0-30 | 0-30A WATER PUMP AND CORROSION RESISTOR
MUX
MU-X 2025
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 063 | I0-28050 816-0 | BOLT; INL PIPE | 2 | 2410- | B | (A) M8X16 FLANGE | ||
| 002 | I7-55243 644-0 | PUMP ASM; WATER | 1 | 2410- | A | |||
| 040 | I0-91180 208-0 | NUT; WATER PUMP | 2 | 2410- 1 | AB | M8 FLANGE | ||
| 036 | I0-28050 850-0 | BOLT; WATER PUMP TO C/BL | 4 | 2410- | B | M8X50 FLANGE | ||
| 022 | I0-95690 226-0 | GASKET | 1 | 2410- 1 | B | ID=26.2 | ||
| 099 | I0-95690 338-0 | GASKET; WATER PIPE | 1 | 2410- | B | (A) | ||
| 042 | I0-41010 825-0 | STUD; WATER PUMP | 2 | 2410- | A | (A) M8X25 L=37 | ||
| 097 | I8-97555 136-0 | PIPE; WATER | 1 | 2410- | B | EURO2 SPECIFICATION(NT2) | ||
| 063 | I0-28050 880-0 | BOLT; INL PIPE | 1 | 2410- | B | (B) M8X80 FLANGE | ||
| 002 | I8-97312 147-4 | PUMP ASM; WATER | 1 | 2410- | B | |||
| 042 | I0-49140 822-0 | STUD; WATER PUMP | 2 | 2410- | B | (C) M8X22 L=40 | ||
| 003 | I7-55243 647-0 | GASKET; PUMP TO C/BL | 1 | 2410- | A | |||
| 042 | I8-97262 717-1 | STUD; WATER PUMP | 1 | 2410- | A | EUROO SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (B) M8X20,M8X45 L=73 | ||
| 036 | I0-28050 850-0 | BOLT; WATER PUMP TO C/BL | 5 | 2410- | A | EUROO SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) M8X50 FLANGE | ||
| 155 | I0-91180 208-0 | NUT; PIPE | 2 | 2410- 1 | B | M8 FLANGE | ||
| 063 | I0-28050 816-0 | BOLT; INL PIPE | 1 | 2410- | B | (A) M8X16 FLANGE | ||
| 099 | I8-98233 994-0 | GASKET; WATER PIPE | 1 | 2410- | B | (B) | ||
| 003 | I8-97312 156-0 | GASKET; PUMP TO C/BL | 1 | 2410- | B | |||
| 097 | I8-98480 910-0 | PIPE; WATER | 1 | 2410- | B | EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) | ||
| 036 | I0-28050 850-0 | BOLT; WATER PUMP TO C/BL | 6 | 2410- | A | EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) M8X50 FLANGE |
