| 034 |
I8-98125 360-1 |
|
BOLT; DOVETAIL TO BACK DOOR |
4 |
2410- |
|
AB |
M6X16 W/LK&PL WASHER |
| 104 |
I8-97935 320-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR MERCURY SILVER MET(568) POWER TAIL GATE<E61> (C) SILVER |
| 168 |
I8-97935 303-0 |
|
SENSOR; TAIL GATE |
2 |
2410- |
|
AB |
BODY COLOR ONYX BLACK MICA(569) POWER TAIL GATE<E61> (B) BLACK |
| 104 |
I8-98378 093-0 |
|
BRACKET |
1 |
2410- |
|
AB |
EXC. POWER TAIL GATE<E61> (B) |
| 104 |
I8-97935 321-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR RED SPINEL MICA(564) POWER TAIL GATE<E61> (C) RED |
| 168 |
I8-97935 305-0 |
|
SENSOR; TAIL GATE |
2 |
2410- |
|
AB |
BODY COLOR RED SPINEL MICA(564) POWER TAIL GATE<E61> (B) RED |
| 169 |
I8-97539 336-0 |
|
CLIP; TAIL GATE |
8 |
2410- |
|
AB |
POWER TAIL GATE<E61> |
| 137 |
I8-97842 413-0 |
|
CUSHION; BACK DOOR |
2 |
2410- |
|
AB |
POWER TAIL GATE<E61> |
| 036 |
I8-98049 357-0 |
|
BOLT; LINK |
4 |
2410- |
|
AB |
M6X16 FLANGE |
| 104 |
I7-47501 700-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR BIARRITZ BLUE MET(587) POWER TAIL GATE<E61> (C) BLUE |
| 168 |
I8-97935 300-0 |
|
SENSOR; TAIL GATE |
2 |
2410- |
|
AB |
BODY COLOR SPLASH WHITE(527) POWER TAIL GATE<E61> (B) WHITE |
| 104 |
I8-97935 308-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR SPLASH WHITE(527) POWER TAIL GATE<E61> (C) WHITE |
| 165 |
I8-97539 355-0 |
|
TAPE; TAIL GATE |
2 |
2410- |
|
AB |
|
| 104 |
I7-47501 697-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR EIGER GRAY MET(400) POWER TAIL GATE<E61> (C) GRAY |
| 162 |
I0-28050 625-0 |
|
SCREW; SWITCH, BACK DOOR LK |
2 |
2410- |
|
AB |
M6X25 FLANGE |
| 104 |
I8-97935 319-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR ONYX BLACK MICA(569) POWER TAIL GATE<E61> (C) BLACK |
| 168 |
I7-47501 695-0 |
|
SENSOR; TAIL GATE |
2 |
2410- |
|
AB |
BODY COLOR EIGER GRAY MET(400) POWER TAIL GATE<E61> (B) GRAY |
| 104 |
I8-97512 084-0 |
|
BRACKET |
1 |
2410- |
|
AB |
POWER TAIL GATE<E61> (A) |
| 104 |
I8-97512 085-0 |
|
BRACKET |
1 |
2410- |
|
AB |
POWER TAIL GATE<E61> (A) |
| 168 |
I8-97842 385-0 |
|
SENSOR; TAIL GATE |
1 |
2410- |
|
AB |
POWER TAIL GATE<E61> (A) |
| 168 |
I8-97842 384-0 |
|
SENSOR; TAIL GATE |
1 |
2410- |
|
AB |
POWER TAIL GATE<E61> (A) |
| 104 |
I7-47501 699-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR EIGER GRAY MET(400) POWER TAIL GATE<E61> (C) GRAY |
| 170 |
I8-97685 528-0 |
|
CLIP; COVER |
2 |
2410- |
|
AB |
|
| 166 |
I8-98483 495-3 |
|
COVER; HINGE |
1 |
2410- |
|
AB |
|
| 005 |
I8-98337 563-1 |
|
LOCK; BACK DOOR |
1 |
2410- |
|
AB |
POWER TAIL GATE<E61> |
| 104 |
I8-98378 094-0 |
|
BRACKET |
1 |
2410- |
|
AB |
EXC. POWER TAIL GATE<E61> (B) |
| 168 |
I8-97935 304-0 |
|
SENSOR; TAIL GATE |
2 |
2410- |
|
AB |
BODY COLOR MERCURY SILVER MET(568) POWER TAIL GATE<E61> (B) SILVER |
| 001 |
I8-97539 082-0 |
|
HANDLE; OUTSIDE,BACK DOOR |
1 |
2410- |
|
AB |
|
| 104 |
I8-97935 318-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR DOLOMITE WHITE PEARL(575) POWER TAIL GATE<E61> (C) WHITE |
