB1-TC |
NHR55 ( BAKRIE ) |
| 49 |
I8-97304 377-2 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 60 |
I8-97383 656-0 |
|
BREATHER; RR AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 47 |
I0-91510 606-0 |
|
WASHER; LK OIL CATCHER |
10 |
9312- |
|
4BE1 |
NKR 58 |
| 18 |
I9-09720 517-0 |
|
RETAINER; RR AXLE |
2 |
9312- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 24 |
I0-50540 616-0 |
|
BOLT; LK WASHER |
4 |
9312- |
|
4HF1 |
NKR 66 |
| 9 |
I5-89931 945-0 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
LH |
4JB1-TC |
NHR55 BUS ( FOR ALLOY ) |
| 25 |
I8-97032 496-0 |
|
SHAFT; AXLE, RR |
2 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 49 |
I8-97122 348-4 |
|
CASE; RR AXLE |
1 |
9811- |
|
4HF1 |
NKR 66, NKR 71 |
| 37 |
I9-00032 209-A |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4JB1 |
(IADG) NHR 55 |
| 60 |
I8-97383 656-0 |
|
BREATHER; RR AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 49 |
I8-97070 484-5 |
|
CASE; RR AXLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 1 |
I8-97034 799-A |
|
DRUM; BRK, RR |
2 |
0702- |
|
4JB1-TC |
NHR55 ( BAKRIE ) |
| 46 |
I0-28050 610-0 |
|
BOLT; OIL PIPE |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 16 |
I8-98202 911-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4BE1 |
NKR58,NR66-2, NKR55 EURO 2 |
| 34 |
I7-05110 010-A |
|
NUT; AXLE SHAFT |
16 |
9312-0304 |
|
4JB1 |
NHR 55 |
| 58 |
I8-97109 869-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 38 |
I6-94336 316-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
(IADG) TKK, NKR66, NKR71, NKR71 E2 |
| 49 |
I8-98151 843-0 |
|
CASE; RR AXLE |
1 |
0702- |
|
4HG1-T |
NKR71-T/THD EURO 2 |
| 34 |
I6-94178 278-0 |
|
NUT; AXLE SHAFT |
2 |
0305- |
|
4JB1 |
(IADG) NHR55, NHR55 EURO 2 |
| 9 |
I8-97017 043-2 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
RH |
4HG1-T |
NKR71-T/THD E2 GOLD |
| 58 |
I8-97307 060-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 1 |
I8-97036 367-A |
|
DRUM; BRK, RR |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 1 |
I8-97081 219-A |
|
DRUM; BRK, RR |
2 |
1202- |
|
4HG1-T |
NKR71-T, NKR71-THD E2, 8970812192 ( BAKRI ) HARIMAU |
| 49 |
I8-97357 375-2 |
|
CASE; RR AXLE |
1 |
0402- |
|
4JB1 |
NHR 55, NHR55 EURO 2 |
| 20 |
I8-97137 093-0 |
|
NUT; BRG, RR HUB |
2 |
9312-9606 |
|
4HF1 |
NKR 66 |
| 10 |
I0-91110 522-0 |
|
NUT; WHEEL PIN, RR AXLE |
12 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 10 |
I0-91110 522-0 |
|
NUT; WHEEL PIN, RR AXLE |
12 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 9 |
I8-98007 976-0 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
LH |
4HG1-T |
NKR71-T/THD E2 GOLD |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
2 |
9312- |
|
4JB1 |
NHR 55 |
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
0211- |
|
4JB1 |
NKR71 EURO 2 |
| 75 |
I0-91510 612-0 |
|
WASHER; L K, RR BRK ASM SETTING |
12 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 39 |
I9-42119 618-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.13 ( NHR 55 ) |
| 76 |
I0-91110 512-0 |
|
NUT; RR BRK ASM SETTING |
12 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 1 |
I8-97081 219-A |
|
DRUM; BRK, RR |
2 |
1202- |
|
4HG1-T |
NKR71-T, NKR71-THD E2, 8970812192 ( BAKRI ) HARIMAU |
| 39 |
I9-42119 617-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.500 ( NHR 55 ) |
| 39 |
I9-42119 617-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.500 ( NHR 55 ), EURO 2 |
| 25 |
I8-97083 094-2 |
|
SHAFT; AXLE, RR |
2 |
9312-0701 |
|
4JB1 |
NHR55-T/B |
| 44 |
I8-97029 433-0 |
|
CATCHER; OIL, REAR AXLE SHAFT |
2 |
9312-9406 |
|
4HF1 |
NKR 66 |
| 49 |
I8-97357 375-2 |
|
CASE; RR AXLE |
1 |
0211-0401 |
