Catalog
| FIG NO | FIG TITLE |
|---|---|
| 0-42 | FUEL PUMP AND PIPE |
| 0-45 | EVAPORATOR SYSTEM; ENGINE |
| 0-50 | OIL COOLER AND OIL FILTER |
| 0-51 | OIL PUMP AND OIL STRAINER |
| 0-52 | OIL AND VACUUM PIPING; ENGINE |
| 0-56 | EMISSION SYSTEM |
| 0-57 | EMISSION PIPING |
| 0-60 | ENGINE ELECTRICAL CONTROL PARTS |
| 0-61 | BATTERY AND BATTERY CABLE |
| 0-86 | MISELLANEOUS PARTS; INJECTION PUMP |
| PART NO | DESCRIPTION |
|---|---|
| I0-01158 300-0 | HOSE; FUEL TANK TO FUEL PIPE |
| I0-01254 300-0 | HOSE; RUBBER, FUEL LEAK |
| I0-01258 300-0 | HOSE; RUBBER, SEDIMENTER TO FUEL FILTER |
| I0-01259 300-0 | HOSE; BREATHER, FUEL TANK |
| I0-01262 300-0 | HOSE; FUEL TANK TO FUEL PIPE |
| I0-03157 300-0 | HOSE; RAD TO SURGE TANK |
| I0-04740 300-0 | HOSE; VAC, FAST IDLE, A/C |
| I0-04920 300-0 | HOSE; VAC |
| I0-04930 300-0 | HOSE; VAC |
| I0-08358 100-0 | HOSE; VAC, VAC PUMP TO PIPE |
| PART NO | DESCRIPTION |
|---|---|
| I0-08358 300-0 | HOSE; VAC, VAC PUMP TO PIPE |
| I0-09814 400-0 | HOSE; FLEX, P/S OIL PUMP, INL |
| I0-10806 260-0 | BOLT; STARTER |
| I0-10806 285-0 | BOLT; TRANS CASE TO ENG |
| I0-10806 490-0 | BOLT; LWR LINK TO FRT C/MBR |
| I0-10810 850-0 | BOLT; BRKT |
| I0-10856 250-0 | BOLT; S/ABS TO LWR LINK |
| I0-10856 490-0 | BOLT; LWR LINK TO FRT C/MBR |
| I0-10956 050-0 | BOLT; LWR LINK |
| I0-19809 300-0 | HOSE; RETURN, P/S TANK |
| PART NO | DESCRIPTION |
|---|---|
| I0-20800 508-0 | BOLT; VAC SW |
| I0-20800 610-0 | BOLT; UNDER COVER TO TRANS |
| I0-20800 612-0 | BOLT; CLIP, PIPE |
| I0-20800 625-0 | BOLT; CLAMP BATTERY |
| I0-20800 630-0 | BOLT; STOPPER, ACCEL PEDAL |
| I0-20800 640-0 | BOLT; STOPPER, ACCEL PEDAL |
| I0-20800 814-0 | BOLT; NOISE SHIELD COVER |
| I0-20800 816-0 | BOLT; LOCK PLATE, COUNTER SHAFT, TRANSFE |
| I0-20800 820-0 | BOLT; SPR 8 SHACKLE |
| I0-20801 016-0 | BOLT; CABLE BATTERY |
| PART NO | DESCRIPTION |
|---|---|
| I0-20801 025-0 | BOLT; BRKT TO BRKT |
| I0-20801 035-1 | BOLT; CLU PEDAL ADJ |
| I0-20801 070-0 | BOLT; ADJ PLATE |
| I0-20801 240-0 | BOLT; TRANS CASE TO ENG |
| I0-20850 816-0 | BOLT; LOCK PLATE, COUNTER SHAFT, TRANSFE |
| I0-20850 820-0 | BOLT; SPR 8 SHACKLE |
| I0-20851 016-0 | BOLT; CABLE BATTERY |
| I0-20851 025-0 | BOLT; BRKT TO BRKT |
| I0-20851 070-0 | BOLT; ADJ PLATE |
| I0-20851 240-0 | BOLT; TRANS CASE TO ENG |
| PART NO | DESCRIPTION |
|---|---|
| I0-20951 020-0 | BOLT; LWR LINK |
| I0-28010 812-0 | BOLT; CLIP, WATER HOSE, OUTLET |
| I0-28010 820-0 | BOLT; LK PIECE |
| I0-28050 040-0 | BOLT; UNDER COVER TO TRANS |
| I0-28050 610-0 | BOLT; SHAFT SIDE |
