| 29 |
I5-09030 038-1 |
|
BOLT; BRKT, POWER STRG |
1 |
9009-9601 |
|
ABCDE |
POWER STEERING<N40> M10X55 |
| 41 |
I1-09503 045-0 |
|
WASHER; PL, BRKT |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> ID=10.5 OD=22 T=4 |
| 17 |
I0-91180 210-0 |
|
NUT; POWER STRG PUMP |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> M10 FLANGE |
| 37 |
I0-50140 822-0 |
|
BOLT; P/S PUMP |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> M8X22 W/LK8PL WASHER |
| 1 |
I8-97129 593-3 |
|
PUMP ASM; OIL, P/S |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> |
| 42 |
I0-91150 208-0 |
|
NUT; ADJ PLATE |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M8 FLANGE |
| 1 |
I8-97942 188-0 |
|
PUMP ASM; OIL, P/S |
1 |
0612- |
|
E |
|
| 29 |
I0-50041 035-0 |
|
BOLT; BRKT, POWER STRG |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M10X35 W/LK WASHER |
| 45 |
I5-19587 028-0 |
|
BRACKET; IDLE PULLEY, P/S |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> (A) |
| 29 |
I0-50041 028-0 |
|
BOLT; BRKT, POWER STRG |
2 |
9602- |
|
ABCDE |
POWER STEERING<N40> M10X28 W/LK WASHER |
| 36 |
I8-94254 647-2 |
|
BRACKET; PLATE, P/S PUMP |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> |
| 15 |
I8-94120 262-0 |
|
CLIP; OIL PIPE SUCTION |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> DELETION ID=22 |
| 29 |
I0-50040 830-1 |
|
BOLT; BRKT, POWER STRG |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M8X30 W/LK WASHER |
| 32 |
I8-97942 187-0 |
|
PULLEY; IDLER, P/S |
1 |
0612- |
|
E |
POWER STEERING<N40> (B) |
| 13 |
I9-09150 512-0 |
|
WASHER; LK, FLEX HOSE, P/S |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> ID=12 |
| 29 |
I0-50540 818-0 |
|
BOLT; BRKT, POWER STRG |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M8X18 W/LK WASHER |
| 19 |
I8-97359 618-0 |
|
NUT; PULLEY OIL PUMP |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> M12 |
| 13 |
I0-91510 512-0 |
|
WASHER; LK, FLEX HOSE, P/S |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> ID=12 |
| 48 |
I9-13369 603-0 |
|
COVER; IDLER |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> (B) |
| 17 |
I7-05110 010-A |
|
NUT; POWER STRG PUMP |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> M10 FLANGE |
| 1 |
I8-97331 940-1 |
|
PUMP ASM; OIL, P/S |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> |
| 38 |
I8-94104 660-2 |
|
BRACKET; POWER STRG, ENG FOOT |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> |
| 36 |
I8-97066 758-1 |
|
BRACKET; PLATE, P/S PUMP |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> (B) |
| 48 |
I8-97092 819-0 |
|
COVER; IDLER |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> (A) |
| 36 |
I8-97562 167-A |
|
BRACKET; PLATE, P/S PUMP |
1 |
0612- |
|
E |
(A) |
| 21 |
I9-09164 710-0 |
|
WASHER; PL, P/S OIL PUMP |
2 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> ID=10.5 T=2.6 |
| 7 |
I0-50041 025-0 |
|
BOLT; OIL PUMP, P/S |
2 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> M10X25 W/LK WASHER |
| 1 |
I8-97331 940-0 |
|
PUMP ASM; OIL, P/S |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> |
| 7 |
I0-50051 020-0 |
|
BOLT; OIL PUMP, P/S |
3 |
9009-9601 |
|
ABCDE |
POWER STEERING<N40> M10X20 W/LK WASHER |
| 58 |
I8-94479 122-0 |
|
