| 116 |
I8-98249 822-0 |
|
BOLT; EXPANSION VALVE |
2 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 23 |
I8-98249 818-0 |
|
SCREW; CASE TO MOTOR |
3 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 81 |
I8-98192 306-1 |
|
DUCT; RR COOLER |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 22 |
I8-97321 273-0 |
|
RESISTOR; RR COOLER |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 78 |
I8-98249 827-0 |
|
GROMMET; COOLER UNIT |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> 08.552 |
| 14 |
I8-98249 820-0 |
|
EVAPORATOR; RR COOLER |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 29 |
I8-98249 818-0 |
|
SCREW; CASE |
13 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 4 |
I8-98249 825-0 |
|
GASKET; VLV TO PIPE |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> (A) ID=13.6 |
| 121 |
I8-98251 842-0 |
|
INSULATOR; EVAP |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 84 |
I8-98249 812-0 |
|
RUBBER |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 40 |
I8-98249 818-0 |
|
SCREW; RESISTOR FIX,COOLER UNIT |
2 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 123 |
I8-98249 828-0 |
|
SCREW |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 1 |
I8-98192 297-3 |
|
COOLING UNIT; RR |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 124 |
I8-98249 829-0 |
|
BLOWER ASM |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 89 |
I8-98249 824-0 |
|
GASKET; EVAP TO VLV |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> (B) ID=14.3 |
| 89 |
I8-98249 823-0 |
|
GASKET; EVAP TO VLV |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> (A) ID=10.7 |
| 8 |
I8-98249 821-0 |
|
VALVE; EXPANSION |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 43 |
I8-98249 830-0 |
|
BOLT; COOLER UNIT |
2 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 115 |
I8-98249 819-0 |
|
EVAPORATOR ASM; COOLING UNIT |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 2 |
I8-98249 810-0 |
|
CASE; RR COOLER |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 28 |
I8-98249 815-0 |
|
LINING; CASE |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 16 |
I8-98249 817-0 |
|
LINING; CASE |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 114 |
I8-98249 816-0 |
|
SEAL; CASE |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 79 |
I8-98249 813-0 |
|
COLLAR; COOLER UNIT |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 4 |
I8-98249 826-0 |
|
GASKET; VLV TO PIPE |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> (B) ID=6.8 |
| 58 |
I8-98055 704-0 |
|
NUT; CASE |
3 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> 08 . 915 M6 FLANGE |
| 67 |
I8-98249 814-0 |
|
HOSE; DRAIN |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
| 122 |
I8-98251 843-0 |
|
PIPE ASM; EVAP |
1 |
1812- |
|
AB |
REAR COOLER WO/HEATER<C6 9> |
