| 5 |
I8-97254 316-0 |
|
RING; SNAP, BRG TO TOP GEAR SHAFT |
1 |
9009-9408 |
|
ABC |
ID=37 |
| 135 |
I5-33361 019-1 |
|
GEAR; REV IDLER |
1 |
9009-9408 |
|
A |
Z=25 |
| 226 |
I5-33363 004-0 |
|
WASHER; THRUST, REV GEAR, COUNTER |
2 |
9009-9408 |
|
A |
ID=22. 0 |
| 135 |
I8-98080 126-0 |
|
GEAR; REV IDLER |
1 |
9009- |
|
BC |
Z=23 |
| 51 |
I6-94151 510-0 |
|
RING; BLOCK LOW 8 2ND |
2 |
9009-9408 |
|
ABC |
(IADG) |
| 132 |
I8-94435 146-0 |
|
SHAFT; REV |
1 |
0612- |
|
C |
|
| 225 |
I9-09150 508-0 |
|
WASHER; LK, LOCK PLATE, COUNTER SHAFT |
1 |
9009-9408 |
|
A |
M8 |
| 71 |
I5-33239 043-3 |
|
WASHER; THRUST, LOW |
2 |
9409- |
|
BC |
ID=32. 0 |
| 88 |
I8-94473 936-2 |
|
RING; THRUST, THRUST WASHER |
2 |
9009- |
|
BC |
|
| 140 |
I0-28050 820-0 |
|
BOLT; LK PIECE |
1 |
9009- |
|
B |
M8X20 FLANGE |
| 65 |
I5-09442 003-0 |
|
NUT; MAINSHAFT |
1 |
9009-9408 |
|
A |
|
| 132 |
I5-33351 006-0 |
|
SHAFT; REV |
1 |
9009-9408 |
|
A |
|
| 221 |
I5-09500 009-0 |
|
WASHER; REV GEAR, COUNTER |
1 |
9009-9408 |
|
A |
|
| 40 |
I8-94152 558-1 |
|
SPRING; INSERT, LOW 8 2ND |
2 |
9009-9408 |
|
ABC |
|
| 224 |
I8-98035 678-0 |
|
NUT; SELF LK, COUNTER |
1 |
9009- |
|
BC |
M16 |
| 66 |
I6-94463 830-0 |
|
RING; BLOCK SYN |
1 |
9009- |
|
BC |
(IADG) |
| 224 |
I5-09400 030-0 |
|
NUT; SELF LK, COUNTER |
1 |
9009-9307 |
|
A |
M20 |
| 65 |
I8-94238 094-1 |
|
NUT; MAINSHAFT |
1 |
9009- |
|
BC |
|
| 13 |
I8-94161 912-3 |
|
GEAR; STH, MAINSHAFT |
1 |
9009- |
|
BC |
Z=25 |
| 50 |
I8-94311 564-1 |
|
GEAR; 2ND, MAINSHAFT |
1 |
9602- |
|
BC |
Z=31 |
| 220 |
I8-94223 043-0 |
|
SPACER; REV GEAR, COUNTER |
1 |
9009-9408 |
|
A |
|
| 224 |
I9-09844 195-0 |
|
NUT; SELF LK, COUNTER |
1 |
9009- |
|
BC |
M16 |
| 64 |
I5-09533 003-0 |
|
WASHER; LK, LOW |
1 |
9009-9408 |
|
A |
|
| 313 |
I8-94161 990-2 |
|
BEARING; NEEDLE. LOW GEAR |
1 |
9009-9408 |
|
A |
NSK |
| 99 |
I0-91610 516-0 |
|
WASHER; PL, COUNTER 5TH GEAR |
1 |
9009- |
|
BC |
ID=16 |
| 63 |
I5-33263 002-3 |
|
INSERT; SYN REV & 5TH |
3 |
9009- |
|
BC |
|
| 52 |
I8-94379 936-0 |
|
COLLAR; NEEDLE BRG, LOW |
1 |
9009-9408 |
|
ABC |
|
| 52 |
I8-94248 620-1 |
|
COLLAR; NEEDLE BRG, LOW |
2 |
