| 37 |
I9-00093 081-0 |
|
BEARING, HUB INNER, RR AXLE |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 9 |
I9-42332 605-5 |
|
PIN; WHEEL, RR AXLE |
6 |
1512- |
L |
NLR |
(A) NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; M14X50 LH THREAD |
| 49 |
I8-98061 921-0 |
|
CASE, RR AXLE |
1 |
1512- |
|
NLR |
WB 3300MM, 41/7 , 41/8 , 41/9 , 43/9 , 41/10 , 43/10 |
| 31 |
I8-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
12 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; M10X30 L=49 |
| 9 |
I8-97081 585-4 |
|
PIN, WHEEL, RR AXLE |
6 |
1512- |
L |
NMR |
(B) M20X28 LH THREAD,M22X57 RH THREAD |
| 74 |
I8-97359 819-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
1512- |
|
NMR |
M12X32 |
| 75 |
I0-91510 810-0 |
|
WASHER; L K, RR BRK ASM SETTING |
12 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; ID=10.2 |
| 25 |
I8-98272 242-0 |
|
SHAFT; AXLE, RR |
2 |
1512- |
|
NMR71 |
RR AXLE HD 343MM |
| 2 |
I0-20800 618-0 |
|
BOLT, BRK DRUM |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, M6X18 |
| 25 |
I8-94366 192-0 |
|
SHAFT; AXLE, RR |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 39 |
I9-42119 620-0 |
|
SHIM, BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T , NLR55-B, T=0.050 |
| 39 |
I9-42119 618-0 |
|
SHIM; BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T ; NLR55-B; T=0.13 |
| 67 |
I1-09000 398-0 |
|
BOLT, FINAL DRIVE SETTING |
8 |
1807- |
|
NMR81 |
M10X35 |
| 63 |
I1-09604 022-0 |
|
PLUG, OIL FILLER, AXLE CASE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 343MM, M24X17 |
| 67 |
I0-50561 040-0 |
|
BOLT, FINAL DRIVE SETTING |
11 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, M10X40 |
| 67 |
I1-09000 398-0 |
|
BOLT, FINAL DRIVE SETTING |
8 |
1512- |
|
NMR71 |
RR AXLE HD 343MM, M10X35 |
| 76 |
I7-05014 012-A |
|
NUT, RR BRK ASM SETTING |
12 |
1512- |
|
NMR71 |
M12 |
| 37 |
I9-00032 209-0 |
|
BEARING, HUB INNER, RR AXLE |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B, ID=45 OD=85 |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
2 |
1512- |
|
NMR |
RR AXLE HD 320MM; M10 |
| 37 |
I9-00093 624-0 |
|
BEARING; HUB INNER, RR AXLE |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM |
| 16 |
I8-98202 911-0 |
|
SEAL, OIL, RR HUB, OUTER |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 49 |
I8-97304 377-2 |
|
CASE; RR AXLE |
1 |
1512- |
|
NLR |
WB 2400MM; 41/7 ; 41/8 ; 41/9 ; 43/9 ; 41/10 ; 43/10 |
| 10 |
I0-91110 522-0 |
|
NUT; WHEEL PIN, RR AXLE |
12 |
1512- |
|
NMR |
M22 |
| 67 |
I1-09000 429-1 |
|
BOLT; FINAL DRIVE SETTING |
4 |
1512- |
|
NMR71 |
RR AXLE HD 343MM; M10X55 |
| 25 |
I8-98272 242-0 |
|
SHAFT, AXLE, RR |
2 |
1512- |
|
NMR71 |
RR AXLE HD 343MM |
| 25 |
I6-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 320MM; 41/7; 43/7; 39/6 |
| 12 |
I8-94477 674-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; M12X72 |
| 58 |
I8-97307 060-0 |
|
PLUG; DRAIN, AXLE CASE |
1 |
1512- |
|
ALL |
M16X12.5 |
| 14 |
I7-05014 012-A |
|
NUT, BRG HOLDER TO CASE |
8 |
1512- |
|
NLR |
NLR55-T , NLR55-B, M12 |
| 24 |
I0-28050 610-0 |