| I0-28050 612-0 | BOLT |
| I0-28050 616-0 | BOLT; COVER FIX |
| I0-28050 625-0 | BOLT; BREATHER NIPPLE |
| I0-28050 810-0 | BOLT; OIL PIPE, OIL JET |
| I0-28050 812-0 | BOLT; NOISE SHIELD COVER |
| PART NO | DESCRIPTION |
|---|---|
| I0-28050 816-0 | BOLT; BRKT |
| I0-28050 820-0 | BOLT; PLATE TO PLATE |
| I0-28050 825-0 | BOLT; MANIF TO INL PIPE |
| I0-28050 830-0 | BOLT; MANIF TO INL PIPE |
| I0-28050 840-0 | BOLT; EGR VLV |
| I0-28050 850-0 | BOLT; HAND BRAKE LEVER |
| I0-28050 870-0 | BOLT; A/C CMPR BRKT |
| I0-28051 030-0 | BOLT; UNDER COVER TO TRANS |
| I0-28051 035-0 | BOLT; UNDER COVER TO TRANS |
| I0-28051 040-0 | BOLT; TRANS CASE TO ENG |
| PART NO | DESCRIPTION |
|---|---|
| I0-28051 045-0 | BOLT; TRANS CASE TO ENG |
| I0-28051 080-0 | BOLT; BRKT |
| I0-28051 235-0 | BOLT; TRANS CASE TO ENG |
| I0-28051 290-0 | BOLT; SLAVE CYL TO TRANS CASE |
| I0-28055 812-0 | BOLT; CRANKCASE TO C/BL |
| I0-28056 013-0 | BOLT; GEN |
| I0-28061 025-0 | BOLT; RELAY LEVER BRKT |
| I0-28080 610-0 | BOLT; UNDER COVER TO TRANS |
| I0-28080 612-0 | BOLT; OIL PAN |
| I0-28080 625-0 | BOLT; STRG LOCK TO COLUMN |
| PART NO | DESCRIPTION |
|---|---|
| I0-28080 812-0 | BOLT; CLIP, WATER HOSE, OUTLET |
| I0-28080 816-0 | BOLT; BRKT |
| I0-28080 818-0 | BOLT; RET, DRIVEN GEAR |
| I0-28080 820-0 | BOLT; LK PIECE |
| I0-28080 825-0 | BOLT; STRAINER, OIL PUMP |
| I0-28080 830-0 | BOLT; STRAINER, OIL PUMP |
| I0-28080 850-0 | BOLT; HAND BRAKE LEVER |
| I0-28081 030-0 | BOLT; FUEL FILTER CLAMP |
| I0-28081 035-0 | BOLT; TRANS CASE TO ENG |
| I0-28081 040-0 | BOLT; TRANS CASE TO ENG |
| PART NO | DESCRIPTION |
|---|---|
| I0-28081 235-0 | BOLT; TRANS CASE TO ENG |
| I0-28091 025-0 | BOLT; STRG UNIT |
| I0-28251 025-0 | BOLT; 3RD C/MBR |
| I0-28280 616-0 | BOLT; QOS CONTROLLER |
| I0-28280 618-0 | BOLT; TAIL GATE LOCK |
| I0-28281 025-0 | BOLT; 3RD C/MBR |
| I0-28410 616-0 | SCREW; RELAY, FOG LAMP, RR |
| I0-28450 616-0 | BOLT; BRKT |
| I0-28450 816-0 | BOLT; HEAD PROTECTOR |
| I0-28480 616-0 | BOLT; CLIP |
| PART NO | DESCRIPTION |
|---|---|
| I0-28480 820-0 | BOLT; CLIP FIX |
| I0-28481 225-0 | BOLT; BACK BAR TO BODY |
| I0-28650 620-0 | BOLT; WATER PIPE |
| I0-28650 635-0 | BOLT; CLIP |
| I0-28650 820-0 | BOLT; CABLE CLIP |
| I0-28650 830-0 | BOLT; CLIP TO FRAME |
| I0-28650 835-0 | BOLT; COVER TO CASE |
| I0-28650 840-0 | BOLT; ROLLER, PARK BRK CABLE |
| I0-28651 025-0 | BOLT; CUSHION RUBBER TO MTG BRKT |
| I0-28651 030-0 | BOLT; CUSHION RUBBER TO MTG BRKT |
| PART NO | DESCRIPTION |
|---|---|
| I0-28651 035-0 | BOLT; FUEL FILTER |
