| 540 |
I8-97679 746-1 |
|
PIPE; WATER |
1 |
2410- |
|
A |
EURO5 SPECIFICATION(NT5) (G) |
| 217 |
I0-28661 230-0 |
|
BOLT; BRKT |
3 |
2410- |
|
B |
(C) M12X30 FLANGE |
| 488 |
I8-97519 138-0 |
|
HOSE; RUBBER |
1 |
24í0- |
|
A |
EURO4 SPECIFICATION(NT4) COOLER W/FRESH AIR(C65) (F) |
| 320 |
I8-98189 923-0 |
|
BOLT; BRKT,TURBOCHARGER |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (D) M10X25 FLANGE |
| 426 |
I8-98332 270-0 |
|
BRACKET; VLV |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 032 |
I8-98247 223-3 |
|
PROTECTOR; HEAT,TURBOCHARGER |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 118 |
I8-98179 581-0 |
|
CLIP; WATER HOSE |
2 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) (A) ID=15.1 |
| 002 |
I8-98317 728-0 |
|
GASKET; TURBOCHARGER TO EXH MANIF |
1 |
2410- |
|
B |
|
| 101 |
I0-28050 820-0 |
|
BOLT; HEAT PROTECTOR |
2 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) M8X20 FLANGE |
| 001 |
I8-97821 624-0 |
|
TURBOCHARGER ASM |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4) |
| 032 |
I8-97679 754-1 |
|
PROTECTOR; HEAT,TURBOCHARGER |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) |
| 540 |
I8-97498 114-1 |
|
PIPE; WATER |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (C) |
| 016 |
I8-97555 005-1 |
|
ADAPTER; EXH PIPE |
1 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) (B) |
| 002 |
I8-98248 088-2 |
|
GASKET; TURBOCHARGER TO EXH MANIF |
1 |
2410- |
|
A |
|
| 528 |
I0-91180 106-0 |
|
NUT; VLV |
2 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) M6 FLANGE |
| 101 |
I0-28050 820-0 |
|
BOLT; HEAT PROTECTOR |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) M8X20 FLANGE |
| 162 |
I0-28060 825-0 |
|
BOLT; ADAPTER |
2 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) M8X25 FLANGE |
| 320 |
I0-28651 030-0 |
|
BOLT; BRKT,TURBOCHARGER |
1 |
2410- |
|
B |
(B) M10X30 FLANGE |
| 380 |
I8-97679 744-0 |
|
HOSE; RUBBER,PIPE TO PIPE |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (C) |
| 309 |
I0-28050 835-0 |
|
BOLT; TURBOCHARGER |
1 |
2410- |
|
B |
EURO4 SPECIFICATION(NT4) (B) M8X35 FLANGE |
| 001 |
I8-97652 435-0 |
|
TURBOCHARGER ASM |
1 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 539 |
I8-97510 812-0 |
|
SENSOR; TURBOCHARGER |
1 |
2410- |
|
B |
EURO5 SPECIFICATION(NT5) (B) |
| 540 |
I8-98247 211-2 |
|
PIPE; WATER |
1 |
2410- |
|
A |
M/T MVL 6 SPEED 6Y(Y6P) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (A) |
| 231 |
I8-98332 238-0 |
|
HOSE; RUBBER,TURBOCHARGER OUT |
1 |
2410- |
|
A |
|
| 217 |
I0-28151 020-0 |
|
BOLT; BRKT |
2 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B) M10X20 FLANGE |
| 066 |
I0-44011 025-0 |
|
STUD; EXH PIPE |
2 |
2410- 1 |
|
B |
M10X25 L=40 |
| 459 |
I8-98487 362-0 |
|