|
4JB1 |
NHR 55 |
| 49 |
I8-98192 225-0 |
|
CASE; RR AXLE |
1 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 9 |
I8-97081 584-4 |
|
PIN; WHEEL, RR AXLE |
6 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 4 |
I8-97324 241-0 |
|
HOLDER; BRG, AXLE SHAFT |
1 |
9312- |
|
4JB1 |
RH ( NHR 55 ) |
| 15 |
I9-00093 082-0 |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4JB1 |
NHR55 |
| 58 |
I8-97307 060-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 9 |
I8-98007 976-0 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
LH |
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
4 |
9312- |
|
4HF1 |
NKR 66, NKR71 EURO 2 |
| 24 |
I0-50540 612-0 |
|
BOLT; LK WASHER |
4 |
9508- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 16 |
I8-98202 911-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4BE1 |
NKR58,NR66-2, NKR55 EURO 2 |
| 9 |
I5-89931 944-0 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
RH |
4JB1-TC |
NHR55 BUS ( FOR ALLOY ) |
| 25 |
I8-97032 496-0 |
|
SHAFT; AXLE, RR |
2 |
1011- |
|
4JB1-TC |
NKR55L-T (6T) EURO 2 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
4 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 1 |
I8-97034 770-A |
|
DRUM; BRK, RR |
2 |
0305-1010 |
|
4HF1-2 |
NKR 66-2 ( TRUK ) |
| 1 |
I8-94455 285-A |
|
DRUM; BRK, RR |
2 |
0702- |
|
4JB1-TC |
NKR55 ( CKD ) |
| 9 |
I8-97017 043-2 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
RH |
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 67 |
I0-50561 050-0 |
|
BOLT; FINAL DRIVE SETTING |
4 |
0211- |
|
4HG1 |
NKR66,NKR71, NKR71 EURO 2 |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
4 |
9312- |
|
4BE1 |
NKR58, NKR66-2, NKR55 E2 |
| 38 |
I5-09625 092-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4JB1 |
NHR55 EURO 2 |
| 21 |
I9-09653 002-1 |
|
WASHER; LK, BRG NUT |
2 |
9312- |
|
4HF1 |
NKR 66, NKR71, NKLR71 E2 |
| 8 |
I5-42311 009-A |
|
HUB; RR AXLE |
2 |
1106- |
|
4JB1-TC |
NKR55 EURO 2 |
| 39 |
I9-42119 616-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 1.000 ( NHR 55 ) |
| 38 |
I6-09625 092-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4JB1 |
(IADG) NHR55 EURO 2 |
| 47 |
I0-91510 606-0 |
|
WASHER; LK OIL CATCHER |
10 |
9312- |
|
4BE1 |
NKR 58 |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 9 |
I8-97126 489-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9312- |
LH |
4JB1 |
NHR 55 |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
9 |
9312- |
|
4HF1 |
NKR66, NKR55 EURO 2 |
| 46 |
I0-28050 610-0 |
|
BOLT; OIL PIPE |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 49 |
I8-97357 375-2 |
|
CASE; RR AXLE |
1 |
0402- |
|
4JB1 |
NHR 55, NHR55 EURO 2 |
| 9 |
I8-97081 584-4 |
|
PIN; WHEEL, RR AXLE |
6 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 12 |
I9-42119 603-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
9312- |
|
4JB1 |
M12X69 ( NHR 55 ) |
| 38 |
I8-94336 314-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
TKK, KR58,NKR66-2,NKR55 E2 |
| 8 |
I8-97122 626-A |
|
HUB; RR AXLE |
2 |
0702-1201 |
|
4HG1-T |
NKR71 EURO 2 |
| 25 |
I8-97083 094-2 |
|
SHAFT; AXLE, RR |
2 |
0702- |
|
4JB1-TC |
NHR55-T/B EURO 2 |
| 15 |
I9-00093 082-A |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4BE1 |
(IADG) NKR58 |
| 38 |
I6-94336 316-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
(IADG) TKK, NKR66, NKR71, NKR71 E2 |
| 38 |
I8-94336 316-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
TKK, NKR66, NKR71, NKR71 E2 |
| 9 |
I8-98007 976-0 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
LH |
4HG1-T |
NKR71-T/THD E2 GOLD |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
9312- |
|
4BE1 |