| I0-28680 620-0 | BOLT; CLAMP BATTERY |
| I0-28680 830-0 | BOLT; CLIP TO FRAME |
| I0-28680 840-0 | BOLT; BRKT, EXH PIPE |
| I0-28681 025-0 | BOLT; CUSHION RUBBER TO MTG BRKT |
| I0-28681 035-0 | BOLT; FUEL FILTER CLAMP |
| I0-35050 520-0 | SCREW; HINGE |
| I0-36210 412-0 | SCREW; STRG COWL UPR |
| I0-36210 620-0 | SCREW; STOPPER RUBBER |
| I0-36220 408-0 | SCREW; VENTILATOR TO HD COVER |
| PART NO | DESCRIPTION |
|---|---|
| I0-36220 514-0 | SCREW; COMB SW |
| I0-36230 510-0 | SCREW; RADIO |
| I0-36230 514-0 | SCREW; HEADLAMP |
| I0-36410 616-0 | BOLT; BRK DRUM |
| I0-41010 618-0 | STUD; FAN CLU |
| I0-41010 630-0 | STUD; INL MANIF |
| I0-41010 818-0 | STUD; OIL DRAIN PIPE |
| I0-41010 822-0 | STUD; WATER PUMP |
| I0-41010 825-0 | STUD; INL MANIF |
| I0-41010 830-0 | STUD; COVER |
| PART NO | DESCRIPTION |
|---|---|
| I0-41010 835-0 | STUD; CRANKCASE |
| I0-41010 840-0 | STUD; EXH MANIF |
| I0-50040 512-0 | BOLT; SEDIMENTER |
| I0-50040 612-0 | BOLT; SHAFT SIDE |
| I0-50040 614-0 | BOLT; CHECK HOLE COVER |
| I0-50040 625-0 | BOLT; BREATHER NIPPLE |
| I0-50040 645-0 | BOLT; FAN |
| I0-50040 812-0 | BOLT; CLIP, OIL COOLER HOSE |
| I0-50040 814-0 | BOLT; PIPE FIX |
| I0-50040 816-0 | BOLT; BRKT |
| PART NO | DESCRIPTION |
|---|---|
| I0-50040 818-0 | BOLT; COVER TO C/BL |
| I0-50040 820-0 | BOLT; HSG TO HD |
| I0-50040 822-0 | BOLT; SUCTION PIPE |
| I0-50040 825-0 | BOLT; BRKT TO BRKT |
| I0-50040 830-1 | BOLT; HSG TO HD |
| I0-50040 832-1 | BOLT; ROLLER, PARK BRK CABLE |
| I0-50040 845-0 | BOLT; SUCTION PIPE |
| I0-50040 860-0 | BOLT; BRKT, POWER STRG |
| I0-50041 016-0 | BOLT; BRKT, GRAND |
| I0-50041 020-0 | BOLT; HELPER RUBBER |
| PART NO | DESCRIPTION |
|---|---|
| I0-50041 022-0 | BOLT; ENG FOOT |
| I0-50041 025-0 | BOLT; OIL PUMP, P/S |
| I0-50041 028-0 | BOLT; INL PIPE |
| I0-50041 035-0 | BOLT; BRKT, POWER STRG |
| I0-50041 040-0 | BOLT; FUEL FILTER CLAMP |
| I0-50041 050-0 | BOLT; WATER PUMP TO C/BL |
| I0-50041 060-0 | BOLT; BRKT, POWER STRG |
| I0-50041 070-0 | BOLT; GEN BRKT |
| I0-50041 425-0 | BOLT; ENG FOOT |
| I0-50051 020-0 | BOLT; BRKT TO INJ PUMP |
| PART NO | DESCRIPTION |
|---|---|
| I0-50080 616-0 | BOLT; OIL PAN |
| I0-50140 612-0 | BOLT; FUEL FILLER LID |
| I0-50140 614-0 | BOLT; CLIP |
| I0-50140 616-0 | BOLT |
| I0-50140 618-0 | BOLT; COVER FIX |
| I0-50140 625-0 | BOLT; OIL JET |
| I0-50140 630-0 | BOLT; CLIP |
| I0-50140 635-0 | BOLT; INL MANlIF |
| I0-50140 800-0 | BOLT; ENG HARNESS CLIP |
| I0-50140 816-0 | BOLT; BRKT TO ACL |
| PART NO | DESCRIPTION |