|
BOLT, LK WASHER |
6 |
1512- |
|
NLR |
WB 3300MM |
| 38 |
I8-97122 937-0 |
|
SEAL; OIL,RR HUB,INNER |
2 |
1807- |
|
NMR81 |
|
| 67 |
I1-09000 398-0 |
|
BOLT; FINAL DRIVE SETTING |
8 |
1807- |
|
NMR81 |
M10X35 |
| 38 |
I8-94336 316-1 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM, TKK |
| 75 |
I0-91510 812-0 |
|
WASHER; L K, RR BRK ASM SETTING |
12 |
1512- |
|
NMR71 |
41/7; 43/7; 39/6; ID=12.2 |
| 38 |
I8-94336 314-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; TKK |
| 24 |
I0-28050 610-0 |
|
BOLT, LK WASHER |
6 |
1512- |
|
NMR71 |
43/8, M6X10 |
| 37 |
I8-97122 938-0 |
|
BEARING; HUB INNER,RR AXLE |
2 |
1807- |
|
NMR81 |
|
| 39 |
I9-42119 617-0 |
|
SHIM; BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T ; NLR55-B; T=0.500 |
| 38 |
I8-94367 959-0 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, NOK |
| 187 |
I5-87411 891-1 |
|
PIN; WHEEL SET, RR |
6 |
1512- |
R |
NMR |
|
| 33 |
I8-97086 472-0 |
|
WASHER, AXLE SHAFT |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B |
| 2 |
I0-20800 618-0 |
|
BOLT; BRK DRUM |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; M6X18 |
| 31 |
I8-97359 803-0 |
|
STUD, AXLE SHAFT TO HUB |
16 |
1512- |
|
NMR |
M10X30 L=49 |
| 12 |
I9-42119 603-2 |
|
BOLT; BRG HOLDER TO CASE |
4 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; M12X69 REAMER |
| 38 |
I6-97122 937-0 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 343MM, NOK |
| 25 |
I6-98272 242-0 |
|
SHAFT; AXLE,RR |
2 |
1807- |
|
NMR81 |
(IADG) |
| 187 |
I6-87411 891-0 |
|
PIN, WHEEL SET, RR |
6 |
1512- |
R |
NMR |
(IADG) |
| 38 |
I6-97122 937-0 |
|
SEAL, OIL,RR HUB,INNER |
2 |
1807- |
|
NMR81 |
(IADG) |
| 49 |
I8-98192 225-0 |
|
CASE, RR AXLE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 320MM |
| 24 |
I0-28050 612-0 |
|
BOLT, LK WASHER |
4 |
1512- |
|
NMR71 |
41/7, 43/7, 39/6 |
| 16 |
I9-09724 022-1 |
|
SEAL, OIL, RR HUB, OUTER |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B, ID=50.5 OD=72 |
| 76 |
I0-91110 510-0 |
|
NUT, RR BRK ASM SETTING |
12 |
1512- |
|
NLR |
M10 |
| 154 |
I0-36410 616-0 |
|
SCREW; SLOTTED |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; M6X16 |
| 12 |
I9-42119 603-2 |
|
BOLT, BRG HOLDER TO CASE |
4 |
1512- |
|
NLR |
NLR55-T , NLR55-B, M12X69 REAMER |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
11 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; M10X40 |
| 38 |
I8-94367 958-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM; NOK |
| 269 |
I9-09720 517-0 |
|
GASKET, REAR AXLE |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B |
| 24 |
I0-28050 612-0 |
|
BOLT, LK WASHER |
4 |
1512- |
|
NLR |
WB 2400MM |
| 37 |
I9-00093 081-A |
|
BEARING; HUB INNER, RR AXLE |
2 |
1512- |
|
NLR |
(IADG) NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 64 |
I1-09623 179-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 343MM; ID=26.8 |
| 38 |
I6-94367 959-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
(IADG) NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; NOK |
| 15 |
I9-00093 082-A |
|
