| 85 |
I8-98037 823-0 |
|
BOLT, EYE,OIL PIPE FIX |
1 |
1807- |
|
4HL1-TC |
M10X28 EYE-BOLT |
| 325 |
I8-94125 862-1 |
|
CLIP, RUBBER HOSE, OIL RETRUN |
2 |
1512- |
|
4JB1-TC |
ID=20.8 |
| 83 |
I8-97228 671-0 |
|
PIPE, OIL,C/BL TO VAC PUMP |
1 |
1807- |
|
4HL1-TC |
|
| 157 |
I8-97181 586-A |
|
BRACKET OIL PIPE |
1 |
1512- |
|
4HG1-T |
|
| 202 |
I1-09630 083-0 |
|
GASKET, OIL PIPE |
2 |
1512- |
|
4HG1-T |
(A) ID=10.2 OD=15.2 |
| 312 |
I8-97581 233-0 |
|
NUT, PIPE FIX |
1 |
1512- |
|
4JB1-TC |
M8 |
| 310 |
I8-94125 862-1 |
|
CLIP, WATER HOSE FIX |
4 |
1512- |
|
4JB1-TC |
ID=20.8 |
| 147 |
I8-98029 475-0 |
|
GASKET, OIL PIPE TO TURBOCHARGER |
1 |
1512- |
|
4HG1-T |
(C) ID=16 |
| 202 |
I1-09630 083-0 |
|
GASKET, OIL PIPE |
2 |
1807- |
|
4HL1-TC |
(B) ID=10.2 OD=15.2 |
| 312 |
I0-91180 108-0 |
|
NUT, PIPE FIX |
2 |
1601- |
|
4HG1-T |
M8 |
| 304 |
I0-28050 820-0 |
|
BOLT, BRKT,OIL PIPE |
2 |
1807- |
|
4HL1-TC |
M8X20 |
| 147 |
I8-98029 475-0 |
|
GASKET, OIL PIPE TO TURBOCHARGER |
1 |
1807- |
|
4HL1-TC |
ID=16 |
| 202 |
I8-98251 345-0 |
|
GASKET, OIL PIPE |
2 |
1807- |
|
4HL1-TC |
(A) ID=14.2 OD=19.2 |
| 86 |
I8-94455 311-1 |
|
PIPE, OIL,VAC PUMP RETURN |
1 |
1807- |
|
4HL1-TC |
|
| 1 |
I8-97200 615-4 |
|
PIPE, OIL, INJ PUMP TO C/BL |
1 |
1512- |
|
4HG1-T |
|
| 58 |
I8-97311 976-1 |
|
VALVE, RELIEF, OIL JET ,PISTON COO |
1 |
1512- |
|
4JB1-TC |
|
| 28 |
I5-09623 002-0 |
|
GASKET, OIL PIPE |
2 |
1512- |
|
4JB1-TC |
ID=11 |
| 202 |
I8-98251 345-0 |
|
GASKET, OIL PIPE |
3 |
1512- |
|
4HG1-T |
(B) ID=14.2 OD=19.2 |
| 309 |
I8-97224 318-1 |
|
HOSE OIL COOLER RETURN |
1 |
1512- |
|
4JB1-TC |
|
| 89 |
I8-94122 679-0 |
|
CLIP, VAC HOSE |
1 |
1512- |
|
ALL |
ID=17.1 |
| 340 |
I8-94339 073-3 |
|
HOSE, VAC PUMP,RETURN |
1 |
1807- |
|
4HL1-TC |
|
| 28 |
I1-09630 083-0 |
|
GASKET, OIL PIPE |
2 |
1807- |
|
4HL1-TC |
ID=10.2 OD=15.2 |
| 331 |
I8-97108 102-0 |
|
CLAMP, VAC HOSE PUMP, RETRUN |
2 |
1512- |
|
4JB1-TC |
|
| 68 |
I8-98037 825-0 |
|
BOLT, EYE,OIL PIPE,TURBOCHARGER |
1 |
1512- |
|
4HG1-T |
M10X26 |
| 40 |
I0-28050 610-0 |
|
BOLT, OIL PIPE |
1 |
1512- |
|
4JB1-TC |
M6X10 |
| 27 |
I0-28050 816-0 |
|
BOLT, OIL PIPE FIX |
2 |
