| 137 |
I8-97495 800-1 |
|
PIPE ASM; LEAK OFF |
1 |
2410- |
|
B |
(D) |
| 068 |
I8-97879 634-0 |
|
CLIP; INJ PIPE |
2 |
2410- |
|
B |
(A) ID=7 & 7 L=22 |
| 219 |
I1-09623 541-0 |
|
GASKET |
1 |
2410- 1 |
|
B |
ID=49.7 |
| 210 |
I8-98247 225-1 |
|
PIPE; INJ,C/R |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 175 |
I8-98271 921-0 |
|
GASKET; EYE BOLT,OUTLET,FUEL FEED PUMP |
2 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) ID=10.2 |
| 018 |
I8-97536 773-0 |
|
PIPE; INJ NO.3 |
1 |
2410- |
|
B |
EURO5 SPECIFICATION(NT5) |
| 211 |
I8-98399 620-0 |
|
RAIL ASM; COMMON |
1 |
2410- 1 |
|
B |
|
| 120 |
I8-98248 157-2 |
|
BRACKET; IN |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (A) |
| 009 |
I0-41010 630-0 |
|
STUD; CLIP |
2 |
2410- |
|
B |
M6X30 L=38 |
| 169 |
I0-91180 208-0 |
|
NUT; BRKT |
4 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) M8 FLANGE |
| 313 |
I8-98228 637-0 |
|
BOLT; BRKT,INJ NOZZLE |
4 |
2410- |
|
B |
M8X85 W/WASHER |
| 110 |
I0-91180 106-0 |
|
NUT; CLIP |
3 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) M6 FLANGE |
| 216 |
I8-98220 020-0 |
|
BOLT; EYE |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (C) |
| 029 |
I8-97944 126-0 |
|
CLIP; HOSE |
10 |
2410- |
|
B |
(A) ID=10.5 |
| 216 |
I8-97499 383-0 |
|
BOLT; EYE |
1 |
2410- |
|
B |
(B) |
| 349 |
I8-98247 356-0 |
|
RAIL; COMMON |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 066 |
I8-98362 076-1 |
|
GASKET; INJ NOZZLE |
4 |
2410- |
|
B |
ID=9 OD=16 |
| 128 |
I8-98247 227-3 |
|
PIPE ASM; INJ |
2 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (A) |
| 408 |
I8-98247 350-3 |
|
PUMP ASM; FUEL,SUPPLY |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 424 |
I8-98283 485-0 |
|
OVERHAUL KIT; SUPPLY PUMP |
1 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 030 |
I8-97512 198-0 |
|
HOSE; RUBBER,FUEL LEAK |
1 |
2410- |
|
B |
(D) |
| 334 |
I0-91180 108-0 |
|
NUT; FLANGE |
2 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) M8 FLANGE |
| 137 |
I8-98211 776-0 |
|
PIPE ASM; LEAK OFF |
1 |
2410- |
|
B |
(A) |
| 066 |
I8-97679 867-0 |
|
GASKET; INJ NOZZLE |
4 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) ID=9 OD=16 |
| 452 |
I0-91180 208-0 |
|
NUT; SUPPLY PUMP |
2 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) M8 FLANGE |
| 019 |
I8-98480 944-0 |
|
PIPE; INJ NO.4 |
1 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) |
| 068 |
I8-97879 635-0 |
|
CLIP; INJ PIPE |
2 |
2410- |
|
B |
(B) ID=7 & 7 L=22 |
| 030 |
I8-97679 782-0 |
|
HOSE; RUBBER,FUEL LEAK |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (J) |
| 450 |
I8-97679 752-0 |
|
ADAPTER; SUPPLY PUMP |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) |
| 450 |
I8-98248 086-4 |
|
ADAPTER; SUPPLY PUMP |
1 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 029 |
I8-97944 126-0 |
|
CLIP; HOSE |
10 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (A) ID=10.5 |
| 110 |
I0-91180 106-0 |
|
NUT; CLIP |
2 |
2410- |
|
B |
M6 FLANGE |
| 289 |
I8-98138 695-0 |
|
LIMITER; FUEL PRESS |
1 |
2410- 1 |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 205 |