BEARING, HUB OUTER, RR AXLE |
2 |
1512- |
|
NLR |
(IADG) NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 37 |
I8-97122 938-A |
|
BEARING; HUB INNER, RR AXLE |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 343MM |
| 39 |
I9-42119 619-0 |
|
SHIM, BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T , NLR55-B, T=0.076 |
| 8 |
I8-97107 549-A |
|
HUB; RR AXLE |
2 |
1807- |
|
NMR81 |
|
| 8 |
I8-97081 323-A |
|
HUB; RR AXLE |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM |
| 38 |
I8-94336 314-1 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, TKK |
| 37 |
I9-00032 209-A |
|
BEARING; HUB INNER, RR AXLE |
2 |
1512- |
|
NLR |
(IADG) NLR55-T ; NLR55-B; ID=45 OD=85 |
| 9 |
I8-97081 585-4 |
|
PIN; WHEEL, RR AXLE |
6 |
1512- |
L |
NMR |
(B) M20X28 LH THREAD,M22X57 RH THREAD |
| 37 |
I9-00093 624-0 |
|
BEARING, HUB INNER, RR AXLE |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM |
| 64 |
I8-94462 734-0 |
|
GASKET, OIL FILLER, AXLE CASE |
1 |
1512- |
|
NLR |
|
| 4 |
I8-97324 241-0 |
|
HOLDER; BRG, AXLE SHAFT |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B |
| 75 |
I0-91510 812-0 |
|
WASHER, L K, RR BRK ASM SETTING |
12 |
1512- |
|
NMR71 |
41/7, 43/7, 39/6, ID=12.2 |
| 16 |
I8-98202 911-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 25 |
I8-97083 094-2 |
|
SHAFT, AXLE, RR |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B |
| 38 |
I6-94336 316-1 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 320MM, TKK |
| 37 |
I9-00093 081-A |
|
BEARING, HUB INNER, RR AXLE |
2 |
1512- |
|
NLR |
(IADG) NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 187 |
I5-87411 892-1 |
|
PIN; WHEEL SET, RR |
6 |
1512- |
L |
NMR |
|
| 13 |
I0-91510 512-0 |
|
WASHER; LK, BRG HOLDER TO CASE |
8 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; ID=12.2 |
| 16 |
I6-94336 317-2 |
|
SEAL, OIL, RR HUB, OUTER |
2 |
1512- |
|
NMR |
(IADG) |
| 15 |
I9-00093 609-A |
|
BEARING, HUB OUTER, RR AXLE |
2 |
1512- |
|
NMR |
|
| 15 |
I9-00093 609-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
1512- |
|
NMR |
|
| 10 |
I0-91110 522-0 |
|
NUT, WHEEL PIN, RR AXLE |
12 |
1512- |
|
NMR |
M22 |
| 38 |
I6-94367 958-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 320MM; NOK |
| 21 |
I9-09853 214-0 |
|
WASHER, LK, BRG NUT |
2 |
1512- |
|
NMR71 |
ID=52 |
| 274 |
I0-91510 810-0 |
|
WASHER; HSG |
12 |
1807- |
|
NMR81 |
ID=10.2 |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
7 |
1512- |
|
NMR71 |
RR AXLE HD 320MM; M10X40 |
| 38 |
I8-97122 937-0 |
|
SEAL, OIL,RR HUB,INNER |
2 |
1807- |
|
NMR81 |
|
| 15 |
I9-00093 082-0 |
|
BEARING; HUB OUTER, RR AXLE |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 39 |
I9-42119 617-0 |
|
SHIM, BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T , NLR55-B, T=0.500 |
| 38 |
I5-09625 092-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; ID=37.5 OD=60 |
| 49 |
I8-97357 375-2 |
|
CASE; RR AXLE |
1 |
1512- |
|
NLR |
NLR55-T ; NLR55-B |
| 38 |
I8-97122 937-0 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
RR AXLE HD 343MM, NOK |
| 31 |
