| 58 |
I0-28050 612-0 |
|
BOLT; CHECK HOLE COVER |
6 |
0612- |
|
C |
M6X12 |
| 60 |
I9-01900 614-0 |
|
BOLT; COVER TO CASE |
4 |
9009-9204 |
|
A |
M6X14 W/LK WASHER |
| 158 |
I0-50740 820-0 |
|
BOLT; FRT PLATE |
3 |
9205- |
|
A |
M8X20 W/LK WASHER |
| 78 |
I8-97131 706-1 |
|
SPACER; MTG RUBBER, NOISE COVER |
1 |
9602- |
|
B |
|
| 60 |
I9-95821 255-0 |
|
BOLT; COVER TO CASE |
1 |
9602- |
|
BC |
M12X55 (C) |
| 32 |
I9-11312 034-1 |
|
GASKET; GEAR CASE TO C/BL |
1 |
9009-9601 |
|
A |
ALSO INCLUDED IN GASKET SET(ENGINE) |
| 73 |
I0-50140 618-0 |
|
BOLT; COVER FIX |
4 |
9602- |
|
B |
M6X18 W/LKBPL WASHER |
| 65 |
I8-97118 698-0 |
|
GASKET; COVER, TIMING CHECK HOLE |
2 |
9602- |
|
B |
ALSO INCLUDED IN GASKET SET(ENGINE) |
| 54 |
I8-97306 431-2 |
|
COVER; GEAR CASE |
1 |
0612- |
|
C |
|
| 54 |
I8-97231 214-1 |
|
COVER; GEAR CASE |
1 |
9602- |
|
B |
|
| 57 |
I5-11321 009-0 |
|
COVER; TIMING CHECK HOLE |
2 |
9602- |
|
BC |
(B) |
| 75 |
I5-19389 002-0 |
|
RUBBER; NOISE COVER MTG, TIMING GEAR CA |
2 |
9602- |
|
B |
|
| 68 |
I8-98086 763-0 |
|
COVER ASM; GEAR CASE COVER |
1 |
0612- |
|
C |
(A) |
| 33 |
I8-94109 707-0 |
|
GASKET; BRKT TO CASE |
1 |
9602- |
|
B |
|
| 1 |
I8-97306 429-1 |
|
CASE; TIMING GEAR |
1 |
0612- |
|
C |
|
| 175 |
I8-97071 561-1 |
|
SEAL; OIL, CR/SHF, RR |
1 |
9602- |
|
BC |
|
| 60 |
I0-58311 255-0 |
|
BOLT; COVER TO CASE |
1 |
9602- |
|
BC |
M12X55 (C) |
| 60 |
I0-58331 255-0 |
|
BOLT; COVER TO CASE |
1 |
9602- |
|
BC |
M12X55 (C) |
| 36 |
I0-50740 845-0 |
|
BOLT; GEAR CASE |
2 |
9602- |
|
BC |
M8X45 W/LK WASHER |
| 73 |
I0-28050 616-0 |
|
BOLT; COVER FIX |
5 |
0612- |
|
C |
M6X16 |
| 158 |
I0-50040 820-0 |
|
BOLT; FRT PLATE |
3 |
9205-9601 |
|
A |
M8X20 W/LK WASHER |
| 56 |
I9-09920 601-0 |
|
GASKET; GEAR CASE TO COVER |
1 |
9009-9601 |
|
A |
ALSO INCLUDED IN GASKET SET(ENGINE) |
| 72 |
I5-19389 009-0 |
|
BUSHING; SPACER, COVER TO COVER |
1 |
0612- |
|
C |
(A) |
| 60 |
I0-28650 835-0 |
|
BOLT; COVER TO CASE |
8 |
9602- |
|
B |
M8X32 W/LK WASHER |
| 246 |
I9-12363 112-1 |
|
SPACER; OIL SEAL, CR/SHF |
1 |
9009-9601 |
|
A |
|
| 69 |
I8-97306 548-1 |
|
SEAL; RUBBER, COVER TO COVER |
1 |
0612- |
|
C |
(B) |
| 54 |
I8-97131 705-0 |
|
COVER; GEAR CASE |
1 |
9602- |
|
B |
|
| 245 |
I9-09806 020-0 |
|
BOLT; C/BL TO TRANS CASE |
1 |
9009-9601 |
|
A |
M10X52 |
| 65 |
I8-97118 698-1 |
|
GASKET; COVER, TIMING CHECK HOLE |
2 |
9602- |
|
B |
ALSO INCLUDED IN GASKET SET(ENGINE) |
| 68 |
I8-97255 034-1 |
|
COVER ASM; GEAR CASE COVER |
1 |
0612- |
|
C |
(A) |
| 39 |
I9-11312 046-0 |
|
GASKET; TIMING GEAR CASE |
2 |
9009-9601 |
|
A |
|
| 69 |
I8-97329 009-0 |
|
SEAL; RUBBER, COVER TO COVER |
1 |
0612- |
|
C |
(A) |
| 36 |
I0-50040 832-1 |
|
BOLT; GEAR CASE |
7 |
9009-9601 |
|
A |
M8X32 W/LK WASHER |
| 56 |
I8-97238 631-0 |
|
GASKET; GEAR CASE TO COVER |
1 |
9602- |
|
B |
|
| 11 |
I8-97912 556-0 |
|
PLATE; RR, C/BL |
1 |
0612- |
|
C |
|
| 36 |