|---|---|
| I0-50140 818-0 | BOLT; CROSS BEAM |
| I0-50140 820-0 | BOLT; BRKT |
| I0-50140 822-0 | BOLT; P/S PUMP |
| I0-50140 825-0 | BOLT; OIL PUMP |
| I0-50140 830-0 | BOLT; OUTLET PIPE |
| I0-50141 030-0 | BOLT; BRKT |
| I0-50141 035-0 | BOLT; UNDER COVER TO TRANS |
| I0-50141 040-0 | BOLT; TRANS CASE TO ENG |
| I0-50141 045-1 | BOLT; TRANS CASE TO ENG |
| I0-50540 612-0 | BOLT; GUIDE TUBE |
| PART NO | DESCRIPTION |
|---|---|
| I0-50540 616-0 | BOLT; ACL |
| I0-50540 812-0 | BOLT; BRKT TO BODY |
| I0-50540 816-0 | BOLT; CLU MTG BRKT |
| I0-50540 818-0 | BOLT; BRKT, POWER STRG |
| I0-50540 825-0 | BOLT; ADJ PLATE |
| I0-50540 830-0 | BOLT |
| I0-50540 850-0 | BOLT; SUCTION PIPE |
| I0-50540 860-0 | BOLT; COVER TO CASE |
| I0-50541 020-0 | BOLT; BRAKT |
| I0-50541 035-0 | BOLT; UNDER COVER TO TRANS |
| PART NO | DESCRIPTION |
|---|---|
| I0-50541 040-0 | BOLT; FUEL FILTER CLAMP |
| I0-50541 060-0 | BOLT; BRKT, POWER STRG |
| I0-50541 070-0 | BOLT; WATER PUMP TO C/BL |
| I0-50541 425-0 | BOLT; ENG FOOT |
| I0-50551 020-0 | BOLT; BRKT TO INJ PUMP |
| I0-50640 625-0 | BOLT; OIL JET |
| I0-50640 630-0 | BOLT; CLIP |
| I0-50640 800-0 | BOLT; ENG HARNESS CLIP |
| I0-50640 816-0 | BOLT; GUIDE TUBE |
| I0-50640 820-0 | BOLT; BRKT |
| PART NO | DESCRIPTION |
|---|---|
| I0-50640 825-0 | BOLT; OIL PUMP |
| I0-50640 830-0 | BOLT; OIL PUMP |
| I0-50641 030-0 | BOLT; BRKT |
| I0-50740 820-0 | BOLT; INL PIPE TO BRKT |
| I0-50740 845-0 | BOLT; ADJ PLATE |
| I0-50741 025-0 | BOLT; CUSHION RUBBER TO MTG BRKT |
| I0-58311 255-0 | BOLT; COVER TO CASE |
| I0-58331 255-0 | BOLT; COVER TO CASE |
| I0-71040 512-0 | SCREW; TAP, LICENSE LAMP BODY |
| I0-71090 416-0 | SCREW; TREAD PLATE |
| PART NO | DESCRIPTION |
|---|---|
| I0-71090 430-0 | SCREW; FRT COMB LAMP |
| I0-71190 420-0 | SCREW; LICENSE PLATE LAMP |
| I0-71190 530-0 | SCREW; RR COMB LAMP |
| I0-71240 410-0 | SCREW; RR COMB LAMP |
| I0-71240 510-0 | SCREW; ASH TRAY |
| I0-74100 408-0 | SCREW |
| I0-74100 514-0 | SCREW; METER, INST PANEL |
| I0-74100 614-0 | SCREW; BODY MTG GASKET |
| I0-74160 514-0 | SCREW; METER, INST PANEL |
| I0-74300 616-0 | SCREW; TAP, PEDAL TO BRKT |
| PART NO | DESCRIPTION |
|---|---|
| I0-81122 015-0 | PIN; SNAP, CABLE TO LEVER |
| I0-81123 020-0 | PIN; SPLIT, ROD END |
| I0-81123 025-0 | PIN; SPLIT, LINK END TO KNUCKLE |
| I0-81123 028-0 | PIN; SPLIT, LINK END TO KNUCKLE |
| I0-81124 025-0 | PIN; SPLIT, HUB TO AXLE SHAFT |
| I0-81124 030-0 | PIN; SPLIT, RELIEF VALVE |
| I0-82353 820-0 | PIN; JOINT, RELAY LEVER |
| I0-91110 506-0 | NUT; ACCEL PEDAL STOPPER |