1807- |
|
4HL1-TC |
M8X16 |
| 63 |
I8-98261 644-0 |
|
PIPE, OIL, TURBOCHARGER FEED |
1 |
1512- |
|
4HG1-T |
|
| 46 |
I8-97372 239-0 |
|
BOLT, JOIN, OIL FEED PIPE, VAC PU |
1 |
1512- |
|
4HG1-T |
(A) M10X21 |
| 307 |
I8-97264 168-0 |
|
GASKET, WATER PIPE |
1 |
1512- |
|
4JB1-TC |
|
| 46 |
I1-09675 086-0 |
|
BOLT, JOIN, OIL FEED PIPE, VAC PU |
1 |
1512- |
|
4HG1-T |
(B) M14X27 |
| 332 |
I8-94443 644-1 |
|
PIPE, OIL, C/BL TO VAVC PUMP |
1 |
1512- |
|
4JB1-TC |
|
| 86 |
I8-94455 311-1 |
|
PIPE, OIL VAC PUMP RETURN |
1 |
1512- |
|
4HG1-T |
|
| 311 |
I0-28080 814-0 |
|
BOLT, PIPE FIX |
1 |
1512- |
|
4JB1-TC |
M8X14 |
| 27 |
I0-28050 816-0 |
|
BOLT, OIL PIPE FIX |
1 |
1512- |
|
4HG1-T |
M8X16 |
| 46 |
I1-09675 086-0 |
|
BOLT, JOINT,OIL FEED PIPE,VAC PUMP |
1 |
1807- |
|
4HL1-TC |
(A) M14X27 EYE-BOLT |
| 83 |
I8-97228 671-0 |
|
PIPE OIL C/BL TO VAC PUMP |
1 |
1512- |
|
4HG1-T |
|
| 473 |
I8-97101 331-0 |
|
INSULATOR, HOSE |
2 |
1512- |
|
4JB1-TC |
|
| 26 |
I8-97923 928-0 |
|
PIPE, OIL, PUMP TO C/BL |
1 |
1512- |
|
4JB1-TC |
|
| 68 |
I8-94443 535-0 |
|
BOLT, EYE,OIL PIPE, TURBOCHARGER SIDE |
1 |
1807- |
|
4HL1-TC |
M10X28 EYE-BOLT |
| 147 |
I8-94362 672-1 |
|
GASKET, OIL PIPE TO TURBOCHARGER |
1 |
1512- |
|
4JB1-TC |
(A) |
| 53 |
I0-91180 108-0 |
|
NUT, OIL PIPE |
3 |
1807- |
|
4HL1-TC |
M8 |
| 340 |
I8-94339 073-3 |
|
HOSE, VOC PUMP, RETRUN |
1 |
1512- |
|
4HG1-T |
|
| 46 |
I8-97372 239-0 |
|
BOLT, JOINT,OIL FEED PIPE,VAC PUMP |
1 |
1807- |
|
4HL1-TC |
(B) M10X21 EYE-BOLT |
| 340 |
I6-94339 073-3 |
|
HOSE, VOC PUMP, RETRUN |
1 |
1512- |
|
4HG1-T |
(IADG) |
| 339 |
I9-09571 410-0 |
|
GASKET, OIL PIPE |
2 |
1512- |
|
4JB1-TC |
(B) ID=10.2 0D=16.0 |
| 335 |
I8-97203 568-0 |
|
STOPPER, OIL PIPE |
1 |
1512- |
|
4JB1-TC |
|
| 3 |
I8-98158 135-0 |
|
GASKET, EYE BOLT, OIL PIPE |
2 |
1512- |
|
4HG1-T |
(B) ID=10.2 |
| 40 |
I0-28050 816-0 |
|
BOLT, OIL PIPE |
1 |
1807- |
|
4HL1-TC |
M8X16 |
| 29 |
I0-28050 810-0 |
|
BOLT, OIL PIPE, OIL JET |
1 |
1512- |
|
4JB1-TC |
(A) M8X10 |
| 2 |
I9-09906 205-1 |
|
BOLT, EYE, OIL PIPE |
1 |
1512- |
|
4HG1-T |
(B) M10X24 |
| 306 |
I8-97225 604-1 |
|
PIPE ASM, CYL HD TO OIL COOLER |
1 |
1512- |
