| 392 |
I8-98115 793-0 |
|
RING; OUTSIDE,SYN |
2 |
1812- |
|
A |
OD=90.0 |
| 72 |
I8-97943 878-0 |
|
BEARING; BALL,MAINSHAFT |
1 |
1812- |
|
A |
NSK |
| 376 |
I8-97238 590-0 |
|
INSERT; 4X2-4X4 SYN,TRANSFER |
3 |
1812- |
|
B |
|
| 238 |
I8-94448 202-2 |
|
INSERT |
3 |
1812- |
|
A |
|
| 110 |
I8-94422 107-0 |
|
RING; SNAP,COUNTER BRG |
1 |
1812- |
|
A |
T=1.50 GREEN |
| 390 |
I8-94422 089-1 |
|
RING; SNAP,CLU HUB |
1 |
1812- |
|
A |
T=1.85 YELLOW |
| 65 |
I8-94422 071-1 |
|
NUT; MAINSHAFT |
1 |
1812- |
|
A |
M34 |
| 86 |
I8-94422 113-2 |
|
WASHER; THRUST,5TH |
1 |
1812- |
|
A |
T=8 . 20 BLUE |
| 35 |
I8-94151 510-3 |
|
RING; BLOCK,4TH & 3RD |
2 |
1812- |
|
A |
Z = 4 5 |
| 377 |
I8-94448 045-0 |
|
SPRING; INSERT,4X2-4X4 SYN,TRANS |
2 |
1812- |
|
B |
|
| 152 |
I8-94363 060-0 |
|
SLEEVE; 4X2-4X4 SHIFT,TRANSFER |
1 |
1812- |
|
B |
|
| 386 |
I9-08150 640-0 |
|
PIN; REV SHAFT |
1 |
1812- |
|
A |
OD= 6 L=4 0 |
| 87 |
I8-94201 356-0 |
|
BALL; THRUST WASHER |
1 |
1812- |
|
ABC |
|
| 61 |
I8-97188 800-0 |
|
SYNCHRONIZER; REV & 5TH |
1 |
1812- |
|
A |
|
| 86 |
I8-94422 110-2 |
|
WASHER; THRUST,5TH |
1 |
1812- |
|
A |
T=7.90 WHITE |
| 110 |
I8-94422 108-0 |
|
RING; SNAP,COUNTER BRG |
1 |
1812- |
|
A |
T=1.60 BROWN |
| 36 |
I8-98210 226-0 |
|
GEAR; 3RD,MAINSHAFT |
1 |
1812- |
|
A |
Z = 2 7 |
| 3 |
I8-94380 015-A |
|
BEARING; TOP GEAR SHAFT |
1 |
1812- |
|
A |
(IADG) NSK |
| 499 |
I8-97300 954-0 |
|
COLLAR; OIL SEAL |
1 |
1812- |
|
A |
4X4(UCS***) |
| 97 |
I8-94377 434-0 |
|
GEAR; 5TH,COUNTER |
1 |
1812- |
|
A |
Z = 50 |
| 110 |
I8-94422 104-0 |
|
RING; SNAP,COUNTER BRG |
1 |
1812- |
|
A |
T=1 . 20 YELLOW |
| 246 |
I8-97029 600-4 |
|
BEARING; ROLLER,COUNTER SHAFT FR |
1 |
1812- |
|
A |
NSK |
| 396 |
I8-98172 355-0 |
|
BEARING; NEEDLE,MAINSHAFT |
1 |
1812- |
|
A |
NSK |
| 82 |
I8-97300 980-0 |
|
SHAFT; MAIN,TRANS |
1 |
1812- |
|
A |
4X4(UCS***) Z=28-34-26-27 |
| 60 |
I8-97031 079-0 |
|
COLLAR; REV MAIN |
1 |
1812- |
|
A |
|
| 110 |
I8-94422 103-0 |
|
RING; SNAP,COUNTER BRG |
1 |
1812- |
|
A |
T=1 . 10 WHITE |
| 306 |
I8-97129 617-0 |
|
RING; SNAP,MAINSHAFT |
1 |
1812- |
|
A |
(A) T=1.80 WHITE |
| 397 |
I8-94422 075-0 |
|
SPRING; INSERT,4TH & 3RD |
2 |
1812- |
|
A |
|
| 59 |
I8-98210 228-0 |
|
GEAR; REV MAINSHAFT |
1 |
1812- |
|
A |
Z = 41 |
| 51 |
I8-98115 804-0 |
|
RING; BLOCK,LOW & 2ND |
2 0 |
1812- |
|
A |