HOSE; WATER |
1 |
2410- |
|
A |
EUROO SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (A) |
| 485 |
I8-98480 911-0 |
|
PIPE; WATER EGR |
1 |
24í0- 1 |
|
B |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) |
| 317 |
I0-28151 025-0 |
|
BOLT; EXH PIPE |
2 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) M10X25 FLANGE |
| 468 |
I8-97220 552-2 |
|
STUD; HEAT PROTECTOR |
1 |
24í0- |
|
A |
EURO5 SPECIFICATION(NT5) M8X11,M8X25 L=45 |
| 459 |
I8-98368 055-0 |
|
HOSE; WATER |
1 |
2410- |
|
A |
EURO5 SPECIFICATION(NT5) (C) |
| 458 |
I8-98332 239-0 |
|
PIPE; WATER,TURBOCHARGER |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (C) |
| 309 |
I8-98173 443-0 |
|
BOLT; TURBOCHARGER |
2 |
2410- |
|
B |
(A) |
| 320 |
I0-28051 030-0 |
|
BOLT; BRKT,TURBOCHARGER |
2 |
2410- |
|
B |
(A) M10X30 FLANGE |
| 119 |
I8-98332 237-0 |
|
HOSE; WATER,TURBOCHARGER |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (D) |
| 320 |
I8-98189 923-0 |
|
BOLT; BRKT,TURBOCHARGER |
1 |
2410- |
|
B |
(D) M10X25 FLANGE |
| 101 |
I0-28050 812-0 |
|
BOLT; HEAT PROTECTOR |
3 |
2410- |
|
B |
M8X12 FLANGE |
| 231 |
I8-98480 908-1 |
|
HOSE; RUBBER,TURBOCHARGER OUT |
1 |
2410- |
|
B |
|
| 118 |
I8-98127 648-0 |
|
CLIP; WATER HOSE |
4 |
2410- |
|
B |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (D) ID=20 |
| 459 |
I8-97650 497-0 |
|
HOSE; WATER |
1 |
2410- |
|
B |
EURO5 SPECIFICATION(NT5) (B) |
| 488 |
I8-98248 222-2 |
|
HOSE; RUBBER |
1 |
24í0- |
|
A |
M/T MVL 6 SPEED 6Y(Y6P) COOLER W/FRESH AIR(C65) EUROO SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (E) |
| 117 |
I8-98299 210-0 |
|
GASKET; WATER PIPE |
1 |
2410- 1 |
|
A |
|
| 527 |
I8-98317 711-1 |
|
BRACKET; TURBOCHARGER |
1 |
24í0- |
|
B |
(A) |
| 320 |
I0-28151 020-0 |
|
BOLT; BRKT,TURBOCHARGER |
2 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (E) M10X20 FLANGE |
| 539 |
I8-97510 811-0 |
|
SENSOR; TURBOCHARGER |
1 |
2410- |
|
B |
EURO5 SPECIFICATION(NT5) (A) |
| 021 |
I0-28050 825-0 |
|
BOLT; PIPE |
2 |
2410- |
|
A |
A/T 6 SPEED AISIN(Y6A) EUROO SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (D) M8X25 FLANGE |
| 488 |
I8-98383 325-1 |
|
HOSE; RUBBER |
1 |
24í0- |
|
A |
EURO4 SPECIFICATION(NT4) (G) |
| 122 |
I0-91180 108-0 |
|
NUT; ADAPTER |
2 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) M8 FLANGE |
| 021 |
I0-28050 840-0 |
|
BOLT; PIPE |
1 |
2410- |
|
B |
(A) M8X40 FLANGE |
| 021 |
I0-28050 820-0 |
|
BOLT; PIPE |
2 |
2410- |
|
A |
EURO5 SPECIFICATION(NT5) (F) M8X20 FLANGE |
| 001 |
I8-97678 798-1 |
|
TURBOCHARGER ASM |
1 |
2410- |
|
A |
EURO5 SPECIFICATION(NT5) |
| 380 |
I8-97498 118-0 |
|
HOSE; RUBBER,PIPE TO PIPE |
1 |
2410- |
|
A |
A/T 6 SPEED AISIN(Y6A) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (B) |
| 217 |