I6-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
1512- |
|
NMR |
(IADG) M10X30 L=49 |
| 37 |
I8-97122 938-A |
|
BEARING, HUB INNER,RR AXLE |
2 |
1807- |
|
NMR81 |
(IADG) |
| 74 |
I8-98007 877-0 |
|
BOLT; RR BRK ASM SETTING |
12 |
1512- |
|
NLR |
|
| 25 |
I6-98272 242-0 |
|
SHAFT; AXLE, RR |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 343MM |
| 9 |
I8-97081 584-4 |
|
PIN, WHEEL, RR AXLE |
6 |
1512- |
R |
NMR |
(B) M20X28,M22X57 RH THREAD |
| 36 |
I8-97360 004-0 |
|
WASHER, SPECIAL, AXLE SHAFT |
12 |
1512- |
|
ALL |
|
| 38 |
I6-94367 959-0 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
(IADG) NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, NOK |
| 4 |
I8-97324 241-0 |
|
HOLDER, BRG, AXLE SHAFT |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B |
| 39 |
I9-42119 616-0 |
|
SHIM; BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T ; NLR55-B; T=1.000 |
| 59 |
I9-09571 416-0 |
|
GASKET, DRAIN PLUG |
1 |
1512- |
|
ALL |
ID=16.2 OD=24 |
| 1 |
I8-94455 285-A |
|
DRUM, BRK, RR |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 9 |
I8-97081 584-4 |
|
PIN; WHEEL, RR AXLE |
6 |
1512- |
R |
NMR |
(B) M20X28,M22X57 RH THREAD |
| 16 |
I9-09724 022-1 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; ID=50.5 OD=72 |
| 37 |
I8-97122 938-A |
|
BEARING, HUB INNER, RR AXLE |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 343MM |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
1512- |
|
NLR |
|
| 38 |
I8-94367 959-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; NOK |
| 38 |
I6-09625 092-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
(IADG) NLR55-T ; NLR55-B; ID=37.5 OD=60 |
| 34 |
I8-94178 278-0 |
|
NUT, AXLE SHAFT |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B, M45 |
| 38 |
I6-97122 937-0 |
|
SEAL; OIL,RR HUB,INNER |
2 |
1807- |
|
NMR81 |
(IADG) |
| 49 |
I8-98327 595-0 |
|
CASE; RR AXLE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 343MM; 41/7 ; 43/7 ; 39/6 ; 43/8 |
| 37 |
I8-97122 938-0 |
|
BEARING, HUB INNER, RR AXLE |
2 |
1512- |
|
NMR71 |
RR AXLE HD 343MM |
| 74 |
I8-97359 819-0 |
|
BOLT, RR BRK ASM SETTING |
12 |
1512- |
|
NMR |
M12X32 |
| 49 |
I8-98061 921-0 |
|
CASE; RR AXLE |
1 |
1512- |
|
NLR |
WB 3300MM; 41/7 ; 41/8 ; 41/9 ; 43/9 ; 41/10 ; 43/10 |
| 38 |
I8-94367 958-0 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM, NOK |
| 274 |
I0-91510 810-0 |
|
WASHER; HSG |
12 |
1512- |
|
NMR |
RR AXLE HD 343MM; ID=10.2 |
| 8 |
I8-97107 549-A |
|
HUB, RR AXLE |
2 |
1512- |
|
NMR71 |
RR AXLE HD 343MM |
| 21 |
I9-09853 214-1 |
|
WASHER; LK, BRG NUT |
2 |
1512- |
|
NMR71 |
ID=52 |
| 37 |
I8-97122 938-0 |
|
BEARING; HUB INNER, RR AXLE |
2 |
1512- |
|
NMR71 |
RR AXLE HD 343MM |
| 20 |
I8-98236 850-0 |
|
NUT, BRG, RR HUB |
2 |
1512- |
|
NLR |
WB 2400MM, NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 1 |
I8-97081 219-A |
|
DRUM, BRK, RR |
2 |
1512- |
|
NMR |
|
| 67 |
I0-50561 050-0 |
|
BOLT; FINAL DRIVE SETTING |
4 |
1512- |
|
NMR71 |
RR AXLE HD 320MM; M10X50 |
| 24 |
I0-28050 612-0 |
|
BOLT; LK WASHER |
4 |
1512- |
|
NMR71 |
41/7; 43/7; 39/6 |