9009-0901 |
|
B |
|
| 387 |
I9-33263 048-2 |
|
INSERT; SYN 4TH 8 3RD |
3 |
9009-9408 |
|
ABC |
|
| 36 |
I8-94161 137-1 |
|
GEAR; 3RD, MAINSHAFT |
1 |
9009-9408 |
|
ABC |
Z=29 |
| 59 |
I8-94310 158-1 |
|
GEAR; REV MAINSHAFT |
1 |
9009- |
|
BC |
Z=37 |
| 306 |
I5-09588 022-1 |
|
RING; SNAP, MAINSHAFT |
1 |
9009-9408 |
|
ABC |
T=1. 60 |
| 98 |
I8-98019 664-0 |
|
BEARING; BALL, COUNTER END |
1 |
0612- |
|
C |
|
| 224 |
I9-99111 520-0 |
|
NUT; SELF LK, COUNTER |
1 |
9308-9408 |
|
A |
M20 |
| 276 |
I8-94161 087-0 |
|
SPACER; BRG TO DRIVE GEAR |
1 |
9009- |
|
BC |
|
| 306 |
I5-09588 023-1 |
|
RING; SNAP, MAINSHAFT |
1 |
9009-9408 |
|
ABC |
T=1. 65 |
| 137 |
I9-09844 195-0 |
|
NUT; REV GEAR |
1 |
9009- |
|
BC |
M16 |
| 306 |
I5-09588 021-1 |
|
RING; SNAP, MAINSHAFT |
1 |
9009-9408 |
|
ABC |
T=1. 55 |
| 222 |
I9-09150 520-0 |
|
WASHER; LK, REV GEAR, COUNTER |
1 |
9009-9408 |
|
A |
ID=20 |
| 52 |
I8-97238 834-0 |
|
COLLAR; NEEDLE BRG, LOW |
2 |
0902- |
|
A |
|
| 401 |
I9-09180 030-0 |
|
RING; SNAP, SPD DRIVE GEAR |
1 |
9009- |
|
BC |
ID=27. 9 |
| 87 |
I8-94201 356-0 |
|
BALL; THRUST WASHER |
1 |
9009- |
|
BC |
|
| 224 |
I0-91111 520-0 |
|
NUT; SELF LK, COUNTER |
1 |
9009- |
|
A |
M20 |
| 225 |
I0-91510 508-0 |
|
WASHER; LK, LOCK PLATE, COUNTER SHAFT |
1 |
9009- |
|
A |
M8 |
| 62 |
I5-33264 010-0 |
|
SPRING; INSERT, REV & 5TH |
2 |
9009- |
|
BC |
|
| 215 |
I9-09180 030-0 |
|
RING; SNAP, BALL BRG |
1 |
9009- |
|
BC |
ID=27. 9 |
| 405 |
I8-94152 557-1 |
|
INSERT; SYN LOW & 2ND |
3 |
9009-9408 |
|
ABC |
|
| 95 |
I8-94161 120-1 |
|
GEAR; REV, COUNTER |
1 |
9009- |
|
BC |
Z=16 |
| 53 |
I8-94161 991-0 |
|
BEARING; NEEDLE, LOW & REV |
2 |
9009- |
|
BC |
NSK |
| 86 |
I8-94238 104-4 |
|
WASHER; THRUST, STH |
1 |
9009- |
|
BC |
T=8.30 |
| 97 |
I8-94161 098-2 |
|
GEAR; 5TH, COUNTER |
1 |
9009- |
|
BC |
Z=4T |
| 90 |
I9-09180 040-0 |
|
RING; SNAP, RUST RING |
1 |
9009- |
|
B |
ID=37 |
| 59 |
I5-33257 013-2 |
|
GEAR; REV MAINSHAFT |
1 |
9009-9408 |
|
A |
Z=38 |
| 99 |
I9-09160 516-0 |
|
WASHER; PL, COUNTER 5TH GEAR |
1 |
9009- |
|
BC |
ID=16 |
| 53 |
I8-94161 990-2 |
|
BEARING; NEEDLE, LOW & REV |
2 |
9009- |
|
BC |
NSK |
