| 85 |
I9-09916 883-0 |
|
CLIP; BRKT |
2 |
9009-9408 |
|
ABC |
(B) ID=14 |
| 72 |
I8-94369 492-1 |
|
CABLE; PARKING BRK |
1 |
9009-9408 |
|
ABC |
LONG(TB*0*F) (B) |
| 72 |
I6-94369 491-1 |
|
CABLE; PARKING BRK |
1 |
9009-9408 |
|
ABC |
(IADG) LONG(TB*0*F) (B) |
| 86 |
I0-28050 612-0 |
|
BOLT |
9 |
0612- |
|
C |
M6X12 |
| 91 |
I8-97045 075-0 |
|
CLIP; PARK BRK CABLE |
1 |
9012-9408 |
|
ABC |
|
| 69 |
I8-94314 430-0 |
|
ROD; RELAY LEVER |
1 |
9009-9408 |
|
ABC |
|
| 168 |
I0-91510 506-0 |
|
WASHER; LK, HAND BRK STEM |
4 |
0612- |
|
C |
ID=6.1 |
| 22 |
I9-08112 520-0 |
|
PIN; SHAFT, PARKING BRK |
1 |
9009-9408 |
|
ABC |
L=20 |
| 38 |
I1-09985 180-0 |
|
WASHER; LK, RELAY LEVER, PARK BRK |
1 |
9009-9408 |
|
AB |
ID=10,2 |
| 72 |
I8-94369 493-1 |
|
CABLE; PARKING BRK |
1 |
9009-9408 |
|
AB |
SHORT(TB*0*C) (B) |
| 41 |
I0-91110 510-0 |
|
NUT; HAND BRAKE STEM |
4 |
9009-9408 |
|
ABC |
M6 |
| 63 |
I8-94377 307-0 |
|
LEVER; RELAY, HAND BRK |
1 |
9009-9408 |
|
ABC |
|
| 86 |
I0-50140 614-0 |
|
BOLT |
4 |
9009-9204 |
|
AB |
SHORT(TB*0*C) M6X14 W/LK&PL WASHER |
| 70 |
I9-09111 508-A |
|
NUT; EQUALIZER TO FRT CABLE |
2 |
9009-9408 |
|
ABC |
M8 |
| 26 |
I9-09150 508-0 |
|
WASHER; PARKING BRK SW |
1 |
9009-9408 |
|
AB |
M8 |
| 51 |
I0-82353 820-0 |
|
PIN; JOINT, RELAY LEVER |
2 |
9009- |
|
ABC |
OD=8 L=20 |
| 43 |
I0-50040 832-1 |
|
BOLT; ROLLER, PARK BRK CABLE |
1 |
9205-9408 |
|
AB |
M8X32 W/LK WASHER |
| 37 |
I5-46149 012-0 |
|
BUSHING; RELAY LEVER, PARK BRK |
2 |
9009-9408 |
|
ABC |
|
| 168 |
I1-09985 179-0 |
|
WASHER; LK, HAND BRK STEM |
4 |
9009-9408 |
|
AB |
ID=6 |
| 54 |
I9-08112 015-0 |
|
PIN; SNAP, CABLE TO LEVER |
2 |
9009-9408 |
|
ABC |
L=15 |
| 42 |
I8-94341 286-0 |
|
ROLLER; PARK BRK CABLE |
1 |
9009-9408 |
|
ABC |
|
| 51 |
I9-08233 820-0 |
|
PIN; JOINT, RELAY LEVER |
2 |
9009-9408 |
|
ABC |
OD=8 L=20 |
| 55 |
I9-09160 508-0 |
|
WASHER; PL, PARK BRK CABLE |
2 |
9009-9408 |
|
ABC |
M8 |
| 52 |
I5-09509 001-0 |
|
WASHER; CURVED RELAY LEVER |
2 |
9009-9408 |
|
ABC |