| 167 |
I8-98372 406-1 |
|
ACTUATOR; TAIL GATE |
2 |
2410- |
|
AB |
POWER TAIL GATE<E61> |
| 140 |
I7-55197 762-0 |
|
STAY; TAIL GATE |
1 |
2410- |
|
AB |
EXC. POWER TAIL GATE<E61> |
| 104 |
I8-97935 312-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR MERCURY SILVER MET(568) POWER TAIL GATE<E61> (C) SILVER |
| 161 |
I8-97498 300-0 |
|
SWITCH; BACK DOOR LK |
1 |
2410- |
|
AB |
PASSIVE ENTRY AND START SYSTEM<AP3>,PASSIVE ENTRY & START SYSTEM W/REMOTE ENG<8SR> |
| 157 |
I8-98394 786-0 |
|
ANTENNA; DOOR LOCK |
1 |
2410- |
|
AB |
PASSIVE ENTRY AND START SYSTEM<AP3>,PASSIVE ENTRY & START SYSTEM W/REMOTE ENG<8SR>,PASSIVE ENTRY W/PUSH START<8WY> |
| 104 |
I8-97935 310-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR DOLOMITE WHITE PEARL(575) POWER TAIL GATE<E61> (C) WHITE |
| 161 |
I8-97498 299-0 |
|
SWITCH; BACK DOOR LK |
1 |
2410- |
|
AB |
REMOTE CONT DOOR LOCK<AP5>,PASSIVE ENTRY W/PUSH START<8WY> |
| 010 |
I8-97687 080-0 |
|
BOLT; LOCK |
3 |
2410- |
|
AB |
EXC. POWER TAIL GATE<E61> |
| 104 |
I8-97935 309-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR OBSIDIAN GRAY MICA(554) POWER TAIL GATE<E61> (C) DARK GRAY |
| 104 |
I8-97935 313-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR RED SPINEL MICA(564) POWER TAIL GATE<E61> (C) RED |
| 158 |
I8-97372 006-0 |
|
FASTENER; DOOR LOCK |
2 |
2410- |
|
AB |
EXC. REMOTE CONT DOOR LOCK<AP5> |
| 168 |
I8-97935 301-0 |
|
SENSOR; TAIL GATE |
2 |
2410- |
|
AB |
BODY COLOR OBSIDIAN GRAY MICA(554) POWER TAIL GATE<E61> (B) DARK GRAY |
| 168 |
I7-47501 696-0 |
|
SENSOR; TAIL GATE |
2 |
2410- |
|
AB |
BODY COLOR BIARRITZ BLUE MET(587) POWER TAIL GATE<E61> (B) BLUE |
| 104 |
I7-47501 698-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR BIARRITZ BLUE MET(587) POWER TAIL GATE<E61> (C) BLUE |
| 140 |
I7-55197 764-0 |
|
STAY; TAIL GATE |
1 |
2410- |
|
AB |
EXC. POWER TAIL GATE<E61> |
| 005 |
I8-98337 562-1 |
|
LOCK; BACK DOOR |
1 |
2410- |
|
AB |
EXC. POWER TAIL GATE<E61> |
| 103 |
I0-91180 106-0 |
|
NUT |
2 |
2410- |
|
AB |
POWER TAIL GATE<E61> (A) M6 FLANGE |
| 168 |
I8-97935 302-0 |
|
SENSOR; TAIL GATE |
2 |
2410- |
|
AB |
BODY COLOR DOLOMITE WHITE PEARL(575) POWER TAIL GATE<E61> (B) WHITE |
| 104 |
I8-97935 311-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR ONYX BLACK MICA(569) POWER TAIL GATE<E61> (C) BLACK |
| 104 |
I8-97935 317-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR OBSIDIAN GRAY MICA(554) POWER TAIL GATE<E61> (C) DARK GRAY |
| 066 |
I0-91614 708-0 |
|
WASHER; PL,BACK DOOR |
4 |
2410- |
|
AB |
ID=8.4 OD=22 T=2 |
| 104 |
I8-97935 316-1 |
|
BRACKET |
1 |
2410- |
|
AB |
BODY COLOR SPLASH WHITE(527) POWER TAIL GATE<E61> (C) WHITE |
| 166 |
I8-98483 496-3 |
|
COVER; HINGE |
1 |
2410- |
|
AB |
|
| 139 |
I8-97507 262-0 |
|
DOVETAIL; BODY |
2 |
2410- |
|
AB |
|
| 010 |
I8-97687 080-0 |
|
BOLT; LOCK |
4 |
2410- |
|
AB |
POWER TAIL GATE<E61> |
| 103 |
I0-91180 208-0 |
|
NUT |
4 |
2410- |
|
AB |
(B) M8 FLANGE |
