| 128 |
I0-91614 710-0 |
|
WASHER; PL, STRUT |
2 |
9009- |
|
ABCDE |
ID= 10. 5 T=2. 6 |
| 25 |
I8-94366 122-1 |
|
ARM; UPR CONT |
1 |
9009- |
L |
ABCDE |
|
| 45 |
I6-94408 840-0 |
|
BUSHING; UPR LINK, FRT |
4 |
9009- |
|
ABCDE |
(IADG) |
| 48 |
I8-94365 165-2 |
|
JOINT ASM; BALL, LWR CONT ARM |
1 |
9009- |
L |
ABCDE |
|
| 20 |
I8-94478 727-0 |
|
BOLT; UPR LINK END TO UPR LINK |
8 |
9009- |
|
ABCDE |
|
| 41 |
I9-09150 808-0 |
|
WASHER; LK, UPR LINK END TO UPR LINK |
8 |
9009- |
|
ABCDE |
ID=8 |
| 158 |
I5-09000 226-1 |
|
BOLT; UPR LINK TO FRAME |
1 |
9009- |
|
ABCDE |
|
| 96 |
I9-02061 020-0 |
|
BOLT; LWR LINK |
2 |
9009- |
|
ABCDE |
(B) M10X20 |
| 78 |
I0-50040 614-0 |
|
BOLT; DUST COVER, S/ABS |
4 |
9205- |
|
ABCDE |
M6X14 W/LK WASHER |
| 17 |
I9-51631 603-0 |
|
BUSHING; RUBBER, S/ABS |
4 |
9009- |
|
ABCDE |
|
| 105 |
I8-94237 412-0 |
|
BOLT; STRUT BAR TO LWR LINK |
2 |
9009- |
|
ABCDE |
(A) M10X35 |
| 176 |
I8-94230 350-1 |
|
COVER; DUST S/ABS |
2 |
9009- |
|
ABCDE |
|
| 165 |
I0-91510 612-0 |
|
WASHER; LK, FULCRUM PIN |
4 |
9009- |
|
ABCDE |
ID=12 |
| 112 |
I8-94223 672-2 |
|
BAR; STRUT |
4 |
9009- |
|
ABCDE |
|
| 21 |
I6-94459 453-4 |
|
JOINT ASM; BALL, UPR CONT ARM |
2 |
9009- |
|
ABCDE |
(IADG) |
| 53 |
I0-91116 518-0 |
|
NUT; LWR LINK |
1 |
9009-9408 |
|
ABCD |
M18 |
| 13 |
I1-09985 185-0 |
|
WASHER; LK, LWR LINK |
2 |
9009- |
|
ABCDE |
ID=10 |
| 130 |
I8-97065 439-0 |
|
NUT; STRUT BAR TO LWR LINK |
2 |
9009- |
|
ABCDE |
M10 |
| 106 |
I8-94259 086-A |
|
RUBBER; REBOUND, STRUT |
2 |
9009- |
|
ABCDE |
|
| 163 |
I8-94223 217-1 |
|
PLATE; FULCRUM PIN, UPR LINK |
4 |
9009- |
|
ABCDE |
|
| 18 |
I8-94467 498-0 |
|
WASHER; CENTERING, S/ABS |
2 |
9009- |
|
ABCDE |
|
| 81 |
I0-81124 030-0 |
|
PIN; SPLIT, LWR LINK TO KNUCKLE |
2 |
9009- |
|
ABCDE |
|
| 164 |
I9-09164 712-0 |
|
WASHER; PL, FULCRUM PIN |
4 |
9009- |
|
ABCDE |
ID=12 |
| 155 |
I0-91510 614-0 |
|
WASHER; LK, UPR LINK TO FRT C/MBR |
2 |
9009- |
|
ABCDE |
ID=14 |
| 131 |
I6-94223 699-0 |
|
RUBBER; CUSHION, STRUT BAR |
4 |
9009- |
|
ABCDE |
(IADG) |
| 128 |
I9-09164 710-0 |
|
WASHER; PL, STRUT |
2 |
9009- |
|
ABCDE |
ID= 10. 5 T=2. 6 |
| 53 |
I9-99116 418-0 |
|
NUT; LWR LINK |
1 |
9009-9408 |
|
ABCD |
M18 |
| 152 |
I9-99110 514-0 |
|
NUT; LWR LINK TO FRT C/MBR |
2 |
9009- |
|
ABCDE |
M14 |
| 58 |
I6-94223 366-1 |
|
BUSHING; LWR LINK |
2 |
9009- |
|
ABCDE |
(IADG) |
| 104 |
I8-94366 120-0 |
|
BUMPER; RUBBER, STRUT |
2 |
9009- |
|
ABCDE |
|
| 45 |
I8-94408 840-3 |
|
BUSHING; UPR LINK, FRT |