I0-28050 845-0 |
|
BOLT; BRKT |
2 |
2410- |
|
B |
EURO5 SPECIFICATION(NT5) (G) M8X45 FLANGE |
| 488 |
I8-97519 138-0 |
|
HOSE; RUBBER |
1 |
24í0- |
|
A |
EUROO SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) A/T 6 SPEED AISIN(Y6A) COOLER W/FRESH AIR(C65) (F) |
| 217 |
I0-28050 820-0 |
|
BOLT; BRKT |
1 |
2410- |
|
B |
EURO5 SPECIFICATION(NT5) (E) M8X20 FLANGE |
| 380 |
I8-97498 117-0 |
|
HOSE; RUBBER,PIPE TO PIPE |
1 |
2410- |
|
A |
M/T MVL 6 SPEED 6Y(Y6P) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (A) |
| 214 |
I8-98317 730-0 |
|
BAND; "V",TURBOCHARGER TO EXH PIPE |
1 |
2410- |
|
B |
|
| 118 |
I8-97944 127-0 |
|
CLIP; WATER HOSE |
2 |
2410- |
|
A |
M/T MVL 6 SPEED 6Y(Y6P) EURO4 SPECIFICATION(NT4) (B) ID=20.8 |
| 011 |
I8-97309 942-0 |
|
NUT; TURBOCHARGER |
2 |
2410- |
|
B |
M10 FLANGE |
| 021 |
I0-28050 816-0 |
|
BOLT; PIPE |
1 |
2410- |
|
B |
(B) M8X16 FLANGE |
| 014 |
I0-41010 855-0 |
|
STUD; TURBOCHARGER TO EXH PIPE |
2 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) M8X55 L=67 |
| 011 |
I8-97309 942-0 |
|
NUT; TURBOCHARGER |
4 |
2410- |
|
A |
M10 FLANGE |
| 032 |
I8-98480 939-1 |
|
PROTECTOR; HEAT,TURBOCHARGER |
1 |
2410- |
|
B |
|
| 021 |
I0-28050 835-0 |
|
BOLT; PIPE |
2 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4) (E) M8X35 FLANGE |
| 001 |
I8-98480 819-1 |
|
TURBOCHARGER ASM |
1 |
2410- |
|
B |
|
| 526 |
I8-98299 2í0-0 |
|
GASKET; PLATE |
1 |
24í0- 1 |
|
B |
|
| 527 |
I8-98248 089-2 |
|
BRACKET; TURBOCHARGER |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (C) |
| 540 |
I8-97826 471-1 |
|
PIPE; WATER |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4) (E) |
| 458 |
I8-98480 909-1 |
|
PIPE; WATER,TURBOCHARGER |
1 |
2410- |
|
B |
(B) |
| 217 |
I0-28050 820-0 |
|
BOLT; BRKT |
5 |
2410- |
|
B |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (E) M8X20 FLANGE |
| 013 |
I0-44011 025-0 |
|
STUD; EXH PIPE |
2 |
2410- |
|
A |
M10X25 L=40 |
| 217 |
I0-28060 825-0 |
|
BOLT; BRKT |
1 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) (F) M8X25 FLANGE |
| 118 |
I8-98179 581-0 |
|
CLIP; WATER HOSE |
4 |
2410- |
|
A |
(A) ID=15.1 |
| 488 |
I8-98383 326-0 |
|
HOSE; RUBBER |
1 |
24í0- |
|
A |
EURO5 SPECIFICATION(NT5) (H) |
| 540 |
I8-97498 116-0 |
|
PIPE; WATER |
1 |
2410- |
|
A |
A/T 6 SPEED AISIN(Y6A) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (D) |
| 021 |
I0-28050 816-0 |
|
BOLT; PIPE |
2 |
2410- |
|
A |
M/T MVL 6 SPEED 6Y(Y6P) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (B) M8X16 FLANGE |
| 012 |
I8-97378 063-0 |
|
STUD; TURBOCHARGER |
4 |
2410- |
|
A |
M10X28.5 L=41.5 |
| 191 |
I0-91180 108-0 |
|
NUT; HEAT PROTECTOR |
1 |
2410- |
|
A |
M8 FLANGE |
| 380 |
I8-97679 742-0 |
|
HOSE; RUBBER,PIPE TO PIPE |
1 |
2410- |
|
A |