| 25 |
I6-98272 242-0 |
|
SHAFT, AXLE,RR |
2 |
1807- |
|
NMR81 |
(IADG) |
| 25 |
I8-98272 242-0 |
|
SHAFT; AXLE,RR |
2 |
1807- |
|
NMR81 |
|
| 24 |
I0-28050 612-0 |
|
BOLT; LK WASHER |
4 |
1512- |
|
NLR |
WB 2400MM |
| 34 |
I8-94178 278-0 |
|
NUT; AXLE SHAFT |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; M45 |
| 24 |
I0-28050 612-0 |
|
BOLT; LK WASHER |
6 |
1512- |
|
NMR81 |
M6X12 |
| 31 |
I8-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
16 |
1512- |
|
NMR |
M10X30 L=49 |
| 39 |
I9-42119 616-0 |
|
SHIM, BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T , NLR55-B, T=1.000 |
| 67 |
I0-50561 050-0 |
|
BOLT, FINAL DRIVE SETTING |
4 |
1512- |
|
NMR71 |
RR AXLE HD 320MM, M10X50 |
| 24 |
I0-28050 610-0 |
|
BOLT; LK WASHER |
6 |
1512- |
|
NMR71 |
43/8; M6X10 |
| 76 |
I0-91110 510-0 |
|
NUT; RR BRK ASM SETTING |
12 |
1512- |
|
NLR |
M10 |
| 38 |
I6-94336 316-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 320MM; TKK |
| 64 |
I8-94462 734-0 |
|
GASKET; OIL FILLER, AXLE CASE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 320MM; ID=20 OD=30 |
| 25 |
I8-94366 192-0 |
|
SHAFT, AXLE, RR |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 14 |
I7-05014 012-A |
|
NUT; BRG HOLDER TO CASE |
8 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; M12 |
| 37 |
I9-00093 624-A |
|
BEARING, HUB INNER, RR AXLE |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 320MM |
| 187 |
I6-87411 892-0 |
|
PIN; WHEEL SET, RR |
6 |
1512- |
L |
NMR |
(IADG) |
| 67 |
I1-09000 429-1 |
|
BOLT, FINAL DRIVE SETTING |
4 |
1807- |
|
NMR81 |
M10X55 |
| 59 |
I9-09571 416-0 |
|
GASKET; DRAIN PLUG |
1 |
1512- |
|
ALL |
ID=16.2 OD=24 |
| 34 |
I7-05110 010-A |
|
NUT; AXLE SHAFT |
16 |
1807- |
|
NMR81 |
M10 |
| 75 |
I0-91510 810-0 |
|
WASHER, L K, RR BRK ASM SETTING |
12 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, ID=10.2 |
| 37 |
I9-00093 081-0 |
|
BEARING; HUB INNER, RR AXLE |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 63 |
I8-98009 333-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 320MM; M20X10.5 |
| 67 |
I1-09000 429-1 |
|
BOLT; FINAL DRIVE SETTING |
4 |
1807- |
|
NMR81 |
M10X55 |
| 36 |
I8-97360 004-0 |
|
WASHER; SPECIAL, AXLE SHAFT |
12 |
1512- |
|
ALL |
|
| 38 |
I6-94367 958-0 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 320MM, NOK |
| 9 |
I5-87411 898-0 |
|
PIN; WHEEL, RR AXLE |
6 |
1512- |
L |
NLR |
(A) NLR55-T ; NLR55-B; M14X42 LH THREAD |
| 25 |
I8-98272 242-0 |
|
SHAFT, AXLE,RR |
2 |
1807- |
|
NMR81 |
|
| 9 |
I5-87411 897-0 |
|
PIN, WHEEL, RR AXLE |
6 |
1512- |
R |
NLR |
(A) NLR55-T , NLR55-B, M14X42 RH THREAD |
| 76 |
I0-91110 512-0 |
|
NUT; RR BRK ASM SETTING |
12 |
1807- |
|
NMR81 |
M12 |
| 187 |
I6-87411 892-0 |
|
PIN, WHEEL SET, RR |
6 |
1512- |
L |
NMR |
(IADG) |
| 38 |
I8-94336 316-1 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM; TKK |
| 24 |
I0-28050 612-0 |
|
BOLT, LK WASHER |
6 |
1512- |
|
NMR81 |
M6X12 |
| 63 |
I8-98009 333-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
1512- |
|
NLR |
M20X10.5 |
| 64 |
I1-09623 179-0 |
|
