5-30 | 2-46 - AUTO TRANS SUPPORT AND PLANETARY GEAR
MUX
MU-X 2024
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 39 | I8-97506 807-0 | GUIDE, SPARE TIRE HANGER | 2311- | |||||
| 6 | I8-97808 623-0 | CLIP, ENG HOOD INSULATION | 7 | 2202- | AB | ID=6.2 L=11.4 | ||
| 9 | I8-98360 675-1 | INSULATION, DASH ENG ROOM | 1 | 2110- | AB | |||
| 1 | I8-98362 796-1 | INSULATION | 1 | 2110- | AB | |||
| 76 | I8-98385 869-0 | DEADENER, DASH ENG ROOM | 1 | 2110- | R | AB | (C) | |
| 6 | I8-97808 623-0 | CLIP, ENG HOOD INSULATION | 9 | 2110-2201 | AB | ID=6.2 L=11.4 | ||
| 133 | I8-97506 870-0 | HANGER, SPARE TIRE | 2311- | |||||
| 4 | I8-98393 612-2 | INSULATION, DASH PNL.INNER | 1 | 2110- | AB | RZ4E-TC ENG(RDZ) A/T 6 SPEED-AISIN(Y6A) GRADE LUXURY(RBC) | ||
| 39 | I8-97506 808-0 | GUIDE, SPARE TIRE HANGER | 2311- | |||||
| 76 | I8-98385 868-0 | DEADENER, DASH ENG ROOM | 1 | 2110- | L | AB | (B) | |
| 4 | I8-97507 214-1 | INSULATION, DASH PNL.INNER | 1 | 2110- | AB | 4JJ3 ENG(LNG) | ||
| 4 | I8-97507 214-1 | INSULATION, DASH PNL.INNER | 1 | 2110- | AB | RZ4E-TC ENG(RDZ) A/T 6 SPEED-AISIN(Y6A) GRADE CUSTOM(RBD) | ||
| 76 | I8-98487 040-1 | DEADENER, DASH ENG ROOM | 2 | 2110- | AB | (D) | ||
| 76 | I8-98385 867-0 | DEADENER, DASH ENG ROOM | 1 | 2110- | AB | (A) |