M/T MVL 6 SPEED 6Y(Y6P) EURO4 SPECIFICATION(NT4) (D) |
| 118 |
I8-97944 127-0 |
|
CLIP; WATER HOSE |
4 |
2410- |
|
A |
(B) ID=20.8 |
| 540 |
I8-97498 114-1 |
|
PIPE; WATER |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) A/T 6 SPEED AISIN(Y6A) (C) |
| 217 |
I0-28661 235-0 |
|
BOLT; BRKT |
2 |
2410- |
|
B |
(D) M12X35 FLANGE |
| 116 |
I0-58330 620-0 |
|
BOLT; WATER PIPE |
2 |
2410- 1 |
|
A |
M6X20 HEX SOCKET |
| 488 |
I8-97555 137-0 |
|
HOSE; RUBBER |
1 |
24í0- |
|
B |
EURO2 SPECIFICATION(NT2) (D) |
| 217 |
I0-28050 830-0 |
|
BOLT; BRKT |
2 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (A) M8X30 FLANGE |
| 012 |
I8-97378 063-0 |
|
STUD; TURBOCHARGER |
2 |
2410- |
|
B |
M10X28.5 L=41.5 |
| 119 |
I8-98298 388-0 |
|
HOSE; WATER,TURBOCHARGER |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (C) |
| 021 |
I0-28050 660-0 |
|
BOLT; PIPE |
2 |
2410- |
|
B |
(C) M6X60 FLANGE |
| 119 |
I8-98239 061-0 |
|
HOSE; WATER,TURBOCHARGER |
1 |
2410- |
|
B |
(A) L=163.5 |
| 540 |
I8-97498 115-0 |
|
PIPE; WATER |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (B) |
| 118 |
I8-97944 127-0 |
|
CLIP; WATER HOSE |
2 |
2410- |
|
A |
COOLER W/FRESH AIR(C65) (B) ID=20.8 |
| 016 |
I8-97555 004-0 |
|
ADAPTER; EXH PIPE |
1 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) (A) |
| 488 |
I8-98480 913-0 |
|
HOSE; RUBBER |
1 |
24í0- |
|
B |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (B) |
| 101 |
I0-28050 820-0 |
|
BOLT; HEAT PROTECTOR |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4) M8X20 FLANGE |
| 119 |
I8-98480 907-1 |
|
HOSE; WATER,TURBOCHARGER |
1 |
2410- |
|
B |
(B) |
| 251 |
I8-97555 138-0 |
|
BRACKET; ADAPTER |
1 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) |
| 529 |
I8-98190 325-0 |
|
INSULATOR; HOSE |
1 |
2410- |
|
B |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) |
| 118 |
I8-98179 581-0 |
|
CLIP; WATER HOSE |
6 |
2410- |
|
B |
(A) ID=15.1 |
| 384 |
I8-97263 052-0 |
|
GASKET; EXH PIPE |
1 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2) ID=65 |
| 527 |
I8-98480 937-1 |
|
BRACKET; TURBOCHARGER |
1 |
24í0- |
|
B |
(B) |
| 458 |
I8-98298 390-1 |
|
PIPE; WATER,TURBOCHARGER |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (A) |
| 530 |
I8-97101 337-0 |
|
CLIP; INSULATOR |
2 |
2410- |
|
B |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) |
| 488 |
I8-98317 698-0 |
|
HOSE; RUBBER |
1 |
24í0- |
|
B |
(C) |
| 118 |
I8-98202 540-0 |
|
CLIP; WATER HOSE |
2 |
2410- |
|
B |
(C) ID=26.2 |
| 540 |
I8-97679 745-0 |
|
PIPE; WATER |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (F) |
| 005 |
I0-28751 025-0 |
|
BOLT; BRKT TO EXH PIPE |
5 |
2410- |
|
A |
M10X25 FLANGE |
| 320 |
I0-28050 880-0 |
|
BOLT; BRKT,TURBOCHARGER |
2 |
2410- |
|
B |
(C) M8X80 FLANGE |