ID=8. 5 T=0.3 |
| 35 |
I8-94222 473-0 |
|
WASHER; PL. RELAY LEVER, PARK BRK |
1 |
9009-9408 |
|
ABC |
(A) ID=15.5 OD=24 |
| 33 |
I9-09160 506-0 |
|
WASHER; PL, HAND BRK LEVER |
4 |
9009-9408 |
|
ABC |
ID=6 T=0.8 |
| 71 |
I8-94479 600-2 |
|
SPRING; RETURN, PARKING BRK TO BODY |
1 |
9009-9407 |
|
ABC |
|
| 28 |
I0-28050 850-0 |
|
BOLT; HAND BRAKE LEVER |
1 |
9501- |
|
ABC |
M8X50 FLANGE |
| 91 |
I8-94126 639-1 |
|
CLIP; PARK BRK CABLE |
1 |
9009-9011 |
|
AB |
|
| 72 |
I8-94367 560-0 |
|
CABLE; PARKING BRK |
1 |
9009-9408 |
|
ABC |
(A) |
| 86 |
I0-50140 616-0 |
|
BOLT |
4 |
9409- |
|
B |
SHORT(TB*0*C) M6X16 W/LK&PL WASHER |
| 54 |
I0-81122 015-0 |
|
PIN; SNAP, CABLE TO LEVER |
2 |
9009- |
|
ABC |
L=15 |
| 28 |
I0-28080 850-0 |
|
BOLT; HAND BRAKE LEVER |
1 |
9501- |
|
ABC |
M8X50 FLANGE |
| 72 |
I8-94369 494-1 |
|
CABLE; PARKING BRK |
1 |
9009-9408 |
|
AB |
SHORT(TB*0*C) (B) |
| 6 |
I5-46129 009-0 |
|
PIN; STEM, PARK BRK |
1 |
9009-9408 |
|
ABC |
|
| 65 |
I9-09110 510-0 |
|
NUT; RELAY LEVER |
1 |
9009-9408 |
|
ABC |
M10 |
| 91 |
I8-94126 640-1 |
|
CLIP; PARK BRK CABLE |
1 |
9009-9011 |
|
AB |
|
| 35 |
I0-91610 710-0 |
|
WASHER; PL. RELAY LEVER, PARK BRK |
1 |
9009- |
|
ABC |
(B) ID=10 OD=26 |
| 55 |
I0-91610 508-0 |
|
WASHER; PL, PARK BRK CABLE |
2 |
9009- |
|
ABC |
M8 |
| 85 |
I5-09709 039-0 |
|
CLIP; BRKT |
2 |
9009-9408 |
|
ABC |
(C) |
| 43 |
I0-28650 835-0 |
|
BOLT; ROLLER, PARK BRK CABLE |
1 |
9205- |
|
AB |
M8X32 W/LK WASHER |
| 53 |
I8-94377 308-0 |
|
CABLE; PARK BRAKE, FRT LWR |
1 |
9009-9408 |
|
ABC |
|
| 23 |
I9-82750 367-0 |
|
SWITCH; PARKING BRAKE |
1 |
9009-9408 |
|
ABC |
12V |
| 58 |
I0-28650 820-0 |
|
BOLT; RELAY LEVER, PARK BRK |
4 |
9501- |
|
ABC |
M8X20 FLANGE |
| 5 |
I9-46129 022-0 |
|
BUSHING; PARKING BRK |
1 |
9009-9408 |
|
ABC |
|
| 20 |
I8-94171 208-1 |
|
PIN; PARKING BRK |
1 |
9009-9408 |
|
ABC |
|
| 66 |
I1-09985 345-0 |
|
WASHER; LK, RELAY LEVER |
1 |
9009-9408 |
|
ABC |
ID= 10. 2 |
| 66 |
I1-09985 180-0 |
|
WASHER; LK, RELAY LEVER |
1 |
9009-9408 |