4 |
9009- |
|
ABCDE |
|
| 80 |
I0-91116 518-0 |
|
NUT; LWR LINK END TO KNUCKLE |
2 |
9409- |
|
ABCDE |
M18 |
| 131 |
I8-94223 699-0 |
|
RUBBER; CUSHION, STRUT BAR |
4 |
9009- |
|
ABCDE |
|
| 84 |
I6-94223 222-0 |
|
ARM; LWR CONT |
1 |
9009- |
L |
ABCDE |
(IADG) |
| 84 |
I8-94223 222-3 |
|
ARM; LWR CONT |
1 |
9009- |
L |
ABCDE |
|
| 76 |
I9-09150 512-0 |
|
WASHER; LK, S/ABS TO LWR LINK |
2 |
9009- |
|
ABCDE |
ID=12 |
| 161 |
I5-51249 005-1 |
|
NUT ASM; UPR LINK TO FRAME |
2 |
9009- |
|
ABCDE |
|
| 25 |
I8-94366 121-2 |
|
ARM; UPR CONT |
1 |
9009- |
R |
ABCDE |
|
| 80 |
I9-99116 418-0 |
|
NUT; LWR LINK END TO KNUCKLE |
2 |
9409- |
|
ABCDE |
M18 |
| 105 |
I9-01066 065-0 |
|
BOLT; STRUT BAR TO LWR LINK |
2 |
9009- |
|
ABCDE |
(B) M10X65 |
| 77 |
I0-81123 025-0 |
|
PIN; SPLIT, LINK END TO KNUCKLE |
2 |
0612- |
|
E |
OD=2.8 L=25 |
| 112 |
I6-94223 672-0 |
|
BAR; STRUT |
4 |
9009- |
|
ABCDE |
(IADG) |
| 14 |
I9-09110 510-0 |
|
NUT; S/ABS, UPR |
2 |
9009- |
|
ABCDE |
M10 |
| 58 |
I8-94223 366-1 |
|
BUSHING; LWR LINK |
2 |
9009- |
|
ABCDE |
|
| 133 |
I7-05014 012-A |
|
NUT; STRUT BAR |
4 |
9009- |
|
ABCDE |
M14 |
| 84 |
I8-94223 221-3 |
|
ARM; LWR CONT |
1 |
9009- |
R |
ABCDE |
|
| 79 |
I8-94124 556-0 |
|
NUT; UPR LINK END TO KNUCKLE |
2 |
9009- |
|
ABCDE |
(B) M14 H=16 |
| 48 |
I6-94365 165-1 |
|
JOINT ASM; BALL, LWR CONT ARM |
1 |
9009- |
L |
ABCDE |
(IADG) |
| 96 |
I0-10956 050-0 |
|
BOLT; LWR LINK |
2 |
9009- |
|
ABCDE |
(A) M10X50 |
| 65 |
I1-51631 005-0 |
|
WASHER; S/ABS |
4 |
9009- |
|
ABCDE |
ID=10,5 OD=38 |
| 165 |
I9-09150 612-0 |
|
WASHER; LK, FULCRUM PIN |
4 |
9009- |
|
ABCDE |
ID=12 |
| 62 |
I2-00003 011-0 |
|
ABSORBER ASM; SHOCK, FRT |
2 |
9009- |
|
CD |
ROYALE |
| 103 |
I9-99111 412-0 |
|
NUT; S/ABS TO LWR LINK |
2 |
9009- |
|
ABCDE |
M12 |
| 103 |
I0-91111 512-0 |
|
NUT; S/ABS TO LWR LINK |
2 |
9009- |
|
ABCDE |
M12 |
| 62 |
I8-97014 042-0 |
|
ABSORBER ASM; SHOCK, FRT |
2 |
9009-9408 |
|
ABCD |
EXC. REAR SPRING HEAVY DUTY<G50> STD DELETION |
| 62 |
I8-97955 175-0 |
|
ABSORBER ASM; SHOCK, FRT |
2 |
9009- |
|
CD |
ROYALE |
| 48 |
I8-94365 164-2 |
|
JOINT ASM; BALL, LWR CONT ARM |
1 |
9009- |
R |
ABCDE |
|
| 129 |
I9-09150 614-0 |
|
WASHER; LK, STRUT BAR |
4 |
9009- |
|
ABCDE |
ID=14 |
| 79 |
I0-91180 208-0 |
|
NUT; UPR LINK END TO KNUCKLE |
8 |
9009- |
|
ABCDE |
(A) F18 FLANGE |
| 21 |
I8-94459 453-4 |
|
JOINT ASM; BALL, UPR CONT ARM |
2 |
9009- |
|
ABCDE |
|
| 7 |
I8-94225 581-3 |
|
PIN; FULCRUM, UPR LINK |
2 |
9009- |
|
ABCDE |