I8-98023 581-0 |
|
SENSOR; FUEL TEMP |
1 |
2410- 1 |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 283 |
I0-28051 040-0 |
|
BOLT; COMMON RAIL |
2 |
2410- 1 |
|
B |
M10X40 FLANGE |
| 210 |
I8-97821 035-0 |
|
PIPE; INJ,C/R |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) |
| 210 |
I8-98481 098-0 |
|
PIPE; INJ,C/R |
1 |
2410- |
|
B |
|
| 030 |
I8-97679 771-0 |
|
HOSE; RUBBER,FUEL LEAK |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (I) |
| 324 |
I8-98248 159-0 |
|
PIPE; FUEL RETURN |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (A) |
| 030 |
I8-98250 822-0 |
|
HOSE; RUBBER,FUEL LEAK |
3 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (E) |
| 030 |
I8-98480 950-0 |
|
HOSE; RUBBER,FUEL LEAK |
1 |
2410- |
|
B |
(C) |
| 068 |
I8-98148 996-2 |
|
CLIP; INJ PIPE |
6 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (C) ID=11 & 11 L=19 |
| 175 |
I8-98271 921-0 |
|
GASKET; EYE BOLT,OUTLET,FUEL FEED PUMP |
2 |
2410- |
|
B |
ID=10.2 |
| 068 |
I8-98148 996-2 |
|
CLIP; INJ PIPE |
4 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (D) ID=11 & 11 L=19 |
| 120 |
I8-97821 034-0 |
|
BRACKET; IN |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (C) |
| 029 |
I8-97525 800-0 |
|
CLIP; HOSE |
2 |
2410- |
|
B |
(B) ID=11 |
| 128 |
I8-97679 756-0 |
|
PIPE ASM; INJ |
2 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (C) |
| 122 |
I8-97315 286-0 |
|
CLIP; LEAK OFF PIPE |
4 |
2410- 1 |
|
AB |
|
| 349 |
I8-97664 860-1 |
|
RAIL; COMMON |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) |
| 030 |
I8-98053 693-0 |
|
HOSE; RUBBER,FUEL LEAK |
3 |
2410- |
|
B |
(A) L=96 |
| 199 |
I8-97602 218-0 |
|
GASKET; EYE BOLT |
2 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 016 |
I8-98480 941-0 |
|
PIPE; INJ NO.1 |
1 |
2410- |
|
B |
|
| 029 |
I8-97944 126-0 |
|
CLIP; HOSE |
8 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (A) ID=10.5 |
| 120 |
I8-98315 357-1 |
|
BRACKET; IN |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (B) |
| 059 |
I8-98092 539-0 |
|
CLAMP; NOZZLE HOLDER |
4 |
2410- |
|
B |
|
| 148 |
I1-09623 541-0 |
|
RING |
1 |
2410- 1 |
|
A |
ID=49.7 |
| 031 |
I8-98399 618-0 |
|
NOZZLE ASM; INJ |
4 |
2410- |
|
B |
|
| 094 |
I8-98248 087-1 |
|
BRACKET; INJ NOZZLE |
4 |
2410- |
|
A |
|
| 166 |
I9-09566 111-0 |
|
GASKET; FUEL INJECTOR |
4 |
2410- 1 |
|
B |
ID=11 OD=14.8 |
| 452 |
I0-91180 208-0 |
|
NUT; SUPPLY PUMP |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) M8 FLANGE |
| 137 |
I8-98481 100-0 |
|
PIPE ASM; LEAK OFF |
1 |
2410- |
|
B |
(C) |
| 066 |
I8-98181 540-0 |
|
GASKET; INJ NOZZLE |
4 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) ID=7.1 |
| 382 |
I8-98161 995-0 |
|
KEY; DRIVE SHAFT |
1 |
2410- 1 |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 017 |
I8-98480 942-0 |
|
PIPE; INJ NO.2 |
1 |
2410- |
|
B |
|
| 031 |
I8-98247 354-0 |
|
NOZZLE ASM; INJ |
4 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 334 |
I0-91180 208-0 |
|
NUT; FLANGE |
2 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) M8 FLANGE |
| 451 |
I0-28050 825-0 |
|
BOLT; SUPPLY PUMP |
