8-03 | 8-03 - LAMP, REAR AND REAR SIDE
MUX
MU-X 2024
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 57 | I8-94279 043-A | WASHER, PL,LICENSE PLATE LAMP | 2 | 2110- | AB | D=7.8X7.8 L=18 NATURAL | ||
| 81 | I8-97684 585-0 | GASKET, STOP LAMP | 1 | 2110- | AB | |||
| 301 | I8-97684 351-0 | SOCKET ASM, | 1 | 2110- | AB | (B) | ||
| 287 | I8-97684 403-0 | LAMP UNIT, RR COMB | 1 | 2110- | AB | EXC. RR FOG LAMP<T79> (B) | ||
| 298 | I8-97515 122-0 | CAP, BREATH ER, RR COMB LAMP | 1 | 2110- | AB | (A) | ||
| 49 | I8-98386 269-1 | LAMP, LICENSE PLATE | 2 | 2110- | AB | |||
| 5 | I8-94372 897-0 | BULB, RR COMB LAMP | 1 | 2110- | AB | EXC. RR FOG LAMP<T79> 12V 16W | ||
| 310 | I8-97842 991-0 | LAMP ASM, RR COMB,BODY SIDE | 1 | 2311- | ||||
| 68 | I8-97494 804-0 | LAMP, LUGGAGE ROOM | 1 | 2110- | AB | |||
| 267 | I8-97678 928-0 | BULB, TURN SIGNAL | 2 | 2110- | AB | 12V 21W | ||
| 310 | I8-97842 990-0 | LAMP ASM, RR COMB,BODY SIDE | 1 | 2311- | ||||
| 311 | I8-97842 992-0 | LAMP ASM, RR COMB,GATE SIDE | 1 | 2311- | ||||
| 287 | I8-97871 553-0 | LAMP UNIT, RR COMB | 2311- | |||||
| 300 | I8-97839 184-0 | HOLDER, LAMP | 2 | 2203- | AB | (B) | ||
| 311 | I8-97842 993-0 | LAMP ASM, RR COMB,GATE SIDE | 1 | 2311- | ||||
| 301 | I8-97184 970-0 | SOCKET ASM, | 1 | 2110- | AB | EXC. RR FOG LAMP<T79> (A) | ||
| 88 | I0-91180 106-0 | NUT, STOP LAMP | 2 | 2110- | AB | M6 FLANGE | ||
| 298 | I8-97684 353-0 | CAP, BREATH ER, RR COMB LAMP | 4 | 2110- | AB | (B) | ||
| 287 | I8-97684 404-0 | LAMP UNIT, RR COMB | 1 | 2110- | AB | (B) | ||
| 3 | I8-97678 935-0 | GASKET, RR COMB LAMP | 2 | 2110- | AB | (B) | ||
| 3 | I8-97678 934-0 | GASKET, RR COMB LAMP | 1 | 2110- | AB | (A) | ||
| 166 | I0-91180 106-0 | NUT, BACKUP LAMP | 4 | 2110- | AB | M6 FLANGE | ||
| 302 | I8-98001 518-0 | FILTER, BREATH ER, RR COMB LAMP | 4 | 2110- | AB | |||
| 90 | I8-98381 335-0 | COVER, STOP LAMP | 1 | 2110- | AB | |||
| 189 | I8-97555 328-0 | BOLT, FIX | 4 | 2110- | AB | M 6X23.5 W/LK+PL WASHER | ||
| 1 | I8-98374 510-1 | LAMP ASM, RR COMB | 1 | 2110- | AB | |||
| 234 | I8-98251 882-0 | SOCKET ASM, | 2 | 2110- | AB | |||
| 287 | I8-97871 552-0 | LAMP UNIT, RR COMB | 2311- | |||||
| 51 | I8-97310 952-0 | BULB, LICENSE PLATE LAMP | 2 | 2110- | AB | 12V 5W | ||
| 300 | I8-97175 217-0 | HOLDER, LAMP | 2 | 2110- | AB | (A) | ||
| 1 | I8-98374 509-1 | LAMP ASM, RR COMB | 1 | 2110- | AB | EXC. RR FOG LAMP<T79> | ||
| 301 | I8-97684 352-0 | SOCKET ASM, | 1 | 2110- | AB | (B) | ||
| 5 | I8-94372 897-0 | BULB, RR COMB LAMP | 1 | 2110- | AB | 12V 16W | ||
| 75 | I8-98328 815-3 | LAMP ASM, STOP.HIGHMOUNTED | 1 | 2110- | AB | |||
| 298 | I8-97515 122-0 | CAP, BREATH ER, RR COMB LAMP | 1 | 2110- | AB | (A) | ||
| 9 | I8-98055 704-0 | NUT, LAMP,RR COMB | 6 | 2110- | AB | M6 FLANGE | ||
| 3 | I8-97678 933-0 | GASKET, RR COMB LAMP | 1 | 2110- | AB | (A) | ||
| 301 | I8-97184 970-0 | SOCKET ASM, | 1 | 2110- | AB | (A) | ||
| 59 | I8-98167 449-0 | SCREW, TAP.LICENSE LAMP BODY | 2 | 2110- | AB | M5X16 TAPPING |
