| 1 |
I8-98190 116-0 |
|
DRIVE ASM; FINAL,RR |
1 |
1812- |
|
AB |
FINAL GEAR RATIO 43/11(GW1) EXC. LIMITED SLIP DIFF<G80> 43/11 |
| 24 |
I8-97200 285-1 |
|
GEAR; PINION,DIFF |
4 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> |
| 76 |
I8-97096 209-0 |
|
DISC; BEVEL |
4 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> |
| 22 |
I8-94435 308-1 |
|
SPIDER; DIFF PINION |
1 |
1812- |
|
AB |
EXC. LIMITED SLIP DIFF<G80> |
| 72 |
I8-94325 448-0 |
|
CAGE; DIFF |
1 |
1812- |
|
AB |
FINAL GEAR RATIO 41/11(GT4) EXC. AUSTRALIA EQUIPMENT(B13),L P DIFF<G80> |
| 51 |
I8-94435 372-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2 .26 |
| 51 |
I8-94435 363-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.08 |
| 20 |
I5-41562 007-1 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
EXC. LIMITED SLIP DIFF<G80> T=1 . 10 |
| 51 |
I8-94435 375-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
|
| 73 |
I8-94435 352-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1812- |
|
AB |
T=0 . 30 |
| 51 |
I8-94435 373-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2 .28 |
| 51 |
I8-94435 360-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.02 |
| 20 |
I8-97066 412-0 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> T=1.80 |
| 51 |
I8-94435 374-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2 .30 |
| 21 |
I8-98186 828-1 |
|
GEAR; SIDE,DIFF |
2 |
1812- |
|
AB |
FINAL GEAR RATIO 41/11(GT4) EXC. AUSTRALIA EQUIPMENT(B13),L P DIFF<G80> Z=18 |
| 51 |
I8-94435 365-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.12 |
| 21 |
I8-98186 828-1 |
|
GEAR; SIDE,DIFF |
2 |
1812- |
|
AB |
FINAL GEAR RATIO 41/11(GT4) AUSTRALIA EQUIPMENT(B13) EMISSION SYSTEM R15-04(K75),EUR CATION(NT2),EURO4 SPECIFICATION EXC. LIMITED SLIP DIFF<G80> Z=18 |
| 60 |
I8-98014 984-2 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
1812- |
|
AB |
FINAL GEAR RATIO 41/10(GT5) 41/10 |
| 51 |
I8-94435 371-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2 .24 |
| 24 |
I8-98186 829-0 |
|
GEAR; PINION,DIFF |
2 |
1812- |
|
AB |
FINAL GEAR RATIO 41/11(GT4) AUSTRALIA EQUIPMENT(B13) EMISSION SYSTEM R15-04(K75),EUR CATION(NT2),EURO4 SPECIFICATION EXC. LIMITED SLIP DIFF<G80> Z=10 |
| 51 |
I8-94435 377-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2 .36 |
| 21 |
I8-98186 828-1 |
|
GEAR; SIDE,DIFF |
2 |
1812- |
|
AB |
FINAL GEAR RATIO 41/10(GT5),FIN TIO 43/11(GW1),FINAL GEAR RATIO ) EXC. LIMITED SLIP DIFF<G80> Z = 18 |
| 51 |
I8-94435 364-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.10 |
| 24 |
I8-98186 829-0 |
|
GEAR; PINION,DIFF |
2 |
1812- |
|
AB |
FINAL GEAR RATIO 41/10(GT5),FIN TIO 43/11(GW1),FINAL GEAR RATIO ) EXC. LIMITED SLIP DIFF<G80> Z=10 |
| 51 |
I8-94435 361-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.04 |
| 20 |
I9-41562 602-0 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
EXC. LIMITED SLIP DIFF<G80> T=0 . 90 |
| 37 |
I8-94376 261-1 |
|
NUT; DRIVING PINION |
1 |
1812- |
|
AB |
M24 FLANGE |
| 73 |
I8-94435 348-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1812- |
|
AB |
T=0.12 |
| 100 |
I6-97328 648-0 |
|
SEAL; OIL,FINAL PINION |
1 |
1812- |
|
AB |
(IADG) NOK |
| 42 |
I8-98319 329-0 |
|
COLLAR; DIST,COLLAPSIBLE |
1 |
1812- |
|
AB |
L=58 |
| 73 |
I8-94435 350-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1812- |
|
AB |
T=0.18 |
| 51 |
I8-94435 366-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.14 |
| 84 |
I8-97038 064-0 |
|
BOLT; FINAL DRIVE GEAR |
12 |
1812- |
|
AB |
M10X18.5 |
| 20 |
I8-94435 343-0 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
EXC. LIMITED SLIP DIFF<G80> T=0.80 |
| 72 |
I8-94325 448-0 |
|
CAGE; DIFF |
1 |
1812- |
|
AB |
FINAL GEAR RATIO 41/10(GT5),FIN TIO 43/11(GW1),FINAL GEAR RATIO ) EXC. LIMITED SLIP DIFF<G80> |
| 51 |
I8-94435 359-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.00 |
| 51 |