Z = 3 6 |
| 89 |
I8-94422 395-0 |
|
RING; RET,THRUST RING |
1 |
1812- |
|
A |
ID=31.8 |
| 132 |
I8-98249 849-0 |
|
SHAFT; REV |
1 |
1812- |
|
A |
|
| 259 |
I8-97234 225-0 |
|
SYNCHRONIZER; 4X2 - 4X4,TRANSFER |
1 |
1812- |
|
B |
|
| 390 |
I8-94422 090-2 |
|
RING; SNAP,CLU HUB |
1 |
1812- |
|
A |
T=1.90 BLUE |
| 292 |
I8-94422 081-0 |
|
RING; SNAP,BRG OUTER |
1 |
1812- |
|
A |
NSK |
| 390 |
I8-94422 088-2 |
|
RING; SNAP,CLU HUB |
1 |
1812- |
|
A |
T=1.80 WHITE |
| 398 |
I8-97216 164-1 |
|
GEAR; COUNTER |
1 |
1812- |
|
A |
Z=44-32-25-19 |
| 189 |
I8-94422 102-0 |
|
RING; SNAP,REV,GEAR |
1 |
1812- |
|
A |
(A) T=1.40 BLUE |
| 86 |
I8-94422 111-2 |
|
WASHER; THRUST,5TH |
1 |
1812- |
|
A |
T=8.00 YELLOW |
| 189 |
I8-94422 101-0 |
|
RING; SNAP,REV,GEAR |
1 |
1812- |
|
A |
(A) T=1.30 YELLOW |
| 110 |
I8-94422 105-0 |
|
RING; SNAP,COUNTER BRG |
1 |
1812- |
|
A |
T=1 . 30 BLUE |
| 33 |
I8-94161 990-2 |
|
BEARING; NEEDLE,3RD GEAR |
1 |
1812- |
|
A |
04.419 NSK |
| 14 |
I8-98172 356-0 |
|
BEARING; NEEDLE,5TH |
1 |
1812- |
|
A |
NTN |
| 49 |
I9-00096 625-0 |
|
BEARING; NEEDLE,2ND GEAR |
1 |
1812- |
|
A |
JTEKT |
| 391 |
I8-94363 056-0 |
|
RING; INSIDE,SYN |
2 |
1812- |
|
A |
OD=95.8 |
| 93 |
I9-09180 025-0 |
|
RING; SNAP,COUNTER FRT BRG |
1 |
1812- |
|
A |
08.934 ID=23.2 |
| 394 |
I8-97018 921-1 |
|
BEARING; BALL,MAINSHAFT RR |
1 |
1812- |
|
A |
4X4(UCS***) 04.352 NSK |
| 404 |
I8-94421 892-0 |
|
PLATE; THRUST |
2 |
1812- |
|
A |
|
| 405 |
I8-94363 062-1 |
|
INSERT; SYN,LOW & 2ND |
3 |
1812- |
|
A |
|
| 226 |
I8-94223 069-1 |
|
WASHER; THRUST,REV GEAR,COUNTER |
1 |
1812- |
|
A |
ID=30.0 |
| 211 |
I8-94148 935-0 |
|
BEARING; THRUST NEEDLE,1ST GEAR |
1 |
1812- |
|
A |
NSK |
| 376 |
I8-97238 590-0 |
|
INSERT; 4X2-4X4 SYN,TRANSFER |
3 |
1812- |
|
A CDE |
4X4(UCS***) |
| 377 |
I8-94448 045-0 |
|
SPRING; INSERT,4X2-4X4 SYN,TRANS |
2 |
1812- |
|
A CDE |
4X4(UCS***) |
| 259 |
I8-97234 225-0 |
|
SYNCHRONIZER; 4X2 - 4X4,TRANSFER |
1 |
1812- |
|
A CDE |
4X4(UCS***) |
| 306 |
I8-97129 616-0 |
|
RING; SNAP,MAINSHAFT |
1 |
1812- |
|
A |
(A) T=1 . 85 YELLOW |
| 86 |
I8-94422 112-2 |
|
WASHER; THRUST,5TH |
1 |
1812- |
|
A |
T=8.10 GREEN |
| 152 |
I8-94363 060-0 |
|
SLEEVE; 4X2-4X4 SHIFT,TRANSFER |
1 |
1812- |
|
A CDE |
4X4(UCS***) |
| 145 |
I8-98063 369-1 |
|
SLEEVE; HIGH-LOW SHIFT,TRANSFER |
1 |
1812- |
|
B |
|
| 62 |
I8-98189 962-0 |