GASKET; OIL FILLER,AXLE CASE |
1 |
1807- |
|
NMR81 |
ID=26.8 |
| 20 |
I8-98236 850-0 |
|
NUT; BRG, RR HUB |
2 |
1512- |
|
NLR |
WB 2400MM; NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 20 |
I8-98327 903-0 |
|
NUT, BRG, RR HUB |
2 |
1512- |
|
NLR |
WB 3300MM, NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 63 |
I1-09604 022-0 |
|
PLUG; OIL FILLER, AXLE CASE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 343MM; M24X17 |
| 49 |
I8-97304 377-2 |
|
CASE, RR AXLE |
1 |
1512- |
|
NLR |
WB 2400MM, 41/7 , 41/8 , 41/9 , 43/9 , 41/10 , 43/10 |
| 38 |
I6-09625 092-0 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
(IADG) NLR55-T , NLR55-B, ID=37.5 OD=60 |
| 9 |
I9-42331 605-5 |
|
PIN, WHEEL, RR AXLE |
6 |
1512- |
R |
NLR |
(A) NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, M14X50 RH THREAD |
| 75 |
I0-91510 812-0 |
|
WASHER; LK,RR BRK ASM SETTING |
12 |
1807- |
|
NMR81 |
ID=12.2 |
| 16 |
I6-09724 022-0 |
|
SEAL, OIL, RR HUB, OUTER |
2 |
1512- |
|
NLR |
(IADG) NLR55-T , NLR55-B, ID=50.5 OD=72 |
| 25 |
I8-97083 094-2 |
|
SHAFT; AXLE, RR |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B |
| 67 |
I1-09000 429-1 |
|
BOLT, FINAL DRIVE SETTING |
4 |
1512- |
|
NMR71 |
RR AXLE HD 343MM, M10X55 |
| 70 |
I7-05110 010-A |
|
NUT; CARRIER |
2 |
1512- |
|
NLR |
|
| 21 |
I9-09853 214-1 |
|
WASHER; LK, BRG NUT |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 8 |
I5-42311 009-A |
|
HUB; RR AXLE |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 15 |
I9-00093 082-A |
|
BEARING; HUB OUTER, RR AXLE |
2 |
1512- |
|
NLR |
(IADG) NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 39 |
I9-42119 620-0 |
|
SHIM; BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T ; NLR55-B; T=0.050 |
| 21 |
I9-09653 002-1 |
|
WASHER, LK, BRG NUT |
2 |
1512- |
|
NMR |
ID=55 |
| 39 |
I9-42119 618-0 |
|
SHIM, BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T , NLR55-B, T=0.13 |
| 16 |
I8-98202 912-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
1512- |
|
NMR |
|
| 34 |
I7-05110 010-A |
|
NUT; AXLE SHAFT |
28 |
1512- |
|
NLR |
WB 3300MM; NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; M10 |
| 8 |
I5-42311 009-A |
|
HUB, RR AXLE |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 49 |
I8-98327 595-0 |
|
CASE, RR AXLE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 343MM, 41/7 , 43/7 , 39/6 , 43/8 |
| 69 |
I8-97359 802-0 |
|
STUD; AXLE CASE |
2 |
1512- |
|
NLR |
M10X40.5 L=52.5 |
| 24 |
I0-28050 610-0 |
|
BOLT; LK WASHER |
6 |
1512- |
|
NLR |
WB 3300MM |
| 38 |
I8-97122 937-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
RR AXLE HD 343MM; NOK |
| 38 |
I6-97122 937-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 343MM; NOK |
| 37 |
I9-00093 624-A |
|
BEARING; HUB INNER, RR AXLE |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 320MM |
| 58 |
I8-97307 060-0 |
|
PLUG, DRAIN, AXLE CASE |
1 |
1512- |
|
ALL |
M16X12.5 |
| 31 |
I8-97359 803-0 |
|
STUD, AXLE SHAFT TO HUB |
12 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, M10X30 L=49 |
| 75 |
I0-91510 810-0 |
