8-52 | 8-52A PIPING; AIR CONDITIONING

Partial Engine Partial Engine Partial Engine Partial Engine Partial Engine Partial Engine Partial Engine

MUX

MU-X 2025

Key PART NO ITC DESCRIPTION QTY APP DATE LR MODEL REMARKS
185 I8-97507 116-1 PIPE; EVAP TO FLEX HOSE,PRESS LO 1 2410- AB (A)
067 I8-97512 041-0 GASKET; FLEX HOSE 1 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
067 I8-97512 039-0 GASKET; FLEX HOSE 1 2410- AB 4JJ3 ENG(LNG) (A)
067 I8-97512 041-0 GASKET; FLEX HOSE 3 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
162 I0-28650 825-0 BOLT; FLEX HOSE 1 2410- AB (A) M8X25 FLANGE
226 I8-97491 404-1 TUBE; A/C 1 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) EXC. HIGH ALTITUDE COMPENSATOR<EE2> (B)
049 I8-97686 928-0 CLAMP; FLEX 1 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (A)
192 I8-97686 930-0 PLATE; COOLER HOSE 1 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4)
226 I8-97491 408-0 TUBE; A/C 1 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) EXC. HIGH ALTITUDE COMPENSATOR<EE2> (A)
066 I8-97507 094-1 HOSE; FLEX,A/C 1 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (A)
053 I8-97507 115-1 PIPE; RECEIVER TANK TO EVAP 1 2410- AB RZ4E-TC ENG(RDZ) (A)
147 I8-97512 044-0 CAP; FLEX HOSE 1 2410- AB (B)
067 I8-97512 039-0 GASKET; FLEX HOSE 2 2410- AB RZ4E-TC ENG(RDZ) (A)
066 I8-97491 397-2 HOSE; FLEX,A/C 1 2410- AB 4JJ3 ENG(LNG) (C)
049 I8-97683 078-0 CLAMP; FLEX 1 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
049 I8-97686 928-0 CLAMP; FLEX 1 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (A)
226 I8-97844 542-0 TUBE; A/C 1 2410- A RZ4E-TC ENG(RDZ) HIGH ALTITUDE COMPENSATOR<EE2> EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (A)
214 I8-97686 931-0 RUBBER; CUSHION 1 2410- AB 4JJ3 ENG(LNG)
066 I8-97491 399-2 HOSE; FLEX,A/C 1 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
158 I0-52000 616-0 BOLT; PIPE FIX 2 2410- AB RZ4E-TC ENG(RDZ) M6X16
053 I8-97507 114-1 PIPE; RECEIVER TANK TO EVAP 1 2410- AB 4JJ3 ENG(LNG) (B)
226 I8-97682 472-1 TUBE; A/C 1 2410- AB RZ4E-TC ENG(RDZ) EURO5 SPECIFICATION(NT5) (D)
066 I8-97682 471-0 HOSE; FLEX,A/C 1 2410- AB RZ4E-TC ENG(RDZ) EURO5 SPECIFICATION(NT5) (E)
116 I8-97512 039-0 GASKET; PIPE 1 2410- AB (A)
008 I0-28650 620-0 BOLT; CLIP 10 2410- | AB M6X20 FLANGE
067 I8-97512 041-0 GASKET; FLEX HOSE 3 2410- AB 4JJ3 ENG(LNG) (B)
066 I8-97507 092-0 HOSE; FLEX,A/C 1 2410- AB 4JJ3 ENG(LNG) (D)
185 I8-97507 117-1 PIPE; EVAP TO FLEX HOSE,PRESS LO 1 2410- AB (B)
162 I0-28650 825-0 BOLT; FLEX HOSE 2 2410- AB 4JJ3 ENG(LNG) (A) M8X25 FLANGE
049 I8-97683 078-0 CLAMP; FLEX 1 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
202 I8-97512 048-0 SWITCH; PRESSURE 1 2410- | AB
226 I8-97844 540-0 TUBE; A/C 1 2410- A RZ4E-TC ENG(RDZ) HIGH ALTITUDE COMPENSATOR<EE2> EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
214 I8-97686 931-0 RUBBER; CUSHION 1 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4)
066 I8-97682 470-0 HOSE; FLEX,A/C 1 2410- AB RZ4E-TC ENG(RDZ) EURO5 SPECIFICATION(NT5) (F)
192 I8-97686 930-0 PLATE; COOLER HOSE 1 2410- AB 4JJ3 ENG(LNG)
214 I8-97686 931-0 RUBBER; CUSHION 1 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4)
226 I8-97844 542-0 TUBE; A/C 1 2410- B RZ4E-TC ENG(RDZ) HIGH ALTITUDE COMPENSATOR<EE2> EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (A)
067 I8-97512 041-0 GASKET; FLEX HOSE 1 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
146 I8-97512 046-0 CLIP; RECEIVER PIPE 2 2410- AB (A)
226 I8-97844 540-0 TUBE; A/C 1 2410- B RZ4E-TC ENG(RDZ) HIGH ALTITUDE COMPENSATOR<EE2> EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
216 I0-28650 825-0 BOLT; HOSE FIX 2 2410- AB RZ4E-TC ENG(RDZ) (B) M8X25 FLANGE
067 I8-97512 041-0 GASKET; FLEX HOSE 3 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
116 I8-97512 042-0 GASKET; PIPE 2 2410- AB (C)
066 I8-97491 399-2 HOSE; FLEX,A/C 1 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (B)
162 I0-28650 835-0 BOLT; FLEX HOSE 2 2410- AB RZ4E-TC ENG(RDZ) (B) M8X35 FLANGE
023 I8-97383 407-0 BOLT; BRKT 1 2410- | AB M6X30 W/PL WASHER
123 I8-97512 042-0 GASKET; RECEIVER PIPE 3 2410- | AB
226 I8-97491 404-1 TUBE; A/C 1 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) EXC. HIGH ALTITUDE COMPENSATOR<EE2> (B)
147 I8-97512 045-0 CAP; FLEX HOSE 1 2410- AB (A)
226 I8-97682 473-1 TUBE; A/C 1 2410- AB RZ4E-TC ENG(RDZ) EURO5 SPECIFICATION(NT5) (C)
122 I8-97512 043-0 GASKET 1 2410- | AB
216 I0-28650 620-0 BOLT; HOSE FIX 1 2410- AB (A) M6X20 FLANGE
067 I8-97512 040-0 GASKET; FLEX HOSE 1 2410- AB (C)
049 I8-97686 928-0 CLAMP; FLEX 1 2410- AB 4JJ3 ENG(LNG) (A)
146 I8-97512 047-0 CLIP; RECEIVER PIPE 1 2410- AB (B)
226 I8-97491 408-0 TUBE; A/C 1 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) EXC. HIGH ALTITUDE COMPENSATOR<EE2> (A)
116 I8-97512 041-0 GASKET; PIPE 1 2410- AB (B)
192 I8-97686 930-0 PLATE; COOLER HOSE 1 2410- B RZ4E-TC ENG(RDZ) EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4)
066 I8-97507 094-1 HOSE; FLEX,A/C 1 2410- A RZ4E-TC ENG(RDZ) EURO0 SPECIFICATION(K75),EURO2 SPECIFICATION(NT2),EURO4 SPECIFICATION(NT4) (A)
067 I8-97512 041-0 GASKET; FLEX HOSE 4 2410- AB RZ4E-TC ENG(RDZ) EURO5 SPECIFICATION(NT5) (B)
