2-25 | 2-25 - SPEEDOMETER DRIVEN GEAR
MUX
MU-X 2024
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 22 | I0-28051 200-0 | BOLT, TRANS CASE TO ENG | 1 | 2110- | A | M/T MVL 6 SPEED 6Y(Y6P) (B) M12X100 FLANGE | ||
| 22 | I0-28051 250-0 | BOLT, TRANS CASE TO ENG | 8 | 2110- | A | 4JJ3 ENG(LNG) (A) M12X50 FLANGE | ||
| 22 | I0-28051 250-0 | BOLT, TRANS CASE TO ENG | 9 | 2110- | A | RZ4E-TC ENG(RDZ) (A) M12X50 FLANGE | ||
| 22 | I0-28051 250-0 | BOLT, TRANS CASE TO ENG | 9 | 2110- | B | RZ4E-TC ENG(RDZ) A/T 6 SPEED-AISIN(Y6A) (A) M12X50 FLANGE | ||
| 80 | I0-28050 820-0 | BOLT, SPD SENSOR | 1 | 2110- | B | M8X20 FLANGE | ||
| 84 | I8-98103 318-0 | CAP, BUSHING,SPEEDOMETER GEAR | 1 | 2110- | B | |||
| 14 | I8-98278 957-0 | COVER, UNDERJRANS | 1 | 2110- | AB | A/T 6 SPEED-AISIN(Y6A) | ||
| 15 | I0-28650 616-0 | BOLT, UNDER COVER TO TRANS | 4 | 2110- | A B | A/T 6 SPEED-AISIN(Y6A) M6X16 FLANGE | ||
| 22 | I0-28051 250-0 | BOLT, TRANS CASE TO ENG | 8 | 2110- | B | 4JJ3 ENG(LNG) A/T 6 SPEED-AISIN(Y6A) (A) M12X50 FLANGE | ||
| 101 | I9-09921 100-0 | GASKET, CAP | 1 | 2110- | B | ID=21.7 0D=28.7 |
