| 42 |
I8-97239 010-1 |
|
SPRING, GEAR LOCK RELEASE .TRANSFER |
1 |
2110- |
|
B |
|
| 34 |
I8-98181 233-0 |
|
SWITCH, TRANSFER INDICATOR |
1 |
2110- |
|
B |
(B) PUSH OFF |
| 199 |
I7-55208 326-0 |
|
COLLAR, TRANSFER CONTROL |
|
2311- |
|
|
|
| 34 |
I8-98181 234-0 |
|
SWITCH, TRANSFER INDICATOR |
1 |
2110- |
|
B |
(A) PUSH ON |
| 47 |
I7-55206 895-0 |
|
BLOCK, SHIFT,LOW-HIGH,TRANSFER |
1 |
2311- |
|
|
|
| 206 |
I8-97234 499-0 |
|
ROLLER, GUIDE,SHIFT |
2 |
2110- |
|
B | |
|
| 47 |
I8-98118 922-1 |
|
BLOCK, SHIFT,LOW-HIGH,TRANSFER |
1 |
2110- |
|
B | |
|
| 203 |
I0-28650 825-0 |
|
BOLT, BRACKET.SWITCH |
1 |
2110- |
|
B I |
M8X25 FLANGE |
| 31 |
I8-97873 324-0 |
|
PLUG, DETENT BALL,TRANSFER |
2 |
2311- |
|
|
|
| 48 |
I8-97234 230-0 |
|
ROD, SHIFT,HIGH-LOW,TRANSFER |
|
2311- |
|
|
|
| 41 |
I8-97234 233-1 |
|
BLOCK, SHIFT,4X2-4X4,TRANSFER |
1 |
2110- |
|
B |
|
| 16 |
I8-97145 374-0 |
|
SPRING, DETENT.SHIFT ROD/TRANSFER |
2 |
2110- |
|
B |
L=23.4 |
| 201 |
I8-97305 011-1 |
|
RING, SNAP,SHIFT |
|
2311- |
|
|
|
| 199 |
I8-97234 663-1 |
|
COLLAR, TRANSFER CONTROL |
|
2311- |
|
|
|
| 44 |
I8-97553 219-0 |
|
ARM, SHIFT,HIGH-LOW,TRANSFER |
1 |
2110- |
|
B |
|
| 205 |
I8-98063 364-1 |
|
SHAFT, SHIFT DRUM |
1 |
2110- |
|
B | |
|
| 40 |
I8-97234 229-0 |
|
ROD, SHIFT,4X2-4X4,TRANSFER |
1 |
2110- |
|
B |
|
| 211 |
I8-97553 222-0 |
|
PAD, SHIFT FORK |
2 |
2110- |
|
B | |
|
| 15 |
I8-94435 335-0 |
|
BALL, DETENT,SHIFT ROD .TRANSFER |
2 |
2110- |
|
B |
|
| 45 |
I8-94171 541-0 |
|
PIN, SPR,SHIFT ARM TO ROD |
2 |
2110- |
|
B |
D=4.2 L=25 |
| 35 |
I9-09571 414-0 |
|
GASKET, INDICATOR SWITCHJRANSFER |
2 |
2110- |
|
B |
ID=14.2 0D=20 |
| 200 |
I8-97239 011-0 |
|
SPRING, SHIFT HIGH-LOW |
|
2311- |
|
|
|
| 204 |
I8-98158 123-0 |
|
DRUM, SHIFT |
1 |
2110- |
|
B | |
|
| 208 |
I8-94460 357-0 |
|
RING, SNAP,SHIFT |
1 |
2110- |
|
B I |
ID=12 |
| 207 |
I8-98158 124-0 |
|
BUSHING, CONTROL SHAFT |
1 |
2110- |
|
B | |
|
| 43 |
I8-97234 231-0 |
|
ARM, SHIFT,4X2-4X4,TRANSFER |
1 |
2110- |
|
B |
|