SLIDER; BELT ADJ, P/S OIL PUMP |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> |
| 19 |
I8-94139 015-0 |
|
NUT; PULLEY OIL PUMP |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> M12 |
| 32 |
I8-94470 718-0 |
|
PULLEY; IDLER, P/S |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> (A) |
| 20 |
I9-99111 412-0 |
|
NUT; HOSE TO PUMP |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M12 |
| 44 |
I9-04411 025-0 |
|
STUD; IDLER PULLEY |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> M10X25 L=40 |
| 10 |
I0-09814 400-0 |
|
HOSE; FLEX, P/S OIL PUMP, INL |
1 |
9009- |
|
ABCDE |
POWER STEERING<N40> L=400 |
| 26 |
I8-97134 259-0 |
|
BRACKET; P/S PUMP, RR |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> |
| 7 |
I8-97200 583-0 |
|
BOLT; OIL PUMP, P/S |
3 |
9602- |
|
ABCD |
POWER STEERING<N40> M10X20 W/LK WASHER |
| 34 |
I0-20851 070-0 |
|
BOLT; ADJ PLATE |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M10X70 |
| 29 |
I0-50040 860-0 |
|
BOLT; BRKT, POWER STRG |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M8X60 W/LK WASHER |
| 48 |
I9-13669 603-0 |
|
COVER; IDLER |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> (B) |
| 42 |
I9-09110 510-0 |
|
NUT; ADJ PLATE |
2 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> M10 |
| 29 |
I0-50541 035-0 |
|
BOLT; BRKT, POWER STRG |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M10X35 W/LK WASHER |
| 1 |
I8-97946 697-0 |
|
PUMP ASM; OIL, P/S |
1 |
0612- |
|
E |
|
| 32 |
I8-97112 740-0 |
|
PULLEY; IDLER, P/S |
1 |
9409- |
|
ABCDE |
POWER STEERING<N40> (A) |
| 49 |
I8-94175 036-0 |
|
RING; SNAP, IDLER |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> |
| 21 |
I0-91614 710-0 |
|
WASHER; PL, P/S OIL PUMP |
2 |
9009- |
|
ABCD |
POWER STEERING<N40> ID=10.5 T=2.6 |
| 36 |
I8-97562 169-A |
|
BRACKET; PLATE, P/S PUMP |
1 |
0612- |
|
E |
(A) |
| 1 |
I8-97946 697-0 |
|
PUMP ASM; OIL, P/S |
1 |
0612- |
|
E |
|
| 26 |
I8-97134 259-A |
|
BRACKET; P/S PUMP, RR |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> |
| 25 |
I8-97065 216-0 |
|
BRACKEt; P/S PUMP |
1 |
9108-9601 |
|
ABCD |
POWER STEERING<N40> |
| 11 |
I8-94242 034-0 |
|
CLIP; FLEX HOSE |
2 |
9009- |
|
ABCDE |
POWER STEERING<N40> ID=21 |
| 1 |
I8-97331 940-1 |
|
PUMP ASM; OIL, P/S |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> |
| 58 |
I8-97941 329-0 |
|
SLIDER; BELT ADJ, P/S OIL PUMP |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> |
| 34 |
I0-20801 070-0 |
|
BOLT; ADJ PLATE |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M10X70 |
| 42 |
I0-91180 208-0 |
|
NUT; ADJ PLATE |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M8 FLANGE |
| 22 |
I1-09985 345-0 |
|
WASHER; LK, OIL PUMP, P/S |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> ID=10.2 |
| 20 |
I0-91111 512-0 |
|
NUT; HOSE TO PUMP |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M12 |
| 17 |
I7-05110 010-A |
|
NUT; POWER STRG PUMP |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> M10 FLANGE |
| 22 |
I1-09985 180-0 |
|
WASHER; LK, OIL PUMP, P/S |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> ID=10.2 |
| 46 |
I0-50040 816-0 |
|
BOLT; IDLER TO ADJ SCREW |
2 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> M8X16 W/LK WASHER |
| 7 |
I8-94165 519-1 |