NKR 58, NKR 66, NKR 71 |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
2 |
9312- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
9 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 9 |
I8-97017 043-2 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
RH |
4HG1-T |
NKR71-T/THD E2 GOLD |
| 38 |
I5-09625 092-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4JB1 |
NHR55 EURO 2 |
| 9 |
I8-94383 436-2 |
|
PIN; WHEEL, RR AXLE |
5 |
9312- |
RH |
4BE1 |
NKR 58, NKR 66-2 TRUK |
| 9 |
I8-97081 584-4 |
|
PIN; WHEEL, RR AXLE |
6 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 1 |
I8-97034 770-A |
|
DRUM; BRK, RR |
2 |
0305-1010 |
|
4HF1-2 |
NKR 66-2 ( TRUK ) |
| 1 |
I8-97036 367-A |
|
DRUM; BRK, RR |
2 |
9312- |
|
4HF1 |
NKR 66, NKR 71, NKR 66-2 BUS |
| 9 |
I5-89931 945-0 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
LH |
4JB1-TC |
NHR55 BUS ( FOR ALLOY ) |
| 67 |
I0-50561 050-0 |
|
BOLT; FINAL DRIVE SETTING |
4 |
0211- |
|
4HG1 |
NKR66,NKR71, NKR71 EURO 2 |
| 49 |
I8-97047 980-3 |
|
CASE; RR AXLE |
1 |
9312-0210 |
|
4JB1 |
NHR 55 |
| 58 |
I8-97307 060-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 16 |
I6-94336 317-2 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4HF1 |
(IADG) NKR66, NKR71 EURO 2 |
| 33 |
I8-97086 472-0 |
|
WASHER; AXLE SHAFT |
2 |
9811- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 39 |
I9-42119 620-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.050 ( NHR 55 ) |
| 58 |
I8-97109 869-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 38 |
I8-94367 958-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4HF1 |
NOK, NKR66,NKR71,NKR71 E2 |
| 75 |
I0-91510 612-0 |
|
WASHER; L K, RR BRK ASM SETTING |
12 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 76 |
I0-91110 512-0 |
|
NUT; RR BRK ASM SETTING |
12 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 37 |
I9-00093 081-0 |
|
BEARING; HUB INNER, RR AXLE |
4 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 14 |
I0-91110 512-0 |
|
NUT; BRG HOLDER TO CASE |
8 |
9312- |
|
4JB1 |
M12 ( NHR 55 ) |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
2 |
9312- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 25 |
I6-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
1202- |
|
4HG1-T |
(IADG) NKR71-T/HD E2, HARIMAU |
| 34 |
I7-05110 010-A |
|
NUT; AXLE SHAFT |
16 |
9312- |
|
4HF1 |
NKR 58, NKR 66, NKR 71 |
| 16 |
I8-98202 912-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4HF1 |
NKR66, NKR71 EURO 2 |
| 39 |
I9-42119 619-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.076 ( NHR 55 ) |
| 8 |
I5-42311 009-A |
|
HUB; RR AXLE |
2 |
0702-1105 |
|
4JB1-TC |
NKR55 EURO 2 |
| 49 |
I8-98192 225-0 |
|
CASE; RR AXLE |
1 |
1202- |
|
4HG1-T |
NKR71-T/THD E2 HARIMAU |
| 38 |
I8-94336 314-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
TKK, KR58,NKR66-2,NKR55 E2 |
| 15 |
I9-00093 082-A |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4BE1 |
(IADG) NKR58 |
| 9 |
I8-97126 489-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9811- |
LH |
4JB1 |
M14X42 TREAD,NHR 55T |
| 20 |
I8-97137 094-0 |
|
NUT; BRG, RR HUB |
2 |
9607- |
|
4HF1 |
NKR66, NKR71, NKR71 EURO 2 |
| 38 |
I6-94336 314-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4BE1 |
(IADG) TKK, KR58,NKR66-2,NKR55 E2 |
| 63 |
I9-09662 005-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 37 |
I9-00093 624-A |
|
BEARING; HUB INNER, RR AXLE |
2 |
0211- |
|
4HG1 |
(IADG) NKR 71 |
| 47 |
I0-91510 606-0 |
|
WASHER; LK OIL CATCHER |
10 |
9312- |
|
4HF1 |
NKR 66 |
| 154 |
I0-36410 616-0 |
|
SCREW; SLOTTED |
2 |
0702- |
|
4HG1-T |
NKR71 EURO 2 |
| 9 |
I8-97126 489-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9811- |
LH |
4JB1 |