|
WASHER; L K, RR BRK ASM SETTING |
12 |
1512- |
|
NMR71 |
43/8; ID=10.2 |
| 9 |
I9-42331 605-5 |
|
PIN; WHEEL, RR AXLE |
6 |
1512- |
R |
NLR |
(A) NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; M14X50 RH THREAD |
| 154 |
I0-36410 616-0 |
|
SCREW, SLOTTED |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B, M6X16 |
| 34 |
I7-05110 010-A |
|
NUT; AXLE SHAFT |
12 |
1512- |
|
NLR |
WB 2400MM; NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; M10 |
| 60 |
I8-98006 960-0 |
|
BREATHER, RR AXLE CASE |
1 |
1512- |
|
ALL |
L=29 |
| 16 |
I8-98202 912-0 |
|
SEAL, OIL, RR HUB, OUTER |
2 |
1512- |
|
NMR |
|
| 25 |
I6-98151 846-0 |
|
SHAFT, AXLE, RR |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 320MM, 41/7, 43/7, 39/6 |
| 34 |
I7-05110 010-A |
|
NUT, AXLE SHAFT |
16 |
1512- |
|
NMR71 |
41/7, 43/7, 39/6 |
| 269 |
I9-09720 517-0 |
|
GASKET; REAR AXLE |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B |
| 38 |
I6-94336 314-0 |
|
SEAL; OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
(IADG) NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; TKK |
| 1 |
I8-97081 219-A |
|
DRUM; BRK, RR |
2 |
1512- |
|
NMR |
|
| 25 |
I6-98272 242-0 |
|
SHAFT, AXLE, RR |
2 |
1512- |
|
NMR71 |
(IADG) RR AXLE HD 343MM |
| 63 |
I8-98009 333-0 |
|
PLUG, OIL FILLER, AXLE CASE |
1 |
1512- |
|
NLR |
M20X10.5 |
| 1 |
I8-97034 799-A |
|
DRUM, BRK, RR |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B |
| 38 |
I6-94336 314-0 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
(IADG) NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, TKK |
| 16 |
I6-94336 317-2 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
1512- |
|
NMR |
(IADG) |
| 187 |
I6-87411 891-0 |
|
PIN; WHEEL SET, RR |
6 |
1512- |
R |
NMR |
(IADG) |
| 38 |
I5-09625 092-0 |
|
SEAL, OIL, RR HUB, INNER |
2 |
1512- |
|
NLR |
NLR55-T , NLR55-B, ID=37.5 OD=60 |
| 34 |
I7-05110 010-A |
|
NUT; AXLE SHAFT |
16 |
1512- |
|
NMR71 |
41/7; 43/7; 39/6 |
| 37 |
I8-97122 938-A |
|
BEARING; HUB INNER,RR AXLE |
2 |
1807- |
|
NMR81 |
(IADG) |
| 60 |
I8-98006 960-0 |
|
BREATHER; RR AXLE CASE |
1 |
1512- |
|
ALL |
L=29 |
| 37 |
I9-00032 209-0 |
|
BEARING; HUB INNER, RR AXLE |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; ID=45 OD=85 |
| 70 |
I7-05110 010-A |
|
NUT, CARRIER |
2 |
1512- |
|
NLR |
|
| 64 |
I1-09623 179-0 |
|
GASKET, OIL FILLER, AXLE CASE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 343MM, ID=26.8 |
| 20 |
I8-98327 903-0 |
|
NUT; BRG, RR HUB |
2 |
1512- |
|
NLR |
WB 3300MM; NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
| 76 |
I0-91110 512-0 |
|
NUT, RR BRK ASM SETTING |
12 |
1807- |
|
NMR81 |
M12 |
| 9 |
I9-42332 605-5 |
|
PIN, WHEEL, RR AXLE |
6 |
1512- |
L |
NLR |
(A) NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, M14X50 LH THREAD |
| 15 |
I9-00093 082-0 |
|
BEARING, HUB OUTER, RR AXLE |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 74 |
I8-98007 877-0 |
|
BOLT, RR BRK ASM SETTING |
12 |
1512- |
|
NLR |
|
| 8 |
I8-97107 549-A |
|
HUB; RR AXLE |
2 |
1512- |
|
NMR71 |
RR AXLE HD 343MM |
| 16 |
