0-11 | 0-11A CYLINDER HEAD
MUX
MU-X 2025
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 244 | I9-08150 510-0 | PIN; HEAD GASKET | 1 | 2410- | B | OD=5 L=10 | ||
| 010 | I8-97538 175-0 | PLUG; GLOW | 4 | 2410- | B | EURO5 SPECIFICATION(NT5) BOSCH | ||
| 225 | I8-97945 022-0 | STUD; COVER | 2 | 2410- | B | M8X20 L=31 | ||
| 123 | I0-28050 820-0 | BOLT; COVER | 3 | 2410- | B | M8X20 FLANGE | ||
| 011 | I8-98209 370-0 | CONNECTOR; GLOW PLUG | 1 | 2410- | B | EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) | ||
| 265 | I8-98224 627-0 | PIN; CAM CARRIER SET | 4 | 2410- | A | |||
| 005 | I8-97944 905-1 | SEAT; VLV INSERT | 8 | 2410- | B | (D) EXHAUST OD=31.7 | ||
| 025 | I8-98287 944-0 | PLUG; CYL HD | 2 | 2410- | A | |||
| 004 | I8-94239 423-0 | GUIDE; VLV | 16 | 2410- | B | L=42 AFTER PRESS FITTING, MACHINE IT | ||
| 001 | I8-98480 820-0 | HEAD ASM; CYL | 1 | 2410- | B | EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) | ||
| 168 | I8-97548 046-0 | HANGER; ENG,FRT | 1 | 2410- | B | |||
| 091 | I8-98228 414-0 | PIPE; HTR | 1 | 2410- | B | |||
| 012 | I8-98239 364-0 | HANGER; ENG,RR | 1 | 2410- | B | |||
| 172 | I8-98250 484-0 | PLATE; BAFFLE,CYL HD | 1 | 2410- | B | |||
| 002 | I7-55189 855-0 | GASKET; CYL HD | 1 | 2410- | B | GRADE=B T=1.19 2-HOLE | ||
| 007 | I5-09600 013-0 | CUP; SEALING,CYL HEAD | 7 | 2410- | A | (E) OD=12.3 | ||
| 005 | I8-98301 296-0 | SEAT; VLV INSERT | 8 | 2410- | A | (B) EXHAUST ID=22 OD=26 | ||
| 263 | I0-28050 860-0 | BOLT; CYL HD | 1 | 2410- | B | (A) M8X60 FLANGE | ||
| 047 | I0-41010 625-0 | STUD; CYL HD | 1 | 2410- | A | M6X25 L=34 | ||
| 005 | I8-97944 904-1 | SEAT; VLV INSERT | 8 | 2410- | B | (C) INLET OD=34.5 | ||
| 014 | I8-98048 446-0 | STUD; EXH MANIF | 4 | 2410- | A | (C) M10X70 L=83 | ||
| 003 | I8-98201 019-0 | BOLT; CYL HD TO BLOCK | 18 | 2410- | B | (A) M11X114 W/WASHER | ||
| 263 | I0-28650 835-0 | BOLT; CYL HD | 3 | 2410- | B | (B) M8X35 FLANGE | ||
| 007 | I8-97233 429-0 | CUP; SEALING,CYL HEAD | 1 | 2410- | B | (D) OD=8 | ||
| 002 | I8-98346 417-0 | GASKET; CYL HD | 1 | 2410- | A | T=1.00 2-HOLE | ||
| 005 | I8-98301 295-0 | SEAT; VLV INSERT | 8 | 2410- | A | (A) INLET ID=24 OD=29 | ||
| 195 | I0-28050 670-0 | BOLT; CARRIER | 2 | 2410- | A | (B) M6X70 FLANGE | ||
| 007 | I5-11219 008-0 | CUP; SEALING,CYL HEAD | 3 | 2410- | A | (B) OD=18 | ||
| 003 | I8-98273 485-0 | BOLT; CYL HD TO BLOCK | 10 | 2410- | A | (C) M12X176.5 W/WASHER | ||
| 007 | I5-11219 008-0 | CUP; SEALING,CYL HEAD | 1 | 2410- | B | (B) OD=18 | ||
| 195 | I0-28050 650-0 | BOLT; CARRIER | 15 | 2410- | A | (A) M6X50 FLANGE | ||
| 007 | I5-11219 011-0 | CUP; SEALING,CYL HEAD | 2 | 2410- | B | (C) OD=14 | ||