| 64 |
I8-94238 095-0 |
|
WASHER; LK, LOW |
1 |
9009- |
|
BC |
|
| 86 |
I8-94238 099-4 |
|
WASHER; THRUST, STH |
1 |
9009- |
|
BC |
T=7.80 |
| 82 |
I8-94472 838-1 |
|
SHAFT; MASN TRANS |
1 |
9009-9408 |
|
A |
Z=26-26-8-18 |
| 86 |
I8-94238 100-4 |
|
WASHER; THRUST, STH |
1 |
9009- |
|
BC |
T=7.90 |
| 137 |
I8-98035 678-0 |
|
NUT; REV GEAR |
1 |
9009- |
|
BC |
M16 |
| 6 |
I9-09655 044-0 |
|
SPRING; BEVEL, TOP GEAR SHAFT |
1 |
9009-9408 |
|
AB |
|
| 396 |
I9-00096 100-1 |
|
BEARING; NEEDLE, MAINSHAFT |
1 |
9009-9408 |
|
ABC |
KOYO |
| 80 |
I8-94161 085-1 |
|
GEAR; SPD DRIVE |
1 |
9602- |
|
BC |
Z=6 |
| 132 |
I8-94435 140-0 |
|
SHAFT; REV |
1 |
9009- |
|
B |
|
| 86 |
I8-94238 103-4 |
|
WASHER; THRUST, STH |
1 |
9009- |
|
BC |
T=8 20 |
| 151 |
I9-08020 510-0 |
|
KEY; FEATHER, SPD DRIVE GEAR |
1 |
9009- |
|
B |
|
| 51 |
I8-94151 510-3 |
|
RING; BLOCK LOW 8 2ND |
2 |
9009-9408 |
|
ABC |
|
| 140 |
I0-28010 820-0 |
|
BOLT; LK PIECE |
1 |
9009-9204 |
|
B |
M8X20 FLANGE |
| 80 |
I8-94223 037-1 |
|
GEAR; SPD DRIVE |
1 |
9009-9408 |
|
A |
Z-5 |
| 398 |
I8-94469 524-1 |
|
GEAR; COUNTER |
1 |
9602- |
|
BC |
Z=37-31-20-16 |
| 1 |
I8-94435 160-2 |
|
SHAFT; TOP GEAR, TRANS |
1 |
9009-9408 |
|
ABC |
Z=23 |
| 140 |
I0-28050 820-0 |
|
BOLT; LK PIECE |
1 |
9009- |
|
B |
M8X20 FLANGE |
| 61 |
I5-32260 010-3 |
|
SYNCHRONIZER; REV & 5TH |
1 |
9009- |
|
BC |
|
| 5 |
I9-09180 040-0 |
|
RING; SNAP, BRG TO TOP GEAR SHAFT |
1 |
9009- |
|
AB |
ID=37 |
| 86 |
I8-94238 102-4 |
|
WASHER; THRUST, STH |
1 |
9009- |
|
BC |
T=8.10 |
| 70 |
I8-94310 152-1 |
|
GEAR; 1ST, MAINSHAFT |
1 |
9009-9408 |
|
AB |
Z=41 |
| 98 |
I6-98019 664-0 |
|
BEARING; BALL, COUNTER END |
1 |
0612- |
|
C |
(IADG) |
| 217 |
I9-09180 020-0 |
|
RING; SNAP, COUNTER FRT BRG |
1 |
9009-9408 |
|
ABC |
|
| 14 |
I8-94161 994-0 |
|
BEARING; NEEDLE, STH |
1 |
9009- |
|
BC |
NSK |
| 168 |
I0-20800 816-0 |
|
BOLT; LOCK PLATE, COUNTER SHAFT, TRANSFE |
1 |
9205-9408 |
|
A |
M8X16 |
| 401 |
I9-09952 149-1 |
|
RING; SNAP, SPD DRIVE GEAR |
2 |
9009-9408 |
|
A |
|
| 398 |
I8-94435 144-1 |
|
GEAR; COUNTER |
1 |
9009-9601 |
|
B |
Z=37-31 -20-16 |
| 90 |
I8-94422 093-0 |
|