| I0-91110 508-0 | NUT; BRK M/CYL |
| I0-91110 510-0 | NUT; HAND BRAKE STEM |
| PART NO | DESCRIPTION |
|---|---|
| I0-91110 512-0 | NUT |
| I0-91111 510-0 | NUT; LK, STOPPER BOLT |
| I0-91111 512-0 | NUT; S/ABS TO LWR LINK |
| I0-91111 516-0 | NUT; RELAY LEVER |
| I0-91111 520-0 | NUT; SELF LK, COUNTER |
| I0-91111 522-0 | NUT; PITMAN ARM |
| I0-91116 518-0 | NUT; LWR LINK END TO KNUCKLE |
| I0-91117 512-0 | NUT; ROD END |
| I0-91150 106-0 | NUT; CLU OIL DAMPER |
| I0-91150 108-0 | NUT; BRKT |
| PART NO | DESCRIPTION |
|---|---|
| I0-91150 110-0 | NUT; EXH PIPE |
| I0-91150 208-0 | NUT; CENTER TO SIDE |
| I0-91150 210-0 | NUT; STRG UNIT |
| I0-91180 106-0 | NUT; MUD GUARD |
| I0-91180 108-0 | NUT; CRANKCASE |
| I0-91180 110-0 | NUT; SUPPORT RUBBER |
| I0-91180 206-0 | NUT; CLIP |
| I0-91180 208-0 | NUT; POWER STRG PUMP |
| I0-91180 210-0 | NUT; STRG UNIT |
| I0-91510 505-0 | WASHER; LK, BAFFLE PLATE, TAPPET COVER |
| PART NO | DESCRIPTION |
|---|---|
| I0-91510 506-0 | WASHER; LK, HAND BRK STEM |
| I0-91510 508-0 | WASHER; LK, YOKE TO RR AXLE |
| I0-91510 512-0 | WASHER; LK, STIFFENER |
| I0-91510 516-0 | WASHER; LINK, RELAY LEVER |
| I0-91510 522-0 | WASHER; LK, PITMAN ARM |
| I0-91510 608-0 | WASHER; LK, YOKE TO RR AXLE |
| I0-91510 612-0 | WASHER; LK, FULCRUM PIN |
| I0-91510 614-0 | WASHER; LK, UPR LINK TO FRT C/MBR |
| I0-91510 808-0 | WASHER; LK, UPR LINK END TO UPR LINK |
| I0-91510 810-0 | WASHER; LK, SUPPORT RUBBER |
| PART NO | DESCRIPTION |
|---|---|
| I0-91510 814-0 | WASHER; LK, SUPPORT BRKT TO KNUCKLE |
| I0-91541 216-0 | WASHER; LK, FLEX HOSE |
| I0-91610 508-0 | WASHER; PL |
| I0-91610 510-0 | WASHER; PL, WATER PUMP |
| I0-91610 512-0 | WASHER; PL, SLAVE CYL, CLU |
| I0-91610 516-0 | WASHER; PL, COUNTER 5TH GEAR |
| I0-91610 606-0 | WASHER; PL, GUIDE TUBE, OIL LEVEL GAUGE |
| I0-91610 610-0 | WASHER; PL, GEN |
| I0-91610 706-0 | WASHER; PL, INST PANEL |
| I0-91610 708-0 | WASHER; PL, CHAIN TO RR BODY |
| PART NO | DESCRIPTION |
|---|---|
| I0-91610 710-0 | WASHER; PL. RELAY LEVER, PARK BRK |
| I0-91614 608-0 | WASHER'PL EXH, AMIF BRKT |
| I0-91614 610-0 | WASHER; PL. BRKT TO BRKT |
| I0-91614 708-0 | WASHER; PL, ADJ PLATE |
| I0-91614 710-0 | WASHER; PL, STRUT |
| I0-91614 712-0 | WASHER; PL, FULCRUM PIN |
| I0-91614 808-0 | WASHER; PL |
| I0-91614 810-0 | WASHER; BODY MTG RUBBER |
| I0-92107 005-0 | UNION; OIL PIPE |
| I0-95235 022-0 | CLIP; FUEL PIPE |
| PART NO | DESCRIPTION |
|---|---|
| I0-95235 065-0 | CLIP; ACCEL CONT CABLE |
| I0-95235 532-0 | CLIP; RUBBER HOSE |