I8-94435 362-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.06 |
| 70 |
I8-94435 355-A |
|
BEARING; DIFF CAGE |
2 |
1812- |
|
AB |
(IADG) JTEKT |
| 51 |
I8-94435 369-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2 .20 |
| 73 |
I8-94435 349-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1812- |
|
AB |
T=0 . 15 |
| 100 |
I8-97328 648-0 |
|
SEAL; OIL,FINAL PINION |
1 |
1812- |
|
AB |
NOK |
| 50 |
I8-98362 581-0 |
|
BEARING; FINAL PINION |
1 |
1812- |
|
AB |
NSK |
| 51 |
I8-94435 368-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.18 |
| 70 |
I8-94435 355-A |
|
BEARING; DIFF CAGE |
2 |
1812- |
|
AB |
(IADG) NSK |
| 70 |
I8-94435 355-A |
|
BEARING; DIFF CAGE |
2 |
1812- |
|
AB |
(IADG) JTEKT |
| 1 |
I8-98167 626-0 |
|
DRIVE ASM; FINAL,RR |
1 |
1812- |
|
AB |
FINAL GEAR RATIO 41/10(GT5) LIMITED SLIP DIFF<G80> 41/10 |
| 55 |
I8-97240 889-2 |
|
CARRIER; DIFF |
1 |
1812- |
|
AB |
|
| 73 |
I8-94435 353-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1812- |
|
AB |
T=0 . 50 |
| 56 |
I8-98176 233-0 |
|
BOLT; BRG CAP |
4 |
1812- |
|
AB |
M12X75 FLANGE |
| 51 |
I8-94435 356-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=1.94 |
| 20 |
I8-94453 935-0 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> T=1 . 50 |
| 20 |
I5-41562 007-1 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
EXC. LIMITED SLIP DIFF<G80> T=1 . 30 |
| 72 |
I8-94325 448-0 |
|
CAGE; DIFF |
1 |
1812- |
|
AB |
FINAL GEAR RATIO 41/11(GT4) AUSTRALIA EQUIPMENT(B13) EMISSION SYSTEM R15-04(K75),EUR CATION(NT2),EURO4 SPECIFICATION EXC. LIMITED SLIP DIFF<G80> |
| 78 |
I8-94453 937-0 |
|
DISC; FRICTION |
4 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> |
| 73 |
I8-94435 351-0 |
|
SHIM; DIFF SIDE BRG |
AR |
1812- |
|
AB |
T=0 . 25 |
| 51 |
I8-94435 357-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=1.96 |
| 51 |
I8-94435 376-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2 .34 |
| 24 |
I8-98186 829-0 |
|
GEAR; PINION,DIFF |
2 |
1812- |
|
AB |
FINAL GEAR RATIO 41/11(GT4) EXC. AUSTRALIA EQUIPMENT(B13),L P DIFF<G80> Z=10 |
| 80 |
I8-94453 931-0 |
|
RING; PRESSURE |
2 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> |
| 126 |
I8-98166 552-1 |
|
COUPLING; DRIVING PINION |
1 |
1812- |
|
AB |
|
| 20 |
I5-41562 007-1 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
EXC. LIMITED SLIP DIFF<G80> T=1.20 |
| 51 |
I8-94435 358-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=1.98 |
| 20 |
I8-94365 188-0 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> T=1.70 |
| 74 |
I9-09878 096-0 |
|
PIN; LK,CROSS PIN |
1 |
1812- |
|
AB |
EXC. LIMITED SLIP DIFF<G80> OD= 5 L=3 5 |
| 20 |
I9-41562 602-0 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
EXC. LIMITED SLIP DIFF<G80> T=1 . 00 |
| 79 |
I8-94453 936-0 |
|
PLATE; FRICTION |
4 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> T=1.75 |
| 50 |
I8-98357 664-0 |
|
BEARING; FINAL PINION |
1 |
1812- |
|
AB |
JTEKT |
| 20 |
I8-94365 187-0 |
|
WASHER; THRUST,SIDE GEAR |
2 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> T=1.60 |
| 51 |
I8-94435 367-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.16 |
| 51 |
I8-94435 370-0 |
|
SHIM; PINION,FINAL DRIVE |
AR |
1812- |
|
AB |
T=2.22 |
| 79 |
I8-94365 189-0 |
|
PLATE; FRICTION |
4 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> T=1.85 |
| 82 |
I8-94453 932-0 |
|
SPIDER; DIFF PINION |
1 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> |
| 39 |
I9-00093 078-A |
|
BEARING; FINAL PINION |
1 |
1812- |
|
AB |
(IADG) NSK |
| 39 |
I9-00093 078-A |
|
BEARING; FINAL PINION |
1 |
1812- |
|
AB |
(IADG) NSK |
| 71 |
I8-98167 619-0 |
|
CAGE ASM; DIFF,FINAL DRIVE |
1 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> |
| 60 |
I8-98014 980-2 |
|
GEAR SET; FINAL DRIVE,RR |
1 |
1812- |
|
AB |
FINAL GEAR RATIO 43/11(GW1) 43/11 |
| 21 |
I8-97200 286-0 |
|
GEAR; SIDE,DIFF |
2 |
1812- |
|
AB |
LIMITED SLIP DIFF<G80> |
