| 42 |
I8-97548 842-A |
|
FILTER; BLOWER UNIT |
1 |
2103- |
|
B |
( IADG ) (A) AIR CONDITIONAL MANUAL CONT (C60) |
| 54 |
I8-97555 456-0 |
|
SCREW; ACTUATOR TO CASE |
2 |
2103- |
|
B |
|
| 3 |
I8-97555 459-0 |
|
NUT; CASE |
3 |
2103- |
|
A |
AIR CONDITIONER AUTOMATIC CONT<C61> (A) |
| 23 |
I8-97553 725-0 |
|
SHUTTER; BLOWER UNIT |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> |
| 26 |
I8-97555 455-0 |
|
TRANSISTOR; BLOWER UNIT |
1 |
2103- |
|
B |
|
| 37 |
I8-97555 449-0 |
|
LEVER; MODE LEVER |
1 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61> (A) |
| 34 |
I8-97553 731-0 |
|
LINING; BLOWER UNIT |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> (B) |
| 119 |
I8-97553 730-0 |
|
LINING; CASE |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> |
| 142 |
I8-97555 444-0 |
|
CASE ASM |
1 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61> (A) |
| 104 |
I8-97553 738-0 |
|
RESISTOR; BLOWER UNIT |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> |
| 141 |
I8-97555 567-0 |
|
CASE ASM; BLOWER UNIT |
1 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61 > (A) |
| 107 |
I8-97555 456-0 |
|
SCREW; TRANSISTOR |
2 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61> |
| 107 |
I8-97555 456-0 |
|
SCREW; TRANSISTOR |
2 |
2103- |
|
B |
|
| 10 |
I8-97555 458-0 |
|
MOTOR ASM; FAN,BLOWER UNn" |
1 |
2103- |
|
A |
AIR CONDITIONER AUTOMATIC CONT<C61> (A) |
| 26 |
I8-97555 455-0 |
|
TRANSISTOR; BLOWER UNIT |
1 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61> |
| 34 |
I8-97555 460-0 |
|
LINING; BLOWER UNIT |
1 |
2103- |
|
B |
(A) |
| 42 |
I8-97548 842-0 |
|
FILTER; BLOWER UNIT |
1 |
2103- |
|
B |
(A) AIR CONDITIONAL MANUAL CONT (C60) |
| 50 |
I8-97555 454-0 |
|
COVER; BLOWER UNIT |
1 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61> |
| 14 |
I8-98233 593-0 |
|
SCREW; COVER TO CASE |
3 |
2103- |
|
A |
COOLER W/FRESH AIR<C6S> (B) |
| 10 |
I8-97555 458-0 |
|
MOTOR ASM; FAN,BLOWER UNn" |
1 |
2103- |
|
B |
(A) |
| 50 |
I8-97555 454-0 |
|
COVER; BLOWER UNIT |
1 |
2103- |
|
B |
(A) |
| 37 |
I8-97553 727-0 |
|
LEVER; MODE LEVER |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> (B) |
| 14 |
I8-97555 457-0 |
|
SCREW; COVER TO CASE |
3 |
2103- |
|
B |
(A) |
| 10 |
I8-97553 732-0 |
|
MOTOR ASM; FAN,BLOWER UNIT |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> (B) |
| 38 |
I8-98139 422-1 |
|
CLIP; BLOWER UNIT |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> |
| 142 |
I8-97555 444-0 |
|
CASE ASM |
1 |
2103- |
|
B |
(A) |
| 78 |
I8-97555 456-0 |
|
SCREW; CASE TO CASE |
5 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61> |
| 105 |
I8-98233 593-0 |
|
SCREW; RESISTOR |
2 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> |
| 142 |
I8-97553 722-0 |
|
CASE ASM |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> (B) |
| 50 |
I8-97553 735-0 |
|
COVER; BLOWER UNIT |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> |
| 3 |
I8-97555 459-0 |
|
NUT; CASE |
3 |
2103- |
|
B |
(A) |
| 92 |
I8-97555 447-0 |
|
ACTUATOR; BLOWER UNIT |
1 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61 > |
| 54 |
I8-97555 456-0 |
|
SCREW; ACTUATOR TO CASE |
2 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61 > |
| 78 |
I8-97555 456-0 |
|
SCREW; CASE TO CASE |
5 |
2103- |
|
B |
|
| 3 |
I8-98139 394-1 |
|
NUT; CASE |
3 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> (B) |
| 92 |
I8-97555 447-0 |
|
ACTUATOR; BLOWER UNIT |
1 |
2103- |
|
B |
|
| 141 |
I8-97555 567-0 |
|
CASE ASM; BLOWER UNIT |
1 |
2103- |
|
B |
(A) |
| 141 |
I8-97553 721-0 |
|
CASE ASM; BLOWER UNn" |
1 |
2103- |
|
A |
COOLER W/FRESH AIR<C65> (B) |
| 34 |
I8-97555 460-0 |
|
LINING; BLOWER UNIT |
1 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61> (A) |
| 14 |
I8-97555 457-0 |
|
SCREW; COVER TO CASE |
3 |
2103- |
|
A |
AIR CONDmONER AUTOMATIC CONT<C61> (A) |
| 37 |
I8-97555 449-0 |
|
LEVER; MODE LEVER |
1 |
2103- |
|
B |
(A) |