RING; SNAP, RUST RING |
1 |
9009- |
|
B |
ID=37 |
| 140 |
I8-97021 210-0 |
|
BOLT; LK PIECE |
1 |
9205-9406 |
|
B |
M8X20 W/DRY-ROCK |
| 70 |
I8-94310 154-1 |
|
GEAR; 1ST, MAINSHAFT |
1 |
9602- |
|
BC |
Z=41 |
| 135 |
I8-94161 118-1 |
|
GEAR; REV IDLER |
1 |
9009- |
|
BC |
Z=23 |
| 35 |
I6-94463 830-0 |
|
RING; BLOCK 4TH 8 3RD |
2 |
9009-9408 |
|
ABC |
(IADG) |
| 66 |
I8-94463 830-1 |
|
RING; BLOCK SYN |
1 |
9009- |
|
BC |
|
| 224 |
I0-91111 520-0 |
|
NUT; SELF LK, COUNTER |
1 |
9308- |
|
A |
M20 |
| 4 |
I8-94206 485-0 |
|
RING; SNAP, BRG TO TOP GEAR SHAFT |
1 |
9009-9408 |
|
ABC |
NSK |
| 306 |
I5-09588 020-1 |
|
RING; SNAP, MAINSHAFT |
1 |
9009-9408 |
|
ABC |
T=1. 50 |
| 140 |
I0-28080 820-0 |
|
BOLT; LK PIECE |
1 |
9009-9204 |
|
B |
M8X20 FLANGE |
| 80 |
I8-94443 096-0 |
|
GEAR; SPD DRIVE |
1 |
9009-9601 |
|
B |
Z=5 |
| 168 |
I0-20850 816-0 |
|
BOLT; LOCK PLATE, COUNTER SHAFT, TRANSFE |
1 |
9205- |
|
A |
M8X16 |
| 397 |
I5-33264 010-0 |
|
SPRING; INSERT, 4TH & 3RD |
2 |
9009-9408 |
|
ABC |
|
| 95 |
I5-33336 002-4 |
|
GEAR; REV, COUNTER |
1 |
9009-9408 |
|
A |
Z=16 |
| 86 |
I8-94238 101-4 |
|
WASHER; THRUST, STH |
1 |
9009- |
|
BC |
T=8 00 |
| 82 |
I8-94435 162-3 |
|
SHAFT; MASN TRANS |
1 |
9009- |
|
BC |
Z=26-26-24-27 |
| 167 |
I5-33119 003-0 |
|
PLATE; LK, COUNTER SHAFT, TRANSFER |
1 |
9009-9408 |
|
A |
|
| 50 |
I8-94435 164-1 |
|
GEAR; 2ND, MAINSHAFT |
1 |
9009-9408 |
|
AB |
Z=31 |
| 140 |
I0-28050 816-0 |
|
BOLT; LK PIECE |
1 |
0612- |
|
C |
M8X16 FLANGE |
| 128 |
I5-33363 004-0 |
|
WASHER; THRUST, REV SHAFT |
1 |
9009- |
|
BC |
ID=22. 0 |
| 34 |
I8-94161 860-0 |
|
SYNCHRONIZER; 4TH 8 3RD |
1 |
9009-9408 |
|
ABC |
|
| 90 |
I8-97254 316-0 |
|
RING; SNAP, RUST RING |
1 |
9009- |
|
BC |
ID=37 |
| 136 |
I5-33363 003-3 |
|
WASHER; THRUST, REV IDLE, RR |
1 |
9009- |
|
BC |
ID=16. 2 |
| 38 |
I8-94435 140-0 |
|
SYNCHRONIZER; LOW 8 2ND |
1 |
9009-9408 |
|
ABC |
|
| 5 |
I8-94422 093-0 |
|
RING; SNAP, BRG TO TOP GEAR SHAFT |
1 |
9009-9408 |
|
AB |
ID=37 |
| 76 |
I5-33239 043-3 |
|
WASHER; THRUST, LOW |
2 |
9409- |
|
BC |
ID=32. 0 |
| 35 |
I8-94463 830-1 |
|
RING; BLOCK 4TH 8 3RD |
2 |
9009-9408 |
|
ABC |
|
