5-01 | ENGINE ROOM INSULATOR
MUX
MU-X 2021
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 1 | I8-97496 003-0 | FRAME ASM | 1 | 2103- | A | A/T 6 SPEED-AISIN<Y6A> | ||
| 164 | I8-98392 791-2 | PLATE; FRT | 1 | 2103- | AB | |||
| 29 | I8-98392 797-0 | BRACKET; CAB MTG | 2 | 2103- | AB | (A) | ||
| 256 | I8-98392 818-1 | BRACKET; S/ABS | 1 | 2103- | AB | |||
| 2 | I8-97497 405-0 | MEMBER; CROSS,1ST | 1 | 2103- | AB | |||
| 352 | I8-98392 835-2 | BRACKET; BUMPER RUBBER | 1 | 2103- | AB | |||
| 11 | I8-98392 824-0 | BRACKET; ENG MTG | 1 | 2103- | AB | |||
| 39 | I8-98392 874-0 | BRACKET; FRTSPR.RR | 1 | 2103- | AB | |||
| 352 | I8-98392 834-2 | BRACKET; BUMPER RUBBER | 1 | 2103- | AB | |||
| 24 | I8-98392 873-0 | BRACKET; FRT SPR.FRT | 1 | 2103- | AB | |||
| 29 | I8-98392 840-2 | BRACKET; CAB MTG | 1 | 2103- | AB | (B) | ||
| 164 | I8-98392 790-2 | PLATE; FRT | 1 | 2103- | AB | |||
| 485 | I0-91180 210-0 | NUT; TRANS MTG MBR.FRAME | 2 | 2103- | B | M10 FLANGE | ||
| 29 | I8-97497 430-2 | BRACKET; CAB MTG | 2 | 2103- | AB | (E) | ||
| 497 | I0-28061 080-0 | BOLT; C/MBR | 2 | 2103- | B | (B) M10X80 FLANGE | ||
| 5 | I8-98394 544-3 | MEMBER; CROSS.SUSPENSION | 1 | 2103- | AB | |||
| 309 | I8-98394 497-2 | MEMBER; CROSS | 1 | 2103- | B | |||
| 497 | I0-28651 020-0 | BOLT; C/MBR | 4 | 2103- | B | (A) M10X20 FLANGE | ||
| 80 | I8-98394 492-1 | BRACKET; C/MBR | 1 | 2103- | B | |||
| 204 | I8-97503 418-4 | MEMBER; CROSS.TRANS MTG | 1 | 2103- | A | A/T 6 SPEED-AISIN<Y6A> | ||
| 29 | I8-98392 841-1 | BRACKET; CAB MTG | 1 | 2103- | AB | (C) | ||
| 11 | I8-98392 823-0 | BRACKET; ENG MTG | 1 | 2103- | AB |