|
SPRING; INSERT,REV & 5TH |
2 |
1812- |
|
A |
|
| 40 |
I8-94448 045-0 |
|
SPRING; INSERT,LOW & 2ND |
2 |
1812- |
|
A |
|
| 98 |
I8-97018 535-A |
|
BEARING; BALL,COUNTER END |
1 |
1812- |
|
A |
(IADG) NSK |
| 110 |
I8-94422 106-0 |
|
RING; SNAP,COUNTER BRG |
1 |
1812- |
|
A |
T=1 . 40 PINK |
| 91 |
I8-94322 411-0 |
|
RING; SNAP,CENTER BRG,MAINSHAFT |
1 |
1812- |
|
A |
ID=76.2 |
| 1 |
I8-98210 247-0 |
|
SHAFT; TOP GEAR,TRANS |
1 |
1812- |
|
A |
Z = 2 6 |
| 313 |
I8-94161 990-2 |
|
BEARING; NEEDLE,LOW GEAR |
1 |
1812- |
|
A |
NSK |
| 5 |
I8-97254 316-0 |
|
RING; SNAP,BRG TO TOP GEAR SHAFT |
1 |
1812- |
|
A |
04.525 ID=37.4 |
| 13 |
I8-98210 227-0 |
|
GEAR; 5TH,MAINSHAFT |
1 |
1812- |
|
A |
Z = 2 2 |
| 95 |
I8-94377 433-0 |
|
GEAR; REV,COUNTER |
1 |
1812- |
|
A |
Z = 19 |
| 35 |
I6-94151 510-0 |
|
RING; BLOCK,4TH & 3RD |
2 |
1812- |
|
A |
(IADG) Z = 4 5 |
| 98 |
I8-97018 535-A |
|
BEARING; BALL,COUNTER END |
1 |
1812- |
|
A |
(IADG) NSK |
| 3 |
I8-94380 015-A |
|
BEARING; TOP GEAR SHAFT |
1 |
1812- |
|
A |
(IADG) NSK |
| 189 |
I8-94422 100-0 |
|
RING; SNAP,REV,GEAR |
1 |
1812- |
|
A |
(A) T=1.20 WHITE |
| 314 |
I8-94422 064-0 |
|
BEARING; NEEDLE,REV GEAR |
1 |
1812- |
|
A |
(A) NSK |
| 38 |
I8-94363 059-1 |
|
SYNCHRONIZER; LOW & 2ND |
1 |
1812- |
|
A |
|
| 421 |
I8-97071 688-0 |
|
RING; BLOCK,REV & 5TH |
2 |
1812- |
|
A |
Z = 3 6 |
| 145 |
I8-98063 369-1 |
|
SLEEVE; HIGH-LOW SHIFT,TRANSFER |
1 |
1812- |
|
A CDE |
4X4(UCS***) |
| 306 |
I8-97129 615-0 |
|
RING; SNAP,MAINSHAFT |
1 |
1812- |
|
A |
(A) T=1.90 BLUE |
| 34 |
I8-97188 798-0 |
|
SYNCHRONIZER; 4TH & 3RD |
1 |
1812- |
|
A |
|
| 70 |
I8-97300 952-1 |
|
GEAR; 1ST,MAINSHAFT |
1 |
1812- |
|
A |
Z = 4 5 |
| 306 |
I9-09180 030-0 |
|
RING; SNAP,MAINSHAFT |
1 |
1812- |
|
A |
4X4(UCS***) (B) ID=27.9 |
| 306 |
I9-09180 030-0 |
|
RING; SNAP,MAINSHAFT |
2 |
1812- |
|
A |
4X2(UCB***) (B) ID=27.9 |
| 4 |
I8-94422 083-0 |
|
RING; SNAP,BRG TO TOP GEAR SHAFT |
1 |
1812- |
|
A |
NSK |
| 63 |
I8-98189 965-0 |
|
INSERT; SYN,REV & 5TH |
3 |
1812- |
|
A |
|
| 50 |
I8-97300 953-1 |
|
GEAR; 2ND,MAINSHAFT |
1 |
1812- |
|
A |
Z = 3 4 |
| 135 |
I8-98146 726-1 |
|
GEAR; REV IDLER |
1 |
1812- |
|
A |
Z = 3 3 |
| 314 |
I8-94422 064-0 |
|
BEARING; NEEDLE,REV GEAR |
1 |
1812- |
|
A |
(A) JTEKT |
| 219 |
I8-94436 929-0 |
|
BEARING; BALL,CLUSTER,RR |
1 |
1812- |
|
A |
NSK |