I6-09724 022-0 |
|
SEAL; OIL, RR HUB, OUTER |
2 |
1512- |
|
NLR |
(IADG) NLR55-T ; NLR55-B; ID=50.5 OD=72 |
| 25 |
I8-98151 846-0 |
|
SHAFT, AXLE, RR |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM, 41/7, 43/7, 39/6 |
| 20 |
I8-98327 902-0 |
|
NUT, BRG, RR HUB |
2 |
1512- |
|
NMR |
|
| 8 |
I8-97081 323-A |
|
HUB, RR AXLE |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM |
| 187 |
I5-87411 891-1 |
|
PIN, WHEEL SET, RR |
6 |
1512- |
R |
NMR |
|
| 69 |
I8-97359 802-0 |
|
STUD; AXLE CASE |
2 |
1512- |
|
NMR71 |
|
| 49 |
I8-98327 595-0 |
|
CASE; RR AXLE |
1 |
1807- |
|
NMR81 |
RR AXLE HD 343MM |
| 274 |
I0-91510 810-0 |
|
WASHER, HSG |
12 |
1512- |
|
NMR |
RR AXLE HD 343MM, ID=10.2 |
| 67 |
I0-50561 040-0 |
|
BOLT; FINAL DRIVE SETTING |
8 |
1512- |
|
NLR |
NLR55-T ; NLR55-B; M10X40 |
| 21 |
I9-09653 002-1 |
|
WASHER; LK, BRG NUT |
2 |
1512- |
|
NMR |
ID=55 |
| 9 |
I5-87411 898-0 |
|
PIN, WHEEL, RR AXLE |
6 |
1512- |
L |
NLR |
(A) NLR55-T , NLR55-B, M14X42 LH THREAD |
| 21 |
I9-09853 214-0 |
|
WASHER, LK, BRG NUT |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL |
| 63 |
I1-09604 022-0 |
|
PLUG; OIL FILLER,AXLE CASE |
1 |
1807- |
|
NMR81 |
M24X17 |
| 33 |
I8-97086 472-0 |
|
WASHER; AXLE SHAFT |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B |
| 25 |
I8-98151 846-0 |
|
SHAFT; AXLE, RR |
2 |
1512- |
|
NMR71 |
RR AXLE HD 320MM; 41/7; 43/7; 39/6 |
| 187 |
I5-87411 892-1 |
|
PIN, WHEEL SET, RR |
6 |
1512- |
L |
NMR |
|
| 34 |
I7-05110 010-A |
|
NUT, AXLE SHAFT |
28 |
1512- |
|
NLR |
WB 3300MM, NLR55-Tx/TLx , NLR55-Bx/BLx , NLR71-T/TL/BL, M10 |
| 13 |
I0-91510 512-0 |
|
WASHER, LK, BRG HOLDER TO CASE |
8 |
1512- |
|
NLR |
NLR55-T , NLR55-B, ID=12.2 |
| 39 |
I9-42119 619-0 |
|
SHIM; BRG HOLDER |
AR |
1512- |
|
NLR |
NLR55-T ; NLR55-B; T=0.076 |
| 67 |
I1-09000 398-0 |
|
BOLT; FINAL DRIVE SETTING |
8 |
1512- |
|
NMR71 |
RR AXLE HD 343MM; M10X35 |
| 49 |
I8-97357 375-2 |
|
CASE, RR AXLE |
1 |
1512- |
|
NLR |
NLR55-T , NLR55-B |
| 49 |
I8-98192 225-0 |
|
CASE; RR AXLE |
1 |
1512- |
|
NMR71 |
RR AXLE HD 320MM |
| 1 |
I8-97034 799-A |
|
DRUM; BRK, RR |
2 |
1512- |
|
NLR |
NLR55-T ; NLR55-B |
| 76 |
I7-05014 012-A |
|
NUT; RR BRK ASM SETTING |
12 |
1512- |
|
NMR71 |
M12 |
| 20 |
I8-97137 094-0 |
|
NUT; BRG, RR HUB |
2 |
1512- |
|
NMR |
|
| 12 |
I8-94477 674-2 |
|
BOLT, BRG HOLDER TO CASE |
4 |
1512- |
|
NLR |
NLR55-T , NLR55-B, M12X72 |
| 69 |
I8-97359 802-0 |
|
STUD, AXLE CASE |
2 |
1512- |
|
NLR |
RR AXLE HD 320MM, M10X40.5 L=52.5 |
| 9 |
I5-87411 897-0 |
|
PIN; WHEEL, RR AXLE |
6 |
1512- |
R |
NLR |
(A) NLR55-T ; NLR55-B; M14X42 RH THREAD |
| 31 |
I6-97359 803-0 |
|
STUD; AXLE SHAFT TO HUB |
12 |
1512- |
|
NLR |
(IADG) NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL; M10X30 L=49 |
| 37 |
I8-97122 938-0 |
|
BEARING, HUB INNER,RR AXLE |
2 |
1807- |
|
NMR81 |
|
| 37 |
I9-00032 209-A |
|
BEARING, HUB INNER, RR AXLE |
2 |
1512- |
|
NLR |
(IADG) NLR55-T , NLR55-B, ID=45 OD=85 |
| 1 |
I8-94455 285-A |
|
DRUM; BRK, RR |
2 |
1512- |
|
NLR |
NLR55-Tx/TLx ; NLR55-Bx/BLx ; NLR71-T/TL/BL |