|
BOLT; OIL PUMP, P/S |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> M10X95 |
| 17 |
I0-91150 210-0 |
|
NUT; POWER STRG PUMP |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> M10 FLANGE |
| 41 |
I9-09164 610-0 |
|
WASHER; PL, BRKT |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> ID=10 OD=22 |
| 32 |
I8-97113 181-0 |
|
PULLEY; IDLER, P/S |
1 |
9409-9601 |
|
ABCD |
POWER STEERING<N40> (B) |
| 39 |
I0-50140 822-0 |
|
BOLT; P/S BRKT TO HD |
2 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> M8X22 W/LK&PL WASHER |
| 66 |
I0-28050 812-0 |
|
BOLT; PULLEY |
1 |
0612- |
|
E |
M8X12 FLANGE |
| 7 |
I0-50741 025-0 |
|
BOLT; OIL PUMP, P/S |
2 |
9009- |
|
ABCD |
POWER STEERING<N40> M10X25 W/LK WASHER |
| 44 |
I9-09831 124-0 |
|
STUD; IDLER PULLEY |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> M10X25 L=40 |
| 29 |
I0-50041 060-0 |
|
BOLT; BRKT, POWER STRG |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M10X60 W/LK WASHER |
| 39 |
I0-50740 820-0 |
|
BOLT; P/S BRKT TO HD |
2 |
9009- |
|
ABCD |
POWER STEERING<N40> M8X20 W/lK WASHER |
| 29 |
I0-50540 860-0 |
|
BOLT; BRKT, POWER STRG |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M8X60 W/LK WASHER |
| 39 |
I0-50040 820-0 |
|
BOLT; P/S BRKT TO HD |
2 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> M8X20 W/lK WASHER |
| 46 |
I0-50540 816-0 |
|
BOLT; IDLER TO ADJ SCREW |
2 |
9009- |
|
ABCD |
POWER STEERING<N40> M8X16 W/LK WASHER |
| 11 |
I8-98150 355-0 |
|
CLIP; FLEX HOSE |
2 |
9009- |
|
ABCDE |
POWER STEERING<N40> ID=21 |
| 37 |
I0-50741 025-0 |
|
BOLT; P/S PUMP |
1 |
9009- |
|
ABCD |
POWER STEERING<N40> MlOX25 W/LK WASHER |
| 29 |
I0-50541 060-0 |
|
BOLT; BRKT, POWER STRG |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> M10X60 W/LK WASHER |
| 32 |
I8-97042 266-1 |
|
PULLEY; IDLER, P/S |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> (A) |
| 36 |
I8-94478 880-1 |
|
BRACKET; PLATE, P/S PUMP |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40>(B) |
| 26 |
I8-97562 168-A |
|
BRACKET; P/S PUMP, RR |
1 |
0612- |
|
E |
|
| 17 |
I0-91180 208-0 |
|
NUT; POWER STRG PUMP |
1 |
0612- |
|
E |
M8 FLANGE |
| 1 |
I8-94160 669-0 |
|
PUMP ASM; OIL, P/S |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> SEE FIG-NO 4-42 FOR COMPONENT. |
| 37 |
I0-50041 025-0 |
|
BOLT; P/S PUMP |
1 |
9009-9601 |
|
ABCD |
POWER STEERING<N40> MlOX25 W/LK WASHER |
| 45 |
I8-94449 652-0 |
|
BRACKET; IDLE PULLEY, P/S |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> |
| 1 |
I8-97946 606-0 |
|
PUMP ASM; OIL, P/S |
1 |
0612- |
|
E |
|
| 47 |
I5-13671 111-A |
|
BELT; P/S PUMP |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> |
| 51 |
I8-97092 813-0 |
|
NUT; IDLER |
1 |
9602- |
|
ABCDE |
POWER STEERING<N40> |
| 36 |
I8-97066 759-1 |
|
BRACKET; PLATE, P/S PUMP |
1 |
9602- |
|
ABCD |
POWER STEERING<N40> (B) |
| 41 |
I9-09851 649-0 |
|
WASHER; PL, BRKT |
1 |
0612- |
|
E |
ID=8.8 OD=22 T=4 |
| 41 |
I0-91614 610-0 |
|
WASHER; PL, BRKT |
1 |
9009- |
|
ABCD |
POWER STEERING<N40> ID=10 OD=22 |
| 7 |
I0-50551 020-0 |
|
BOLT; OIL PUMP, P/S |
3 |
9009- |
|
ABCDE |
POWER STEERING<N40> M10X20 W/LK WASHER |
| 7 |
I8-98136 233-0 |
|
BOLT; OIL PUMP, P/S |
3 |
9602- |
|
ABCD |
POWER STEERING<N40> M10X20 W/LK WASHER |