5 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) M8X25 FLANGE |
| 030 |
I8-98250 851-0 |
|
HOSE; RUBBER,FUEL LEAK |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (F) |
| 408 |
I8-97664 859-0 |
|
PUMP ASM; FUEL,SUPPLY |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) |
| 018 |
I8-98480 943-0 |
|
PIPE; INJ NO.3 |
1 |
2410- |
|
B |
EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) |
| 451 |
I0-28050 825-0 |
|
BOLT; SUPPLY PUMP |
3 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) M8X25 FLANGE |
| 031 |
I8-97664 857-0 |
|
NOZZLE ASM; INJ |
4 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) |
| 408 |
I8-98399 619-0 |
|
PUMP ASM; FUEL,SUPPLY |
1 |
2410- |
|
B |
|
| 030 |
I8-97679 770-0 |
|
HOSE; RUBBER,FUEL LEAK |
3 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (H) |
| 110 |
I0-91180 106-0 |
|
NUT; CLIP |
2 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) M6 FLANGE |
| 128 |
I8-97679 757-0 |
|
PIPE ASM; INJ |
2 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (D) |
| 388 |
I8-98356 094-0 |
|
STUD; RAIL |
2 |
2410- 1 |
|
A |
M8X72.5 L=100 |
| 063 |
I8-98211 775-0 |
|
PIPE; FUEL,NOZZLE LEAK OFF |
3 |
2410- |
|
A |
(A) |
| 029 |
I8-97329 627-0 |
|
CLIP; HOSE |
2 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (C) ID=13 |
| 030 |
I8-98480 949-0 |
|
HOSE; RUBBER,FUEL LEAK |
1 |
2410- |
|
B |
(B) |
| 453 |
I8-98302 470-0 |
|
WASHER; INJ NOZZLE |
4 |
2410- |
|
A |
|
| 030 |
I0-01558 300-0 |
|
HOSE; RUBBER,FUEL LEAK |
1 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (G) L=160 SERVICED BY L=3000 |
| 199 |
I8-98279 834-0 |
|
GASKET; EYE BOLT |
2 |
2410- |
|
B |
|
| 324 |
I8-97679 763-0 |
|
PIPE; FUEL RETURN |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (B) |
| 313 |
I8-98247 614-1 |
|
BOLT; BRKT,INJ NOZZLE |
4 |
2410- |
|
A |
M6X25 FLANGE |
| 347 |
I8-98165 035-0 |
|
PIN |
4 |
2410- 1 |
|
B |
|
| 324 |
I8-97821 033-0 |
|
PIPE; FUEL RETURN |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (C) |
| 285 |
I8-98356 094-0 |
|
STUD; BRKT |
4 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) M8X72.5 L=100 |
| 072 |
I8-98287 955-2 |
|
BOLT; BRKT TO INJ PUMP |
4 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) M8X80 FLANGE |
| 216 |
I8-97499 107-0 |
|
BOLT; EYE |
1 |
2410- |
|
B |
(A) |
| 128 |
I8-98247 229-3 |
|
PIPE ASM; INJ |
2 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) (B) |
| 019 |
I8-97536 774-0 |
|
PIPE; INJ NO.4 |
1 |
2410- |
|
B |
EURO5 SPECIFICATION(NT5) |
| 063 |
I8-98211 776-0 |
|
PIPE; FUEL,NOZZLE LEAK OFF |
1 |
2410- |
|
A |
(B) |
| 290 |
I8-98178 706-0 |
|
SENSOR; PRESS |
1 |
2410- 1 |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 445 |
I8-98209 778-0 |
|
SCREW; FILTER,INLET |
1 |
2410- |
|
A |
EUR00 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) |
| 169 |
I0-91180 108-0 |
|
NUT; BRKT |
1 |
2410- |
|
A |
EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2) M8 FLANGE |
| 137 |
I8-98211 775-0 |
|
PIPE ASM; LEAK OFF |
3 |
2410- |
|
B |
(B) |
| 216 |
I8-97499 107-0 |
|
BOLT; EYE |
1 |
2410- |
|
A |
EURO4 SPECIFICATION(NT4),EURO5 SPECIFICATION(NT5) (A) |