M14X42 TREAD,NHR 55T |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
4 |
9312- |
|
4BE1 |
NKR 58, NKR66-2 |
| 16 |
I6-94336 317-2 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4HF1 |
(IADG) NKR66, NKR71 EURO 2 |
| 1 |
I8-97034 799-A |
|
DRUM; BRK, RR |
2 |
0702- |
|
4JB1-TC |
NHR55 ( BAKRIE ) |
| 49 |
I8-97070 484-5 |
|
CASE; RR AXLE |
1 |
9312- |
|
4BE1 |
NKR 58 |
| 9 |
I8-97126 488-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9811- |
RH |
4JB1 |
M14X42 TREAD,NHR 55T |
| 8 |
I8-97122 626-A |
|
HUB; RR AXLE |
2 |
0702-1201 |
|
4HG1-T |
NKR71 EURO 2 |
| 63 |
I9-09662 005-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 13 |
I0-91510 512-0 |
|
WASHER; LK, BRG HOLDER TO CASE |
8 |
9312- |
|
4JB1 |
ID=12 ( NHR 55 ) |
| 46 |
I0-28050 610-0 |
|
BOLT; OIL PIPE |
2 |
9312- |
|
4BE1 |
NKR 58 |
| 69 |
I8-98022 413-0 |
|
STUD; AXLE CASE |
4 |
9312- |
|
4HF1 |
NKR 66, NKR 71 |
| 38 |
I5-09625 092-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
9312- |
|
4JB1 |
NHR55 EURO 2 |
| 14 |
I0-91110 512-0 |
|
NUT; BRG HOLDER TO CASE |
8 |
9312- |
|
4JB1 |
M12 ( NHR 55 ) |
| 16 |
I6-09724 022-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
9312- |
|
4JB1 |
(IADG) NHR 55 |
| 12 |
I9-42119 603-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
0702- |
|
4JB1-TC |
M12X69 ( NHR 55 EURO 2 ) |
| 34 |
I7-05110 010-A |
|
NUT; AXLE SHAFT |
16 |
9312-0304 |
|
4JB1 |
NHR 55 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
0702- |
|
4JB1-TC |
NHR55/NKR55 EURO 2 |
| 49 |
I8-97032 861-5 |
|
CASE; RR AXLE |
1 |
0702- |
|
4JB1-TC |
NKR55L-T (6T) EURO 2 |
| 39 |
I9-42119 616-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 1.000 ( NHR 55 ), EURO 2 |
| 58 |
I8-97109 869-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
9312- |
|
4HF1 |
NKR 66, NKR 66-2, NKR 71 |
| 1 |
I8-97034 799-A |
|
DRUM; BRK, RR |
2 |
9312-0304 |
|
4JB1 |
NHR 55 |
| 39 |
I9-42119 617-0 |
|
SHIM; BRG HOLDER |
AR |
9312- |
|
4JB1 |
T = 0.500 ( NHR 55 ) |
| 49 |
I8-97122 348-4 |
|
CASE; RR AXLE |
1 |
9811- |
|
4HF1 |
NKR 66, NKR 71 |
| 39 |
I9-42119 619-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.076 ( NHR 55 ), EURO 2 |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
9312- |
|
4JB1 |
NHR 55 |
| 9 |
I8-97126 488-0 |
|
PIN; WHEEL, RR AXLE |
6 |
9811- |
RH |
4JB1 |
M14X42 TREAD,NHR 55T |
| 34 |
I7-05110 010-A |
|
NUT; AXLE SHAFT |
16 |
9312-0304 |
|
4JB1 |
NHR 55 |
| 25 |
I8-94366 192-0 |
|
SHAFT; AXLE, RR |
2 |
0702- |
|
4JB1-TC |
NKR55-T/B,NKR55-B (LWB) E2 |
| 4 |
I8-94120 081-0 |
|
HOLDER; BRG, AXLE SHAFT |
1 |
9312- |
|
4JB1 |
LH ( NHR 55 ) |
| 15 |
I9-00093 082-0 |
|
BEARING; HUB OUTER, RR AXLE |
4 |
9312- |
|
4JB1 |
NHR55 |
| 36 |
I8-97360 004-0 |
|
WASHER; SPECIAL, AXLE SHAFT |
16 |
9312- |
|
4HF1 |
NKR 58, NKR 66, NKR 66-2, NKR 71 |
| 9 |
I9-42332 605-5 |
|
PIN; WHEEL, RR AXLE |
5 |
0702- |
LH |
4JB1-TC |
NKR55 TRUCK/BUS |
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
9312- |
|
4HF1 |
NKR 66 |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
8 |
9312- |
|
4JB1 |
NHR55, NHR55 EURO 2 |
| 39 |
I9-42119 620-0 |
|
SHIM; BRG HOLDER |
4 |
0307- |
|
4JB1 |
T = 0.050 ( NHR 55 ), EURO 2 |
| 36 |
I8-97360 004-0 |
|
WASHER; SPECIAL, AXLE SHAFT |
16 |
9312- |
|
4HF1 |
NKR 58, NKR 66, NKR 66-2, NKR 71 |
| 31 |
I8-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4HF1 |
M 10 X 30 L=49 |
| 31 |
I6-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
9312- |
|
4BE1 |
(IADG) M10X30 L=49 ( NKR 58 ) |
| 21 |
I9-09853 214-1 |
|
WASHER; LK, BRG NUT |
2 |
9312- |
|
4BE1 |
NKR58,NKR66-2,NKR55 EURO 2 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
9312- |
|
4BE1 |
NKR 58, NKR 66, NKR 71 |