| 002 | I8-98346 418-0 | GASKET; CYL HD | 1 | 2410- | A | T=1.05 3-HOLE | ||
| 003 | I0-28650 835-0 | BOLT; CYL HD TO BLOCK | 4 | 2410- | A | (B) M8X35 FLANGE | ||
| 002 | I7-55189 854-0 | GASKET; CYL HD | 1 | 2410- | B | GRADE=A T=1.14 1-HOLE | ||
| 221 | I1-09044 074-0 | BOLT; BRKT | 21 | 2410- | B | (B) M8X85 FLANGE | ||
| 002 | I8-98346 416-0 | GASKET; CYL HD | 1 | 2410- | A | T=0.95 1-HOLE | ||
| 013 | I0-58330 820-0 | BOLT; HANGER | 1 | 2410- | B | (A) M8X20 HEX SOCKET | ||
| 013 | I0-58330 830-0 | BOLT; HANGER | 1 | 2410- | B | (B) M8X30 HEX SOCKET | ||
| 262 | I8-98243 226-0 | COVER; CYL HEAD | 1 | 2410- | B | |||
| 224 | I0-91180 208-0 | NUT; COVER | 4 | 2410- | B | M8 FLANGE | ||
| 002 | I7-55189 856-0 | GASKET; CYL HD | 1 | 2410- | B | GRADE=C T=1.24 3-HOLE | ||
| 194 | I8-98243 890-1 | CARRIER; CAM SHAFT | 1 | 2410- | A | |||
| 013 | I0-28151 020-0 | BOLT; HANGER | 2 | 2410- | B | (C) M10X20 FLANGE | ||
| 001 | I8-97491 132-0 | HEAD ASM; CYL | 1 | 2410- | B | EURO5 SPECIFICATION(NT5) | ||
| 014 | I8-97379 383-0 | STUD; EXH MANIF | 1 | 2410- | A | (B) M10X33 L=48 | ||
| 011 | I8-98287 709-0 | CONNECTOR; GLOW PLUG | 1 | 2410- | A | EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) | ||
| 007 | I8-97333 120-0 | CUP; SEALING,CYL HEAD | 5 | 2410- | B | (A) OD=24 | ||
| 010 | I8-98332 041-0 | PLUG; GLOW | 4 | 2410- | A | EURO5 SPECIFICATION(NT5) BOSCH | ||
| 010 | I8-98259 502-0 | PLUG; GLOW | 4 | 2410- | A | EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) NGK | ||
| 183 | I8-98286 973-0 | DOWEL; CYL HEAD | 2 | 2410- | A | |||
| 230 | I8-97943 955-0 | GASKET; SLEEVE,INJECTOR | 4 | 2410- | B | |||
| 009 | I0-41010 830-0 | STUD; INL MANIF | 2 | 2410- | A | M8X30 L=41 | ||
| 001 | I8-98330 416-0 | HEAD ASM; CYL | 1 | 2410- | A | EUROO SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) | ||
| 221 | I0-28050 630-0 | BOLT; BRKT | 8 | 2410- | B | (A) M6X30 FLANGE | ||
| 001 | I8-97679 846-1 | HEAD ASM; CYL | 1 | 2410- | A | EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) | ||
| 198 | I8-98248 244-0 | GASKET; CAM CARRIER | 4 | 2410- | A | |||
| 010 | I8-98117 567-1 | PLUG; GLOW | 4 | 2410- | B | EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) NGK | ||
| 155 | I0-58330 610-0 | BOLT; BAFFLE PLATE | 8 | 2410- | B | M6X10 HEX SOCKET | ||
| 007 | I5-11219 008-0 | CUP; SEALING,CYL HEAD | 6 | 2410- | B | (B) OD=18 | ||
| 004 | I8-98250 248-0 | GUIDE; VLV | 16 | 2410- | A | L=42 AFTER PRESS FITTING, MACHINE IT | ||
| 039 | I8-97329 129-1 | DOWEL; CAP,CM/SHF | 26 | 2410- | B | |||
| 014 | I8-94397 286-0 | STUD; EXH MANIF | 2 | 2410- | A | (A) M10X60 L=75 | ||
| 221 | I0-28060 630-0 | BOLT; BRKT | 20 | 2410- | A | (C) M6X30 FLANGE |