I0-50040 820-0 |
|
BOLT; GEAR CASE |
6 |
9602- |
|
BC |
M8X20 W/LK WASHER |
| 36 |
I0-50740 820-0 |
|
BOLT; GEAR CASE |
6 |
9602- |
|
BC |
M8X20 W/LK WASHER |
| 56 |
I8-97287 694-0 |
|
GASKET; GEAR CASE TO COVER |
1 |
0612- |
|
C |
|
| 77 |
I8-97914 630-1 |
|
BUSHING; MTG RUBBER, NOISE COVER |
2 |
9602- |
|
B |
|
| 1 |
I8-97129 982-3 |
|
CASE; TIMING GEAR |
1 |
9602- |
|
B |
|
| 15 |
I5-09000 227-0 |
|
BOLT; RR PLATE TO C/BL |
3 |
9009- |
|
ABC |
M12X25 |
| 58 |
I0-50040 614-0 |
|
BOLT; CHECK HOLE COVER |
4 |
9602- |
|
B |
M6X14 W/LK WASHER |
| 60 |
I8-94205 986-1 |
|
BOLT; COVER TO CASE |
6 |
9602- |
|
B |
M8X65 |
| 60 |
I0-58331 255-0 |
|
BOLT; COVER TO CASE |
1 |
9602- |
|
BC |
M12X55 (C) |
| 57 |
I8-97353 706-2 |
|
COVER; TIMING CHECK HOLE |
1 |
0612- |
|
C |
(A) |
| 33 |
I8-97912 581-0 |
|
GASKET; BRKT TO CASE |
1 |
0612- |
|
C |
|
| 54 |
I9-11321 148-0 |
|
COVER; GEAR CASE |
1 |
9009-9601 |
|
A |
|
| 103 |
I8-97049 145-0 |
|
SEAL; OIL, CR/SHF, FRT |
1 |
9009-9112 |
|
AB |
|
| 36 |
I0-28650 835-0 |
|
BOLT; GEAR CASE |
7 |
9009- |
|
A |
M8X32 W/LK WASHER |
| 77 |
I5-19389 009-1 |
|
BUSHING; MTG RUBBER, NOISE COVER |
2 |
9602- |
|
B |
|
| 72 |
I8-97914 630-0 |
|
BUSHING; SPACER, COVER TO COVER |
1 |
0612- |
|
C |
(B) |
| 68 |
I8-97943 086-0 |
|
COVER ASM; GEAR CASE COVER |
1 |
0612- |
|
C |
(B) |
| 147 |
I8-97023 364-0 |
|
GASKET; FRT PLATE TO C/BL |
1 |
9105-9601 |
|
A |
|
| 36 |
I8-94205 986-1 |
|
BOLT; GEAR CASE |
2 |
9009-9601 |
|
A |
M8X65 |
| 71 |
I8-97914 631-0 |
|
RUBBER; MTG COVER |
1 |
0612- |
|
C |
(B) |
| 60 |
I0-50540 860-0 |
|
BOLT; COVER TO CASE |
1 |
9602- |
|
B |
M8X60 W/LK WASHER |
| 60 |
I0-50040 832-1 |
|
BOLT; COVER TO CASE |
8 |
9602- |
|
B |
M8X32 W/LK WASHER |
| 38 |
I9-08151 020-0 |
|
PIN; GEAR CASE COVER |
2 |
9602- |
|
BC |
OD=10 L=20 |
| 71 |
I5-19389 002-0 |
|
RUBBER; MTG COVER |
1 |
0612- |
|
C |
(A) |
| 72 |
I8-97914 630-1 |
|
BUSHING; SPACER, COVER TO COVER |
1 |
0612- |
|
C |
(A) |
| 11 |
I8-94437 923-2 |
|
PLATE; RR, C/BL |
1 |
9602- |
|
B |
|
| 103 |
I8-97351 704-0 |
|
SEAL; OIL, CR/SHF, FRT |
1 |
0612- |
|
C |
|
| 60 |
I0-50040 860-0 |
|
BOLT; COVER TO CASE |
1 |
9602- |
|
B |
M8X60 W/LK WASHER |
| 32 |
I8-97129 426-1 |
|
GASKET; GEAR CASE TO C/BL |
1 |
9602- |
|
BC |
|
| 149 |
I9-11311 153-0 |
|
PLATE; FRT, C/BL |
1 |
9009-9601 |
|
A |
|
| 36 |
I0-50040 845-0 |
|
BOLT; GEAR CASE |
2 |
9602- |
|
BC |
M8X45 W/LK WASHER |
| 11 |
I8-94329 551-0 |
|
PLATE; RR, C/BL |
1 |
9009-9601 |
|
A |
|
| 55 |
I8-94420 293-3 |
|
COVER; NOISE SHIELD |
1 |
9602- |
|
B |
|
| 1 |
I5-11311 067-2 |
|
CASE; TIMING GEAR |
1 |
9009-9601 |
|
A |
|
| 60 |
I0-50040 614-0 |
|
BOLT; COVER TO CASE |
4 |
9205-9601 |
|
A |
M6X14 W/LK WASHER |
| 175 |
I5-09625 036-0 |
|
SEAL; OIL, CR/SHF, RR |
1 |
9009-9601 |
|
A |
ALSO INCLUDED IN GASKET SET(ENGINE) |
| 57 |
I8-97353 706-1 |
|
COVER; TIMING CHECK HOLE |
1 |
0612- |
|
C |
(A) |