|
| 41 |
I0-91510 808-0 |
|
WASHER; LK, UPR LINK END TO UPR LINK |
8 |
9009- |
|
ABCDE |
ID=8 |
| 164 |
I8-94224 842-0 |
|
WASHER; PL, FULCRUM PIN |
4 |
9009- |
|
ABCDE |
ID=12. 5 |
| 48 |
I6-94365 164-1 |
|
JOINT ASM; BALL, LWR CONT ARM |
1 |
9009- |
R |
ABCDE |
(IADG) |
| 134 |
I8-94223 697-1 |
|
WASHER; STRUT BAR |
2 |
9009- |
|
ABCDE |
(B) |
| 77 |
I9-08113 028-0 |
|
PIN; SPLIT, LINK END TO KNUCKLE |
2 |
9009- |
|
ABCD |
|
| 62 |
I8-97020 817-A |
|
ABSORBER ASM; SHOCK, FRT |
2 |
9409- |
|
CDE |
HI GRADE |
| 133 |
I9-99110 514-0 |
|
NUT; STRUT BAR |
4 |
9009- |
|
ABCDE |
M14 |
| 96 |
I9-01066 050-0 |
|
BOLT; LWR LINK |
2 |
9009- |
|
ABCDE |
(A) M10X50 |
| 129 |
I0-91510 614-0 |
|
WASHER; LK, STRUT BAR |
4 |
9009- |
|
ABCDE |
ID=14 |
| 167 |
I0-10856 490-0 |
|
BOLT; LWR LINK TO FRT C/MBR |
2 |
9009- |
|
ABCDE |
M14X90 |
| 134 |
I8-98079 312-0 |
|
WASHER; STRUT BAR |
4 |
9009- |
|
ABCDE |
(A) |
| 167 |
I0-10806 490-0 |
|
BOLT; LWR LINK TO FRT C/MBR |
2 |
9009- |
|
ABCDE |
M14X90 |
| 134 |
I8-94103 248-0 |
|
WASHER; STRUT BAR |
4 |
9009- |
|
ABCDE |
(A) |
| 53 |
I8-97065 439-0 |
|
NUT; LWR LINK |
2 |
9009- |
|
ABCDE |
M10 |
| 109 |
I8-94103 247-0 |
|
TUBE; DIST, STRUT BAR |
4 |
9009- |
|
ABCDE |
|
| 81 |
I9-08114 030-0 |
|
PIN; SPLIT, LWR LINK TO KNUCKLE |
2 |
9009- |
|
ABCDE |
|
| 161 |
I8-98020 304-0 |
|
NUT ASM; UPR LINK TO FRAME |
2 |
9009- |
|
ABCDE |
|
| 127 |
I1-09985 185-0 |
|
WASHER; LK, STRUT BAR TO LWR LINK |
2 |
9009- |
|
ABCDE |
ID=10 |
| 84 |
I6-94223 221-0 |
|
ARM; LWR CONT |
1 |
9009- |
R |
ABCDE |
(IADG) |
| 96 |
I0-20951 020-0 |
|
BOLT; LWR LINK |
2 |
9009- |
|
ABCDE |
(B) M10X20 |
| 155 |
I9-09150 614-0 |
|
WASHER; LK, UPR LINK TO FRT C/MBR |
2 |
9009- |
|
ABCDE |
ID=14 |
| 79 |
I0-91150 208-0 |
|
NUT; UPR LINK END TO KNUCKLE |
8 |
9009- |
|
ABCDE |
(A) F18 FLANGE |
| 152 |
I7-05014 012-A |
|
NUT; LWR LINK TO FRT C/MBR |
2 |
9009- |
|
ABCDE |
M14 |
| 76 |
I0-91510 512-0 |
|
WASHER; LK, S/ABS TO LWR LINK |
2 |
9009- |
|
ABCDE |
ID=12 |
| 17 |
I9-51631 055-0 |
|
BUSHING; RUBBER, S/ABS |
4 |
9009- |
|
ABCDE |
|
| 164 |
I0-91614 712-0 |
|
WASHER; PL, FULCRUM PIN |
4 |
9009- |
|
ABCDE |
ID=12 |
| 166 |
I9-92061 228-0 |
|
BOLT; FULCRUM PIN TO UPR LINK |
4 |
9009- |
|
ABCDE |
M12X28 |
| 60 |
I0-10856 250-0 |
|
BOLT; S/ABS TO LWR LINK |
2 |
9205- |
|
ABCDE |
M12X50 |
| 77 |
I0-81123 028-0 |
|
PIN; SPLIT, LINK END TO KNUCKLE |
2 |
9009- |
|
ABCD |
|
| 17 |
I6-51631 603-0 |
|
BUSHING; RUBBER, S/ABS |
4 |
9009- |
|
ABCDE |
(IADG) |
