8-26 | ELECTRICAL CONTROL AND OTHER PARTS
ELF
NLR55 NMR71
| Key | PART NO | ITC | DESCRIPTION | QTY | APP DATE | LR | MODEL | REMARKS |
|---|---|---|---|---|---|---|---|---|
| 21 | I8-98025 954-1 | COVER, HOLE | 3 | 1512- | NLR | |||
| 234 | I8-97328 058-1 | SENSOR, VEHICLE SPD | 1 | 1512- | NLR | 24V | ||
| 549 | I8-97161 633-2 | SHEET | 1 | 1512- | NLR | 4HG1-T | ||
| 67 | I8-98022 170-1 | BRACKET, CONT UNIT | 1 | 1512- | NLR | (A) | ||
| 635 | I8-97214 325-0 | SENSOR, TACHOMETER | 1 | 1512- | NMR71 | |||
| 221 | I8-98029 916-2 | COVER, HOLE,DOOR LOCK SW | 1 | 1807- | L | NMR81 | ||
| 67 | I8-98072 631-4 | BRACKET, CONT UNIT | 1 | 1512- | NLR | (B) 4JB1-TC | ||
| 1 | I7-43502 288-A | LIGHTER, CIGAR | 1 | 1807- | NMR81 | |||
| 21 | I8-97848 832-0 | COVER, HOLE | 1 | 1807- | NMR81 | (B) | ||
| 67 | I8-98217 377-0 | BRACKET, CONT UNIT | 1 | 1807- | NMR81 | (B) | ||
| 234 | I8-97328 058-1 | SENSOR, VEHICLE SPD | 1 | 1807- | NMR81 | 25 PULSE ALUMINUM | ||
| 21 | I8-98025 954-1 | COVER, HOLE | 3 | 1512- | NMR | |||
| 67 | I8-98172 518-0 | BRACKET, CONT UNIT | 1 | 1512- | NMR71 | (C) | ||
| 234 | I8-97377 920-0 | SENSOR, VEHICLE SPD | 1 | 1512- | NLR | 12V | ||
| 67 | I8-98172 518-0 | BRACKET, CONT UNIT | 1 | 1512- | NLR | (C) 4HG1-T | ||
| 67 | I8-98022 170-1 | BRACKET, CONT UNIT | 1 | 1807- | NMR81 | (A) | ||
| 221 | I8-98029 915-2 | COVER, HOLE,DOOR LOCK SW | 1 | 1807- | R | NMR81 | ||
| 549 | I8-97161 633-2 | SHEET | 1 | 1512- | NMR71 | |||
| 221 | I8-98029 915-2 | COVER, HOLE, DOOR LOCK SW | 1 | 1512- | R | ALL | ||
| 21 | I8-98025 954-1 | COVER, HOLE | 3 | 1807- | NMR81 | (A) | ||
| 1 | I8-97314 003-0 | LIGHTER, CIGAR | 1 | 1512- | NLR | 12V | ||
| 67 | I8-98022 170-1 | BRACKET, CONT UNIT | 1 | 1512- | NMR | (A) | ||
| 648 | I8-97606 943-0 | SENSOR, CRANK ANGLE | 1 | 1807- | NMR81 | EURO2 SPECIFICATION<NT2> KD PREPARATORY PACK<6HF | ||
| 1 | I8-98142 962-0 | LIGHTER, CIGAR | 1 | 1512- | NLR | 24V | ||
| 68 | I0-28450 612-0 | BOLT, BRKT | 1 | 1807- | NMR81 | M6X12 | ||
| 635 | I8-97214 325-0 | SENSOR, TACHOMETER | 1 | 1512- | NLR | 4HG1-T | ||
| 221 | I8-98029 916-2 | COVER, HOLE, DOOR LOCK SW | 1 | 1512- | L | ALL | ||
| 448 | I0-28050 616-0 | BOLT, SENSOR | 1 | 1512- | NMR | M6X16 | ||
| 69 | I0-91180 106-0 | NUT, BRKT | 2 | 1807- | NMR81 | M6 | ||
| 68 | I0-28450 612-0 | BOLT, BRKT | 1 | 1512- | ALL | M6X12 | ||
| 448 | I0-28050 616-0 | BOLT, SENSOR | 1 | 1512- | NLR | 4HG1-T, M6X16 | ||
| 234 | I8-97328 058-1 | SENSOR, VEHICLE SPD | 1 | 1512- | NMR | 24V | ||
| 448 | I0-28050 616-0 | BOLT, SENSOR | 1 | 1807- | NMR81 | M6X16 | ||
| 69 | I0-91180 106-0 | NUT, BRKT | 2 | 1512- | ALL | M6 | ||
| 1 | I8-98142 962-0 | LIGHTER, CIGAR | 1 | 1512- | NMR71 | 24V | ||
| 553 | I8-97369 404-0 | GASKET | 1 | 1807- | NMR81 | ID=14.2 OD=18.8 |