|
4JB1-TC |
|
| 147 |
I9-09571 410-0 |
|
GASKET, OIL PIPE TO TURBOCHARGER |
2 |
1512- |
|
4JB1-TC |
(B) ID=10.2 OD=16.0 |
| 2 |
I8-97182 847-0 |
|
BOLT, EYE, OIL PIPE |
1 |
1512- |
|
4HG1-T |
(A) M10X40 |
| 40 |
I0-28050 812-A |
|
BOLT, OIL PIPE |
1 |
1512- |
|
4HG1-T |
M8X12 |
| 252 |
I8-98269 695-A |
|
HOSE, RUBBER, TURBOCHARGER RETURN |
1 |
1512- |
|
4JB1-TC |
|
| 248 |
I1-09675 086-0 |
|
CONNECTOR, TURBOCHARGER OIL FEED |
1 |
1512- |
|
4JB1-TC |
M14X27 |
| 339 |
I9-09571 408-0 |
|
GASKET, OIL PIPE |
2 |
1512- |
|
4JB1-TC |
(A) ID=8.2 OD=14.0 T=1.0 |
| 474 |
I8-97101 337-0 |
|
CLIP, INSULATOR |
4 |
1512- |
|
4JB1-TC |
|
| 157 |
I8-98213 708-3 |
|
BRACKET, OIL PIPE |
1 |
1807- |
|
4HL1-TC |
(A) |
| 414 |
I0-28050 616-0 |
|
BOLT, OIL PIPE |
2 |
1512- |
|
4JB1-TC |
M6X16 |
| 3 |
I1-09630 083-0 |
|
GASKET, EYE BOLT,OIL PIPE |
3 |
1807- |
|
4HL1-TC |
ID=10.2 OD=15.2 |
| 63 |
I8-97224 297-0 |
|
PIPE, OIL, TURBOCHARGER FEED |
1 |
1512- |
|
4JB1-TC |
|
| 63 |
I8-98319 372-0 |
|
PIPE, OIL,TURBOCHARGER FEED |
1 |
1807- |
|
4HL1-TC |
|
| 338 |
I5-09675 018-1 |
|
BOLT, JOINT, OIL PIPE |
1 |
1512- |
|
4JB1-TC |
M8X20 EYE-BOLT |
| 57 |
I8-94469 709-3 |
|
PIPE, OIL, OIL JET |
1 |
1512- |
|
4JB1-TC |
|
| 2 |
I8-94332 831-1 |
|
BOLT, EYE, OIL PIPE |
1 |
1512- |
|
4JB1-TC |
(C) M10X23 |
| 149 |
I8-97192 313-0 |
|
PIPE, OIL RETURN ,TURBOCHARGER |
1 |
1512- |
|
4JB1-TC |
|
| 3 |
I1-09630 083-0 |
|
GASKET, EYE BOLT, OIL PIPE |
3 |
1512- |
|
4HG1-T |
(A) ID=10.2 OD=15.2 |
| 3 |
I9-09571 414-0 |
|
GASKET, EYE BOLT, OIL PIPE |
2 |
1512- |
|
4JB1-TC |
(C) ID=14.2 OD=20.0 |
| 340 |
I6-94339 073-3 |
|
HOSE, VAC PUMP,RETURN |
1 |
1807- |
|
4HL1-TC |
(IADG) |
| 157 |
I8-98319 380-0 |
|
BRACKET, OIL PIPE |
1 |
1807- |
|
4HL1-TC |
(B) |
| 29 |
I0-50640 625-0 |
|
BOLT, OIL PIPE, OIL JET |
4 |
1512- |
|
4JB1-TC |
(B) M6X25&PL |
| 146 |
I0-28050 812-A |
|
BOLT, BRKT |
1 |
1512- |
|
4HG1-T |
M8X12 |
| 330 |
I8-98269 691-A |
|
HOSE, VAC PUMP, RETRUN |
1 |
1512- |
|
4JB1-TC |
|
| 120 |
I0-91614 808-0 |
|
WASHER, PL, PIPE FIX |
2 |
1601- |
|
4HG1-T |
ID=8.4 OD=26 |
| 308 |
I8-94174 464-1 |
|
HOSE, OIL COOLER FEED |
1 |
1512- |
|
4JB1-TC |
|