|
AB |
ID= 10. 2 |
| 43 |
I0-28680 840-0 |
|
BOLT; ROLLER, PARK BRK CABLE |
1 |
9501- |
|
BC |
M8X40 FLANGE |
| 179 |
I9-09110 508-0 |
|
NUT; ROLLER PARK BRK CABLE |
1 |
9009-9408 |
|
ABC |
M8 |
| 57 |
I5-33659 053-0 |
|
BUSHING; RELAY LEVER |
2 |
9009-9408 |
|
ABC |
|
| 68 |
I8-94404 908-1 |
|
PIN; FULCRUM, RELAY LEVER, PARK BRK |
1 |
9009-9408 |
|
ABC |
|
| 44 |
I8-94367 559-A |
|
CABLE; PARKING BRK, FRT |
1 |
9009-9408 |
|
ABC |
|
| 59 |
I8-94479 094-0 |
|
BRACKET; RELAY LEVER |
1 |
9009-9408 |
|
ABC |
|
| 8 |
I8-97031 731-2 |
|
GUIDE; PARKING BRK |
1 |
9009-9408 |
|
ABC |
|
| 43 |
I0-28650 840-0 |
|
BOLT; ROLLER, PARK BRK CABLE |
1 |
9501- |
|
BC |
M8X40 FLANGE |
| 38 |
I1-09985 345-0 |
|
WASHER; LK, RELAY LEVER, PARK BRK |
1 |
9009-9408 |
|
ABC |
ID=10,2 |
| 1 |
I8-94367 557-3 |
|
STEM ASM; PARKING BRK |
1 |
9009-9408 |
|
ABC |
|
| 91 |
I8-97045 074-0 |
|
CLIP; PARK BRK CABLE |
1 |
9012-9408 |
|
ABC |
|
| 70 |
I9-09111 408-0 |
|
NUT; EQUALIZER TO FRT CABLE |
2 |
9009-9408 |
|
AB |
M8 |
| 179 |
I0-91110 508-0 |
|
NUT; ROLLER PARK BRK CABLE |
1 |
9009- |
|
ABC |
M8 |
| 34 |
I8-94113 338-1 |
|
LEVER; PARK BRK CONT |
1 |
9009-9408 |
|
ABC |
|
| 4 |
I8-97031 730-0 |
|
STEM; PARKING BRK |
1 |
9009-9408 |
|
ABC |
|
| 76 |
I8-11042 301-3 |
|
SLEEVE; CABLE GUIDE, PARK BRAKE |
1 |
9009-9408 |
|
ABC |
|
| 39 |
I9-09110 510-0 |
|
NUT; RELAY LEVER, PARK BRK |
1 |
9009-9408 |
|
ABC |
M10 |
| 72 |
I6-94369 492-1 |
|
CABLE P/BRAKE LH TBR54 |
1 |
0908- |
|
ABC |
(IADG) LONG(TB*0*F) (B) |
| 72 |
I8-94369 491-1 |
|
CABLE; PARKING BRK |
1 |
9009-9408 |
|
ABC |
LONG(TB*0*F) (B) |
| 85 |
I8-94146 602-0 |
|
CLIP; BRKT |
3 |
9009-9408 |
|
ABC |
(A) |
| 11 |
I9-46125 071-0 |
|
ROLLER; PARKING BRK |
1 |
9009-9408 |
|
ABC |
|
| 35 |
I9-09160 710-0 |
|
WASHER; PL. RELAY LEVER, PARK BRK |
1 |
9009-9408 |
|
ABC |
(B) ID=10 OD=26 |
| 26 |
I0-91510 508-0 |
|
WASHER; PARKING BRK SW |
1 |
9009- |
|
AB |
M8 |
| 47 |
I9-46129 013-1 |
|
COLLAR; ROLLER, PARK BRK CABLE |
1 |
9009-9408 |
|
AB |
|
